Analog Devices LTC6952 Quick setup guide

1
Rev 0
DEMO MANUAL DC2609A
DESCRIPTION
LTC6952
Ultralow Jitter, 4.5GHz PLL with 11 Outputs
and JESD204B Support
Demonstration circuit 2609A features the LTC6952, an
Ultralow Jitter, 4.5GHz PLL with 11 Outputs and JESD204B
Support.
By default, the DC2609A is powered from two supplies.
The 9V-12V supply input powers the onboard reference
and VCO circuitry, along with the LTC6952 5V supply pin.
The 4V-6V supply input powers the LTC6952 3.3V supply
pins. A reduced power option is provided that allows the
LTC6952’s output supply pins to connect to an LTC Silent
Switcher
®
and the LTC6952 input supply pins to connect
to a low noise LDO.
All differential inputs and six of the differential outputs are
populated with 0.5”spaced SMA connectors. These outputs
are AC-coupled with 50Ω transmission lines making them
suitable to drive 50Ω impedance instruments. The remain-
ing five differential outputs are terminated with 100Ω.
All registered trademarks and trademarks are the property of their respective owners.
The LTC6952’s EZSync™and SYSREF request func-
tions are made available via the LTC6952 SPI interface
or the EZS_SRQ SMA/turret connectors. The DC2609A,
DC2610A, and DC2611A SMA placement was designed
for ease of connection for all multi-part synchronization
and SYSREF request modes.
The VTUNE and VCO SMAs can mate directly with the
DC2664A VCO rider board. This options allows for a quick
method to evaluate multiple VCOs.
A DC2026 USB serial controller board is used for SPI
communication with the LTC6952, controlled by the sup-
plied LTC6952Wizard™ software.
DC2609 Design files are available.
Figure 1. DC2609A Connections
RIBBON CABLE CONNECTION
TO DC590 OR DC2026
OUT1, CML
AC-COUPLED
OUTPUTS, SMA
OUT0, CML
AC-COUPLED
OUTPUTS, SMA
9-12V SUPPLY,
BANANA JACK J30
OUT9, CML
AC-COUPLED
OUTPUTS, SMA
OUT8, CML
AC-COUPLED
OUTPUTS, SMA
ONBOARD VCO &
SUPPORT CIRCUITRY
OUT5, CML
AC-COUPLED
OUTPUTS, SMA
OUT4, CML
AC-COUPLED
OUTPUTS, SMA
STAT LED, D1
4-6V SUPPLY,
BANANA JACK J32
ONBOARD REFERENCE
(BOTTOM SIDE)
POWER SUPPLY
SUPPORT CIRCUITRY
(TOP & BOTTOM SIDE)
LTC6952
DEMO CIRCUIT 2609A

2
Rev 0
DEMO MANUAL DC2609A
QUICK START PROCEDURE
The DC2609A is easy to set up to evaluate the perfor-
mance of the LTC6952. Follow the procedure below.
The LTC6952Wizard and the DC2026 are required to con-
trol the DC2609A through a personal computer (PC).
DC2026 CONFIGURATION
Refer to Figure 2. Set the JP3 jumper to the 3.3V (pre-
ferred) or 5V position.
Connect the DC2026 to one of your computer’s USB ports
with the included USB cable.
The DC2026 has the ability to run Linduino code, refer to
Design Center and the Frequently Asked Question section
(Question #2) for more details.
LTC6952WIZARD INSTALLATION
The LTC6952Wizard software is used to communi-
cate with the LTC6952. It uses the DC2026 to translate
between USB and SPI-compatible serial communications
formats. It also includes advanced design and simulation
capabilities. The following are the LTC6952Wizard system
requirements:
•Windows Operating System:Windows XP, Windows
2003 Server, Windows Vista, Windows 7
• Microsoft.NET 3.5 SP1 or later
• Windows Installer 3.1 or later
•Linear Technology’s DC2026 (with the DC590B emula-
tor sketch loaded)
The DC2026 arrives from the factory with the DC590B
Emulator sketch loaded. If this is not the case refer to the
Troubleshooting section.
Figure 2. DC2026 Connector Location
J5, USB
CONNECTION
TO PC
J1, RIBBON CABLE
CONNECTION
TO DC2609A
JP3, SELECT
3.3V OPTION

3
Rev 0
DEMO MANUAL DC2609A
QUICK START PROCEDURE
Figure 3. LTC6952Wizard Screenshot
Download the LTC6952Wizard setup file.
Run the LTC6952Wizard setup file and follow the instruc -
tions given on the screen. The setup file will verify and/
or install Microsoft.NET and install the LTC6952Wizard.
Refer to the LTC6952Wizard Help menu for software
operation.
DC2609A CONFIGURATION
1. Connect J30, J32 and J33 to the appropriate power
supplies and apply power (see Figure 1 and the Typical
DC2609A Requirements and Characteristics table).
2. Connect the DC2026 to the DC2609A with the provided
ribbon cable.
3. Run the LTC6952Wizard application.
4. In LTC6952Wizard, click File →Load Settings and
select file “LTC6952 EZSync StandAlone.6952set”.
The DC2609A’s red STAT LED (D1) should illuminate.
5. Synchronize outputs by toggling the LTC6952 SSYNC
bit on then off from the LTC6952Wizard.
6. Connect desired output (OUT9, OUT8, OUT5, OUT4,
OUT1 or OUT0) to a test instrument or other demo
board to evaluate performance.
Be sure to power down or terminate any unused RF output
with 50Ω, or poor spurious performance may result.

4
Rev 0
DEMO MANUAL DC2609A
TROUBLESHOOTING
If the green LEDs (D2, D3, or D4) do not illuminate:
1. Verify J30 measures between 9V and 12V (see the Typi-
cal DC2609A Requirements and Characteristics table)
2. Verify the JP3 and JP5 jumpers are installed correctly
(refer to the DC2609A schematic sheet 3)
3. Verify the output voltages at pin 10 of U7, U8, and U11
are correct
a. U7 = 3.3V
b. U8 = 8V
c. U11 = 5V
If the green LED (D5) does not illuminate:
1. Verify J32 measures between 4V and 6V (see the Typi-
cal DC2609A Requirements and Characteristics)
2. Verify JP4, JP6, and JP7 jumpers are installed correctly
(refer to the DC2609A schematic sheet 3)
3. Verify the voltages at jumper JP6 and JP7 are correct
a. JP6 = 3.3V
b. JP7 = 3.3V
If the red LED (D1) does not illuminate:
1. In LTC6952Wizard’s System tab click “Read All”.
LTC6952Wizard should match Figure 3. If not, see
“Verify DC2609A and LTC6952Wizard Communication”
Verify DC2609A and LTC6952Wizard Communication:
To verify communication with the DC2609A. The bottom
status line in LTC6952Wizard should read “LTC6952”and
“Comm Enabled”as shown in Figure 3. If not, then per-
form the following steps:
1. Ensure the DC2026 is connected to PC
2. Disconnect and Reconnect DC2026 to PC
3. Ensure DC2026 is connected to DC2609A
4. Close LTC6952Wizard and restart
5. Verify the DC2026 has the DC590B Emulator sketch
loaded by contacting the factory or following these
steps.
a. Download QuikEval™
b. Run QuikEval (Linduino connected to the PC)
If QuikEval does not find a DC590B, reload the DC590
Linduino sketch. To use the LTSketchbook refer to the-
Linduino Design Center for instructions on how to start
using Linduino.
If DC2609A performance is less than the LTC6952
data sheet specifications:
1. For unexpected spurious response, verify power sup-
plies are low noise and spurious free power supplies.
Power supplies that are based off a switching regulator
architecture are known to generate spurs on low jitter
clock outputs.
2. For poor phase noise results, verify the phase noise
specifications of the input signal and the phase noise
measurement instrument. Traditional signal sources
and spectrum analyzers have higher phase noise than
the LTC6952 and will degrade measurement results.
To measure phase noise performance it is recom-
mended to use a low jitter oscillator and a signal source
analyzer, such as Keysight’s (previously Agilent/HP)
E5052.
3. Contact the factory for further troubleshooting.

5
Rev 0
DEMO MANUAL DC2609A
DC2609A RECONFIGURATION
The following covers the hardware reconfiguration of the
DC2609A. Refer to LTC6952Wizard and the LTC6952 data
sheet to better understand how to change programmed
parameters on the DC2609A.
LTC6952 3.3V POWER SUPPLY OPTIONS
Table 1 provides the 3.3V power supply options for
DC2609A. By default the DC2609A is setup to use the
LDO only supply option. An alternative jumper select-
able supply option is provided that uses an LDO and
Silent Switcher supply. The LDO + Silent Switcher option
powers the higher current LTC6952 output supply pins
from an LTC Silent Switcher, such as the LT8609S. The
LTC Silent Switcher improves the power efficiency over
the low noise LDO. A low noise LDO is required on the
LTC6952’s VVCO+and VREF+supply pins for acceptable
in-band performance.
Table 1. Power Supply Options
Jumper Settings
Default Option JP4 JP6 JP7
X LDO Only 2-3 1-2 2-3
LDO + Silent Switcher 1-2 1-2 1-2
VCO SMA: INPUT TERMINATION OPTIONS
Table 2 provides the single-ended and differential SMA
input termination options. By default the DC2609A is
setup for onboard VCO input and does not use the J28
and J29 SMAs.
Table 2. VCO SMA Input Termination Options (*)
SMA
Inputs
Termination R18
Ω
R22
Ω
R20
Ω
R21
Ω
C14
µF
C16
µF
J28 SE, IN–75 30 DNI DNI 0.1 DNI
J29 SE, IN+30 75 DNI DNI DNI 0.1
J28 &
J29
DIFF, CML or
PECL
DNI DNI 160 DNI 0.1 0.1
DIFF, LVDS DNI DNI DNI 160 0.1 0.1
* SE = Single-Ended, DIFF = Differential, DNI = Do Not Install
LTC6952 6952SET FILES
The LTC6952Wizard provides a 6952set file for all
LTC6952 data sheet application examples and typical
application circuits. After loading a 6952 set file a pop-up
window will detail any user actions and board modifica-
tions required for the selected file.
SYNC OPTIONS
The LTC6952 data sheet describes several synchroniza-
tion modes. After selecting the desired synchronization
mode, refer to Table 3 to identify the required DC2609A
board modifications. Refer to the LTC6952 data sheet for
SYNC timing and level requirements.
CML OUTPUTS, OUT[10:0]
The DC2609A has 11 CML outputs. OUT[9:0] have match-
ing trace lengths, which are optimized for skew measure-
ments. OUT10’s trace lengths are longer than the other
outputs traces due to the shape of the DC2609A.
Six of these outputs are AC-coupled and brought out to
SMAs (OUT9, OUT8, OUT5, OUT4, OUT1, and OUT0). To
drive 50Ω impedance instruments connect OUTx+to the
instrument and OUTx–to a 50Ω termination, or vice versa.
The remaining five outputs (OUT10, OUT7, OUT6, OUT3,
and OUT2) are terminated with a 100Ω resistor onboard.
To connect these outputs to a 50Ω instrument, remove
the 100Ω termination, and install the appropriate SMAs
and AC blocking capacitors.
Refer to LTC6952 data sheet for differential termination
options.

6
Rev 0
DEMO MANUAL DC2609A
DC2609A RECONFIGURATION
Table 3. LTC6952 Sync Mode Programming Options
Board Modifications (DNI = Do Not Install)
SYNC/SYSREF
Method
EZS_SRQ Pins
State
R53 (Ω) R7 (Ω) R5 (Ω) R50 (Ω) R10 (Ω) R3 (Ω) R8 (Ω)
EZS_SRQ Pin Differential, CML
or LVPECL
DNI DNI 100 0 0 DNI DNI
Differential LVDS 100 100 750 50 50 130 130
EZS_SRQ+: CMOS
EZS_SRQ–: GND
200k 0 DNI 0 0 DNI DNI
SSRQ Register Bit EZS_SRQ+: GND
EZS_SRQ–: GND
200k 0 DNI 0 0 DNI DNI
FREQUENTLY ASKED QUESTIONS
1. Can the LTC6952Wizard control a LTC6952 on a board other than the DC2609A?
Yes, follow these steps.
Step 1: Configure the DC2026 for 3.3V SPI as shown in Figure 2
Step 2:Connect the DC2026 J1 connector SPI pins to the LTC6952 SPI pins. Refer to page two of the DC2609A sche-
matic for pin assignments.
2. Does the LTC6952 have Linduino Code available?
Yes, download the LTC6953 sketch in the LTSketchbook. To use the LTSketchbook and for instructions on how to start
using Linduino refer to the Linduino Design Center. This will give programmers a head start in writing code for the
LTC6952. It is recommended to use the LTC6952Wizard to create the best possible register settings for all conditions.
These LTC6952 register settings from LTC6952Wizard can be programmed in a lookup table.

7
Rev 0
DEMO MANUAL DC2609A
TYPICAL DC2609A REQUIREMENTS AND CHARACTERISTICS
PARAMETER INPUT OR OUTPUT PHYSICAL LOCATION DETAILS
9V-12V Power Supply Input J30 Banana Jack Powers the onboard 8V VCO, the onboard 3.3V
reference and the LTC6952 5V VCP+ supply pins.
Power down onboard reference (U2) by setting
jumper JP2 to position 2-3.
Power down onboard VCO (U9) by setting jumper
JP3 to position 2-3.
4V-6V Power Supply Input J32 Banana Jack Powers the LTC6952 3.3V supply pins (VOUT+,
VREF+, VVCO+, and VD+). Option available to power
supplies from single LDO, or an LDO and an LTC
Silent Switcher. Refer to Table 1.
GND Output J33 Banana Jack Pair with J30 and J32
OUT9+; OUT9–J3 and J4 SMA Connectors* CML, AC-Coupled, 800mVpk Differential
OUT8+; OUT8–J5 and J6 SMA Connectors*
OUT5+; OUT5–J19 and J20 SMA Connectors*
OUT4+; OUT4–J17 and J18 SMA Connectors*
OUT1+; OUT1–J11 and J12 SMA Connectors*
OUT0+; OUT0–J9 and J10 SMA Connectors*
OUT10+; OUT10–Two Outputs
(Not Connected)
J1 and J2 (SMA Not Populated) Onboard Differential 100Ω termination
OUT7+; OUT7–J7 and J8 (SMA Not Populated)
OUT6+; OUT6–J21 and J22 (SMA Not Populated)
OUT3+; OUT3–J15 and J16 (SMA Not Populated)
OUT2+; OUT2–J13 and J14 (SMA Not Populated)
VCO+; VCO–Input
(Not connected)
J28 and J29 SMA Connector Default: Not Connected
(see Table 2, for correct input termination options)
REF+;REF–Input
(Not connected)
J24 and J25 SMA Connector Default: Not Connected
EZS_SRQ+Input J27 SMA Connector/E1 Turret Default: Preferred Single-Ended Input
EZS_SRQ–Input J26 SMA Connector/E3 Turret Default: Shorted to GND
ISD Input Test Point 3.3V(Default): Device Active, set by pull-up resistor
GND: Shut Down Device
STAT Output JP1 Jumper Red LED D1 illuminates when STAT pin in high state
*Any unused RF output must be powered down or terminated with 50Ω, or poor spurious performance may result.
ASSEMBLY OPTIONS
Table 5. DC2609A Options
Assembly Version Part Number
DC2609A-A LTC6952IUKG

8
Rev 0
DEMO MANUAL DC2609A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 0 CI1_A, C3, CP_A (OPT) CAP., OPTION, 0603 OPT
2 1 CI1_P CAP., 0.68µF, X7R, 16V, 10%, 0603, AEC-
Q200
SAMSUNG, CL10B684KO8VPNC
3 0 CI2_A (OPT) CAP., OPTION, 1206 OPT
4 1 CI2_P CAP., 1µF, X7R, 25V, 10%, 1206, AEC-Q200 SAMSUNG, CL31B105KAPWPNE
5 1 CP_P CAP., 0.033µF, X7R, 50V, 10%, 0603 MURATA, GRM188R71H333KA61D
6 18 C1, C4, C6, C9, C50, C51, C52,
C53, C54, C55, C56, C57, C58,
C59, C60, C61, C110, C112
CAP., 1µF, X5R, 16V, 10%, 0402 MURATA, GRM155R61C105KE01D
7 1 C2 CAP., 0.022µF, X7R, 50V, 10%, 0603 MURATA, GRM188R71H223KA01D
8 25 C5, C11, C17, C18, C19, C20,
C21, C22, C23, C24, C26, C29,
C30, C31, C32, C63, C64, C65,
C66, C67, C81, C88, C89, C101,
C111
CAP., 0.1µF, X7R, 10V, 10%, 0402 MURATA, GRM155R71A104KA01D AVX,
0402ZC104KAT2A
9 1 C7 CAP., 0.01µF, X7R, 16V, 10%, 0402 AVX, 0402YC103KAT2A
10 0 C8, C12, C14, C15, C16, C25,
C27, C28, C33, C34, C35, C36,
C37, C82, C83, C84, C85
CAP., OPTION, 0402 OPT
11 14 C10, C38, C39, C40, C41, C42,
C43, C44, C45, C46, C47, C48,
C49, C62
CAP., 0.01µF, X7R, 6.3V, 10%, 0201 MURATA, GRM033R70J103KA01D
12 1 C13 CAP., 10pF, C0G, 50V, 10%, 0402 AVX, 04025A100KAT2A
13 3 C68, C91, C106 CAP., 22µF, ALUM., 63V, 20%, SMD
6.3 ×7.7mm, CE-BS Series
SUN ELECTRONIC INDUSTRIES CORPORATION,
63CE22BS
14 4 C69, C74, C92, C97 CAP., 10µF, ALUM., 63V, 20%, SMD
6.3 ×5.4mm, CE-BS Series
SUN ELECTRONIC INDUSTRIES CORPORATION,
63CE10BS
15 13 C70, C72, C73, C75, C77, C78,
C93, C95, C96, C98, C104, C105,
C107
CAP., 4.7µF, X7R, 50V, 10% 1206 MURATA, GRM31CR71H475KA12L AVX,
12065C475KAT2A NIC,
NMC1206X7R475K50TRPLPF
16 6 C71, C76, C79, C86, C94, C103 CAP., 0.1µF, X7R, 16V, 10%, 0603 MURATA, GRM188R71C104KA01D YAGEO,
CC0603KRX7R7BB104
17 3 C80, C87, C90 CAP., 47µF, TANT, 35V, 10%, 7361 AVX, TAJV476K035RNJ
18 1 C99 CAP., 330µF, TANT, 10V, 10%, 7343 AVX, TPME337K010R0035
19 1 C100 CAP., 10µF, X7R, 25V, 10%, 1206 MURATA, GRM31CR71E106KA12L
20 1 C102 CAP., 1µF, X7R, 50V, 10%, 0805 TDK, C2012X7R1H105K125AB
21 1 C108 CAP., 47µF, X5R, 25V, 20%, 1206 TDK, C3216X5R1E476M160AC
22 1 C109 CAP., 4.7µF, X7R, 16V, 10%, 0805 MURATA, GRM21BR71C475KA73L AXV,
0805YC475KAT2A
23 1 D1 LED, RED, CLEAR, 3020 (1208) ROHM, SML-012V8TT86
24 5 D2, D3, D4, D5, D6 LED, GREEN, CLEAR, 3020 (1208) ROHM, SML-012P8TT86
25 15 E1, E2, E3, E4, E5, E6, E7, E8, E9,
E10, E11, E12, E13, E14, E15
TEST POINT, TURRET, 0.064", MTG. HOLE MILL-MAX, 2308-2-00-80-00-00-07-0
26 3 FB1, FB2, FB3 IND., 330Ω at 100MHz, FERRITE BEAD,
25%, 0.8A, 0.21Ω, 0603
TAIYO YUDEN, FBMH1608HL331-T

9
Rev 0
DEMO MANUAL DC2609A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
27 2 FB4, FB5 IND., 220Ω at 100MHz, FERRITE BEAD, 3A,
0.04Ω, 0805
TDK, MPZ2012S221AT000
28 7 JP1, JP2, JP3, JP4, JP5, JP6, JP7 CONN., HDR, MALE, 1 ×3, 2mm, THT, STR Wurth Elektronik, 62000311121
29 0 J1, J2, J7, J8, J13, J14, J15, J16,
J21, J22 (OPT)
CONN., SMA, JACK, RCPT, END LAUNCH,
STR, 50Ω
OPT
30 19 J3, J4, J5, J6, J9, J10, J11, J12,
J17, J18, J19, J20, J24, J25, J26,
J27, J28, J29, J31
CONN., SMA, JACK, RCPT, END LAUNCH,
STR, 50Ω
CINCH CONNECTIVITY SOLUTIONS, 142-0701-851
31 1 J23 CONN., HDR., MALE, 2 ×7, 2mm, THT,
VERT, SHROUDED
MOLEX, 87831-1420
32 3 J30, J32, J33 CONN., BANANA JACK, FEMALE, THT,
NON-INSULATED, SWAGE, 0.218"
KEYSTONE, 575-4
33 1 L1 IND., 0Ω, 1/8W, 0805 VISHAY, CRCW08050000Z0EA YAGEO, RC0805JR-
070RL
34 1 L2 IND., 2.2µH, PWR, 20%, 8A, 23.5mΩ,
4.3mm ×4.3mm, AEC-Q200
“COILCRAFT, XFL4020-222MEB
COILCRAFT, XFL4020-222MEC”
35 2 R1, RZ_P RES., 48.7Ω, 1%, 1/10W, 0603, AEC-Q200 VISHAY, CRCW060348R7FKEA
36 4 R2, R39, R51, R52 RES., 0Ω, 1/10W, 0603 VISHAY, CRCW06030000Z0EA NIC, NRC06ZOTRF
37 0 R3, R8, R11, R13, R14, R15, R17,
R20, R35, R64, R69 (OPT)
RES., OPTION, 0402 OPT
38 2 R4, R73 RES., 49.9Ω, 1%, 1/16W, 0402 VISHAY, CRCW040249R9FKED NIC,
NRC04F49R9TRF
39 0 R5, R6, R21 (OPT) RES., 100Ω, 1%, 1/16W, 0402 OPT
40 8 R7, R9, R10, R42, R50, R54, R63,
R70
RES., 0Ω, 1/16W, 0402 VISHAY, CRCW04020000Z0ED NIC, NRC04ZOTRF
YAGEO, RC0402JR-070RL
41 1 R12 RES., 330Ω, 1%, 1/16W, 0402, AEC-Q200 VISHAY, CRCW0402330RFKED
42 11 R16, R19, R23, R24, R25, R26,
R29, R30, R33, R34, R40
RES., 100Ω, 1%, 1/16W, 0402 VISHAY, CRCW0402100RFKED KOA SPEER,
RK73H1ETTP1000F PANASONIC, ERJ2RKF1000X
ROHM, MCR01MZPF1000
43 1 R18 RES., 75Ω, 1%, 1/16W, 0402, AEC-Q200 VISHAY, CRCW040275R0FKED
44 1 R22 RES., 30Ω, 1%, 1/16W, 0402, AEC-Q200 VISHAY, CRCW040230R0FKED
45 6 R27, R28, R31, R32, R41, R53 RES., 200k, 1%, 1/16W, 0402 VISHAY, CRCW0402200KFKED PANASONIC,
ERJ2RKF2003X YAGEO, RC0402FR-07200KL
46 5 R36, R37, R38, R57, R58 RES., 4.99k, 1%, 1/16W, 0402 VISHAY, CRCW04024K99FKED NIC,
NRC04F4991TRF YAGEO, RC0402FR-074K99L
47 4 R43, R62, R65, R75 RES., 619Ω, 1%, 1/16W, 0402, AEC-Q200 VISHAY, CRCW0402619RFKED
48 1 R44 RES., 33.2k, 1%, 1/4W, 0805, AEC-Q200 VISHAY, CRCW080533K2FKEA
49 1 R45 RES., 1.21k, 1%, 1/16W, 0402 VISHAY, CRCW04021K21FKED KOA SPEER,
RK73H1ETTP1211F ROHM, MCR01MZPF1211
50 1 R46 RES., 80.6k, 1%, 1/4W, 0805, AEC-Q200 VISHAY, CRCW080580K6FKEA
51 0 R47, R48, R49, R55, R56, RZ_A
(OPT)
RES., OPTION, 0603 OPT
52 2 R59, R61 RES., 49.9k, 1%, 1/8W, 0805, AEC-Q200 VISHAY, CRCW080549K9FKEA PANASONIC,
ERJ6ENF4992V
53 1 R60 RES., 698k, 1%, 1/8W, 0805, AEC-Q200 VISHAY, CRCW0805698KFKEA
54 2 R66, R67 RES., 0Ω, 3/4W, 2010, AEC-Q200 VISHAY, CRCW20100000Z0EF
55 2 R68, R74 RES., 1MΩ, 1%, 1/10W, 0603 VISHAY, CRCW06031M00FKEA NIC,
NRC06F1004TRF PANASONIC, ERJ3EKF1004V

10
Rev 0
DEMO MANUAL DC2609A
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
56 1 R71 RES., 18.2k, 1%, 1/10W, 0603 VISHAY, CRCW060318K2FKEA MOUSER ELECT.,
71-CRCW0603-18.2K-E3
57 1 R72 RES., 309k, 1%, 1/10W, 0603, AEC-Q200 VISHAY, CRCW0603309KFKEA
58 1 U1 IC., ULTRALOW JITTER PLL, QFN-52(UKG)
7 ×8
LINEAR TECH., LTC6952IUKG#PBF
LINEAR TECH., LTC6952IUKG#TRPBF
59 1 U2 OSC., 100MHz, 15pF, ±25ppm, 5 ×7.5mm
SMD, 3.3V, HCMOS,
CRYSTEK CORPORATION, CCHD-575-25-100.000
60 1 U3 IC., MEMORY, EEPROM, 2Kb (256 x 8),
TSSOP-8, 400kHz
MICROCHIP, 24LC025-I /ST
61 2 U4, U5 IC., TinyLogic UHS Dual Buffer, SC70-6 FAIRCHILD SEMI., NC7WZ17P6X
62 1 U6 IC., Dual Supply Receiver, SOT363-6
(SC-88), Single Bit, 3-State Outputs
NXP SEMI., 74LVC1T45GW
,125
63 3 U7, U8, U11 IC., PSRR RF LINEAR REGULATOR,
DFN-10(DD)
LINEAR TECH., LT3042EDD#PBF LINEAR TECH.,
LT3042EDD#TRPBF
64 1 U9 OSC. COAXIAL RESONATOR, 4000-
4000MHz, 10pF, 50Ω, 0.50” SQ SMD, VCO,
PS = 8V, MAX VTUNE = 4.7V
CRYSTEK, CVCO55CC-4000-4000
65 1 U10 IC., DUAL/QUAD LOW NOISE OP AMPS,
SO8
LINEAR TECH., LT1678IS8#PBF
LINEAR TECH., LT1678IS8#TRPBF
66 1 U12 IC., 3A, 3.3V, LDO REGULATOR, DDPAK5Q LINEAR TECH., LT1764A-3.3#PBF
LINEAR TECH., LT1764A-3.3#TRPBF
67 1 U13 IC,Silent Switcher 2 Synchronous,
LGA-16 (3 ×3)
LINEAR TECH., LT8609SIV#PBF
LINEAR TECH., LT8609SIV#TRPBF
68 7 JP1, JP2, JP3, JP6, JP6 PINS
1&2; JP4 AND JP7 PINS 2&3
CONN., SHUNT, FEMALE, 2 POS, 2mm Wurth Elektronik, 60800213421
69 4 MH1, MH2, MH3, MH4 STANDOFF, NYLON, SNAP-ON, 0.50" Wurth Elektronik, 702935000
PARTS LIST
SCHEMATIC DIAGRAM
Note: The buffers shown on sheet 2 of 4 of the schematic are used to protect the LTC6952 when connected to the DC2026 before the LTC6952 is powered
up. There is no need for such circuitry if the SPI bus is not active before powering up the LTC6952. The EEPROM is for identification and is not needed to
program the LTC6952.

11
Rev 0
DEMO MANUAL DC2609A
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D
C C
B B A A
3.3V SUPPLIES
PLACE ON TOP SIDE
PLACE ON BOTTOM SIDE
[2]
[2] [2]
ALL INPUT AND OUTPUT CONNECTIONS ARE SAME LENGTH, 50 OHM CONTROLLED IMPEDANCE, USING 20 MIL TRACES, 20 MIL GAP.
VCP+ SUPPLY
3.3V - 5V
(2)
(2)
(2)
(2) (2)
(3)
1. ALL RESISTORS AND CAPACITORS ARE 0402.
NOTES: UNLESS OTHERWISE SPECIFIED
[2]. REFER TO DEMO MANUAL.
(3)
[2]
[2]
OUT0+ OUT0- OUT1+ OUT1-
OUT2-
OUT3+
OUT3-
OUT4+
OUT4-
OUT5-
OUT6+
OUT6-
OUT7+ OUT7- OUT8+ OUT8- OUT9- OUT10+
EZS_SRQ-
EZS_SRQ+
VCO+
REF-
CP
REF+
OUT9+
OUT5+
OUT2+
VCO-
OUT10-
5V VCP+
VCP+
VEXT_REF
VEXT_REF
3.3V_2
3.3V_2
3.3V_2 3.3V_2
3.3V_2
3.3V_2 3.3V_2 3.3V_2
3.3V_2
3.3V_2 3.3V_2 3.3V_2
3.3V_2
3.3V_2
3.3V
3.3V
3.3V
SD
CS
SDI
SDO
SCLK CP
RFOUT
REVISION HISTORY
DESCRIPTION DATEAPPROVEDECO REV
CHRIS P.PRODUCTION
__ 71-31-702
REVISION HISTORY
DESCRIPTION DATEAPPROVEDECO REV
CHRIS P.PRODUCTION
__ 71-31-702
REVISION HISTORY
DESCRIPTION DATEAPPROVEDECO REV
CHRIS P.PRODUCTION
__ 71-31-702
SIZE DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
1 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
1 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
1 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
J10
SMA
OUT0-
C39
0.01uF
0201
C81
0.1uF
R5 100 OPT
R6 100 OPT
J13
SMA
OUT2+
OPT
J21
SMA
OUT6+
OPT
C62 0.01uF 0201
J5
SMA
OUT8-
R4 49.9
C7 0.01uF
C23 0.1uF
J4
SMA
OUT9+
C18 0.1uF
C1 1uF
R19 100
U1
LTC6952
VOUT+ 32
OUT1+ 31
OUT1- 30
VOUT+ 29
OUT2+ 28
OUT2- 27
VOUT+
26
OUT3+
25
OUT3-
24
VOUT+
23
VOUT+
14
CS
1
VD+
2
OUT10-
3
OUT10+
4
VOUT+
5
OUT9-
6
OUT9+
7
VOUT+
8
OUT8-
9
OUT8+
10
VOUT+
11
OUT7-
12
VVCO+ 39
VCO- 38
OUT7+
13
VOUT+
20
VOUT+
17
OUT5+
19
OUT6+
16
OUT4-
21
OUT4+
22
OUT5-
18
VCO+ 37
NC 36
OUT0+ 34
VOUT+ 35
OUT6-
15
OUT0- 33
SD 40
GND 41
VCP+42
CP 43
VREF+ 44
REF+ 45
REF- 46
EZS_SRQ+ 47
EZS_SRQ- 48
STAT 49
SCLK 50
SDO51
SDI52
GND 53
C61 1uF
C10
0.01uF
0201
J14
SMA
OUT2-
OPT
C2
0.022uF
0603
J17
SMA
OUT4+
JP1
HD1X3-079
LED
NC
STAT
1 3
2
C17 0.1uF
C27 OPT
C46
0.01uF
0201
E4
REF+
EN-XO
R12 330
C14
OPT
J3
SMA
OUT9-
C5 0.1uF
R24 100
J25
SMA
REF-
C44
0.01uF
0201
C42
0.01uF
0201
C37 OPT
R20 OPT
J18
SMA
OUT4-
R50
0
C21 0.1uF
E6
GND
R15 OPT
C9 1uF
R25 100
J20
SMA
OUT5-
C33 OPT
J19
SMA
OUT5+
C22 0.1uF
J28
SMA
VCO-
C8 OPT
C45
0.01uF
0201
R3 OPT
R23 100
E5
GND
C30 0.1uF C31
0.1uF
J27
SMA
EZS_SRQ+
R17 OPT
C60 1uF
J8
SMA
OUT7+
OPT
E1
EZS_SRQ+
C49
0.01uF
0201
J6
SMA
OUT8+
C35 OPT
U2
CCHD-575-25-100
VTUNE 1
EN 2
GND 3
OUT+
4
OUT-
5
VCC
6
C54 1uF
R8 OPT
J15
SMA
OUT3+
OPT
C4 1uF
J24
SMA
REF+
C12 OPT
C38
0.01uF
0201
J11
SMA
OUT1+
R9 0
R53 200k
C36 OPT
C6 1uF
C28 OPT
C56 1uF
E9
GND
J1
SMA
OUT10-
OPT
C55 1uF
C43
0.01uF
0201
C50 1uF
R18 75
C15 OPT
J9
SMA
OUT0+
C58 1uF
J29
SMA
VCO+
C59 1uF
J22
SMA
OUT6-
OPT
C57 1uF
C25 OPT
C48
0.01uF
0201
R10
0
C24 0.1uF
J12
SMA
OUT1-
C41
0.01uF
0201
C16 OPT
R26 100
R21 100 OPT
C34 OPT
C112 1uF
C20 0.1uF
J26
SMA
EZS_SRQ-
E3
EZS_SRQ-
E2
REF-
R7 0
C83 OPT
C51 1uF C52
1uF C53
1uF
R13 OPT
R22 30
C82 OPT
C26 0.1uF
C40
0.01uF
0201
J16
SMA
OUT3-
OPT
R16 100
E7
GND
J7
SMA
OUT7-
OPT
C11 0.1uF
E8
GND
C29 0.1uF C32
0.1uF
R14 OPT
C47
0.01uF
0201
R11
OPT
J2
SMA
OUT10+
OPT
D1 RED STAT
2 1
C19 0.1uF

12
Rev 0
DEMO MANUAL DC2609A
SCHEMATIC DIAGRAM
5 5
4
4
3 3
2 2
1 1
D D CC B B A A
EEPROM FOR BOARD IDENTIFICATION
DC2026 (DC590) SPI INTERFACE
(1) (1)
(1) (1) (1)
3.3V
3.3V
3.3V
3.3V
3.3V
CS
SCLK SDI
SDO SD
SIZE
DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
2 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE
DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
2 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE
DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
2 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
R42
0
R28 200k
EEGND
R27 200k
R39 0 0603
R30 100
R31 200k
R40 100
SD
GND VCC
U5
NC7WZ17P6X
16
4
3
5
2
R33 100
GND VCC
U4
NC7WZ17P6X
16
4
3
52
C64 0.1uF
V+DIG
C63 0.1uF
R29 100
R37 4.99k
SCLK
C65 0.1uF
R41 200k
R32 200k
SDI SDO
WP
R38 4.99k
C67 0.1uF
CS
C66 0.1uF
E10
CS
R34 100
R36
4.99k
R35
OPT
J23
HD2X7-079-MOLEX
MOSI/SDA 7
EESDA 9
V+ 1
5V 2
CS 6
SCK/SCL 4
EEVCC 10
MISO 5
EESCL 11
EEGND 12
AUX 14
GND
3
GND
13
GND
8
GND DIR
VCC(A) VCC(B)
U6
74LVC1T45GW
1 6
43 52
EEPROM
ARRAY
U3
24LC025-I /ST
SDA
5
VCC 8
A0
1A1
2A2 3
GND
4
WP
7
SCL
6
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com

13
Rev 0
DEMO MANUAL DC2609A
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D
C C
B B A A
SUNCON 63E22BS
SUNCON 63E10BS SUNCON 63E10BS
POWER SUPPLIES
3.3V EXTREF 8V EXTVCO
5V LTC6952 VCP+, 200mA LDO
SUNCON 63E10BS
3.3V LTC6952 VOUT+ VDIG+ 2A SILENT SWITCHER 3.3V LTC6952 3A LDO OPTION
JP6
3.3V SW & LDO (LOW POWER)
3.3V LDO ONLY
SUNCON 63E22BS
JP7
1-2
2-3
1-2 1-2
SUNCON 63E10BS
SUNCON 63E22BS
9V-12V
4V-6V
VEXT_REF
VEXT_VCO
5V
3.3V_2
3.3V
SIZE DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
3 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
3 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
3 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
R66 0 2010
D3
GREEN
VCO
2 1
R73
49.9
C98 4.7uF 1206 50V
D5
GREEN
3.3V_LDO
2 1
+
C74 10uF 63V
J33
GND
BANANA JACK
C111
0.1uF
JP3
VEXT_VCO
ON
OFF
HD1X3-079
1
3
2
FB2
330 OHMS
FBMH1608HL
C71 0.1uF 0603
C72 4.7uF 1206 25V
U12
LT1764AEQ-3.3
OUT 4
SENSE 5
SHDN
1
IN
2
GND
3
GND
6
GND
+
C106 22uF 63V
C96 4.7uF 1206 25V
R45 1.21k
R69 OPT
R75 619
JP7
HD1X3-079
LT8609 LDO
SW
1
3
2
C78 4.7uF 1206 25V
R71 0603 18.2k
C100
10uF 1206
R63 0
J30
9V - 12V
BANANA JACK
D2
GREEN
REF
2 1
E14
4V - 6V
C109 4.7uF 0805 16V C101 0.1uF
+
C99 330uF 10V 7343
R68 0603 1M
R43 619
+
C69 10uF 63V
C13 10pF
R72 0603 309k
+
C91 22uF 63V
C94 0.1uF 0603
JP4
HD1X3-079
EN
GND
LT8609
1 3
2
R62 619
R70 0
FB3
330 OHMS
FBMH1608HL
FB4
220 OHMS
MPZ2012
C102 1uF 0805 50V
R44 33.2k 0805
C75 4.7uF 1206 50V
L2
2.2uH
XFL4020
+
C97 10uF 63V
U13
LT8609SIV
GND
20
VIN
9
VIN
10
VCC
2
GND
14 GND
8
EP
17
RT
1NC 7
GND
21
SYNC
16 PG 12
GND
19
GND
3
GND
4
GND
18
FB 13
EN
11
SW 6
TR/SS
15
SW 5
R59 49.9k 0805
C103 0.1uF 0603
C76 0.1uF 0603
U7
LT3042EDD
GND 8
PGFB 6
SET 7
OUTS 9
OUT 10
EP
11
EN/UV
3
ILIM
5
PG
4
IN
2
IN
1
R74
0603
1M
C105 4.7uF 1206 50V
+
C68 22uF 63V
JP5
HD1X3-079
5V NC
5V
1 3 2
C107 4.7uF 1206 50V
C104 4.7uF 1206 50V
C77 4.7uF 1206 25V
R65 619
C95 4.7uF 1206 25V
C73 4.7uF 1206 25V
JP2
VEXT_REF
ON
OFF
HD1X3-079
1
3 2
J32
4V - 6V
BANANA JACK
SYNC
C70 4.7uF 1206 50V
+
C92 10uF 63V
U11
LT3042EDD
GND 8
PGFB 6
SET 7
OUTS 9
OUT 10
EP
11
EN/UV
3
ILIM
5
PG
4
IN
2
IN
1
R67
0
2010
JP6
HD1X3-079
3.3V NC
LDO
1 3
2
FB1
330 OHMS
FBMH1608HL
R60 698k 0805
C108 47uF 1206 10V
E11
9V - 12V
R64 OPT
D6
GREEN
3.3V_SW
2 1
C93 4.7uF 1206 50V
FB5
220 OHMS
MPZ2012
R46 80.6k 0805
D4
GREEN
5V
2 1
R61 49.9k 0805
E15
GND
U8
LT3042EDD
GND 8
PGFB 6
SET 7
OUTS 9
OUT 10
EP
11
EN/UV
3
ILIM
5
PG
4
IN
2
IN
1
C110 1uF
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com

14
Rev 0
DEMO MANUAL DC2609A
SCHEMATIC DIAGRAM
5 5
4
4
3 3
2 2
1 1
D D CC B B A A
(1)
(1)
ACTIVE LOOP FILTER
VTUNE
5V
VEXT_VCO
CP
RFOUT
SIZE
DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
4 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE
DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
4 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
SIZE
DATE:
.VER.ONCI
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
2
DEMO CIRCUIT 2609A
Thursday, July 13, 2017
4 4
ULTRALOW JITTER PLL WITH ELEVEN PROGRAMMABLE OUTPUTS
N/A
LTC6952IUKG
KIM T.
CHRIS P.
AND JESD204B SUPPORT
E12
CP
+ -
U10B
LT1678IS8
5
67
84
R49 0603 OPT
RZ_A
OPT 0603
CI2_A
OPT
1206
CI2_P
1uF 1206
R55 OPT 0603
R54
0
R51
0
0603
E13
V+OA
+ -
U10A
LT1678IS8
3
21
84
C88 0.1uF
C3 OPT 0603
+
C80
47uF 35V
7361
R56 0603 OPT
RZ_P 48.7 0603
R2
0
0603
C85 OPT
CI1_P 0.68uF 0603
L1
0
0805
R1
48.7 0603
+
C87 47uF 35V 7361
+
C90 47uF 35V 7361
CI1_A
OPT
0603
C86 0.1uF 0603
U9
CVCO55CC-4000-4000
GND
1
V-TUNE
2
GND
3
GND
4
GND
5
GND
6
GND
7
GND
8
GND 9
RFOUT 10
GND 11
GND 12
GND 13
VCC 14
GND 15
GND 16
C89 0.1uF R58
4.99K
J31
SMA
VTUNE
R48 0603 OPT
R57 4.99K
R52
0
0603
C84 OPT
R47 OPT 0603
C79 0.1uF
0603
CP_P
0.033uF
0603
CP_A
OPT 0603
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com
Fax: [phone] Milpitas, CA 95035
Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
www.linear.com

15
Rev 0
DEMO MANUAL DC2609A
Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications
subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
LAYOUT TOP LAYER

16
Rev 0
DEMO MANUAL DC2609A
 ANALOG DEVICES, INC. 2018
11/18
www.analog.com
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and
conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation
Board until you have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”)
and Analog Devices, Inc. (“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to
Customer a free, limited, personal, temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and
agrees that the Evaluation Board is provided for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted
is expressly made subject to the following additional limitations:Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board;and (ii) permit any Third
Party to access the Evaluation Board. As used herein, the term “Third Party”includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is
NOT sold to Customer;all rights not expressly granted herein, including ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all
be considered the confidential and proprietary information of ADI. Customer may not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of
use of the Evaluation Board or termination of this Agreement, Customer agrees to promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile
or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited
to soldering or any other activity that affects the material content of the Evaluation Board. Modifications to the Evaluation Board must comply with applicable law, including but not limited to the RoHS
Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF
LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS”AND ADI MAKES NO WARRANTIES OR REPRESENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICALLY
DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS
LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF THE EVALUATION BOARD, INCLUDING
BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL. ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE AMOUNT OF ONE
HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable United States
federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of Massachusetts
(excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby submits
to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
