AND UA-1020-W User manual

Digital Blood Pressure Monitor
Model UA-1020-W
Instruction Manual Original
Manuel d’instructions
Traduction
Manual de Instrucciones Traducción
Manuale di Istruzioni Traduzione
Instructiehandleiding Vertaling
Bruksanvisning Översättning
Ohjekirja
Käännös
Instrukcja obsługi Tłumaczenie
使用手冊 翻譯
Talimat Kılavuzu Çeviri
ﻝﺎﻣﻌﺗﺳﻹﺍ ﻝﻳﻟﺩ ﻪﻣﺟﺭﺗ
ﺎﻤﻨﻫﺍﺭ ﻪﭼﺮﺘﻓﺩ ﻪﻤﺟﺮﺗ
1WMPD4002954D
English
Français
Español
Italiano
Nederlands
Svenska
Suomi
Polski
中文
TÜRKÇE
ﻲﺑﺭﻋ
ﯽﺳﺭﺎﻓ

English 1
Contents
Dear Customers.................................................................... 2
Preliminary Remarks ............................................................. 2
Precautions........................................................................... 2
Parts Identification................................................................ 4
Symbols................................................................................ 5
Operation Mode.................................................................... 7
Using the Monitor ................................................................. 8
Installing / Changing the Batteries ................................... 8
Connecting the Air Hose .................................................. 9
Connecting the AC Adapter.............................................. 9
Adjusting the Built-in Clock ........................................... 10
Selecting the Correct Cuff Size ....................................... 11
Applying the Arm Cuff ................................................... 11
How to Take Accurate Measurements............................. 13
Measurement................................................................. 13
After Measurement ........................................................ 13
Measurements .................................................................... 14
Normal Measurement..................................................... 14
Measurement with the SET Pressure ............................... 15
Measurement with the Desired Systolic Pressure ............ 15
Notes for Accurate Measurement ................................... 16
TriCheckTM Measurement .................................................... 16
Recalling the Memory Data ................................................. 18
What Is The IHB/AFib Indicator? .......................................... 19
What Is The AFib? ............................................................... 19
Pressure Bar Indicator ......................................................... 19
WHO Classification Indicator ............................................... 19
About Blood Pressure.......................................................... 20
What is Blood Pressure? ................................................. 20
What is Hypertension and How is it Controlled?.............. 20
Why Measure Blood Pressure at Home?........................... 20
WHO Blood Pressure Classification ................................. 20
Blood Pressure Variations............................................... 20
Troubleshooting ................................................................. 21
Maintenance ....................................................................... 22
Technical Data.................................................................... 22

English 2
Dear Customers
Congratulations on purchasing a state-of-the-art A&D blood pressure
monitor. Designed for ease of use and accuracy, this monitor will facilitate
your daily blood pressure regimen.
We recommend that you read through this manual carefully before
using the device for the first time.
Preliminary Remarks
This device conforms to the European Directive 93/42 EEC for Medical
Products. This is made evident by the mark of conformity.
(0123: The reference number to the involved notified body)
The device is designed for use on adults, not newborns or infants.
Environment for use. The device is for use to operate by yourself in the home
healthcare environment.
This device is designed to measure blood pressure and pulse rate of people
for diagnosis.
Precautions
Precision components are used in the construction of this device. Extremes
in temperature, humidity, direct sunlight, shock or dust should be avoided.
Clean the device and cuff with a dry, soft cloth or a cloth dampened with
water and a neutral detergent. Never use alcohol, benzene, thinner or
other harsh chemicals to clean the device or cuff.
Avoid tightly folding the cuff or storing the hose tightly twisted for long
periods, as such treatment may shorten the life of the components.
Take care to avoid accidental strangulation of babies or infants with the
hose and cable.
Do not twist the air hose during measurement. This may cause injury due
to continuous cuff pressure.
The device and cuff are not water resistant. Prevent rain, sweat and water
from soiling the device and cuff.
Measurements may be distorted if the device is used close to televisions,
microwave ovens, cellular telephones, X-ray or other devices with strong
electrical fields.
Wireless communication devices, such as home networking devices, mobile
phones, cordless phones and their base stations, walkie-talkies can affect this
blood pressure monitor.
Therefore, a minimum distance of 30 cm should be kept from such devices.

English 3
Used equipment, parts and batteries are not treated as ordinary
household waste, and must be disposed of according to the applicable
local regulations.
When the AC adapter is used, make sure that the AC adapter can be
readily removed from the electrical outlet when necessary.
When reusing the device, confirm that the device is clean.
Do not modify the device. It may cause accidents or damage to the device.
To measure blood pressure, the arm must be squeezed by the cuff hard
enough to temporarily stop blood flow through the artery. This may cause
pain, numbness or a temporary red mark to the arm. This condition will
appear especially when measurement is repeated successively.
Any pain, numbness, or red marks will disappear with time.
Measuring blood pressure too frequently may cause harm due to blood flow
interference. Check that the operation of the device does not result in
prolonged impairment of blood circulation, when using the device repeatedly.
If you have had a mastectomy, please consult a doctor before using the device.
Do not let children use the device by themselves and do not use the device
in a place within the reach of infants. It may cause accidents or damage.
There are small parts that may cause a choking hazard if swallowed by
mistake by infants.
Unplug the AC adapter when not in use during the measurement.
Use of accessories not detailed in this manual may compromise safety.
Should the battery short-circuit, it may become hot and potentially cause burns.
Allow the device to adapt to the surrounding environment before use
(about one hour).
Clinical testing has not been conducted on newborn infants and pregnant
woman. Do not use on newborn infants or pregnant woman.
Do not touch the batteries, the DC jack, and the patient at the same time.
That may result in electrical shock.
Do not inflate without wrappping the cuff around the upper arm.
Contraindications
The following are precautions for proper use of the device.
Do not apply the cuff to an arm with another medical electrical equipment
attached. The equipment may not function properly.
People who have a severe circulatory deficit in the arm must consult a
doctor before using the device, to avoid medical problems.
Do not self-diagnose the measurement results and start treatment by yourself.
Always consult your doctor for evaluation of the results and treatment.
Do not apply the cuff on an arm with an unhealed wound.
Do not apply the cuff on an arm receiving an intravenous drip or blood
transfusion. It may cause injury or accidents.
Do not use the device where flammable gases such as anesthetic gases
are present. It may cause an explosion.
Do not use the device in highly concentrated oxygen environments, such as a
high-pressure oxygen chamber or an oxygen tent. It may cause a fire or explosion.

English 4
Parts Identification
Movement Error Symbol
Battery Compartment
Display
Air Hose
Arm Cuff
DC Jack
START Button
Air Connector Plug
Air Socket
Display
WHO Classification Indicato
r
and Pressure Bar Indicato
r
MEMORY
Systolic
Pressure
Diastolic
Pressure
Pulse Rate
Battery Indicator
Heart Mark
1.5V Batteries
(R6P, LR6 or AA)
Clock Display
SET Button
Button
Button
Battery Cover
IHB/AFib symbol
AM / PM Mar
k
Cuff Fit Error Symbol
Average Pressure Settings
TriCheckTM Symbol
Proper Fit Range
Index Mark
Artery Position Mark

English 5
Symbols
Symbols that are printed on the device case and the AC adapter
Symbols Function / Meaning Recommended Action
Standby and Turn the device on.
Battery installation guide
Direct current
SN Serial number
Date of manufacture
Type BF: Device, cuff and tubing are
designed to provide special protection
against electrical shocks.
EC directive medical device label
WEEE label
Manufacturer
EU-representative
Polarity of DC jack
IP International protenction symbol
Keep dry
Symbols that appear on the display
Symbols Function / Meaning Recommended Action
Appears while measurement is in progress.
It blinks when the pulse is detected.
Measurement is in progress.
Remain as still as possible.
IHB/AFib symbol
Appears when an irregular heartbeat
is detected.
It may light when a very slight vibration
like shivering or shaking is detected.
TriCheckTM mode
Takes three consecutive measurements
automatically and displays the average
values of the three measurements.
Appears when a body or arm
movement is detected.
The reading may yield
an incorrect value. Take
another measurement.
Remain still during
measurement.

English 6
Symbols Function / Meaning Recommended Action
Appears during measurement when
the cuff is applied loosely.
The reading may yield an
incorrect value. Apply the
cuff correctly, and take
another measurement.
Previous measurements stored in MEMORY.
Average data
FULL BATTERY
The battery power indicator during
measurement.
LOW BATTERY
The battery power is low when it
blinks.
Replace all batteries with new
ones when the mark blinks.
Unstable blood pressure due to
movement during measurement.
Try the measurement again.
Remain still during
measurement.
The systolic and diastolic values are
within 10 mmHg of each other.
Fasten the cuff correctly,
and try the measurement
again.
The pressure value did not increase
during the inflation.
The cuff is not applied correctly.
PUL DISPLAY ERROR
The pulse is not detected correctly.
Blood pressure monitor internal error
Remove the batteries and
press the START button,
and then install the batteries
again. If the error still
appears, contact the dealer.
SYS Systolic blood pressure in mmHg
DIA Diastolic blood pressure in mmHg
PUL Pulse per minute
AM Data taken between 4:00 and 9:59
PM Data taken between 18:00 and 1:59
Pressure settings
Indicates the pressure value
previously set by the user.

English 7
Operation Mode
1. Normal Measurement
Press the START button. Blood pressure is measured and data is stored
within the device. The device can store the last ninety sets of data in
memory automatically.
2. Recalling the Data
Press the or button to recall the data in
memory. The average of all measurements is
displayed, as indicated in the figure at the right.
Then, each time the button is pressed, the
memory data is displayed as follows.
Average of all AM (morning) measurements
taken between 4:00 and 9:59.
Average of all PM (evening) measurements
taken between 18:00 and 1:59.
Most recent data (No.n, in the example,
No.35)
Last data (No.1)
For details on recalling the data, refer to the
section “Recalling the Memory Data”. (Refer
to page 18)
3. Deleting all Data Stored in Memory
Press both the and buttons. The mark
and the battery indicator appear. Press and hold
both the and buttons until the illuminated
mark starts blinking to delete all data stored in
memory.
4. Measurement with the Desired Systolic Pressure
Refer to page 15 for measurement with the desired systolic pressure.

English 8
Using the Monitor
Installing / Changing the Batteries
1. Remove the battery cover.
2. Remove the used batteries and
insert new batteries into the battery
compartment as shown, taking
care that the polarities (+) and (-)
are correct.
Use only R6P, LR6 or AA batteries.
3. Attach the battery cover.
CAUTION
Insert the batteries as shown in the battery compartment. If installed
incorrectly, the device will not work.
When (LOW BATTERY mark) blinks on the display, replace all batteries
with new ones. Do not mix old and new batteries. It may shorten the battery
life, or cause the device to malfunction.
Replace the batteries two seconds or more after the device turns off.
If (LOW BATTERY mark) appears even after the batteries are replaced,
make a blood pressure measurement. The device may then recognize the new
batteries.
(LOW BATTERY mark) does not appear when the batteries are drained.
The battery life varies with the ambient temperature and may be shorter at
low temperatures. Generally, four new LR6 batteries will last approximately
for one year when used twice for measurement each day.
Use the specified batteries only. The batteries provided with the device are
for testing monitor performance and may have a limited life.
Remove the batteries if the device is not to be used for a long time.
The batteries may leak and cause a malfunction.
Step 3
Step 2
Step 1
Step 1

English 9
Using the Monitor
Connecting the Air Hose
Insert the air connector plug into
the air socket firmly.
Connecting the AC Adapter
Insert the AC adapter plug into the
DC jack.
Next, connect the AC adapter to an
electrical outlet.
Use the specified AC adapter.
(Refer to page 23.)
When disconnecting the AC adapter from the electrical outlet, grasp and
pull the AC adapter body out of the outlet.
When disconnecting the AC adapter plug from the blood pressure
monitor, grasp and pull the AC adapter plug out of the monitor.
A
ir connector plug
Air socket
AC adapter plug
DC
j
ack

English 10
Press
Turn off
Year
Month
Day
Hou
r
Minute
Pressure
settin
g
mode
or
or
or
or
or
Using the Monitor
Adjusting the Built-in Clock
Adjust the clock prior to use.
1. Press the SET button until the year starts
blinking.
2. Select the year using the or button.
Press the SET button to set the current year
and move to month/day selection. The date
can be set anywhere between the years 2010
and 2059.
3. Select the month using the or button.
Press the SET button to set the current
month and move to day selection.
4. Select the day using the or button.
Press the SET button to set the current day
and move to hour/minute selection.
5. Select the hour using the or button.
Press the SET button to set the current hour
and move to minute selection.
6. Select the minute using the or button.
(Press the SET button to go to the pressure
setting mode. For details, refer to page 15.)
Press the START button to turn the device off.
Note: After three minutes of non-operation, the device
will turn off automatically.
When the clock has not been
set, the clock display indicates
dashes as shown to the right.
Holding down the or button
will change the value continuously.
Pressing the START
button will turn the
device off anytime.

English 11
Using the Monitor
Selecting the Correct Cuff Size
Using the correct cuff size is important for an accurate reading. If the cuff is
not the proper size, the reading may yield an incorrect blood pressure value.
The arm size is printed on each cuff.
The index and proper fit range, on the cuff, tell you if you are applying the
correct cuff. (Refer to Table "Symbols that are printed on the cuff" on the next
page)
If the index points outside of the range, contact your local dealer to
purchase a replacement cuff.
The arm cuff is a consumable. If it becomes worn, purchase a new one.
Arm Size Recommended Cuff Size Catalog Number
31 cm to 45 cm Large Adult Cuff CUF-F-LA
22 cm to 42 cm Wide Range Cuff CUF-I
22 cm to 32 cm Adult Cuff CUF-F-A
16 cm to 24 cm Small Adult Cuff CUF-F-SA
Arm size: The circumference at the biceps.
Applying the Arm Cuff
1. Wrap the cuff around the upper arm,
about 1 to 2 cm above the inside of
the elbow, as shown.
Place the cuff directly against the
skin, as clothing may cause a faint
pulse, and result in a measurement
error.
2. Constriction of the upper arm,
caused by tightly rolling up a
shirtsleeve, may prevent accurate
readings.
3. Confirm that the index points
within the proper fit range.
Do not roll up shirtsleeve tightly.
1-2 cm
A
ir Hose
Cuff
A
rtery position mar
k
Secure the fabric
fastener firmly.
Index and proper fit range

English 12
Using the Monitor
Symbols that are printed on the cuff
Symbols Function / Meaning Recommended Action
Artery position mark
Set the mark on the
artery of the upper arm or
in line with the ring finger
on the inside of the arm.
▲Index
REF Catalog number
Proper fit range for the adult cuff.
It's printed on the adult cuff.
Over range printed on the adult cuff
and wide range cuff.
Use the large adult cuff
instead of the adult cuff or
wide range cuff.
Proper fit range for the wide range cuff.
It's printed on the wide range cuff.
Proper fit range for the large adult cuff.
It's printed on the large adult cuff.
Under range printed on the adult cuff
and wide range cuff.
Use the small adult cuff
instead of the adult cuff or
wide range cuff.
Proper fit range for the small adult cuff.
It's printed on the small adult cuff.
It's printed on the large adult cuff and
small adult cuff.
Use the adult cuff instead
of the large adult cuff or
small adult cuff.
Lot number
Proper fit range
Large adult cuff
Wide range cuff
Adult cuff
Small adult cuff
WS
ALS
L
AL
AS

English 13
Using the Monitor
How to Take Accurate Measurements
For the most accurate blood pressure measurement:
Sit comfortably on a chair. Rest your arm on the table. Do not cross your
legs. Keep your feet flat on the floor and straighten your back.
Relax for about five to ten minutes before measurement.
Place the center of the cuff at the same level as your heart.
Remain still and keep quiet during measurement.
Do not measure immediately after physical exercise or a bath. Rest for
twenty or thirty minutes before taking the measurement.
Try to measure your blood pressure at the same time every day.
Measurement
During measurement, it is normal for the cuff to feel very tight. (Do not be
alarmed).
After Measurement
After measurement, press the START button to turn the device off.
Remove the cuff and record your data. After one minute of non-operation,
the device will turn off automatically.

English 14
Measurements
Before measurement, read the section “Notes for Accurate Measurement”
on page 16.
Normal Measurement
1. Place the cuff on the arm (preferably the left arm).
Sit quietly during measurement.
2. Press the START button.
All of the display segments are displayed.
Zero (0) is displayed blinking briefly.
The display changes, as indicated in the
figure at the right, as the measurement
begins. The cuff starts to inflate. It is normal
for the cuff to feel very tight. A pressure bar
indicator is displayed, on the left edge of the
display, during the inflation.
Note: If you wish to stop inflation at any time,
press the START button again.
3. When inflation is complete, deflation starts
automatically and (heart mark) blinks,
indicating that the measurement is in
progress. Once the pulse is detected, the
mark blinks with each pulse beat.
Note: If an appropriate pressure is not obtained, the
device starts to inflate again automatically.
To avoid re-inflation, see the
section “Measurement with the
SET Pressure” on the next page.
4. When the measurement is complete, the
systolic and diastolic pressure readings
and pulse rate are displayed.
The cuff exhausts the remaining air and
deflates completely.
5. Press the START button to turn the device off.
After one minute of non-operation,
the device will turn off automatically.
Note: Allow at least three minutes between
measurements on the same person.
At heart level
Measurement
in progress
Systolic pressure
Diastolic pressure
WHO classification
Pulse rate
Exhausts remaining
air automatically
Press
Pressurizing
Zero display
Starts inflation
A
ll of the displa
y
segments displayed
START

English 15
Turn off TriCheck
settin
g
mode
Measurements
The UA-1020-W is designed to detect the pulse and to inflate the cuff to a
systolic pressure level automatically.
If re-inflation occurs repeatedly, use the following methods.
Measurement with the SET Pressure
During the blood pressure measurement, re-inflation may occur.
A fixed pressure value can be set to avoid re-inflation.
1. At step 6 of the clock adjustment procedure
(see page 10), press the SET button to go to
the pressure setting mode. The current
setting blinks.
2. Press the or button to select a pressure
value about 30 mmHg or more above your
expected systolic pressure from the following.
AUTO : Automatic pressurization (default value)
180 : Pressure value of 180 mmHg (fixed)
210 : Pressure value of 210 mmHg (fixed)
240 : Pressure value of 240 mmHg (fixed)
3. Press the SET button to go to the TriCheck setting mode.
Press the START button to turn the device off. After three minutes of
non-operation, the device will turn off automatically.
The next measurement will be performed with the new pressure value.
Measurement with the Desired Systolic Pressure
Use this method when re-inflation occurs repeatedly even if the pressure value
is set to 240 in the procedure above or when the results are not displayed
even if the pressure decreases to 20 mmHg or less.
1. Place the cuff on the arm (preferably the left arm).
2. Press and hold the START button until a
number about 30 to 40 mmHg higher
than your expected systolic pressure
appears.
3. When the desired number is reached,
release the START button to start
measurement. Continue to measure
your blood pressure as described on
the previous page.
START
Refer to the previous page
for measurement
Press and hold the button
At heart level
Release the button
at the desired
systolic pressure
or

English 16
START
Notes for Accurate Measurement
Sit down in a comfortable position. Place your arm on a table with your
palm facing upward and the cuff at the same level as your heart.
Relax for about five to ten minutes before taking a measurement. If you
are excited or depressed by emotional stress, the measurement will
reflect this stress as a higher (or lower) than normal blood pressure
reading and the pulse reading will usually be faster than normal.
An individual's blood pressure varies constantly, depending on what you
are doing and what you have eaten. What you drink can have a very
strong and rapid effect on your blood pressure.
This device bases its measurements on the heartbeat. If you have a very
weak or irregular heartbeat, the device may have difficulty determining
your blood pressure.
Should the device detect a condition that is abnormal, it will stop the
measurement and display an error symbol. Refer to page 6 for the
description of symbols.
This blood pressure monitor is intended for use by adults. Consult with
your physician before using this device on a child. A child should not use
this device unattended.
The automatic blood pressure monitor’s performance may be affected by
excessive temperature or humidity, or altitude.
TriCheck
TM
Measurement
The TriCheckTM mode takes three consecutive measurements automatically
and displays the average values of the three measurements.
Selecting the TriCheckTM Mode
1. In the pressure setting mode, press
the SET button to enter the
TriCheckTM setting mode. The current
setting blinks.
2. Press the or button to turn the
TriCheckTM mode ON or OFF.
ON: TriCheckTM mode
OFF: Normal measurement mode (default value)
3. Press the START or SET button to
turn the device off. After three
minutes of non-operation, the device
will turn off automatically.
press
or
The current setting blinks
Change the setting
In the pressure setting mode,
or

English 17
Measurement Using the TriCheckTM Mode
1. Press the START button.
All of the display segments are
displayed.
Zero (0) is displayed blinking briefly
and the first measurement starts.
2. When the measurement is complete,
the systolic and diastolic pressure
readings and pulse rate are displayed,
then a one-minute countdown starts for
the second measurement.
3. After one minute, the second
measurement starts.
4. When the measurement is complete,
the average readings of the first and
second measurements are displayed,
then a one-minute countdown starts for
the third measurement.
5. After one minute, the third
measurement starts.
6. When the measurement is complete,
the average readings of the three
measurements are displayed and
stored in memory.
Notes:
During the measurement, the
TriCheckTM symbol is displayed.
To cancel the measurement, press
the START button. In this case, no
data is stored in memory.
When the cuff fit error symbol appears
during the first measurement, cancel
the measurement, reapply the cuff
correctly and start a new measurement.
After measurement, the average
data of the three measurements is
stored in memory.
No data will be stored, when
canceling the measurements,
before completion of the third
measurement.
At heart level
Press
A
ll of the display
segments displayed
First measurement
Second measurement
Third measurement
Results of the
first measurement
A
verage of the first and
second measurements
A
verage of the
three measurements
One minute after
One minute after
START

English 18
Recalling the Memory Data
Note: This device stores the last ninety sets of data in memory automatically.
1. Press the or button.
The average of all measurements and
the number of data are displayed.
(If no data, “0” is displayed. Press the
,or START button to turn the
device off.)
2. Each time the button (or the
button to display the data in the
reverse order) is pressed, the memory
data is displayed as follows.
Average of all AM (morning) measurements
taken between 4:00 and 9:59.
(In the example, 10 measurements. If
no data, “--” is displayed.)
Average of all PM (evening) measurements
taken between 18:00 and 1:59.
(In the example, 9 measurements. If
no data, “--” is displayed.)
Most recent data (No.n, in the
example, No.35)
Three seconds after the data number
display, the measurement data is displayed.
Last data (No.1)
Three seconds after the data number
display, the measurement data is
displayed.
3. After the last data is displayed, press
the button to return the average
display of all measurements.
4. Press the START button to turn the
device off. After one minute of
non-operation, the device will turn off
automatically.
A
verage of
all the data
Average systolic
Average diastolic
Average pulse
Press or
Most recent data
Systolic
Diastolic
Pulse
Last data (Oldest)
A
verage
of AM data
A
verage
of PM data
Average systolic
Average diastolic
Average pulse
Average systolic
Average diastolic
Average pulse
Systolic
Diastolic
Pulse
