Andersen 400 Series Guide

Read these instructions before starting procedure. For
additional information visit www.andersenwindows.com.
For questions call 1-888-888-7020.
Para obtener una versión en español de esta guía,
visite el sitio www.andersenwindows.com
· Use caution when working at elevated heights and around window and door openings. Follow the manufacturers’
instructions for ladders and scaffolding. Failure to do so could result in injury or death.
· Follow manufacturers’ instructions for hand and power tools. Always wear safety glasses. Failure to do so could result in
injury, product or property damage.
· Windows and doors can be heavy. Use safe lifting techniques and a reasonable number of people with enough strength
to lift, carry, and install window and door products. Heavier windows and doors will require mechanical assistance. Failure
to do so could result in injury, product or property damage.
· Metal fasteners and components could corrode when exposed to preservative-treated or fire-retardant treated lumber.
Use approved fasteners and components to fasten window or door. Failure to do so could cause a failure resulting in
injury, product or property damage.
Hinge Replacement &
Hinge and Hardware Adjustment
Product Series: A-Series, 400 Series
Product Type: Hinged Inswing Patio Doors
(Manufactured After November 2005)
“Andersen” and all other marks where denoted are trademarks of Andersen Corporation. ©2008-2023 Andersen Corporation. All rights reserved. 0005413 BC-00 04/13/23
Tools and Supplies Needed:Parts Included:
WARNING
Safety
Glasses
Phillips
Screwdriver
Flat Blade
Screwdriver
Pencil 5/32" Hex Key
(included with Patio Door)
Hinge (1)
#10 x 3" Screw (2)
#10 x 1-3/4" Screw (4)
#10 x 1" Screw (2)
▶ Hinge Replacement page 2.
▶ Hinge and Hardware Adjustment page 3.
Horizontal
Adjustment
Screw
Vertical
Adjustment
Screw

2
0005413
Fasten hinge to door panel using four (4)
#10 x 1-3/4" screws. Repeat steps 1-3
for all hinges being replaced.
3
1
2
▶Hinge replacement is complete.
Remove screws from hinge using a phillips screwdriver. Dispose of hinge and screws properly.
Apply replacement hinge and fasten to frame using two (2) #10 x 1" screws through top and
bottom holes and two (2) #10 x 3" screws through center holes.
▶Proceed to hinge and hardware adjustment, below, for operation check and hinge adjustment instructions.
#10 x 1"
Screws
(top and
bottom holes)
#10 x 3"
Screws
(center holes)
#10 x 1-3/4"
Screws
• Hinge replacement WILL NOT correct problems
resulting from improper door installation
Examples of improper installation include units
not being installed plumb, level, and square,
excessively bowed jambs, and/or crowned sills.
NOTICE IMPORTANT
• Make all horizontal adjustments rst. Horizontal adjustments correct
most problems. Vertical adjustments are rarely needed.
• Adjust hinges with door slightly open. The door panel should be
supported by all hinges for maximum hinge performance.
• Start adjustments at bottom hinge and move upward.
Hinge Replacement
Remove and replace only one
hinge at a time. Removal of more
than one hinge may result in door
panel falling and potentially
causing personal injury, product,
and/or property damage.
WARNING
Door Panel Frame
Door Panel Frame Door Panel Frame Door Panel Frame

3
0005413
1
Hinge and Hardware Adjustments
Panel Horizontal Adjustment (Side to Side)
2Panel Vertical Adjustment (Up and Down)
•Check for equal gap between panel and frame at top and bottom.
•Starting with the bottom hinge, turn vertical adjustment screw
clockwise (+) 1/2 turn and then continue turning until panel is
centered vertically in frame.
•Turn next hinge vertical adjustment screw clockwise (+) until panel
moves slightly, then turn counterclockwise (−) 1/4" turn. Repeat for
remaining hinges working upward.
• Check for equal gap between panel and frame along both sides.
• Starting with the bottom hinge, turn horizontal adjustment screw as shown
to adjust panel as needed. Repeat for remaining hinges working upward.
• Check that gap between panel and frame on latch side and hinge side is
equal to the thickness of the 5/32" hex key.
Turn counterclockwise
(IN) to move panel
toward hinge side jamb.
Turn counterclockwise
toward (−)
to lower panel
Turn clockwise
toward (+)
to raise panel
Turn clockwise (OUT)
to move panel away
from hinge side jamb.
Move all
hinges IN or
OUT to correct
gap and
center panel
in frame.
5/32"
Hex Key
5/32"
Hex Key
Horizontal
Adjustment
Screw
Vertical
Adjustment
Screw Bottom
View
During counterclockwise rotation, stop adjustment
when adjustment screw hits the back side of the cover
and resistance increases. Failure to do so could cause
product damage.
NOTICE
Equal gap
along top
and bottom
Equal gap
along both
sides

40005413
3
•Make a pencil mark where top of latch bolt strikes
latch receiver.
•Loosen blocker adjustment screw.
•Slide blocker up or down so lower surface of
blocker lines up with pencil mark.
•Tighten blocker adjustment screw.
•Close and lock panel(s).
Latch
Bolt
Blocker
Blocker
Adjustment
Screw
Pencil mark,
showing top
of Latch
Lower
Surface
Latch
Receiver
Door
Panel
•Adjust tabs in latch receiver, hook bolt receivers, and ush bolt receivers using a at blade screwdriver to achieve adequate
weatherstrip compression when the door panel is closed.
•Adjust tab on hook bolt receivers if hook bolts do not stay engaged.
Latch Receiver/Trim
AP/PA
(Astragal)
Latch Receiver/Trim
AR/AL
(Jamb)
Flush Bolt Receiver
Head PA/Sill AP
(Astragal)
Flush Bolt Receiver
Head AP/Sill PA
(Astragal)
Hook Bolt Receiver
AL/AR
(Jamb)
Hook Bolt Receiver
AP/PA
(Astragal)
Tab
4
Tab
Tab
Tab
Tab
Tab Tab
Blocker Adjustment
Tab Adjustment
▶Hinge and hardware adjustment is complete.
