EVAL-ADGS5412SDZ User Guide
UG-1141
One Technology Way •P. O. Box 9106 •Norwood, MA 02062-9106, U.S.A. •Tel: [phone] •Fax: [phone] •www.analog.com
Evaluation Board for the ADGS5412 Serially Controlled, High Voltage, Latch-Up Proof,
Quad SPST Switch
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS. Rev. 0 | Page 1 of 12
FEATURES
SPI interface with error detection
Includes CRC, invalid read/write address, and SCLK count
error detection
Analog supply voltages
Dual-supply: ±9 V to ±22 V
Single-supply: 9 V to 40 V
PC control in conjunction with the evaluation software
EVAL-SDP-CB1Z SDP
EVALUATION KIT CONTENTS
EVAL-ADGS5412SDZ
DOCUMENTS NEEDED
ADGS5412 data sheet
EQUIPMENT NEEDED
EVAL-SDP-CB1Z controller board
ACE software with EVAL-ADGS5412SDZ plug-in
DC voltage source
±22 V for dual-supply
40 V for single-supply
Optional digital logic supply: 3.3 V
Analog signal source
Method to measure voltage, such as a digital multimeter (DMM)
GENERAL DESCRIPTION
The EVAL-ADGS5412SDZ is the evaluation board for the
ADGS5412. The ADGS5412 is a latch-up proof, quad single-pole,
single-throw (SPST) switch controlled by a serial peripheral
interface (SPI). The SPI has robust error detection features,
including cyclic redundancy check (CRC) error detection,
invalid read/write address detection, and serial clock (SCLK)
count error detection. It is possible to daisy-chain multiple
ADGS5412 devices together. This enables the configuration of
multiple devices with a minimal amount of digital lines. The
ADGS5412 also supports burst mode that decreases the time
between SPI commands.
Figure 1 shows the EVAL-ADGS5412SDZ in a typical evaluation
setup. The EVAL-ADGS5412SDZ is controlled by the EVAL-SDP-
CB1Z system demonstration platform (SDP), which connects to a
PC via a USB port. The ADGS5412 is on the center of the
evaluation board and wire screw terminals are provided to
connect to each of the source and drain pins. Three screw
terminals power the device, and a fourth terminal provides
users with a defined digital logic supply voltage, if required.
Alternatively, the digital logic supply voltage can be supplied
from the SDP.
Full specifications on the ADGS5412 are available in the
ADGS5412 data sheet available from Analog Devices, Inc., and
should be consulted in conjunction with this user guide when
using the evaluation board.
The evaluation board interfaces to the USB port of a PC via the
SDP board. The EVAL-SDP-CB1Z board (SDP-B controller
board) is available to order on the Analog Devices website at
www.analog.com.

UG-1141 EVAL-ADGS5412SDZ User Guide
Rev. 0 | Page 2 of 12
TABLE OF CONTENTS
Features .............................................................................................. 1
Evaluation Kit Contents................................................................... 1
Documents Needed.......................................................................... 1
Equipment Needed........................................................................... 1
General Description......................................................................... 1
Revision History ............................................................................... 2
ADGS5412 Evaluation Board Layout ............................................ 3
Evaluation Board Hardware............................................................ 4
Power Supplies .............................................................................. 4
Input Signals.................................................................................. 4
Link Options ................................................................................. 4
Evaluation Board Software...............................................................5
Installing the Software..................................................................5
Initial Set Up ..................................................................................5
Block Diagram And Description.....................................................6
Memory Map .................................................................................7
Evaluation Board Schematics and Artwork...................................8
Ordering Information.................................................................... 12
Bill of Materials........................................................................... 12
REVISION HISTORY
5/2017—Revision 0: Initial Version

EVAL-ADGS5412SDZ User Guide UG-1141
Rev. 0 | Page 3 of 12
ADGS5412 EVALUATION BOARD LAYOUT
Figure 1.
15896-001

UG-1141 EVAL-ADGS5412SDZ User Guide
Rev. 0 | Page 4 of 12
EVALUATION BOARD HARDWARE
POWER SUPPLIES
Connector J1 provides access to the supply pins of the
ADGS5412. VDD, GND, and VSS on J1 terminal block link to the
appropriate pins on the ADGS5412. For dual-supply voltages,
the evaluation board can be powered from ±9 V to ±22 V. For
single-supply voltages, the GND and VSS terminals must
connect together and power the evaluation board with 9 V to 40
V. Additionally, 3.3 V is supplied to the VLpin of the
ADGS5412 by the SDP when Link LK1 is in Position B. When
controlling the ADGS5412 by another method other than the
SDP, supply between 2.7 V and 5.5 V to the VLpin of the
ADGS5412 via the EXT_VL screw terminal input on J1. LK1 must
be in Position A.
INPUT SIGNALS
Two screw connectors, J2 and J3, are provided to connect to
both the source and drain pins of the ADGS5412. Additional
subminiature version B (SMB) connector pads are available if
extra connections are required.
Each trace on the source and drain side includes two sets of
0603 pads, which can place a load on the signal path to ground.
A 0 Ω resistor is placed in the signal path and can be replaced
with a user defined value. The resistor combined with the 0603
pads can create a simple resistor-capacitor (RC) filter.
LINK OPTIONS
A number of link options are provided on the EVAL-
ADGS5412SDZ evaluation board that must be set for the
required operating conditions before using. Table 1 describes
the positions of the links to control the evaluation board via the
SDP board using a PC and external power supplies. The
functions of these link options are described in detail in Table 2.
When using the SDP in conjunction with the EVAL-
ADGS5412SDZ, LK1 must be in Position B to avoid damage to
the SDP.
Table 1. Link Options for SDP Control (Default)
Link Number Option
LK1 B
LK2 B
Table 2. Link Functions
Link Number Function
LK1 This link selects the source of the VLvoltage supplied to the ADGS5412.
Position A selects EXT_VL from J1.
Position B selects the 3.3 V from the SDP.
LK2 This link selects how a hardware reset is performed.
Position A indicates the SW1 push button performs a hardware reset.
Position B indicates the SDP can perform a hardware reset.

EVAL-ADGS5412SDZ User Guide UG-1141
Rev. 0 | Page 5 of 12
EVALUATION BOARD SOFTWARE
INSTALLING THE SOFTWARE
The EVAL-ADGS5412SDZ evaluation board uses the Analog
Devices Analysis Control Evaluation (ACE) software. ACE is a
desktop software application that allows the evaluation and
control of multiple evaluation systems.
ACE installs the necessary SDP drivers and .NET Framework 4
by default. Install ACE before connecting the SDP. The ACE
software and access to full instructions on how to install and
use ACE can be found on the Analog Devices website.
After the installation is finished, the EVAL-ADGS5412SDZ
evaluation board plug-ins appear when opening ACE.
INITIAL SET UP
To set up the evaluation board, complete the following steps:
1. Connect the evaluation board to the SDP board and
connect the SDP board to the computer via a USB cable.
2. Power the evaluation board as described in the Power
Supplies section.
3. Run the ACE application. The EVAL-ADGS5412SDZ
board plug-ins appear in the attached hardware section of
the Start tab.
4. Double-click on the evaluation board plug-in to open the
evaluation board view seen in Figure 2.
5. The chip block diagram can be accessed by double-clicking
on the ADGS5412 icon (see Figure 2). This view provides a
basic representation of functionality of the evaluation board.
The main functions are labeled in Figure 3.
Figure 2. Evaluation Board View of the EVAL-ADGS5412SDZ
Figure 3. Chip Block Diagram View for the ADGS5412
15896-002
15896-003

UG-1141 EVAL-ADGS5412SDZ User Guide
Rev. 0 | Page 6 of 12
BLOCK DIAGRAM AND DESCRIPTION
The EVAL-ADGS5412SDZ software is organized so that it
appears similar to the functional block diagram shown in the
ADGS5412 data sheet. In this way, it is easy to correlate the
functions on the EVAL-ADGS5412SDZ board with the
description in the data sheets. A full description of each block,
register, and setting is given in the ADGS5412 data sheet.
Some of the blocks and their functions are described here as
they pertain to the evaluation board. The full screen block
diagram, shown in Figure 4, describes the functionality of each
Figure 4. EVAL-ADGS5412SDZ Block Diagram with Labels
Table 3. Block Diagram Functions
Label Function
A The dropdown menus configure SW1 to SW4 as open or closed.
B The INVALID RW ENABLE, SCLK COUNT ENABLE, and CRC ENABLE checkboxes enable or disable the error detection
features on the SPI interface.
C The BURST MODE ENABLE checkbox enables or disables burst mode.
D The RW ERROR FLAG, SCLK ERROR, and CRC ERROR FLAG indicators illuminate red if the relevant error flags assert in the
error flags register.
E The Clear Flags button clears the error flags register.
F The Apply Changes button applies all modified values to the devices.
F
A
BD
E
C
15896-004

EVAL-ADGS5412SDZ User Guide UG-1141
Rev. 0 | Page 7 of 12
MEMORY MAP
All registers are fully accessible from the Memory Map tab; this
allows registers to be edited at a bit level (see Figure 5 and Figure 6).
The bits shaded in dark gray are read-only bits and cannot be
accessed from ACE. All other bits are toggled. The Apply Changes
button transfers data to the device.
All changes here correspond to the block diagram; for example,
if the internal register bit is enabled, it displays as enabled on
the block diagram. Any bits or registers that are bold are
modified values that have not been transferred to the evaluation
board. After clicking Apply Changes, the data is transferred to
the evaluation board.
Figure 5. ADGS5412 Memory Map
Figure 6. ADGS5412 Memory Map with Unapplied Changes in the SW_DATA Register
15896-005
15896-006

UG-1141 EVAL-ADGS5412SDZ User Guide
Rev. 0 | Page 8 of 12
EVALUATION BOARD SCHEMATICS AND ARTWORK
Figure 7. EVAL-ADGS5412SDZ Schematic 1
Figure 8. EVAL-ADGS5412SDZ Schematic 2
15896-007
15896-008

EVAL-ADGS5412SDZ User Guide UG-1141
Rev. 0 | Page 9 of 12
Figure 9. EVAL-ADGS5412SDZ Schematic 3
Figure 10. EVAL-ADGS5412SDZ Silk Screen
15896-009
15896-010

UG-1141 EVAL-ADGS5412SDZ User Guide
Rev. 0 | Page 10 of 12
Figure 11. EVAL-ADGS5412SDZ Top Layer
Figure 12. EVAL-ADGS5412SDZ Layer 2
15896-011
15896-012
