Evaluation Board User Guide
UG-110
One Technology Way •P. O. Box 9106 •Norwood, MA 02062-9106, U.S.A. •Tel: [phone] •Fax: [phone] •www.analog.com
Evaluation Board for Fractional-N/Integer-N PLL Frequency Synthesizer
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS. Rev. 0 | Page 1 of 12
FEATURES
Self-contained board including PLL, VCO, loop filter (20 kHz),
10 MHz TCXO reference, USB interface, and voltage
regulators
Accompanying software allows control of synthesizer
functions from a PC
Choice of power supply via USB or external feeding
Typical phase noise performance of −99 dBc/Hz @ 1 kHz
offset from carrier (1 GHz output frequency)
GENERAL DESCRIPTION
The EVAL-ADF4350EB2Z is designed to evaluate the
performance of the ADF4350 frequency synthesizer. A
block diagram of the board is shown in Figure 1. It contains
the ADF4350 synthesizer, a USB connector and related inter-
face, a 10 MHz TCXO reference source, SMA connectors for
the RF outputs, and reference signal plus headers for various
signals and voltages. There is also a loop filter (20 kHz) on
board. A USB cable is included with the board to connect to
a PC USB port.
The package also contains Windows® software (2000- and XP-
compatible) to allow easy programming of the synthesizer.
EVALUATION KIT CONTENTS
Evaluation board software CD
USB cable
EVAL-ADF4350EB2Z
EVALUATION BOARD BLOCK DIAGRAM
HEADERS
EXTERNAL DC
SUPPLY
EXTERNAL DC
GND
HEADERS
TCXO
ADF4350
LOOP FILTER
LOCK DETECT LED
USB
POWER
LED
PLL
POWER
LED
USB POWER SWITCH
EXTERNAL POWER
SWITCH
USB
CONNECTOR
USB CRYSTAL
AND PROCESSOR
REFERENCE IN/OUT
RF
OUT
A+
RF
OUT
A–
RF
OUT
B+
RF
OUT
B−
08909-001
Figure 1.

UG-110 Evaluation Board User Guide
Rev. 0 | Page 2 of 12
TABLE OF CONTENTS
Features .............................................................................................. 1
General Description......................................................................... 1
Evaluation Kit Contents................................................................... 1
Evaluation Board Block Diagram................................................... 1
Revision History ............................................................................... 2
Evaluation Board Hardware............................................................ 3
Overview........................................................................................ 3
Power Supplies .............................................................................. 3
RF Output.......................................................................................3
Loop Filter......................................................................................3
Reference Source ...........................................................................3
Evaluation Setup................................................................................4
Evaluation Board Software...............................................................5
Evaluation Board Schematics and Artwork...................................6
Ordering Information.................................................................... 10
Bill of Materials........................................................................... 10
REVISION HISTORY
3/10—Revision 0: Initial Version

Evaluation Board User Guide UG-110
Rev. 0 | Page 3 of 12
EVALUATION BOARD HARDWARE
OVERVIEW
The EVAL-ADF4350EB2Z comes with a cable for connecting to
the USB port of a PC. The silk screen for the evaluation board is
shown in Figure 8. The board schematic is shown in Figure 5,
Figure 6, and Figure 7.
POWER SUPPLIES
The EVAL-ADF4350EB2Z can be powered either from the
USB port or via dc power connectors (4 mm banana connec-
tors). When feeding via banana connectors, 3.75 V to 11 V is
a suitable feeding voltage. The power supply circuitry allows
the user to use one, two, or three separate LDOs to feed the
ADF4350 (using fewer LDOs increases the risk of spur
contaminated dc feeds). Consult the board schematic in
Figure 5, Figure 6, and Figure 7 to determine a suitable jumper
setting on Header J7.
An LED, D6, indicates when USB power is available, and
another LED, D5, indicates when the ADF4350 is powered.
Switch SW1 is used to power the ADF4350 from the USB port
and Switch SW2 is used to power the part from the external dc
connectors.
In case the USB processor or clock causes spurs on the RF
output signal, the user may feed the evaluation board via the
dc connectors and unplug the USB cable, thereby removing
power from the USB interface circuitry. There is also a
grounded frame surrounding the USB interface circuitry
to allow mounting of a shielding box.
The J8 to J13 connectors can be populated if the user wishes
to measure any spectral contamination on a specific dc voltage.
Otherwise, the voltages are also present on either Header J6 or
Header J7 for easy access and measurements.
RF OUTPUT
The EVAL-ADF4350EB2Z has four SMA output connectors
(dual differential output). The device is quite sensitive to
impedance unbalance. If only one port of a differential pair
is used, terminate the other with a 50 Ω load.
LOOP FILTER
The loop filter schematic is included in the board schematic on
Figure 5. The loop filter component placements are clarified in
Figure 2.
C14
R11
C12
R9C15
C13
08909-003
Figure 2. Loop Filter Placement
REFERENCE SOURCE
The 10 MHz TCXO from Fox Electronics provides the necessary
reference signal. An external REFIN may be used if desired. In
this case, disable the on-board TCXO by removing R1 and R2.
R3 can be populated with 50 Ω to adjust impedance matching
of the evaluation board to the external reference source.

UG-110 Evaluation Board User Guide
Rev. 0 | Page 4 of 12
EVALUATION SETUP
HEADERS
EXTERNAL DC
SUPPLY
EXTERNAL DC
GND
HEADERS
TCXO
ADF4350
LOOP FILTER
LOCK DETECT LED
USB
POWER
LED
PLL
POWER
LED
USB POWER SWITCH
EXTERNAL POWER
SWITCH
USB CRYSTAL
AND PROCESSOR
REFERENCE IN/OUT
SPECTRUM ANALYZER
50Ω
TERMINATION
PC
OSCILLOSCOPE
(OPTIONAL)
(OPTIONAL)
08909-007
Figure 3. Evaluation Setup

Evaluation Board User Guide UG-110
Rev. 0 | Page 5 of 12
EVALUATION BOARD SOFTWARE
The control software for the EVAL-ADF4350 accompanies the
EVAL-ADF4350EB2Z on a CD. To install the software, use the
following steps:
1. Click setup.exe.
2. The install wizard guides you through the installation
process. The software is installed in a default directory
called C:/Program Files/Analog Devices/ADF4350.
3. To run the software, click the .exe file.
The main interface window appears (see Figure 4). Confirm
that USB OK is displayed on the right side of the screen. Other-
wise, the software has no connection to the evaluation board.
It is also possible to disconnect the USB by clicking the
Disconnect USB button. Should this happen, no data is sent
to the part. This function is to be used before disconnecting
the board from the USB connection. When the board is
connected again, click the USB connect button to enable the
programming of the part. This ensures the PC does not freeze
up when the USB cable is disconnected.
Use the Reference section to set the correct reference frequency
and reference frequency divider. The reference TCXO on the
evaluation board runs at 10 MHz. To force the device to operate
in integer-N mode, set the R divider so that the PFD frequency
(displayed in the Settings section) equals the channel spacing
(set in the Output Frequency section) and select the Integer-N
when possible check box (in the Options section).
The Outputs section controls the charge pump current setting,
the output power setting, and the multiplexer output setting.
Use the Output Frequency section to control the output
frequency. You may specify two frequencies, and select which
one the device operates at. For some frequencies, the device can
operate in two modes: the low end of the VCO band or the high
end, plus an extra divide by two. To control which mode is used,
select Minimum Output Divider in the Options section.
The device can be set to toggle between the two set frequencies
by selecting Alternate in the Dynamic section. The time spent
on each frequency is set in the Approximate Delay field. To
stop, click Stop. It is also possible to sweep from f1 to f2 with
the channel spacing resolution with an approximate time delay
on each frequency.
It is also possible to select Low Spur Mode or Low Noise Mode
for the frac-N mode in the Options section. You can also set the
cycle slip reduction bit.
The Settings section displays selected settings. Click Registers to
display every bit of the register settings. To download these to
the device, click Update ALL.
08909-008
Figure 4. Software Front Panel

UG-110 Evaluation Board User Guide
Rev. 0 | Page 6 of 12
EVALUATION BOARD SCHEMATICS AND ARTWORK
08909-004
Figure 5. Evaluation Board Schematic (Page 1)

Evaluation Board User Guide UG-110
Rev. 0 | Page 7 of 12
08909-005
Figure 6. Evaluation Board Schematic (Page 2)

UG-110 Evaluation Board User Guide
Rev. 0 | Page 8 of 12
0
8909-006
Figure 7. Evaluation Board Schematic (Page 3)

Evaluation Board User Guide UG-110
Rev. 0 | Page 9 of 12
08909-002
Figure 8. Evaluation Board Silk Screen

UG-110 Evaluation Board User Guide
Rev. 0 | Page 10 of 12
ORDERING INFORMATION
BILL OF MATERIALS
Table 1.
Qty Reference Designator Description
21 C1, C4, C5, C8, C17, C18, C21, C22, C25, C29, C53,
C54, C55, C57, C60, C61, C62, C63, C64, C65, C66
Capacitor, 0.1 μF, 10%, 0402, 16 V, X7R
13 C2, C3, C6, C7, C10, C16, C19, C20, C23, C24, C28,
C52, C56
Capacitor, 10 pF, 5%, 0402, 50 V, NPO
9 C9, C33, C36, C38, C41, C43, C46, C48, C51 Capacitor+, 22 μF, 10%, TAJ_A, 6.3 V, tantalum
10 C11, C12, C26, C27, C30, C31, C34, C39, C44, C49 Capacitor, 1 nF, 10%, 0603, 50 V, X7R
1 C13 Capacitor, 1.5 nF, 10%, 0603, 50 V, X7R
3 C14, C58, C59 Capacitor, 22 nF, 10%, 0603, 50 V, X7R
1 C15 Capacitor, 680 pF, 10%, 0603, 50 V, X7R
8 C32, C35, C37, C40, C42, C45, C47, C50 Capacitor+, 1 μF, 10%, TAJ_A, 16 V, tantalum
1 D1 LED_CHIP, light emitting diode
2 D2, D3 SS16, DO-214AC, Schottky diode, −1 A, 60 V
1 D4 Zener-diode-S, 6.8 V, 5%, SOT23, OT23
2 D5, D6 LED, LED_CHIP, light emitting diode
5 J1, J2, J3, J4, J5 SMA, SMA_CARD_EDGE_RF
2 J6, J7 HEADER-7X2POL, HEADER14-POL
6 J8 to J13 DNI, SMA_CARD_EDGE_RF
1 J14 Red, 4 mm, banana socket
1 J15 Black, 4 mm, banana socket
1 J16 USB mini-B connector (usb-otg)
4 L1, L4, L5, L8 Inductor, 0 Ω, 1%, 0603
4 L2, L3, L6, L7 Inductor, 3.9 nH, 5%, 0603, Coilcraft 0603CS
14 R1, R2, R13, R32, R33, R34, R35, R36, R37, R47,
R51, R52, R56, R58
Resistor, 0 Ω, 1%, 0603
13 R3, R5, R6, R8, R11, R14, R18, R46, R48, R53,
R54, R55, R57
Resistor, DNI, 1%, 0603
1 R4 Resistor, 4.7 kΩ, 1%, 0603
2 R7, R38 Resistor, 1 kΩ, 1%, 0603
1 R9 Resistor, 820 Ω, 1%, 0603
1 R10 Resistor, 100 Ω, 1%, 0603
1 R12 Resistor, 330 Ω, 1%, 0603
4 R15, R16, R17, R19 Resistor, 10 kΩ, 1%, 0603
8 R20, R22, R24, R26, R28, R30, R40, R42 Resistor, 220 kΩ, 1%, 0603
4 R21, R25, R29, R41 Resistor, 390 kΩ, 1%, 0603
4 R23, R27, R31, R43 Resistor, 120 kΩ, 1%, 0603
3 R39, R49, R50 Resistor, 2.2 kΩ, 1%, 0603
2 R44, R45 Resistor, 100 kΩ, 1%, 0603
2 SW1, SW2 SW_POWER, SW_SIP-3P, NKK SPST N/O momentary push button switch
9 T1 to T9 Testpoint
1 U1 ADF4350, LFCSP-32 PLL
4 U2 to U5 ADP3334 MSO8 adjustable LDO regulator
1 U6 CY7C68013-CSP, LFCSP-56, USB microcontroller
1 U7 24LC64, SO8NB, 64K I2C serial EEPROM
1 Y1 OSC_TCXO, 10.0 MHz, OSC_TCXO, FOX
1 Y2 XTAL-CM309S, 24 MHz, XTAL_CM309S, CM309S SMD crystal

Evaluation Board User Guide UG-110
Rev. 0 | Page 11 of 12
NOTES

UG-110 Evaluation Board User Guide
Rev. 0 | Page 12 of 12
NOTES
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD.Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and conditions
set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation Board until you
have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”) and Analog Devices, Inc.
(“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to Customer a free, limited, personal,
temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and agrees that the Evaluation Board is provided
for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted is expressly made subject to the following additional
limitations: Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board; and (ii) permit any Third Party to access the Evaluation Board. As used herein, the term
“Third Party” includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is NOT sold to Customer; all rights not expressly granted herein, including
ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all be considered the confidential and proprietary information of ADI. Customer may
not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of use of the Evaluation Board or termination of this Agreement, Customer agrees to
promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any
occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited to soldering or any other activity that affects the material content of the Evaluation Board.
Modifications to the Evaluation Board must comply with applicable law, including but not limited to the RoHS Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice
to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS” AND ADI MAKES NO
WARRANTIES OR REPRESENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICALLY DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED
TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL
PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF
THE EVALUATION BOARD, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL. ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE
AMOUNT OF ONE HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable
United States federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of
Massachusetts (excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby
submits to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
©2010 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
UG08909-0-3/10(0)
