EMX34/CK34 Cardkey Interface
Board Installation Guide
The EMX34/CK34 Cardkey Interface Board is designed to convert the signals fromup to four
Cardkey Model #L47 readers (or two Model#L40-6 readers, which drawmore current) into
Wiegand format, which canbe read by the ACX700/780 family of controllers.
Warranty Registration
Your warranty is effective for 18 months starting on the date the system is shipped.
Site/System Setup Requirements
Before you install the controller, you should map out where you plan to install each inter-
face. When planning the sites, be aware of dimensions, power requirements, and
environmental requirements.
Dimensions
The EMX 34 printed circuit board is approximately 6.125 × 3.625” (160 × 92 mm).
Power Requirements
The EMX 34 receives power from anACX 700/780 to supply the Cardkey reader.The EMX
34 requires an additional 24 VAC (1 amp) which powers the Cardkey reader incandescent
lamps (LEDs). The EMX 34 board converts the power to 9 VDC output for the lamps.
Environmental Requirements
The EMX 34 operates in the same environment as any Infinet controller.
Controlling Tomorrow’s World
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 2
Version A
Reproduction or distribution forbidden.
Copyright  1992–1996 by Andover Controls.
Subject to change without notice.
Order No. 30-3001-494
Copyright 1992–1996
Andover Controls Corporation
300 Brickstone Square
Andover, Massachusetts 01810 USA
All Rights Reserved.
Published by the Engineering Department at Andover Controls Corporation.
IMPORTANT NOTICE
This product is subject to change without notice. This document does not
constitute any warranty, express or implied. Andover Controls Corporation
reserves the right to alter capabilities, performance, and presentation of this
product at any time.
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 3
Parts Included and Required
Unpacking
When unpacking the unit, do not damage the packaging material—you must reuse it if you
ship the product back for repair.
Parts Included with the EMX 34
• EMX 34 Printed Circuit Board
• Two Plastic PCB Mounting Brackets
• Two Plastic DIN Rail Mounting Brackets
• Hardware Installation Guide (this manual)
Additional Items Required
• An ACX 700 or 780 Family Controller
• Cardkey Readers
• An Extra Cable and Female Molex Connector per Reader
• AC Power Cable
• Output Wires
• Two End Clamps
• DIN Rail
• Enclosure
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 4
Mechanical Installation
The EMX 34 is designed to be mounted to a DIN rail within an enclosure.
Mounting the EMX 34 to a DIN Rail
Refer to the illustrations for more details on the parts involved in the mounting procedure.
1. Slide an end clamp onto the DIN Rail. Tighten the screws when the clamp is in the
position desired.
2. Slide a DIN Rail mounting bracket under the PCB bracket until flush on the back side.
3. Slide the DIN Rail mounting bracket with PCB bracket (back/flat side first)onto the DIN
Rail. Position the flat side up against the end clamp.
DIN Rail
End Clamp
PCB Mounting Bracket
DIN Rail
Mounting Bracket
Assembling Mounting Brackets to DIN Rail
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 5
4. Insert the top of the printed circuit board into the PCB bracket.
5. Slide the other DIN Rail mounting bracket onto the remaining PCB bracket.
6. Slide the DIN Rail bracket and PCB bracket onto the DIN Rail, flat side last. Carefully
slide the assembled brackets onto the bottom of the printed circuit board until tight.
7. Slide another end clamp onto the DIN Rail. Position it up against the flat side of the
brackets.
8. Tighten the end clamp screws to secure.
P1
P2
P3
P4
P5
P6
P7
P8
P9
C 1993
MADE IN USA BY ANDOVER CONTROLS 05-1000-793 EMX34 REV A
+
–
5VDC
LED
1
∅
GND
5VDC
LED
1
∅
GND
5VDC
LED
1
∅
GND
5VDC
LED
1
∅
GND
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
F1
DIN
End Clamp
DIN Rail PCB Mounting Bracket
DIN Rail Mounting Bracket
Attaching the PCB to Brackets
Top of PCB
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 6
Wiring the EMX 34
The EMX 34 must be connected to an ACX 700/780 family controller, to an AC power
source, and to a Cardkey reader.
Warning
Be sure that all equipment is not receiving electrical power while you are wiring the controller, or
you could receive an electrical shock that is life-threatening.
Warning
Be sure that wiring and installations comply with local, state, and national electrical codes.
Refer to the figure of the printed circuit board.
The EMX 34 printed circuit board has four inputs (P2, P4, P6, P8) and four outputs (P3,
P5, P7, P9). The inputs from the Cardkey reader are wired on the right-hand side of the
physical board, and the outputs on the left-hand side.
Cardkey Reader ACX 700/780
∅
DATA 1
Data
Lamp
Driver
Converter
LED
LED LED
Channel 1
Data Conversion
Channel 3
(same as above)
The schematic to the right represents the data
conversion action of the EMX 34. Data flows
from the Cardkey reader to the ACX 700/780,
and is converted into Wiegand format. The Cardkey
reader’s lamps are switched ON or OFF as a function
of the status of the ACX controller’s LEDs.
The same wiring schematic applies to each of the
four channels.
Note: In this schematic, data conversion is
represented from left to right, which is not
the same direction as the physical board.
∅
DATA 1
Data
Lamp
Driver
Converter
LED
LED LED
Channel 2
(same as above)
∅
DATA 1
Data
Lamp
Driver
Converter
LED
LED LED
Channel 4
(same as above)
∅
DATA 1
Data
Lamp
Driver
Converter
LED
LED LED
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 7
The EMX 34 converts the Cardkey input data into Wiegand format, which can be read by
the ACX 700/780 controllers. The dotted-line arrows in the EMX 34 PCB figure indicate the
flow of data from the inputs to the outputs.
P1
P2
P3
P4
P5
P6
P7
P8
P9
C 1993
MADE IN USA BY ANDOVER CONTROLS 05-1000-793 EMX34 REV A
+
–
5VDC
LED
1
∅
GND
5VDC
LED
1
∅
GND
5VDC
LED
1
∅
GND
5VDC
LED
1
∅
GND
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
F1
24 VAC
Power
Connection
EMX 34 Printed Circuit Board
1 amp picofuse
P2/P3 = Channel 1
P4/P5 = Channel 2
P6/P7 = Channel 3
P8/P9 = Channel 4
Inputs
(from Cardkey readers)
Outputs*
(to ACX)
*Please note that on the REV A board, ø and 1 outputs are incorrectly marked (switched).
This drawing reflects the REV A board.
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 8
Wiring the EMX34 to an ACX Controller
1. Locate the Wiegand outputs, along the left-hand side of the EMX 34 printed circuit
board (P3, P5, P7 P9). Each output includes five connections.
Note that on the REV A board, the 1 and Ø terminals are labeled incorrectly.
2. Strip the end of an 18 AWG wire. Insert it into the appropriate terminal block connector
according to the diagram and tighten the screw.
3. Repeat this procedure for the remaining four wires.
Wiring AC Power to the EMX 34
1. Locate the terminal labeled P1 in the upper left-hand corner of the printed circuit board.
2. Connect the stripped ends of a 24 VAC (±20%) external power supply to the
appropriate terminals and tighten the screws.
Should you need to replace the 1 amp socket picofuse, it is located at F1 on the printed
circuit board.
Wiring the EMX 34 to an ACX 700/780
ACX 700/780 EMX 34
+5V
LED
1/DATA
0/CLK
GND
5VDC
LED
∅
(1 on rev A)
1 (∅on rev A)
GND
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 9
Wiring the Cardkey Reader to the EMX 34 Interface Board
Each Cardkey input on the EMX34 takes 6 wires. There are four inputs, located along the
right-hand side of the printed circuit board (P2, P4, P6, and P8).
1. Locate the existing gray cable on the back side of the Cardkey reader. Strip the end
of the cable to expose the wires.
2. Strip the ends of the black, white and red wires.
3. Following the wiring diagram below, place the appropriate wires into the correct
terminals and tighten the screws. Insert the shield into the GND terminal.
P2
5VDC
DATA
GND
LED
PWR
RED
LED
GREEN
LED
5VDC
LED
PWR
RED
EMX 34 PCB
Cardkey Reader
existing cable (for reader)
(1)
(2)
(3)
(4)
(5)
(6)
Red
White
Black
Shield
Black
Red
White
Shield
extra cable (for LEDs)
Wiring the EMX 34 to the Cardkey Reader and LEDs
Molex
Connector
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 10
Wiring the LEDs to the EMX 34
1. Locate the plastic Molex connector with the four whitewires on thebackofthe Cardkey
reader.
One wire is connected to male pin 4 and one to pin 5, and two wires are connected to
pin 3. Pin numbers 3, 4, and 5 power the LEDs.
2. Obtain a supplementary Cardkey cable, number 913002/A715 style 2095 300V with a
female Molex connector attached.
If you need to wire the female Molex connector, follow the figure below.
Pins 3, 4, and 5 are the only pins required in the connector. From the extra cable, the
black wire is connected to pin 3, the white wire to pin 4 and the red to pin 5.
3. Plug the Molex connector into the one on the back of the Cardkey reader.
4. Strip the other end of the supplementary Cardkey cable to expose the wires.
5. Strip the ends of the black, white, and red wires.
6. Following the two preceding figures, place the appropriate wires into the correct
terminals and tighten the screws.
EMX 34 Cardkey Unit
5VDC (pin6)
LED
RED
GREEN
DATA (pin 2)
RED (5 VDC)
WHITE (DATA)
GND (pin 1) BLACK (GND)
PWR (pin 5)
LED (pin 4)
LED (pin3)
SHIELD (GND)
Molex pin 3 (LED PWR)
Molex pin 5 (RED LED)
Molex pin 4 (GRN LED)
GND (pin 1)
Molex Connector
1
4
25
36
Molex Connector Pinouts
on Cardkey Reader
Note: The EMX 34 pin numbers correspond to the screws on the EMX 34 printed circuit board.
Technical Manuals Online! - http://www.tech-man.com

EMX 34 Installation Guide 11
Powering Up the EMX34
1. Be sure the 24 VAC power source is wired properly; be sure all three wires are
connected.
2. Turn on the AC power source (or close the connection) and the interface starts
automatically.
Troubleshooting
For information on how to assign point numbers and program the outputs, seethe SX 8000
Programmer’s Guide or the Andover Controls
Infinity CX Programmer’s Guide.
If you have problems with the Infinet controller after installing the module, see the ACX 700
or 780 Installation Guide, and the
Infinity Network Configuration Guide.
Technical Manuals Online! - http://www.tech-man.com
