EVAL-AD5678DBZ User Guide
UG-987
One Technology Way •P. O. Box 9106 •Norwood, MA 02062-9106, U.S.A. •Tel: [phone] •Fax: [phone] •www.analog.com
Evaluation Board for the AD5678 4 × 12-Bit and 4 × 16-Bit, Octal-Channel,
Voltage Output DAC
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS. Rev. A | Page 1 of 13
FEATURES
Full featured evaluation board in conjunction with the
nanoDAC® motherboard (EVAL-MBnanoDAC-SDZ)
On-board references
Various link options
PC control in conjunction with Analog Devices, Inc., system
demonstration platform (SDP)
PACKAGE CONTENTS
EVAL-AD5678DBZ evaluation board
EVAL-MBnanoDAC-SDZ motherboard
SOFTWARE NEEDED
EVAL-AD5678DBZ evaluation software
HARDWARE NEEDED
EVAL-SDP-CB1Z (SDP-B) board, must be purchased
separately
DOCUMENTS NEEDED
Electronic version of the AD5678 data sheet
Electronic version of the EVAL-AD5678DBZ user guide
GENERAL DESCRIPTION
This user guide details the operation of the evaluation board for
the AD5678 octal channel, voltage output, digital-to-analog
converter (DAC).
The evaluation board is designed to help users quickly prototype
new AD5678 circuits and reduce design time. The AD5678
operates from a single 2.7 V to 5.5 V supply.
For full data, see the AD5678 data sheet, which must be consulted
in conjunction with this user guide when using the evaluation
board.
The evaluation board interfaces to the USB port of a PC via the
SDP-B board. Software is available for download from the EVAL-
AD5678DBZ evaluation board page to allow the user to program
the AD5678.
EVAL-AD5678DBZ, EVAL-MBnanoDAC-SDZ, AND SDP-B BOARDS
14523-001
Figure 1.

UG-987 EVAL-AD5678DBZ User Guide
Rev. A | Page 2 of 13
TABLE OF CONTENTS
Features .............................................................................................. 1
Package Contents.............................................................................. 1
Software Needed ............................................................................... 1
Hardware Needed ............................................................................. 1
Documents Needed.......................................................................... 1
General Description ......................................................................... 1
EVAL-AD5678DBZ, EVAL-MBnanoDAC-SDZ, and SDP-B
Boards................................................................................................. 1
Revision History ............................................................................... 2
Evaluation Board Hardware ............................................................ 3
Motherboard Power Supplies...................................................... 3
Link Options ..................................................................................3
Evaluation Board Software Quick Start Procedures.....................4
Installing the Software ..................................................................4
Running the Software ...................................................................4
Software Operation .......................................................................5
Evaluation Board Schematics and Artwork...................................7
EVAL-MBnanoDAC-SDZ Motherboard ...................................7
EVAL-AD5678DBZ Daughter Board ...................................... 10
Ordering Information.................................................................... 12
Bill of Materials........................................................................... 12
REVISION HISTORY
11/2017—Rev. 0 to Rev. A
Change to Table 5 ........................................................................... 12
3/2017—Revision 0: Initial Version

EVAL-AD5678DBZ User Guide UG-987
Rev. A | Page 3 of 13
EVALUATION BOARD HARDWARE
MOTHERBOARD POWER SUPPLIES
The EVAL-MBnanoDAC-SDZ motherboard supports single
and dual power supplies.
The EVAL-AD5678DBZ evaluation board can be powered either
from the SDP port or externally by the J5 and J6 connectors, as
described in Table 1.
Both the AGND and DGND inputs are provided on the board.
The AGND and DGND planes are connected at one location on
the EVAL-MBnanoDAC-SDZ. It is recommended that AGND
and DGND not be connected elsewhere in the system to avoid
ground loop problems.
All supplies are decoupled to ground with 10 µF tantalum and
0.1 µF ceramic capacitors.
Table 1. Power Supply Connectors
Connector No. Label Voltage
J5, Pin 1 (J5-1)
VDD
Analog positive power supply, V
DD
.
Single supply 5 V, dual supply 5 V.
J5, Pin 2 (J5-2) AGND Analog ground.
J5, Pin 3 (J5-3) VSS Analog negative power supply, VSS.
Dual supply −5 V.
J6, Pin 1 (J6-1) VLOGIC Digital supply from 1.8 V to VDD.
J6, Pin 2 (J6-2)
DGND
Digital ground.
LINK OPTIONS
A number of link options are incorporated in the E VA L -
MBnanoDAC-SDZ and must be set for the required operating
conditions before using the board. Table 2 describes the positions of
the links to control the evaluation board via the SDP-B board
using a PC and external power supplies. The functions of these
link options are described in detail in Table 3. The positions listed
in Table 2 and Table 3 match the evaluation board imprints (see
Figure 12).
Table 2. Link Options Setup for SDP-B Control (Default)
Link No. Position
REF1 EXT
REF2 EXT
REF3 EXT
REF4
EXT
LK5 C
LK6 3.3V
LK7 B
Table 3. Link Functions
Link Number Function
REF1 to REF4 These links select the reference source.
Position EXT selects an off-board voltage reference via the appropriate EXT_REF_x connector.
Position VDD selects VDD as the reference source.
Position 4.096V selects the on-board 4.096 V reference as the reference source.
Position 2.5V selects the on-board 2.5 V reference as the reference source.
Position 5V selects the on-board 5 V reference as the reference source, V
DD
= 5.5 V.
LK5 This link selects the positive DAC analog voltage source.
Position A selects the internal voltage source from the SDP-B board.
Position B selects the internal voltage source 3.3 V from the ADP121 on the motherboard.
Position C selects an external supply voltage, VDD.
LK6
This link selects the VLOGIC voltage source.
Position 3.3V selects the digital voltage source from the SDP-B board, 3.3 V.
Position VLOGIC selects an external digital supply voltage, VLOGIC.
LK7
This link selects the negative DAC analog voltage source.
Position A selects VSS.
Position B selects AGND.

UG-987 EVAL-AD5678DBZ User Guide
Rev. A | Page 4 of 13
10954-003
EVALUATION BOARD SOFTWARE QUICK START PROCEDURES
INSTALLING THE SOFTWARE
The EVAL-AD5678DBZ evaluation software is compatible with
Windows® Vista (64-bit/32-bit), and Windows 7 (64-bit/32-bit).
The software must be installed before connecting the SDP-B board
to the USB port of the PC to ensure that the SDP-B board is
recognized by the PC.
To install the software, take the following steps:
1. Start the Windows operating system. Download the
installation software from the EVAL-AD5678DBZ
evaluation board page.
2. Run the setup.exe file from the installer folder if it does not
open automatically.
3. After installation is completed, power up the evaluation
board as described in the Motherboard Power Supplies
section.
4. Connect the evaluation board to the SDP-B board and the
SDP-B board into the PC using the USB cable included in
the evaluation kit.
5. When the software detects the evaluation board, click
through any dialog boxes that appear to finalize the
installation.
RUNNING THE SOFTWARE
To run the program, take the following steps:
1. Connect the evaluation board to the SDP-B board and
connect the USB cable between the SDP-B board and the PC.
2. Power up the evaluation board as described in the
Motherboard Power Supplies section.
3. From the Start menu, click All Programs, Analog Devices,
AD5678 Evaluation Software.
4. If the SDP-B board is not connected to the USB port when
the software is launched, a connectivity error displays (see
Figure 2). Connect the evaluation board to the USB port of
the PC and wait a few seconds. When the SDP-B board is
detected, the display is updated (see Figure 3).
Alternatively, the software can be used without an evaluation
board. The software runs in simulation mode displaying expected
outputs based on the input data. The main window of the AD5678
evaluation software then opens, as shown in Figure 4.
14523-002
Figure 2. Connectivity Error
14523-003
Figure 3. Hardware Select

EVAL-AD5678DBZ User Guide UG-987
Rev. A | Page 5 of 13
14523-004
Figure 4. AD5678 Evaluation Software Main Window
SOFTWARE OPERATION
The software for the AD5678 allows the user to program values
to the DAC REGISTER of the DAC.
Write to Input Register
Click Write to Input Register to load the code of the input data
control to the input register of the selected DAC in the DAC
selection box.
Update DAC Register from Input Register
Click Update DAC Register from Input Register to copy the
value in the input register to the corresponding DAC register.
The DAC outputs are automatically updated with the appropriate
voltage.
Write to Input and DAC Registers
Click Write to Input and DAC Registers to load the code of the
input data control to the input register and DAC register of the
selected DAC. The DAC outputs are automatically updated with
the appropriate voltage.
LDAC Control
Click Pulse LDAC to bring the LDAC pin low and then back
high. This action copies the data from the input register to the
DAC register, and the output updates accordingly.
Alternatively, the LDAC pin can be set to logic high or logic low
by selecting the corresponding LDAC HIGH or LDAC LOW
option.
Power-Down Control
Each DAC can be powered down individually. Click the POWER-
DOWN LOGIC blue progressive disclosure option to access the
Powerdown Configuration window, as shown in Figure 5. The
selected DAC can operate in normal operation or one of the three
different power-down, pull-down termination options. When the
power-down setting for each DAC is selected, click OK to write
the appropriate values to the AD5678.
14523-005
Figure 5. Powerdown Configuration Window

UG-987 EVAL-AD5678DBZ User Guide
Rev. A | Page 6 of 13
Reference Control
The DAC has an on-chip reference with an internal gain of 2.
Click the blue progressive option on the REFERENCE INPUT
block to access the Reference Input window, as shown in Figure 6,
which allows the user to select between the on-chip reference or
external reference voltage.
14523-006
Figure 6. Reference Input Window
When using an external reference, write the actual value of the
reference voltage in the External Reference (V) input box to make
sure that the software reflects the voltage output correctly.
LDAC Mask Register
Each DAC can be configured to respond to or override the LDAC
pin settings in the LDAC control. Click the blue progressive
disclosure option on the INTERFACE LOGIC block to access
the LDAC Register window, as shown in Figure 7. When the
LDAC selections are completed, click OK to write the appropriate
values to the AD5678. The LDAC REGISTER indicator lights
up accordingly when an LDAC mask of a DAC is enabled.
14523-007
Figure 7. LDAC Register Window

EVAL-AD5678DBZ User Guide UG-987
Rev. A | Page 7 of 13
EVALUATION BOARD SCHEMATICS AND ARTWORK
EVAL-MBnanoDAC-SDZ MOTHERBOARD
EXT_VDD
VLOGIC
GND
EXT_VSS
SDP
STANDARD
CONNECTOR
PARALLEL
PORT
SPORT
SPI
I2C
GENERAL
INPUT/OUTPUT
TIMERS
*NC ON BLACKFIN SDP 120
NC
119
NC
118
GND
117
GND
116
VIO(+3.3V)
115
GND
114
PAR_D22*
113
PAR_D20*
112
PAR_D18*
111
PAR_D16*
110
PAR_D15
109
GND
108
PAR_D12
107
PAR_D10
106
PAR_D8
105
PAR_D6
104
GND
103
PAR_D4
102
PAR_D2
101
PAR_D0
100
PAR_WR
99
PAR_INT
98
GND
97
PAR_A2
96
PAR_A0
95
PAR_FS2
94
PAR_CLK
93
GND
92
SPORT_RSCLK
91
SPORT_DR0
90
SPORT_RFS
89
SPORT_TFS
88
SPORT_DT0
87
SPORT_TSCLK
86
GND
85
SPI_SEL_A
84
SPI_MOSI
83
SPI_MISO
82
SPI_CLK
81
GND
80
SDA_0
79
SCL_0
78
GPIO1
77
GPIO3
76
GPIO5
75
GND
74
GPIO7
73
TMR_B
72
TMR_D
71
CLK_OUT
70
NC
69
GND
68
NC
67
NC
66
NC
65
WAKE
64
SLEEP
63
GND
62
UART_TX
61
BMODE1
60 RESET_IN
59 UART_RX
58 GND
57 RESET_OUT
56 EEPROM_A0
55 NC
54 NC
53 NC
52 GND
51 NC
50 NC
49 TMR_C*
48 TMR_A
47 GPIO6
46 GND
45 GPIO4
44 GPIO2
43 GPIO0
42 SCL_1
41 SDA_1
40 GND
39 SPI_SEL1/SPI_SS
38 SPI_SEL_C
37 SPI_SEL_B
36 GND
35 SPORT_INT
34 SPI_D3*
33 SPI_D2*
32 SPORT_DT1
31 SPORT_DR1
30 SPORT1_TDV*
29 SPORT0_TDV*
28 GND
27 PAR_FS1
26 PAR_FS3
25 PAR_A1
24 PAR_A3
23 GND
22 PAR_CS
21 PAR_RD
20 PAR_D1
19 PAR_D3
18 PAR_D5
17 GND
16 PAR_D7
15 PAR_D9
14 PAR_D11
13 PAR_D13
12 PAR_D14
11 GND
10 PAR_D17*
9PAR_D19*
8PAR_D21*
7PAR_D23*
6GND
5USB_VBUS
4GND
3GND
2NC
1VIN
J10
1A0
2A1
3A2
4VSS
8
VCC 7
WP 6
SCL 5
SDA
U3
24LC32
R2
100kΩ
R3
100kΩ
R4
DNP
DGND AGND
L1
BEAD
R1
1.6Ω
+
C11
4.7µF
C10
0.1µF
+C7
10µF
1VIN
2GND
3EN 4
NC
5
VOUT
U2
ADP121-AUJZ33
C3
1µF C4
1µF
C
B
A
LK5
J6-1
J6-2
C5
0.1µF
+
C6
10µF
A
B
LK6
J5-1
J5-2
J5-3
C2
0.1µF +
C1
10µF
A
B
LK7
R7 100Ω
R5 100Ω
R6 100Ω
R8 100Ω
R9 100Ω
R10 100Ω
R11 100Ω
R12 100Ω
R13 100Ω
R14 100Ω
C8
0.1µF
+C9
10µF
R15
100Ω
R16
DNP
PD
GAIN
SCL
SDA
CS WR
DB0
DB2
DB4
DB6
DB8
DB10
DB1
DB3
DB5
DB7
DB9
DB11
+3.3V
+3.3V
DGND
+5V
USB_VBUS
USB_VBUS
+3.3V
VDD
+3.3V
DGND
VLOGIC
DGND
+3.3V
DGNDDGND
VSS
+5V
CLR
LDAC
SCLK
SDO
SDIN
SYNC
EXT_VDD
EXT_VDD
+5V DGND
DGND
DGND
DGND
DGND
DGND
14523-008
Figure 8. EVAL-MBnanoDAC-SDZ Motherboard SDP-B Connector and Power Supply

UG-987 EVAL-AD5678DBZ User Guide
Rev. A | Page 8 of 13
EX_REF_1 EX_REF_2 EX_REF_3 EX_REF_4
VREF_1 VREF_2 VREF_3 VREF_4
D
C
A
B
E
REF3
D
C
A
B
E
REF4
D
C
A
B
E
REF1
D
C
A
B
E
REF2
+5VREF
+2_5VREF
+4_096VREF
VREF1
+5VREF
+2_5VREF
+4_096VREF
VREF2
+5VREF
+2_5VREF
+4_096VREF
VREF3
+5VREF
+2_5VREF
+4_096VREF
VREF4
VDD VDD VDD VDD
14523-009
+2.5V +4.096V
C16
1µF
C15
1µF
6
OUTPUT
2VS
3SLEEP
4
GND
U6
REF198
C17
1µF
+5V
+2.5V +4.096V
2VIN
5TRIM
6
VOUT
4
GND
U4
ADR445ARMZ
2VIN
4
GND
5
TRIM
7COMP
6
VOUT
U5
ADR431BRZ
+5VREF+2_5VREF +4_096VREF VDD VDD VDD
Figure 9. EVAL-MBnanoDAC-SDZ Motherboard Reference Voltage Selector Circuit
DAUGHTER BOARD CONNECTOR
SPI PMOD CONNNECTOR GPIO PMOD CONNNECTOR
I2C PMOD CONNNECTOR
1
3
5
7
9
2
4
6
8
10
J2
1 2
3 4
5 6
7 8
910
11 12
13 14
15 16
J1
SDIN SDO SCLK SYNC SCL LDAC CLR PD GAIN SDA
1 2
3 4
5 6
7 8
J9
J8-1
J8-2
J8-3
J8-4
J8-5
J8-6
J7-1
J7-2
J7-3
J7-4
J7-5
J7-6
J3-1
J3-2
J3-3
J3-4 J3-5
J3-6
J4-1
J4-2
J4-3
J4-4
J4-5
J4-6
J4-7
J4-8
VDD
VREF1 VREF2 VREF3 VREF4
VLOGIC
SDASCL
SYNC
SCLK
SDO
SDIN LDAC
CLR
PD
GAIN
DB6
DB7
DB8
DB9
DB0
DB1
DB2
DB3
VOUT_0
VOUT_1
VOUT_2
VOUT_3
VOUT_4
VOUT_5
VOUT_6
VOUT_7
SCL
SDA
DGND
VLOGIC
SCL
SDA
DGND
VLOGIC
SYNC
SDO
SDIN
SCLK
DGND
VLOGIC
PD
GAIN
DGND
LDAC
CLR
VLOGIC
DGND
CS WR
DB11 DB5
DB10 DB4
AGND
14523-010
Figure 10. EVAL-MBnanoDAC-SDZ Motherboard Connectors to Daughter Board and Serial Interface
VOUT_0
VOUT_1
VOUT_2
VOUT_3
VOUT_4
VOUT_5
VOUT_6
VOUT_7
+
-
3
21
U10-A
AD8608ARUZ
+
–
5
67
U10-B
AD8608ARUZ
+
–
10
98
U10-C
AD8608ARUZ
+
–
12
13 14
U10-D
AD8608ARUZ
3+
2–
1
U7-A
AD8616ARZ
5+
6–
7
U7-B
AD8616ARZ
8
V+
4
V–
U7-C AD8616ARZ
2–
3+6
OP
4
V–
7
V+
U11
AD8655
2–
3+6
OP
4
V–
7
V+
U12
AD8655
VOUT_0
VOUT_1
VOUT_2
VOUT_3
VOUT_4
VOUT_5
VOUT_6
VOUT_7
VDD
VSS
VDD
VDD
VSS
VSS
14523-011
Figure 11. EVAL-MBnanoDAC-SDZ Motherboard Output Amplifier Circuit

EVAL-AD5678DBZ User Guide UG-987
Rev. A | Page 9 of 13
14523-012
Figure 12. EVAL-MBnanoDAC-SDZ Motherboard Component Placement
14523-013
Figure 13. EVAL-MBnanoDAC-SDZ Motherboard Top Side Routing

UG-987 EVAL-AD5678DBZ User Guide
Rev. A | Page 10 of 13
14523-014
Figure 14. EVAL-MBnanoDAC-SDZ Motherboard Bottom Side Routing
EVAL-AD5678DBZ DAUGHTER BOARD
3
VDD
14 GND
4
VOUT_A 13
VOUT_B 5
VOUT_C 12
VOUT_D 6
VOUT_E 11
VOUT_F 7
VOUT_G 10
VOUT_H
15 DIN
16 SCLK
2SYNC
9CLR
1LDAC
8
VREFIN/OUT
U1
AD5678BRUZ-2
R1 DNP
A
R2 DNP
B
R3 DNP
C
R4 DNP
D
R5 DNP
E
R6 DNP
F
R7 DNP
G
R8 DNP
H
C1
DNP
C2
DNP
C3
DNP
C4
DNP
C5
DNP
C6
DNP
C7
DNP
C8
DNP
C9
0.1µF
+C10
10µF
1
3
5
7
9
2
4
6
8
10
J2
J3-1
J3-2
J3-3
J3-4
J3-5
J3-6
J4-1
J4-2
J4-3
J4-4
J4-5
J4-6
J4-7
J4-8
12
3 4
5 6
7 8
910
11 12
13 14
15 16
J1
SDIN
SCLK
SYNC
VOUT_0
VOUT_1
VOUT_2
VOUT_3
VOUT_4
VOUT_5
VOUT_6
VOUT_7
VDD
VREF1
LDAC
CLR
VDD
VREF1 VREF2 VREF3 VREF4
VLOGIC
SDASCL
SYNC
SCLK
SDO
SDIN LDAC
CLR
PD
GAIN
VOUT_0
VOUT_1
VOUT_2
VOUT_3
VOUT_4
VOUT_5
VOUT_6
VOUT_7
DB6
DB7
DB8
DB9
DB0
DB1
DB2
DB3
DGND
CS WR
DB11 DB5
DB10 DB4
AGND
14523-015
Figure 15. EVAL-AD5678DBZ Daughter Board Schematics

EVAL-AD5678DBZ User Guide UG-987
Rev. A | Page 11 of 13
14523-0176
Figure 16. EVAL-AD5678DBZ Daughter Board Component Placement
14523-018
Figure 17. EVAL-AD5678DBZ Daughter Board Top Side Routing
14523-017
Figure 18. EVAL-AD5678DBZDaughter Board Bottom Side Routing

UG-987 EVAL-AD5678DBZ User Guide
Rev. A | Page 12 of 13
ORDERING INFORMATION
BILL OF MATERIALS
Table 4. EVAL-MBnanoDAC-SDZ Motherboard
Qty Reference Designator Description Supplier/Part Number1, 2
4 C1, C6, C7, C9 6.3 V, tantalum capacitor (Case A), 10 µF, ±20% FEC/1190107
7 C2, C5, C8, C10, C15, C16, C17 50 V, X7R ceramic capacitor, 0.1 µF, ±10% FEC/1759122
2 C3, C4 10 V, X5R, ceramic capacitor, 1 μF, ±10% GRM188R61A105KA61D
1 C11 6.3 V, tantalum capacitor (Case A), 4.7 µF, ±20% FEC/1432350
4 EXT_REF_1 to EXT_REF_4 Straight printed circuit board (PCB) mount SMB jack, 50 Ω FEC/1206013
1 J1 Header, 2.54 mm, 2 × 8-way FEC/2308428
1 J2 Header, 2.54 mm, 2 × 5-way FEC/9689583
3 J3, J7, J8 Header, 2.54 mm, 1 × 6-way FEC/9689508
1 J4 Header, 2.54 mm, 1 × 8-way FEC/1766172
1 J5 3-pin terminal block FEC/1667472
1 J6 2-pin terminal block FEC/151789
1 J9 Header, 2.54 mm, 2 × 4-way FEC/1667509
1 J10 120-way connector FEC/1324660
1 L1 Inductor, SMD, 600 Ω FEC/9526862
1 LK5 6-pin (3 × 2) 0.1", header and shorting block FEC/148-535 and 150-411 (36-pin strip)
2
LK6, LK7
4-pin (2 × 2) 0.1", header and shorting block
FEC/148-535 and 150-411 (36-pin strip)
4 REF1 to REF4 10-pin (5 × 2) 0.1", header and shorting block FEC/1022227 and 150-411
1 R1 Resistor, surge, 1.6 Ω, 1%, 0603 FEC/1627674
2 R2, R3 SMD resistor, 100 kΩ, 1%, 0603 FEC/9330402
11 R5 to R15 SMD resistor, 100 Ω, 1%, 0603 FEC/9330364
1 U2 3.3 V linear regulator Analog Devices/ADP121-AUJZ33R7
1 U3 32 kb I2C serial EEPROM FEC/1331330
1 U4 5 V reference, MSOP Analog Devices/ADR445ARMZ
1 U5 Ultralow noise XFET voltage reference Analog Devices/ADR431BRZ
1 U6 4.096 V reference Analog Devices/REF198ESZ
1 U7 Dual op amp Analog Devices/AD8616ARZ
1
U10
Quad op amp
Analog Devices/AD8608ARMZ
2 U11, U12 Op amp Analog Devices/AD8655ARMZ
1FEC refers to Farnell Electronic Component Distributors.
2GRM refers to Murata Manufacturing Company.
Table 5. EVAL-AD5678DBZ Daughter Board
Qty
Reference Designator
Description
Supplier/Part Number
1
8 A to H Red test point Do not insert
8
C1 to C8
Not applicable
Not inserted
1 C9 50 V, X7R, ceramic capacitor FEC/1759122
1 C10 6.3 V, tantalum capacitor (Case A) FEC/1190107
1 J1 16-pin (2 × 8) header FEC/2308428 inserted from solder side
1 J2 10-pin (2 × 5) straight header, 2.54 mm pitch FEC/9689583 inserted from solder side
1 J3 6-pin (1 × 6) straight header, 2.54 mm pitch FEC/9689508 inserted from solder side
1
J4
Header, 2.54 mm, PCB, 1 × 8-way
FEC/1766172 inserted from solder side
8 R1 to R8 Not applicable Not inserted
1 U1 Octal DAC, 4 × 12-bit DACs, 4 × 16-bit DACs Analog Devices/AD5678ARUZ-2
1FEC refers to Farnell Electronic Component Distributors.

EVAL-AD5678DBZ User Guide UG-987
Rev. A | Page 13 of 13
NOTES
I2C refers to a communications protocol originally developed by Philips Semiconductors (now NXP Semiconductors).
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD.Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and conditions
set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation Board until you
have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”) and Analog Devices, Inc.
(“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to Customer a free, limited, personal,
temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and agrees that the Evaluation Board is provided
for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted is expressly made subject to the following additional
limitations: Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board; and (ii) permit any Third Party to access the Evaluation Board. As used herein, the term
“Third Party”includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is NOT sold to Customer; all rights not expressly granted herein, including
ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all be considered the confidential and proprietary information of ADI. Customer may
not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of use of the Evaluation Board or termination of this Agreement, Customer agrees to
promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any
occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited to soldering or any other activity that affects the material content of the Evaluation Board.
Modifications to the Evaluation Board must comply with applicable law, including but not limited to the RoHS Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice
to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF
LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS” AND ADI MAKES NO
WARRANTIES OR REPRESENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICALLY DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED
TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL
PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF
THE EVALUATION BOARD, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL. ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE
AMOUNT OF ONE HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable
United States federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of
Massachusetts (excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby
submits to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
©2017 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
UG14523-0-11/17(A)

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Analog Devices Inc.:
EVAL-AD5678DBZ
