Ancom IDAG065X9-A Series User manual

Model Number:
IDAG065X9-Ax (x=0, 1, 2 for PIM3 value)
Wide-band Directional MIMO Antenna, X-pol, 698-960/1710-2700MHz, 6.5-8.5dBi
Rev:2016-0-8i
*In pursuance of continual product improvement, the right to change specifications without prior notice is reserved.
1/2
Electrical Specifications
Frequency Range
MHz
698-864
870-960
1710-1880
1920-2170
2200-2500
2490-2700
Gain
dBi
6.5
7.0
8.5
8.5
8.0
7.5
Polarization
+/-45
Beam-width
Horizontal
deg
78
73
65
60
Vertical
70
55/65
75/55
VSWR
≤2.0:1
≤ 1.6:1
Isolation
dB
25
PIM3
IDAG065X09-A0
dBc
/
IDAG065X09-A1
≤-140@2x43dBm
IDAG065X09-A2
≤-150@2x43dBm
Power Handling
W
100
50
Impedance
Ω
50
Mechanical Specifications
Dimensions, HxWxD
mm (in)
315x200x75 (12.4x7.9x3.0)
Weight
kg (lb)
1.0 (2.2)
Radome Material and Color
ABS, white
Reflector Material
Aluminum
Radiating Element Material
Brass and PCB
Connector Type
2 x N-Female
Environmental Class
Indoor
Mounting
Wall mount with bracket
Shipping Dimensions, HxWxD
mm (in)
435x210x85 (17.1x8.3x3.3)
Shipping Weight
kg (lb)
1.2 (2.6)
Radiation Patterns
Co/X-pol
Horizont
al
pattern
Vertical
pattern
+ 45deg Port
-45deg Port
Features and Product Description
Broadband, coverage for 698MHz-2700MHz 2x2 MIMO application.
Typically used in micro-cell or in-building distribution of 2G/3G/LTE and
WLAN(Wi-Fi) services.
Low return loss and low PIM design.
Aesthetically pleasing and easy for in-building installations.

Model Number:
IDAG065X9-Ax (x=0, 2 for PIM3 value)
Wide-band Directional MIMO Antenna, X-pol, 698-960/1710-2700MHz, 6-10dBi
Rev:2016-0-8i
*In pursuance of continual product improvement, the right to change specifications without prior notice is reserved.
2/2
Note for Installation
Thanks for choosing our product! Before exciting installation, please read this guide carefully.
Make sure qualified personnel are hired for installing this product such as working at height
with safety awareness, tools operating skills, and etc.
This is low PIM designed product and be gentle to bend the jumper cable and fasten the
connectors.
Please check the items against the below packing list and make sure the product is in good
condition without any damage and none is missing.
Check the necessary installation tools below are prepared on site before the installation.
Find proper position and the flat surface of wall to mount this antenna based on the
coverage design and planning documents.
Mounting Instruction
STEP1: Mark the 4 drilling points by Mounting
Plate at the desired position on the wall. Drill 4
holes on the wall and tap the 4 plastic plugs
into them. Fix the Mounting Plate by screwing
the 4 tapping screws into the plastic plugs.
STEP2: Place the Antenna on the Mounting Plate
and make sure the antenna is securely hooked up
on the Mounting Plate.
STEP3: Joint the connectors with systems.
Packing List
List of Installation Tools
Antenna
1
Percussion Drill andΦ6mm bit
Mounting Plate
1
Phillips Screwdriver
St 4*25 Tapping Screw
4
6mm Plastic Plug
4
QC Check
