GENERAL DESCRIPTION
The AD8333-EVAL evaluation board enables the user to quickly
become familiar with the operating characteristics and features
of the AD8333 dual I/Q demodulator and phase shifter. Jumpers
provide a convenient means for exercising the user-selectable
features of the AD8333.
The board is tested prior to shipment and shipped with the
phase-encoding bits set to 0000 (no phase shift) for both
channels. The LNA is set up for a 50 Ω source, and the VGA
sections of the AD8332 are disabled. Test points are provided
along the signal path to facilitate signal tracing.
EVALUATION BOARD
05836-001
Figure 1. Evaluation Board—Actual Size

AD8333-EVALZ
Rev. B | Page 2 of 12
TABLE OF CONTENTS
Features .............................................................................................. 1
Applications....................................................................................... 1
General Description ......................................................................... 1
Evaluation Board .............................................................................. 1
Revision History ............................................................................... 2
Introduction ...................................................................................... 3
Features and Options................................................................... 3
Measurement Setup.......................................................................4
Evaluation Board Schematic and Artwork.....................................5
Board Layout..................................................................................7
Ordering Information.......................................................................9
Bill of Materials..............................................................................9
Ordering Guide .......................................................................... 10
ESD Caution................................................................................ 10
REVISION HISTORY
9/07—Rev. A to Rev. B
Changes to Features and Options Section..................................... 3
Changes to Figure 3.......................................................................... 5
Changes to Table 4............................................................................ 9
6/07—Rev. 0 to Rev. A
Changes to Figure 1.......................................................................... 1
Changes to Figure 2.......................................................................... 4
Changes to Figure 4.......................................................................... 6
Changes to Figure 6 and Figure 7................................................... 7
Changes to Table 4............................................................................ 9
Changes to Ordering Guide .......................................................... 10
1/06—Revision 0: Initial Version

AD8333-EVALZ
Rev. B | Page 3 of 12
INTRODUCTION
The AD8333-EVAL evaluation board provides a platform for
test and evaluation of the AD8333 I/Q demodulator and phase
shifter. The board is shipped fully assembled and tested, and the
user need only connect appropriate signals to the RF input and
f4LO SMA connectors. An AD8332 is included with the board
and acts as a buffer and bias supply for the AD8333, converting
single-ended signals to differential, centered at half the supply.
A photograph of the board is shown in Figure 1 and a schematic
diagram is shown in Figure 3. The board requires dual 5 V
supplies capable of supplying 300 mA or greater. Except for the
components shown in grayscale, the board is built and tested
using all the components illustrated in Figure 3.
FEATURES AND OPTIONS
The evaluation board has several features and options that are
configurable according to the specific needs of the user. Table 1
lists the jumpers and their functions.
Table 1. Jumper Functions
Jumper Function Position
ENBL Enable the AD8333 Bottom = disable; top = enable
PH10 Ch 1 Phase 0 bit Top = 0; bottom = 1
PH11 Ch 1 Phase 1 bit Top = 0; bottom = 1
PH12 Ch 1 Phase 2 bit Top = 0; bottom = 1
PH13 Ch 1 Phase 3 bit Top = 0; bottom = 1
PH20 Ch 2 Phase 0 bit Top = 1; bottom = 0
PH21 Ch 2 Phase 1 bit Top = 1; bottom = 0
PH22 Ch 2 Phase 2 bit Top = 1; bottom = 0
PH23 Ch 2 Phase 3 bit Top = 1; bottom = 0
RST Reset pin Left = reset; right = normal
The Phase Bits
The phase bits configure the channel for one of sixteen 22.5°
increments from 0° to 337.5°. The increments increase according
to a simple binary code from 0000 to 1111 embodied in the
phase bits from 0° (0x0) to 337.5° (0xF). Table 2 lists the phase
shift and corresponding code for each bit. The bits labeled 0 and
1 correspond to low and high, respectively, on the silkscreen.
Jumpers are provided to select the desired state.
Enable and Reset Jumpers
For normal operation, place a jumper in the upper position of
ENBL. To disable the AD8333, move the jumper to the lower
position. For normal operation, the jumper for RST is in its
right position. When the jumper is in the left position, the
device counter is held in reset and no mixing occurs.
Table 2. Phase Shift Select Codes
Ф Shift PHx3 PHx2 PHx1 PHx0
0° 0 0 0 0
22.5° 0 0 0 1
45° 0 0 1 0
67.5° 0 0 1 1
90° 0 1 0 0
112.5° 0 1 0 1
135° 0 1 1 0
157.5° 0 1 1 1
180° 1 0 0 0
202.5° 1 0 0 1
225° 1 0 1 0
247.5° 1 0 1 1
270° 1 1 0 0
292.5° 1 1 0 1
315° 1 1 1 0
337.5° 1 1 1 1
Fixed Options
Several options can be realized by adding or changing resistors.
LNA Input Impedance
The shipping configuration of the input impedance of the LNA
is 50 Ω to match the output impedance of most signal generators.
Input impedances of up to 14.7 kΩ are obtained by selection of
the values of R9 and R10. Details concerning this circuit feature
are found in the AD8332 data sheet. For reference, Table 3 lists
common values of input impedance and corresponding
feedback resistor values.
Table 3. LNA External Component Values for Common
Source Impedances
RIN (Ω) RFB, Nearest STD 1% Value (Ω) CSH (pF)
50 280 22
75 412 12
100 562 8
200 1.13 k 1.2
500 3.01 k None
6 k ∞ None

AD8333-EVALZ
Rev. B | Page 4 of 12
Current Summing
The output transimpedance amplifiers, A1 through A4, are
configured as I-to-V converters to convert the output current of
the AD8333 to a voltage. The low-pass filters formed by the
feedback components are designed for single-channel operation
with ±5 V supplies.
Optional R4 and R5 resistors are provided to sum the two
channels. When R4 and R5 are installed, R2 and R3 are
removed and the sum of the outputs is seen at the I1 and Q1
output SMA connectors. If large signal levels are expected, the
feedback resistor and capacitor values, 787  and 2.2 nF, can be
halved and doubled, respectively, to optimize the output swing.
The filter capacitor values can be changed if other frequencies
are desired.
Reset Input
For normal operation, the reset input is high (no reset). To drive
the reset with a dynamic signal, provision is made to connect a
signal generator at the RST input. A 49.9 Ω, 0603 surface-
mount resistor can be installed at R15 to terminate the reset
input for pulsed experiments. In this configuration, the jumper
at RST is not used and must be removed to avoid loading the
power supply.
MEASUREMENT SETUP
Figure 2 displays the connector and user-selectable jumper
locations. A typical board and test equipment setup is shown in
Figure 4. Two signal generators, a power splitter, and a ±5 V,
300 mA (minimum) power supply are required. Synchronize
the signal generators for optimum results. Remember that the
f4LO signal generator frequency is four times that of the nominal
frequency of the RF source. For example, to detect signals with
a nominal center frequency of 5 MHz, an f4LO frequency of 20 MHz
is applied to the oscillator input. For an applied RF signal of
5.01 MHz, the mix frequencies are 10 kHz and 10.01 MHz.
Because of the low-pass active filter of the transconductance
amplifiers (A1 through A4), 10 kHz is observed at the output.
Take care to avoid over driving the LNA input of the AD8332.
The LNA gain is 19 dB (9.5×) and the maximum output swing
must not be exceeded; −10 dBm suffices for many experiments.
The f4LO input is ac-coupled to a 5 V LVDS buffer to provide an
ideal interface to the AD8333.
The f4LO level is frequency dependent; consult the AD8333 data
sheet for minimum signal levels, then adjust the signal generator
output level accordingly.
05836-002
f
4LO
INPUT
CHANNEL 1
PHASE BITS
ENABLE
RESET
CHANNEL 2
PHASE BITS
CH 2 RF INPUT
CH 1 RF INPUT
CH 1 I OUTPUT
CH 1 Q OUTPU
T
CH 2 I OUTPUT
CH 2 Q OUTPU
T
+5V, GND, –5V
Figure 2. Evaluation Board Layout
