1
DEMO MANUAL DC3186A
Rev. 0
DESCRIPTION
LTC3311
3.3V to 1.2V at 50A, 37.5A, 25A Multiphase
2MHz Automotive Low EMI Buck Regulator
Demonstration Circuit 3186A features the LT C
®
3311
12.5A, low voltage synchronous step-down Silent
Switcher
®
operating as a multiphase 2MHz, 3V to 5.5V
input, 1.2V buck regulator. The DC3186A has three build
options to provide a two phase 25A, three phase 37.5A,
or four phase 50A output solution. The LTC3311 supports
adjustable output voltages from 0.5V to VIN and operat-
ing frequencies from 500kHz up to 5MHz in multiphase
operation. All phases of DC3186A operate in forced con-
tinuous mode.
The DC3186A also has an EMI filter to reduce conducted
EMI. This EMI filter can be included by applying the input
voltage at the VIN EMI terminal. All registered trademarks and trademarks are the property of their respective owners.
PERFORMANCE SUMMARY
The Efficiency vs Load graph shows the efficiency of the
circuit with a 3.3V input for all three build options.
An on-board transient circuit is included to measure fast
transient performance.
The LTC3311 data sheet gives a complete description
of the part, its operation, and application information.
The data sheet must be read in conjunction with this
demo manual. The LTC3311 is assembled in a 3mm ×
3mm LQFN package with exposed pads for low thermal
resistance.
Design files for this circuit board are available.
Specifications are at TA= 25°C
SYMBOL PARAMETER CONDITIONS MIN. T Y P. MAX. UNITS
VIN/VIN EMI DC3186A Input Voltage Range 3 5.5 V
VOUT DC3186A Output Voltage Range 1.176 1.2 1.224 V
IOUT DC3186A Output Current DC3186A-A, 4-Phase Build Option, VIN ≥ 3V
DC3186A-B, 3-Phase Build Option, VIN ≥ 3V
DC3186A-C, 2-Phase Build Option, VIN ≥ 3V
50
37.5
25
A
A
A
fSW Switching Frequency 1.8 2.2 MHz
EFF Efficiency VIN = 3.3V, IOUT = 15A, 4-Phase 92.5 %

2
DEMO MANUAL DC3186A
Rev. 0
QUICK START PROCEDURE
Refer to Figure1 for the proper measurement equipment
setup and follow the procedure below:
NOTE:For accurate V
IN
, V
OUT
and efficiency measure-
ments, measure VIN at the VIN SNSE and GND SNSN
turrets, and measure VOUT at the VOUT SNSE and GND
SNSE turrets, as illustrated as VM1 and VM2 in Figure1.
When measuring the input or output ripple, care must
be taken to avoid a long ground lead on the oscilloscope
probe. Measure the output voltage ripple by touching the
probe tip directly across the output turrets or to TP1 as
shown in Figure2.
1. Set the JP1 Jumper to the HI position.
2. With power off, connect the input power supply to VIN
and GND. If the input EMI filter is desired, connect the
input power supply to VIN EMI and GND.
3. Set power supply PS1 current limit to 40A. Set the
electronic load LD1 to CC mode and 0A current. Slowly
increase PS1 to 1V. If PS1 output current reads less
than20mA,increasePS1to3.3V.VerifythatVM1reads
3.3V and VM2 reads 1.2V. Check VM1, VM2, VM3,
PS1 output current, and LD1 input current. Connect
an oscilloscope voltage probe as shown in Figure2.
Set Channel to AC-coupled, voltage scale to 20mV and
time base to 10µs. Check VOUT ripple voltage. Verify
that PGOOD voltage is above 3V.
4. Increase the load by 1A intervals up to full load and
observe the voltage output regulation, ripple voltage.
5. To test the transient response with a base load, add the
desired resistor to produce a minimum load between
VOUT and I_STEP turrets (RL shown on Figure1).
Note that the total load resistance will be RL plus
R16 (10mΩ). The DC3186A uses a buffered signal
generator input to drive a source follower circuit, and
to control the slew rate and amplitude of the current
transient. The source follower FET, Q1, operates in the
linear region during the load step.
6. Connect PS2 to DRIVER BIAS and GND turrets. Turn
on and set PS2 to 8V.
7. Set a signal generator with a 1ms pulse width, a 10ms
period and an amplitude from 0V to 4V, and then
connect it to SG_INPUT turret.
NOTE: Do not allow the pulse generator to have more
than a 20% duty cycle. This can allow too much power
to be dissipated in Q1 and can damage the FET.
8. Connect an oscilloscope with a time scale of 200µs/
div with one channel having a vertical scale of 2V/div
on the SG_INPUT and another with a vertical scale of
50mV/div to the I_STEP turret.
9. Measure the I_STEP voltage to observe the current,
VI_STEP/10mΩ. Adjust the amplitude of the pulse to
provide the desired transient. Adjust the rising and
falling edge of the pulse to provide the desired ramp
rate. Figure5 shows a load step from 10A to 20A in
1µs. Refer to the following equations:
I
OUT =
V
I_STEP
10mΩ
(1)
VGS = VSG_INPUT – VI_STEP (2)
10. When done, turn off SG1, PS1 and Load. Remove all
the connections to the demo board.

3
DEMO MANUAL DC3186A
Rev. 0
TEST SETUP
Figure2. Technique for Measuring Output Ripple and Step Response
Figure1. Test Setup for DC3186A Demo Board
PS1
3.3V
40A
V
VM3
VM1
V
VM2
V
PS2
8V
100mA
SCOPE
LD1
1.2V
50A
SG1
RL

4
DEMO MANUAL DC3186A
Rev. 0
TYPICAL PERFORMANCE CHARACTERISTICS
Figure3. LTC3311 Multiphase Typical Solution Schematic
Figure4. DC3186A-A Thermal Performance with 40A Load at Room Temperature
LTC3311
LTC3311
VOUT
1.2V
50A
PGOOD
SW
FB
RT
EN
MODE/SYNC
ITH
PGOOD
SW
FB
RT
EN
MODE/SYNC
SSTT
ITH
22µF
×2
22µF
×2
0.01µF
0.01µF
1M
0.01µF
0.01µF 22µF
L, 100nH
22µF
L, 100nH
22µF
22µF
0.1µF
3.32k
470pF
NC
10µF 1µF
10µF 1µF
VIN
VIN
3V TO 5.5V
AGND PGNDSSTT
VIN
VIN
VIN
AGND PGND
140k
100k
6.8pF
274k
100k
PGOOD
PGOOD
22µF
249k
MASTER
PHASE
SLAVE
PHASES
dc3186a F03
L = COILCRAFT, XEL4030-101ME

5
DEMO MANUAL DC3186A
Rev. 0
Figure5. Efficiency vs Load Current Figure6. Load Step Response
f
SW
= 2MHz
V
IN
= 3.3V
4-PHASE
3-PHASE
2-PHASE
LOAD CURRENT (A)
0
10
20
30
40
50
50
55
60
65
70
75
80
85
90
95
100
EFFICIENCY (%)
dc3186a F04
10A
20A
V
IN
= 3.3V
5µs/DIV
I
LOAD
5A/DIV
V
OUT
50mV/DIV
dc3186a F05
TYPICAL PERFORMANCE CHARACTERISTICS
THEORY OF OPERATION
Introduction to the DC3186A
The DC3186A demonstration circuit features the LTC3311,
an automotive grade low voltage synchronous step-down
Silent Switcher in a two, three, or four phase operation.
The LTC3311 is a monolithic, constant frequency, current
mode step-down DC/DC converter. Connecting the RT pin
of the master phase with a resistor to AGND programs
the frequency from 500kHz to 5MHz. With RTresistor
on master phase, the MODE/SYNC pin becomes a clock
output to drive the MODE/SYNC pins of the slave phases.
The DC3186A can operate with an external clock by short-
ing the master phase RT pin to VIN with a 0Ω resistor in
the R5 location and applying a clock signal on the MODE/
SYNC turret. If the EN pin is low, the LTC3311 is in shut-
down and in a low quiescent current state. When the EN
pin is above its threshold, the switching regulator will be
enabled.
Connecting the FB pin to VIN configures a phase as a
slave. The MODE/SYNC pin becomes an input, and the
voltage control loop is disabled. The current control loop
in the slave phase is still active, and the peak current
is controlled via the shared ITH node. The phasing of a
slave phase relative to the master phase is programmed
with a resistor divider on the RT pin. Refer to Table 5 of
the data sheet for more information on setting the slave
phase angle.
In the multiphase application, the LTC3311 operates in
forced continuous mode. At light loads, the slave phases
will continue to operate in forced continuous mode.
Setting the compensation for the multiphase is similar
to setting the compensation to the single phase. When
designing the compensation network, controlling the loop
stability and transient response are the two main con-
siderations. The LTC3311 has been designed to operate
at a high bandwidth for fast transient response capabili-
ties. This reduces output capacitance required to meet
the desired transient voltage range. The mid-band gain
of the loop increases with R8 and the bandwidth of the
loop increases with decreasing C14. C11 along with R6
provides a phase lead which will improve the phase mar-
gin. C13, C33, C34, and C44 along with R8 provides a
high frequency pole to reduce the high frequency gain.
C13, C33, C34, and C44 are in parallel on the ITH node.
The sum of these caps will be the total capacitance on the
master phase ITH pin. Too much capacitance will slow
down the response time.
Loop stability is generally measured using the Bode Plot
method of plotting loop gain in dB and phase shift in
degrees. The 0dB crossover frequency should be less
the 1/6 of the operating frequency to reduce the effects
of added phase shift of the modulator. The control loop
phase margin goal should be 45° or greater and a gain

6
DEMO MANUAL DC3186A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
DC3186A-A Required Circuit Components
1 4 C2, C16, C23, C36 CAP., 1µF, X7T, 6.3V, 20%, 0201 MURATA, GRM033D70J105ME01D
2 17 C3-C5, C10, C17-C19, C21, C24, C25,
C28, C37, C38, C41, C42, C49, C52
CAP., 22µF, X7S, 6.3V, 20%, 0805 TDK, C2012X7S0J226M125AC
3 2 C6, C12 CAP., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200 MURATA, GCM155R71C104KA55D
4 8 C7, C8, C20, C26, C27, C31, C43, C45 CAP., 0.01µF, X7R, 6.3V, 10%, 0201 AVX, 02016C103KAT2A
5 1 C11 CAP., 6.8pF, C0G/NP0, 50V, ±0.5pF, 0402 AVX, 04025A6R8DAT2A
6 1 C14 CAP., 470pF, C0G, 50V, 5%, 0402, AEC-Q200 TDK, CGA2B2C0G1H471J050BA
7 4 C30, C50, C51, C53 CAP., 10µF, X7S, 6.3V, 20%, 0603 TDK, C1608X7S0J106M080AC
8 4 L1-L4 IND., 0.1µH, PWR, SHIELDED, 20%, 25.8A, 1.8mΩ,
4.3mm × 4.3mm, XEL4030, AEC-Q200
COILCRAFT, XEL4030-101MEB
9 1 R1 RES., 1M, 1%, 1/16W, 0402, AEC-Q200 STACKPOLE ELECTRONICS, INC.,
RMCF0402FT1M00
10 3 R2, R11, R14 RES., 100k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F1003TRF
11 1 R3 RES., 249k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F2493TRF
12 1 R4 RES., 274k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F2743TRF
13 1 R6 RES., 140k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F1403TRF
14 1 R7 RES., 100k, 5%, 1/16W, 0402, AEC-Q200 NIC, NRC04J104TRF
15 1 R8 RES., 3.32k, 1%, 1/10W, 0402, AEC-Q200 PANASONIC, ERJ2RKF3321X
16 4 R9, R15, R20, R21 RES., 0Ω, 1/16W, 0402 VISHAY, CRCW04020000Z0ED
17 2 R12, R13 RES., 301k, 1%, 1/16W, 0402 SAMSUNG, RC1005F3013CS
18 4 U1-U4 IC, LOW VOLTAGE SYN. STEPDOWN REG, LQFN-18 ANALOG DEVICES, LTC3311JV#PBF
Additional Demo Board Circuit Components
1 8 C1, C15, C29, C35, C39, C40, C60, C64 CAP., 470µF, TANT POLY, 6.3V, 20%, 7343 PANASONIC, 6TCE470MI
2 6 C9, C32, C54, C57, C61, C65 CAP., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200 MURATA, GCM155R71C104KA55D
3 8 C46, C47, C55, C56, C58, C59, C62, C63 CAP., 10µF, X7S, 6.3V, 20%, 0603 TDK, C1608X7S0J106M080AC
4 4 L5-L8 IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A,
6mΩ, 1812
WURTH ELEKTRONIK, 74279226101
5 1 Q1 XSTR., MOSFET, N-CH, 60V, 120A, TO-263 VISHAY, SUM50020E-GE3
6 2 R16, R18 RES., 0.02Ω, 1%, 10W, 2818, HP, METAL, SENSE,
AEC-Q200
VISHAY, WSHP2818R0200FEA
THEORY OF OPERATION
margin goal of 8dB or greater. Refer to the LTC3311 data
sheet and LTPowerCAD for more information on choosing
the required components.
The soft-start of the multiphase regulator is controlled by
a single cap, C12, on the master phase. After the regulator
is in regulation the SSTT pin can be used to monitor the
temperature of each IC. The master phase temperature
can be monitored at the SSTT turret and slave 1, 2, and 3
can be monitored at TP3, 4, and 6 respectively. Calculate
the die temperature with the formula below:
TJ(°C) =
V
SSTT
4mV
– 273
(3)

7
DEMO MANUAL DC3186A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
7 2 R17, R19 RES., 10k, 5%, 1/16W, 0402, AEC-Q200 NIC, NRC04J103TRF
8 1 RG1 RES., 20Ω, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F20R0TRF
9 1 U5 IC, OPAMP BUFFER, 20MHz, ±150mA, DFN-8 ANALOG DEVICES, LT1010CDD#PBF
Hardware: For Demo Board Only
1 12 E1-E3, E5, E12, E14-E17, E19-E21 TEST POINT, TURRET, 0.064" MTG. HOLE, PCB
0.062" THK
MILL-MAX, 2308-2-00-80-00-00-07-0
2 11 E4, E7, E10, E13, E18, E22-E24, E26-E28 TEST POINT, TURRET, 0.094" MTG. HOLE, PCB
0.062" THK
MILL-MAX, 2501-2-00-80-00-00-07-0
3 5 E6, E8, E9, E11, E25 STUD, #10-32, FASTENER, 0.625" LENGTH PENCOM, PR1422
4 1 JP1 CONN., HDR, MALE, 1 × 3, 2mm, VERT, ST, THT WURTH ELEKTRONIK, 62000311121
5 4 MP1-MP4 STANDOFF, NYLON, SNAP-ON, 0.25" (6.4mm) KEYSTONE, 8831
6 5 MP5-MP9 RING, LUG, #10, CRIMP, 8 AWG, FLAT, NON-
INSULATED, SOLDERLESS TERMINAL
MOLEX, 0192210223
7 10 MP10-MP19 NUT, HEX, #10-32, BRASS PENCOM, NU1132
8 5 MP20-MP24 WASHER, #10, LOCK, EXT, TIN FINISH PENCOM, WA4526
9 1 XJP1 CONN., SHUNT, FEMALE, 2-POS, 2mm WURTH ELEKTRONIK, 60800213421
DC3186A-B Required Circuit Components
1 3 C2, C16, C36 CAP., 1µF, X7T, 6.3V, 20%, 0201 MURATA, GRM033D70J105ME01D
2 13 C3-C5, C10, C17-C19, C21, C37, C38,
C41, C42, C49
CAP., 22µF, X7S, 6.3V, 20%, 0805 TDK, C2012X7S0J226M125AC
3 2 C6, C12 CAP., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200 MURATA, GCM155R71C104KA55D
4 6 C7, C8, C20, C26, C27, C45 CAP., 0.01µF, X7R, 6.3V, 10%, 0201 AVX, 02016C103KAT2A
5 1 C11 CAP., 6.8pF, C0G/NP0, 50V, ±0.5pF, 0402 AVX, 04025A6R8DAT2A
6 1 C14 CAP., 470pF, C0G, 50V, 5%, 0402, AEC-Q200 TDK, CGA2B2C0G1H471J050BA
7 3 C30, C50, C53 CAP., 10µF, X7S, 6.3V, 20%, 0603 TDK, C1608X7S0J106M080AC
8 3 L1-L3 IND., 0.1µH, PWR, SHIELDED, 20%, 25.8A, 1.8mΩ,
4.3mm × 4.3mm, XEL4030, AEC-Q200
COILCRAFT, XEL4030-101MEB
9 1 R1 RES., 1M, 1%, 1/16W, 0402, AEC-Q200 STACKPOLE ELECTRONICS, INC.,
RMCF0402FT1M00
10 1 R2 RES., 100k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F1003TRF
11 1 R3 RES., 249k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F2493TRF
12 1 R4 RES., 274k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F2743TRF
13 1 R6 RES., 140k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F1403TRF
14 1 R7 RES., 100k, 5%, 1/16W, 0402, AEC-Q200 NIC, NRC04J104TRF
15 1 R8 RES., 3.32k, 1%, 1/10W, 0402, AEC-Q200 PANASONIC, ERJ2RKF3321X
16 2 R9, R12 RES., 243k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F2433TRF
17 2 R10, R11 RES., 174k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F1743TRF
18 2 R15, R20 RES., 0Ω, 1/16W, 0402 VISHAY, CRCW04020000Z0ED
19 3 U1-U3 IC, LOW VOLTAGE SYN. STEPDOWN REG, LQFN-18 ANALOG DEVICES, LTC3311JV#PBF

8
DEMO MANUAL DC3186A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Additional Demo Board Circuit Components
1 5 C9, C32, C57, C61, C65 CAP., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200 MURATA, GCM155R71C104KA55D
2 6 C15, C29, C39, C40, C60, C64 CAP., 470µF, TANT POLY, 6.3V, 20%, 7343 PANASONIC, 6TCE470MI
3 6 C46, C47, C58, C59, C62, C63 CAP., 10µF, X7S, 6.3V, 20%, 0603 TDK, C1608X7S0J106M080AC
4 3 L6-L8 IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A,
6mΩ, 1812
WURTH ELEKTRONIK, 74279226101
5 1 Q1 XSTR., MOSFET, N-CH, 60V, 120A, TO-263 VISHAY, SUM50020E-GE3
6 2 R16, R18 RES., 0.02Ω, 1%, 10W, 2818, HP, METAL, SENSE,
AEC-Q200
VISHAY, WSHP2818R0200FEA
7 2 R17, R19 RES., 10k, 5%, 1/16W, 0402, AEC-Q200 NIC, NRC04J103TRF
8 1 RG1 RES., 20Ω, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F20R0TRF
9 1 U5 IC, OPAMP BUFFER, 20MHz, ±150mA, DFN-8 ANALOG DEVICES, LT1010CDD#PBF
Hardware: For Demo Board Only
1 12 E1-E3, E5, E12, E14-E17, E19-E21 TEST POINT, TURRET, 0.064" MTG. HOLE, PCB
0.062" THK
MILL-MAX, 2308-2-00-80-00-00-07-0
2 11 E4, E7, E10, E13, E18, E22-E24, E26-E28 TEST POINT, TURRET, 0.094" MTG. HOLE, PCB
0.062" THK
MILL-MAX, 2501-2-00-80-00-00-07-0
3 5 E6, E8, E9, E11, E25 STUD, #10-32, FASTENER, 0.625" LENGTH PENCOM, PR1422
4 1 JP1 CONN., HDR, MALE, 1 × 3, 2mm, VERT, ST, THT WURTH ELEKTRONIK, 62000311121
5 4 MP1-MP4 STANDOFF, NYLON, SNAP-ON, 0.25" (6.4mm) KEYSTONE, 8831
6 5 MP5-MP9 RING, LUG, #10, CRIMP, 8 AWG, FLAT, NON-
INSULATED, SOLDERLESS TERMINAL
MOLEX, 0192210223
7 10 MP10-MP19 NUT, HEX, #10-32, BRASS PENCOM, NU1132
8 5 MP20-MP24 WASHER, #10, LOCK, EXT, TIN FINISH PENCOM, WA4526
9 1 XJP1 CONN., SHUNT, FEMALE, 2-POS, 2mm WURTH ELEKTRONIK, 60800213421
DC3186A-C Required Circuit Components
1 2 C2, C16 CAP., 1µF, X7T, 6.3V, 20%, 0201 MURATA, GRM033D70J105ME01D
2 9 C3-C5, C10, C17-C19, C21, C49 CAP., 22µF, X7S, 6.3V, 20%, 0805 TDK, C2012X7S0J226M125AC
3 2 C6, C12 CAP., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200 MURATA, GCM155R71C104KA55D
4 4 C7, C8, C26, C27 CAP., 0.01µF, X7R, 6.3V, 10%, 0201 AVX, 02016C103KAT2A
5 1 C11 CAP., 6.8pF, C0G/NP0, 50V, ±0.5pF, 0402 AVX, 04025A6R8DAT2A
6 1 C14 CAP., 470pF, C0G, 50V, 5%, 0402, AEC-Q200 TDK, CGA2B2C0G1H471J050BA
7 2 C30, C53 CAP., 10µF, X7S, 6.3V, 20%, 0603 TDK, C1608X7S0J106M080AC
8 2 L1, L2 IND., 0.1µH, PWR, SHIELDED, 20%, 25.8A, 1.8mΩ,
4.3mm × 4.3mm, XEL4030, AEC-Q200
COILCRAFT, XEL4030-101MEB
9 1 R1 RES., 1M, 1%, 1/16W, 0402, AEC-Q200 STACKPOLE ELECTRONICS, INC.,
RMCF0402FT1M00
10 1 R2 RES., 100k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F1003TRF
11 1 R3 RES., 249k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F2493TRF

9
DEMO MANUAL DC3186A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
12 1 R4 RES., 274k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F2743TRF
13 1 R6 RES., 140k, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F1403TRF
14 1 R7 RES., 100k, 5%, 1/16W, 0402, AEC-Q200 NIC, NRC04J104TRF
15 1 R8 RES., 3.32k, 1%, 1/10W, 0402, AEC-Q200 PANASONIC, ERJ2RKF3321X
16 2 R11, R15 RES., 0Ω, 1/16W, 0402 VISHAY, CRCW04020000Z0ED
17 2 U1, U2 IC, LOW VOLTAGE SYN. STEPDOWN REG, LQFN-18 ANALOG DEVICES, LTC3311JV#PBF
Additional Demo Board Circuit Components
1 4 C9, C32, C57, C61 CAP., 0.1µF, X7R, 16V, 10%, 0402, AEC-Q200 MURATA, GCM155R71C104KA55D
2 4 C15, C29, C39, C60 CAP., 470µF, TANT POLY, 6.3V, 20%, 7343 PANASONIC, 6TCE470MI
3 4 C58, C59, C62, C63 CAP., 10µF, X7S, 6.3V, 20%, 0603 TDK, C1608X7S0J106M080AC
4 2 L6, L7 IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A,
6mΩ, 1812
WURTH ELEKTRONIK, 74279226101
5 1 Q1 XSTR., MOSFET, N-CH, 60V, 120A, TO-263 VISHAY, SUM50020E-GE3
6 2 R16, R18 RES., 0.02Ω, 1%, 10W, 2818, HP, METAL, SENSE,
AEC-Q200
VISHAY, WSHP2818R0200FEA
7 2 R17, R19 RES., 10k, 5%, 1/16W, 0402, AEC-Q200 NIC, NRC04J103TRF
8 1 RG1 RES., 20Ω, 1%, 1/16W, 0402, AEC-Q200 NIC, NRC04F20R0TRF
9 1 U5 IC, OPAMP BUFFER, 20MHz, ±150mA, DFN-8 ANALOG DEVICES, LT1010CDD#PBF
Hardware: For Demo Board Only
1 12 E1-E3, E5, E12, E14-E17, E19-E21 TEST POINT, TURRET, 0.064" MTG. HOLE, PCB
0.062" THK
MILL-MAX, 2308-2-00-80-00-00-07-0
2 11 E4, E7, E10, E13, E18, E22-E24, E26-E28 TEST POINT, TURRET, 0.094" MTG. HOLE, PCB
0.062" THK
MILL-MAX, 2501-2-00-80-00-00-07-0
3 5 E6, E8, E9, E11, E25 STUD, #10-32, FASTENER, 0.625" LENGTH PENCOM, PR1422
4 1 JP1 CONN., HDR, MALE, 1x3, 2mm, VERT, ST, THT WURTH ELEKTRONIK, 62000311121
5 4 MP1-MP4 STANDOFF, NYLON, SNAP-ON, 0.25" (6.4mm) KEYSTONE, 8831
6 5 MP5-MP9 RING, LUG, #10, CRIMP, 8 AWG, FLAT, NON-
INSULATED, SOLDERLESS TERMINAL
MOLEX, 0192210223
7 10 MP10-MP19 NUT, HEX, #10-32, BRASS PENCOM, NU1132
8 5 MP20-MP24 WASHER, #10, LOCK, EXT, TIN FINISH PENCOM, WA4526
9 1 XJP1 CONN., SHUNT, FEMALE, 2-POS, 2mm WURTH ELEKTRONIK, 60800213421

10
DEMO MANUAL DC3186A
Rev. 0
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
1.2V
VOUT
MODE/SYNC
GND
EN
SSTT
PGOOD
GND
GND
GND
VOUT GND
VOUT
SNSE
GND
SNSE
VIN
SNSE
GND
SNSE
(VIN MAX)
FSW = 2MHz
MASTER
SKU#
DO NOT
POPULATE
TPA TPB
DNP
DESCRIPTION DATEREV
REVISION HISTORY
APPROVEDECO
SLAVE 3
NONE
SLAVE 2 & 3
R9 R10
R11 R12 R13 R14
DC3186A-A
DC3186A-B DC3186A-C
0DNP100k 301k 301k 100k
174k243k
DNP
243k
174k
0
ASSEMBLY OPTIONS TABLE
HI
LO
* SEE TABLE
*
DNP
DNP
- 02 PRODUCTION 09/20/21
NOTES: UNLESS OTHERWISE SPECIFIED 1. RESISTORS: OHMS, 0402, 1%, 1/16W 2. CAPACITORS: 0402
25A 37.5A
IOUT
50A
*
DNP
DNP
DNP DNP
# OF
PHASES
4
2 3
SLAVE 1 SLAVE 2 SLAVE 3
EN
GND
VIN
3.0V - 5.5V
VIN
3.3V TO 1.2V AT 50A, 37.5A, 25A, MULTIPHASE 2MHz AUTOMOTIVE LOW EMI BUCK REGULATOR IN A 1.18cm² PER PHASE SOLUTION
MODECOM
VOUT
EN
ITH PGOOD
VIN
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
14
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
14
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
14
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
C6
0.1uF
JP1
U1
LTC3311JV
EN
1
SW 6
FB 18
ITH
17
MODE/SYNC
13
RT 15
PGOOD 14
SSTT
16
VIN
3
PGND
5
AGND
2
VIN
11
VIN
12
VIN
4SW 7
SW 8 SW 9
PGND
19
PGND
10
C2
1uF
0201
R2
100K
E10
C19
22uF 0805
E1
L1
0.1uH
XEL4030-101MEB
E9
R1
1M
E7
R6
140k
E2
R7
100k
E14
C7
0.01uF 0201
C12
0.1uF
TP1
C13
OPT
JP2
1 2
E3
E8
E24
R4 274k
C11
6.8pF
E15
R5
OPT
E16
E13
E25
E12
C4 22uF 0805
E11
E21
C3
22uF 0805
C53
10uF 0603 RG1
20
C5
22uF 0805
R3
249k
R8
3.32k
E17
C14
470pF
E5
C9
0.1uF
C10
22uF
0805
C8
0.01uF 0201
VFB1 RT1 SW1
VIN
VOUT

11
DEMO MANUAL DC3186A
Rev. 0
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
SLAVE 1
SLAVE 2
*
*
*
*
*
*
* SEE TABLE ON PAGE 1
3.3V TO 1.2V AT 50A, 37.5A, 25A, MULTIPHASE 2MHz AUTOMOTIVE LOW EMI BUCK REGULATOR IN A 1.18cm² PER PHASE SOLUTION
MODECOM
EN
ITH
VOUT
PGOOD
PGOOD
VIN
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
24
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
24
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
24
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
U3
LTC3311JV
EN
1
SW 6
FB 18
ITH
17
MODE/SYNC
13
RT 15
PGOOD 14
SSTT
16
VIN
3
PGND
5
AGND
2
VIN
11
VIN
12
VIN
4SW 7
SW 8 SW 9
PGND
19
PGND
10
C26
0.01uF 0201
C49
22uF 0805
R20
0
L3
0.1uH
XEL4030-101MEB
C33
OPT
C27
0.01uF 0201
TP3
C44
OPT
R12
C45
0.01uF 0201
L2
0.1uH
XEL4030-101MEB
C37
22uF 0805
TP4
C20
0.01uF 0201
R15
0
C36
1uF 0201
R11
C30 10uF
C50
10uF 0603
C42
22uF 0805
C18 22uF 0805
C17
22uF 0805
R9
TP2
U2
LTC3311JV
EN
1
SW 6
FB 18
ITH
17
MODE/SYNC
13
RT 15
PGOOD 14
SSTT
16
VIN
3
PGND
5
AGND
2
VIN
11
VIN
12
VIN
4SW 7
SW 8 SW 9
PGND
19
PGND
10
C16
1uF 0201
C21
22uF 0805
C38 22uF 0805
TP5
R10
C41
22uF 0805
VIN
RT2
SW2
VIN
EN
VIN
RT3
SW3
MODECOM
ITH
VIN
VIN

12
DEMO MANUAL DC3186A
Rev. 0
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
* SEE TABLE ON PAGE 1
SLAVE 3
*
*
*
I_STEP
SG_INPUT
OPTIONAL TRANSIENT RESPONSE CIRCUIT
GND
GND
GND
DRIVER BIAS 10V MAX
VIN EMI
VIN EMI
3.0V - 5.5V
GND GND
10V MAX
OPT
3.3V TO 1.2V AT 50A, 37.5A, 25A, MULTIPHASE 2MHz AUTOMOTIVE LOW EMI BUCK REGULATOR IN A 1.18cm² PER PHASE SOLUTION
VIN_EMI
MODECOM
VOUT
EN
ITH PGOOD
VIN
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
34
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
34
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
34
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
R18 0.02
2818 10W
C58
10uF 0603
C28
22uF 0805
+
C60
470uF
C51
10uF 0603
+
C64
470uF
R14
C61
0.1uF
C32
0.1uF
C59
10uF 0603 E18
C65
0.1uF
L4
0.1uH
XEL4030-101MEB
C62
10uF 0603
TP9
E19
C46
10uF 0603
E27
C63
10uF 0603
L5
100 OHMS@100MHz
R19
10k 5%
E4
R13
TP8
C47
10uF 0603
C23
1uF
0201
E28
U5
LT1010-DD
8
16 2
3
9
R21
0
Q1
SUM50020E-GE3
2
1
3
E23
E6
R16 0.02
2818 10W
R17
10k 5%
U4
LTC3311JV
EN
1
SW 6
FB 18
ITH
17
MODE/SYNC
13
RT 15
PGOOD 14
SSTT
16
VIN
3
PGND
5
AGND
2
VIN
11
VIN
12
VIN
4SW 7
SW 8 SW 9
PGND
19
PGND
10
C54
0.1uF
+
C29
470uF
L6
100 OHMS@100MHz
TP6
C55
10uF 0603
C31
0.01uF 0201
+
C39
470uF
C22
C56
10uF 0603
C34
OPT
TP7
+
C40
470uF
C24
22uF 0805
L7
100 OHMS@100MHz
E20
+
C1
470uF
C43
0.01uF 0201
L8
100 OHMS@100MHz
+
C35
470uF
C52
22uF 0805
+
C15
470uF
E22
E26
C25 22uF 0805
C57
0.1uF
SW4
VIN
RT4 VIN
VOUT
VIN

13
DEMO MANUAL DC3186A
Rev. 0
Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications
subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
* SEE TABLE ON PAGE 1
PCA ADDITIONAL PARTS
3.3V TO 1.2V AT 50A, 37.5A, 25A, MULTIPHASE 2MHz AUTOMOTIVE LOW EMI BUCK REGULATOR IN A 1.18cm² PER PHASE SOLUTION
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
44
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
44
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
www.analog.com
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
44
NC
WL
710-DC3186A_REV02
N/A
LTC3311
09/20/21
MP18 NUT,HEX,#10-32,BRASS MP11 NUT,HEX,#10-32,BRASS MP14 NUT,HEX,#10-32,BRASS
MP1
STANDOFF,NYLON,SNAP-ON,0.25" (6.4mm)
MP4
STANDOFF,NYLON,SNAP-ON,0.25" (6.4mm)
MP6 RING,LUG,#10,CRIMP,8 AWG,FLAT,NON-INSULATED,SOLDERLESS TERMINAL MP21 WASHER,#10,LOCK,EXT,TIN FINISH MP24 WASHER,#10,LOCK,EXT,TIN FINISH MP16 NUT,HEX,#10-32,BRASS MP9 RING,LUG,#10,CRIMP,8 AWG,FLAT,NON-INSULATED,SOLDERLESS TERMINAL MP19 NUT,HEX,#10-32,BRASS MP12 NUT,HEX,#10-32,BRASS
MP2
STANDOFF,NYLON,SNAP-ON,0.25" (6.4mm)
LB1 LABEL
PCB1 PCB, DC3186A REV02
MP7 RING,LUG,#10,CRIMP,8 AWG,FLAT,NON-INSULATED,SOLDERLESS TERMINAL MP22 WASHER,#10,LOCK,EXT,TIN FINISH MP17 NUT,HEX,#10-32,BRASS MP10 NUT,HEX,#10-32,BRASS MP13 NUT,HEX,#10-32,BRASS
MP3
STANDOFF,NYLON,SNAP-ON,0.25" (6.4mm)
MP5 RING,LUG,#10,CRIMP,8 AWG,FLAT,NON-INSULATED,SOLDERLESS TERMINAL MP20 WASHER,#10,LOCK,EXT,TIN FINISH MP8 RING,LUG,#10,CRIMP,8 AWG,FLAT,NON-INSULATED,SOLDERLESS TERMINAL MP23 WASHER,#10,LOCK,EXT,TIN FINISH MP15 NUT,HEX,#10-32,BRASS

14
DEMO MANUAL DC3186A
Rev. 0
 ANALOG DEVICES, INC. 2022
09/22
www.analog.com
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and
conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation
Board until you have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”)
and Analog Devices, Inc. (“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to
Customer a free, limited, personal, temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and
agrees that the Evaluation Board is provided for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted
is expressly made subject to the following additional limitations:Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board;and (ii) permit any Third
Party to access the Evaluation Board. As used herein, the term “Third Party”includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is
NOT sold to Customer;all rights not expressly granted herein, including ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all
be considered the confidential and proprietary information of ADI. Customer may not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of
use of the Evaluation Board or termination of this Agreement, Customer agrees to promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile
or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited
to soldering or any other activity that affects the material content of the Evaluation Board. Modifications to the Evaluation Board must comply with applicable law, including but not limited to the RoHS
Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF
LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS”AND ADI MAKES NO WARRANTIES OR REPRESENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICALLY
DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS
LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF THE EVALUATION BOARD, INCLUDING
BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL. ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE AMOUNT OF ONE
HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable United States
federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of Massachusetts
(excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby submits
to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
