Anderson Lighting MF18806 User manual
1. Brightness and color temperature ( CCT ) stepless adjusted.
2. Memory function, restore to the luminance of last time close light when
open light again, don’t need to repeat adjusting the light.
3. Adjustable lamp head.
4. Heavy base.
5. Professional eyes-protect light, which make up of no blue light harmful
and no flicker LED, It is less harmful for long time use.
6. The rendering of real colors. The color rendering index ( Ra ) of this lamp
is more than 95, it is good for painter, designer and so on.
Introduction
Thank you for choosing
LED FLoor Lamp.Please read this user manual
carefully
and keep it for future reference. If you need any assistance, please contact
us by email with your order number and details.
Specification
P
Characteristics
ackage Contents
1 × LED Floor Lamp 4 × Iron Pipes
1 × Lamp Base 1 × Remote Controller
1 × User Manual
●
●
●
●
●
●1 × Power Adapter withCable
Product Structure
User Manual
Installation
It’s very easy to install, as shown below:
Step 1: Connect the iron pipe with the light base
by spinning clockwise.
Step 2: Then connect the iron pipe with the other
iron pipes by spinning clockwise.
Step 3: At last, connect the iron pipe with the LED
round light by spinning clockwise.
The installation is finished, then plug in adapter,
you can touch control or remote control the light.
Usage
There are two ways to control: Touch control or Remote control.
Touch control
Please touch the touch bar to control the lamp
Remote Control
The remote distance is within
49.2 ft
.It is magnetic so that you can put
it on whatever contain iron, such as the iron pipe, patch and so on.
Set a 1h timer ( Light get several flicker mean 1h timer is Successful
set).
Short press to turn on/off light.
Short/Long press to enhance the CCT (3000K to 6000K) as you like.
Short/Long press to lower the CCT (6000K to 3000K) as you like.
Short/Long press to enhance the brightness as you like.
Short/Long press to lower the brightness as you like.
Short press to be the max brightness and CCT immediately.
Short press to enter leisure mode,
Short press to enter reading mode.
Short press to enter breastfeed mode.
Short press to enter night light mode.
Short press to enter work mode.
How to adjust the lighting angle?
360 degree adjustable lamp head and 180 degree lamp neck
Product Care
●
Please do not bend violently the lamp head to avoid damage when
adjusting the angle of the lamp.
.
.
.
.
.
●
Please read the user manual before use
●
Suggest Indoor use.
.
It is non waterproof. Do not use this product in
humid environments or at high temperatures
●
Cut off the power when cleaning it or not using it
●
Donotuse it exceed the voltage, the proper voltage for US is AC110-
120V, 60Hz
●
Please use the included power adapter, do not use other brand’s
adapter. Do not plug or unplug the power cord with wet hands
●
Please stop use it if there is any defective issues found in the product
Guarantee
Model MF18806
Material Iron + PC
Light Source 72pcs LED
Power Consumption 12W
Luminous Flux 1200lm
Dimmable Yes (10%-100% full dimming)
Color Temperature
Remote control: 3000K to 6000K Stepless
adjustment OR
Touch control:3000K-4000K-5000K-6000K
Lifespan 50,000Hrs
Battery for Remote Controller AAAbattery x 2
Remote Distance Within 15M / 49.2 FT
Input Voltage AC100-240V 50/60 Hz
Adapter Voltage DC24V 0.5A
Product Size 8.7"(D) x 69"(H)
Make sure the remote control is matching the lamp :
power plug in the lamp , use the remote to control the lamp. Normarlly
the remote controls the lamp perfectly ;
If remote control doesn't work for the lamp , please re-match the Remote
and Lamp.
Matching procedure :
2 Power plug in , then the light on automatically.
3 Continue hold pressing the power switch buttom for seconds , when
LED lights flashes , matching successfully.
1 Press the Remote control's switch botton( power switch button), hold
pressing until match successfully.
How to match the lamp and remote control?
Contact us for more supports:
(E-mail: [email protected]).
●
Turn ON:
Short press the " "botton to turn on. Or short touch any place on the
touch pad can turn on the lamp with the according brightness level.
●
Adjust Color Temperature
Short press the top touch area to change the color temperature 3000K - 4000K -
5000K - 6000K.
●
1 Hour Timer Setting
Long press the “ ”botton until the indicator light flash to set 1 Hour timer.
●
“Brightness +/-” Setting:
Slightly slide your fingers along the touch pad to set the brightness level.
Also can be used as Turn on key.
●
Turn OFF:
Short press the " " botton to turn off.
12
Remote-control Unit
FCCComplianceNotice
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1) Thisdevicemaynotcauseharmfulinterference,and
(2) thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired
operation.
Anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoid
theuser'sauthoritytooperatetheequipment.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
to part 15 ofthe FCC Rules. These limits are designed to providereasonable protection against harmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequency
energyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcan
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interferencebyoneormoreofthefollowingmeasures:
‐Reorientorrelocatethereceivingantenna.
‐Increasetheseparationbetweentheequipmentandreceiver.
‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
