AMX NXA-ENET8POE User manual

Installation Guide
NXA-ENET8POE Gigabit PoE Ethernet Switch
Overview
The NXA-ENET8PoE Gigabit Ethernet Switch (FG2178-62) features 8 x 1000 Base-T ports
and is designed for homes and businesses that require a managed network for efficient
handling of voice, video, and data applications. Both power and data may be transmitted
through a single cable to eight remotely located Power-over-Ethernet (PoE) enabled devices
such as AMX Touch Panels, Wireless Access Points, VoIP Phones and IP Surveillance
cameras. In addition, the user-friendly web-based management interface allows you to easily
adjust settings to improve throughput, data prioritization and security.
Common Application
The NXA-ENET8PoE is a cost-effective solution that brings continuous availability, network
security, and an easy management interface for customers who are looking to migrate from
unmanaged to managed networks. It is perfect for homes and businesses. PoE capabilities
enable one Ethernet cable to deliver both data and power devices such as AMX Touch
Panels, WAPs and VoIP phones.
Note: The NXA-ENET8PoE is not for use with MVP-9000i docking stations, including the
MVP-TDS-9 and MVP-WDS-9. For more information on MVP-9000i docking stations, please
visit www.amx.com.
Features
•Gigabit Ethernet Switch - Gigabit switching capacity significantly improves the 
performance of a network's backbone delivering the throughput needed to support a
broad range of advanced network applications and reduce file transfer times.
•Multiple 10/100/1000 Base-T Ports - supports three different transfer rates on the
same port and auto-selects the best speed and duplex supported by both connected
devices for maximum data throughput.
•Provides Power over Ethernet - can deliver maximum power up to 15.4W for 4 ports
or 7.5W simultaneously for 8 ports over twisted pair cable up to 100 meters.
•Simplified Set-Up - The embedded web interface is user-friendly and enables users
to quickly and simply configure the NXA-ENET8PoE.
•Comprehensive Quality of Service - Four queues per port enable differentiated
management of up to four traffic types - traffic is prioritized providing optimal perfor-
mance for real-time applications such as voice and video.
•Enhanced Security Features - IEEE 802.1X port-based access control ensures all
users are authorized before being granted network access, plus user authentication
can be managed using a RADIUS server.
•Power Management Capabilities - the NXA-ENET8PoE can auto-detect powered
devices and power consumption, cutting power to ports with devices that have been
powered off and prioritization of ports to ensure power to important devices is retained
if the power demand exceeds the maximum power supply.
•Supports IGMP Snooping - The NXA-ENET8PoE supports multicast video for 
solutions such as AMX Vision².
•Send Signals Extreme Distances - The NXA-ENET8PoE can send data over fiber for
distances to 70 kilometers depending on the cable type using the shared 
RJ-45/SFP combo port.
•Fanless Design - Fewer moving parts reduces potential failures and runs more 
quietly.
Product Specifications
Power-over-Ethernet Capability
The NXA-ENET8PoE’s eight 10/100/1000 Mbps ports support the IEEE 802.3af Power-over-
Ethernet (PoE) standard that enables DC power to be supplied to attached devices using
wires in the connecting Ethernet cable. Any 802.3af compliant device attached to a port can
directly draw power from the switch over the Ethernet cable without requiring its own
separate power source. This capability gives network administrators centralized power
control for devices such as IP phones and wireless access points, which translates into
greater network availability.
FIG. 1 NXA-ENET8PoE Gigabit PoE Ethernet Switch
NXA-ENET8PoE Specifications
Dimensions (HWD): 1.7" x 13" x 8" (4.4 cm x 33 cm x 20.3 cm)
Weight: 4 lbs. (1.8 kg)
Power Requirements:
Power consumption: • 165W maximum (full PoE load)
Voltage: • 100-240V
• 50-60Hz
• 1.5 A
Current: • 1.5 A @ 110 VAC
• 0.75 A @ 220 VAC
Power Over Ethernet
Input Voltage:
•48VDC
(rear)
(front)
Power LED PoE LEDs
Link/ACT LEDs
PoE Ports
Status LED
120-240 VAC input
SFP transceiver slot
NXA-ENET8PoE Specifications (Cont.)
Power Requirements (Cont.):
Maximum output power: • 70W
• 15.4 W for any four ports simultaneously
• Port 1 can provide 25 W
Maximum output
current per port:
• 350 mA DC
• Port 1 can reach: 565 mA DC
• Output Voltage: 44 - 57 V DC
Output power on ports: • Max. 25W on Port 1
• Max. 15W on any 4 ports
• Max. 7.5W on any of the ports 1 to 8
Output current: • Max. 350 mA on any port
• Port 1 can provide up to 565mA
Output voltage: • 44-57V DC
Front Panel Components:
Power LED: Green LED indicates unit is powered.
PoE LEDs: Amber LEDs indicate device connected to port and receiving
power.
LINK/ACT LEDs: • Amber LEDs indicate device connected to port.
• Blinking amber LEDs indicate data transmission between
switch and connected device.
Ports: Eight 10/100/1000BaseT RJ-45 ports.
SFP transceiver slot: RJ45 port allowing SPF transceiver communication.
Status LED: Green LED indicates SFP connection.
Rear Panel Components:
Power input: 1 120-240 VAC 3-prong power supply socket.
Operating Environment: • Operating temperature: 32° F to 113° F (0° C to 45° C)
• Non-operating temperature: -40° F to 158° F 
(-40° C to 70° C)
• Max. relative humidity: 90% (Non-condensing)
Certifications: • FCC part 15 Class A
•CE
• UL Listed (US and Canada)
•RoHS
• CISPR Class A
• VCCI (Pending)
Other AMX Equipment: • NXA-WAP1000 Smart Wireless Access Point, US
Operation (FG2255-51)
• NXA-WAP1000 Smart Wireless Access Point, Operation
Outside US (FG2255-53)
• NXA-WAPZD1000 Wireless LAN Zone Director, US
Operation (FG2255-52)
• NXA-WAPZD1000 Wireless LAN Zone Director, Includes
EU Power Adapter for use in Europe (except UK), Chile,
Egypt, Indonesia, Pakistan, Saudi Arabia (except Dharan),
Vietnam (FG2255-54K)
• NXA-WAPZD1000 Wireless LAN Zone Director, Includes
AU Power Adapter for use in Australia and New Zealand
(FG2255-55K)
• NXA-WAPZD1000 Wireless LAN Zone Director, Includes
China AU style CCC certified Power Adapter for use in
China (FG2255-56K)
• NXA-WAPZD1000 Wireless LAN Zone Director, Includes
India Power Adapter (FG2255-57K)
• NXA-WAPZD1000 Wireless LAN Zone Director, Includes
Korea Power Adapter (FG2255-58K)
• NXA-WAPZD1000 Wireless LAN Zone Director, Includes
UK Power Adapter for use in the United Kingdom, Hong
Kong, Malaysia, Singapore, and United Arab Emirates
(UAE) (FG2255-59K)
• NXA-WAPZD1000 Wireless LAN Zone Director, Includes
US Power Adapter with 110 and 220 power input for use in
Brazil, Philippines, Saudi Arabia (Dharan), Taiwan,
Thailand, Uruguay (FG2255-60K)

For full warranty information, refer to the AMX Instruction Manual(s) associated with your Product(s).
3/11
©2011 AMX. All rights reserved. AMX and the AMX logo are registered trademarks of AMX.
AMX reserves the right to alter specifications without notice at any time.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • fax [phone] • technical support 800.932.6993 • www.amx.com
93-2178-62 REV: D
For each attached 802.3af-compliant device, the switch automatically senses the load and
dynamically supplies the required power. Independent overload and short-circuit protection
for each port allows the switch to automatically shut down a port’s power when limits are
exceeded. Port 1 on the switch can provide up to 25 W of power to an attached device at the
standard 48 DC voltage. Ports 2-8 can provide up to 15.4 W of power.
Installing the NXA-ENET8PoE
For more information on installing and configuring the NXA-ENET8PoE, please refer to the
NXA-ENET8PoE Operation Reference Guide, available at www.amx.com.
Selecting a Site
NXA-ENET8PoE units can be mounted in a standard 19-inch equipment rack or on a flat
surface. Be sure to follow the guidelines below when choosing a location.The site should:
• Be at the center of all the devices you want to link and near a power outlet.
• Be able to maintain its temperature within 0 to 45 °C (32 to 113 °F) and its humidity
within 10% to 90%, non-condensing.
• Provide adequate space (approximately five centimeters or two inches) on all sides for
proper air flow.
• Be accessible for installing, cabling and maintaining the devices.
• Allow the status LEDs to be clearly visible.
Make sure twisted-pair cable is always routed away from power lines, fluorescent lighting
fixtures, and other sources of electrical interference, such as radios and transmitters.
Make sure that the unit is connected to a separate grounded power outlet that provides 100
to 240 VAC, 50 to 60 Hz, is within 2 m (6.6 feet) of each device and is powered from an
independent circuit breaker. As with any equipment, using a filter or surge suppressor is
recommended.
Ethernet Cabling
To ensure proper operation when installing the switches into a network, make sure that the
current cables are suitable for 10BASE-T, 100BASE-TX or 1000BASE-T operation. Check
the following criteria against the current installation of your network:
• Cable type: Unshielded twisted pair (UTP) or shielded twisted pair (STP) cables with
RJ-45 connectors; Category 3 or better for 10BASE-T, Category 5 or better for
100BASE-TX, and Category 5, 5e or 6 for 1000BASE-T.
• Protection from radio frequency interference emissions
• Electrical surge suppression
• Separation of electrical wires (switch related or other) and electromagnetic fields from
data-based network wiring
• Safe connections with no damaged cables, connectors or shields
Installing an Optional SFP Transceiver
The NXA-ENET8PoE supports the following optional transceivers:
• 1000BASE-SX
• 1000BASE-LX
• 1000BASE-LH
To install an SFP transceiver:
1. Consider network and cabling requirements to select an appropriate transceiver type.
2. Insert the transceiver with the optical connector facing outward and the slot connector
facing down. Note that SFP transceivers are keyed so they can only be installed in one
orientation.
3. Slide the transceiver into the slot until it clicks into place.
Note: SFP transceivers are hot-swappable. The switch does not need to be powered off
before installing or removing a transceiver. However, always first disconnect the network
cable before removing a transceiver.
Note: SFP transceivers are not provided.
Connecting to a Power Source
To connect the NXA-ENET8PoE to a power source:
1. Insert the power cable plug directly into the socket located at the back of the device.
2. Plug the other end of the cable into a grounded, three-pin, AC power source.
Note: For international use, you may need to change the AC line cord. You must use a line
cord set that has been approved for the socket type in your country.
3. Check the front-panel LEDs as the device is powered on to be sure the Power LED is
on. If not, check that the power cable is correctly plugged in.
Connecting Network Devices
The NXA-ENET8PoE units are designed to interconnect multiple segments (or collision
domains). It can be connected to network cards in PCs and servers, as well as to hubs,
switches or routers. It may also be connected to devices using optional SFP transceivers.
If 802.3af-compliant PoE devices are connected to the NXA-ENET8PoE’s 10/100 Mbps
ports, the device automatically supplies the required power.
Power over Ethernet Connections
The NXA-ENET8PoE automatically detects an 802.3af-compliant device by its authenticated
PoE signature and senses its required load before turning on DC power to the port. This
detection mechanism prevents damage to other network equipment that is not 802.3af
complaint.
Note: Power-over-Ethernet connections work with all existing Category 3, 4, 5, 5e or 6
network cabling, including patch cables and patch-panels, outlets, and other connecting
hardware, without requiring modification.
The NXA-ENET8PoE delivers power to a device using wire pairs in the connecting Ethernet
cable. The switch can provide up to 15.4 W of power continuously on each 10/100 Mbps port.
However, taking into account some power loss over the cable run, the amount of power that
can be delivered to a terminal device is 12.95 W. If a device draws more than 15.4 W, from a
port, an overload condition occurs and the port turns off the power.
The NXA-ENET8PoE controls the power and data on a port independently. Power can be
requested from a device that already has a data link to the switch. Also, the NXA-ENET8PoE
can supply power to a device even if the port’s data connection has been disabled. The
power on a port is continuously monitored by the switch and it will be turned off as soon as a
device connection is removed.
Connecting to PCs, Servers, Hubs and Switches
To connect to a PC, server, hub, or switch:
1. Attach one end of a twisted-pair cable segment to the device’s RJ-45 connector.
2. If the device is a PC card and the NXA-ENET8PoE is in the wiring closet, attach the
other end of the cable segment to a modular wall outlet that is connected to the wiring
closet. Otherwise, attach the other end to an available port on the switch.
3. Make sure each twisted pair cable does not exceed 100 meters (328 ft) in length.
4. As each connection is made, the Link LED (on the NXA=ENET8PoE) corresponding to
each port turns on to indicate that the connection is valid.
Fiber Optic SFP Devices
An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX or 1000BASE-LH) can
be used for a backbone connection between switches, or for connecting to a high-speed
server.
Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC
connector at both ends. Each multimode fiber optic port requires 50/125 or 62.5/125 micron
multimode fiber optic cabling with an LC connector at both ends.
Warning: The switch use lasers to transmit signals over fiber optic cable. The lasers are
compliant with the requirements of a Class 1 Laser Product and are inherently eye safe in
normal operation. However, you should never look directly at a transmit port when it is
powered on.
Note: When selecting a fiber SFP device, considering safety, please make sure that it can
function at a temperature that is not less than the recommended maximum operational
temperature of the product. You must also use an approved Laser Class 1 SFP transceiver.
To connect an SFP device:
1. Remove and keep the LC port’s rubber cover. When not connected to a fiber cable, the
rubber cover should be replaced to protect the optics.
2. Check that the fiber terminators are clean. You can clean the cable plugs by wiping
them gently with a clean tissue or cotton ball moistened with alcohol. Dirty fiber termi-
nators on fiber cables will impair the quality of the light transmitted through the cable
and lead to degraded performance on the port.
3. Connect one end of the cable to the LC port on the NXA-ENET8PoE and the other end
to the LC port on the other device. Since LC connectors are keyed, the cable can be
attached in only one orientation.
4. As a connection is made, check the Link LED on the NXA-ENET8PoE corresponding
to the port to be sure that the connection is valid.
The 1000BASE-SX, 1000BASE-LX and 1000BASE-LH fiber optic ports operate at 1 Gbps
full duplex.The maximum length for fiber optic cable operating at Gigabit speed will depend
on the fiber type.
Browser-Based Configuration Pages
You can access the Browser-Based Configuration Pages in the switch from anywhere within
the attached network using a Web browser, or other network management software tools.
However, you must first configure the switch with a valid IP address, subnet mask, and
default gateway. If you have trouble establishing a link to the management agent, check to
see if you have a valid network connection, then verify that you entered the correct IP
address. Be sure the port through which you are connecting to the switch has not been
disabled. If it has not been disabled, then check the network cabling that runs between your
remote location and the switch.
Resetting the NXA-ENET8PoE to Factory Defaults
If you have forgotten the administration password for the Browser-Based Configuration
Pages, you can return the switch to its factory default state by following these steps:
1. Remove the power cord from the back of the device.
2. Remove all cables from the front-panel ports.
3. Connect port 1 to port 2 on the front panel, using a standard network cable.
4. Reconnect the power cord to the rear of the switch.
5. The PoE LEDs (FIG. 1) will flash on and off at least two times, followed by the 
Link/ACT LEDs. Do not disconnect the cable or the power cord until only the first two
Link/ACT LEDs are a steady green and the others are off.
6. Disconnect the power cord and THEN disconnect the network cable.
7. Reconnect the power cord. The NXA-ENET8PoE is now reset to its factory defaults.
Note: After completing this procedure, the password will be “1988” and the network IP
address will be returned to the default of 192.168.2.10.
For more information on the Browser-Based Configuration Pages, please refer to the 
NXA-ENET8PoE Operation Reference Guide, available at www.amx.com.
Default settings for the NXA-ENET8PoE
IP Address: 192.168.2.10
Subnet mask: 255.255.255.0
Gateway: 0.0.0.0
Password: 1988
