Quick Start Guide
AutoPatch S-Video DA Modules & AF-10 Boards
Overview
S-Video Distribution Amplifier (DA) boards are available as either standalone
distribution amplifier modules (left in FIG. 1) or as distribution amplifier accessory
boards for an AF-10 (right in FIG. 1). The S-Video DA Module has one input and four
outputs for a 1:4 distribution. S-Video DA boards have five S-Video connectors; either
one input and four outputs or five outputs that are paired with the 1:4 board to create a
1:9 distribution amplifier.
Product Specifications
Product specifications below are specifically for AMX AutoPatch S-Video cables.
Installation
S-Video 1:4 Distribution Amplifier Module
Module Mounting Options
Desktop – Attach the rubber feet (included) on the bottom of the module.
Rack Trays & Mounting Brackets – contact your AMX representative for details.
Module System Setup
The S-Video DA Module has five S-Video connectors, one input and four outputs.
AF-10 with 1:4 & 5-out S-Video Distribution Amplifier Boards
Board System Set-up
S-Video DA 1:4 and 5-out boards are available for the AMX AutoPatch AF-10
Accessory Card Frame. The 1:4 board is built to use alone or in conjunction with the
5-out board. When using both, these boards must be installed in adjoining slot pairs,
with the 5-out board to the left of the 1:4 board for a 1:9 distribution.
Attaching Cables
Note: AMX AutoPatch S-Video cables lock onto S-Video connectors. Standard
S-Video cables may be used, but will not lock.
To attach a locking S-Video connector:
1. Hold the connector at a slight angle to the right while pushing in or pull back on
the connector housing while pushing the connector in.
FIG. 1 S-Video DA Module & AF-10 Boards
General
Approvals CE, UL, cUL
Power Consumption (max.) – Module +9 VDC @ 500 mV
Power Connector – Module 2.1 mm DC power jack
Power – AF-10 100 - 240 VAC single phase, 50 - 60 Hz
Operational Temperature 32° - 110° F (0° - 43° C)
Humidity 0 to 90% non-condensing
Dimensions – Module 5.22 in. (13.26 cm) depth
5.82 in. (14.78 cm) width
1.42 in. (3.61 cm) height w/out feet
Weight – Module Approx. 1.5 lb. (0.68 kg)
Connector Options S-Video, Locking S-Video
S-Video Specifications
Frequency Response +/- 3 dB, 50 MHz or better
+/- 1 dB, 15 MHz or better
Signal to Noise Ratio (SNR) Vin = 0.7 V, 100% IRE -45 dB
Level (max.)
Input:
Output: +/- 1.75 V
+/- 1.75 V
Impedance
Input:
Output: 75 ohms
75 ohms
DC Offset Out (max.) Measured with 0 V on input +/- 20 mV
Video Bandwidth Specifications
Module FG1010-70
1:4 Board FG1040-452 5-out Board FG1040-455
+/-3 dB for 100 ft. (30.48 m) 10 MHz 10 MHz
+/-3 dB for 50 ft. (15.24 m) 150 MHz 100 MHz
+/-3 dB for 25 ft. (7.62 m) 200 MHz 125 MHz
+/-3 dB for 12 ft. (3.66 m) 100 MHz 50 MHz
+/-3 dB for 6 ft. (1.83 m) 100 MHz 50 MHz
+/-3 dB for 3 ft. (.91 m) 75 MHz 50 MHz
S-Video Module FG1010-70 1:4 S-Video AF-10 Board FG1040-452
5-out S-Video AF-10 Board FG1040-455
(Not to scale)
FIG. 2 Typical setup using S-Video DA Module
FIG. 3 Typical setup using S-Video DA boards in an AF-10
FIG. 4 Pull back on connector housing while pushing in
DVD
DVD
1:4 board
5-out board
Connector housing
For full warranty information, refer to www.amx.com
7/07
©2007 AMX. All rights reserved. AMX and the AMX logo are registered trademarks of AMX.
AMX reserves the right to alter specifications without notice at any time.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • fax 469.624.7153 • technical support 800.932.6993 • www.amx.com
93-40-819 REV: A1
To attach cables to a module:
1. Fasten the locking S-Video plugs from the source and destination devices onto
the S-Video connectors (FIG. 4 previous page).
2. Plug the power cord into the power jack on the module and the power source
(FIG. 5).
3. Apply power to the source and destination devices.
To attach cables to an AF-10:
1. Fasten the locking S-Video plugs from the source and destination devices onto
the S-Video connectors (FIG. 4 previous page).
2. Plug the power cord into the power jack on the rear of the AF-10 and the power
source.
3. Turn on power source.
The Power Indicator on the front of the AF-10 illuminates.
S-Video Board Placement
Note: For instructions on installing additional boards, see the AF-10
Quick Start Guide.
•1:4 boards only – may be placed in AF-10 in any available slot
•1:4 and 5-out boards – place in AF-10 in alternating board slots
according to the pattern below
To place S-Video 1:4 & 5-out boards in an AF-10:
Install the 1:4 board in an even numbered board slot (counting from left to right).
Install the 5-out board in the adjoining slot to the left of the 1:4 board. The input on
the 1:4 board will then route signals to its own four outputs plus the five outputs on
the 5-out board for a total of nine outputs.
FIG. 5 Attach power cord and S-Video connectors
FIG. 6 Attach S-Video cables onto connectors
FIG. 7 Install 1:4 boards & 5-out boards in adjoining slot pairs
Power
From source To destinations
From source
To destinations
1:4 boards in even-numbered slots
5-out boards to the left of 1:4 boards in odd-numbered slots
