Miranda DENSITE series DAP-1781 Instruction Manual

DENSITÉ series
DAP-1781
8 Channel Digital Audio Processor
with: Dolby Decoder
Dolby-E Encoder
Dolby-D Encoder
upMAXTM Upmixer option
Guide to Installation and Operation
M769-9900-224
5 July 2013
Miranda Technologies
3499 Douglas-B.-Floreani
St-Laurent, Québec, Canada H4S 2C6
Tel. [phone]
Fax. [phone]
www.miranda.com
© 2013 Miranda Technologies

GUIDE TO INSTALLATION AND OPERATION
Electromagnetic Compatibility
This equipment has been tested for verification of compliance with FCC Part 15, Subpart B requirements
for Class A digital devices.
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference, in
which case the user will be required to correct the interference at his own expense.
This equipment has been tested and found to comply with the requirements of the directive
2004/108/CE:
•EN 55022 Radiated emissions, Class A
•EN 55022 Conducted emissions, Class A
•EN 61000-3-2 Harmonic current emission limits
•EN 61000-3-2 Voltage fluctuation and flicker limitations
•EN 61000-4-2 Electrostatic discharge immunity
•EN 61000-4-3 Radiated EMF immunity – RF
•EN 61000-4-4 Electrical fast transient immunity
•EN 61000-4-5 Surge immunity
•EN 61000-4-6 Conducted immunity
•EN 61000-4-8 Power frequency magnetic field
•EN 61000-4-11 Voltage dips, short-interruption and voltage variation immunity
Manufactured under license from Dolby Laboratories. Dolby and the Double-D symbol are trademarks of Dolby
Laboratories.
How to contact us:
For technical assistance, please contact the Miranda Technical support center nearest you:
Americas
Tel: [phone]
Fax: [phone]
9:00 am – 9:00 pm EST
[e-mail]
Asia
Tel: [phone]
Fax: [phone]
9:30 am – 6:00 pm GMT+8
[e-mail]
Europe, Africa
Tel: [phone]
Fax: [phone]
9:00 am – 6:00 pm GMT
[e-mail]
Emergency Support 24/7
Tel: [phone]
-or-
Tel: [phone]
and choose menu option 2
Middle East
Tel: [phone]
Fax: [phone]
9:00 am – 5:30 pm GMT
[e-mail]
China
Tel: [phone]
e-mail:
9:30 am – 6:00 pm GMT+8
[e-mail]
France
Tel: [phone]
Fax: [phone]
9:00 am – 5:00 pm GMT+1
[e-mail]
Visit our web site at www.miranda.com

GUIDE TO INSTALLATION AND OPERATION
DAP-1781 | 3
Table of Contents
1DAP-1781 8 Channel Digital Audio Processor..................................................................... 5
1.1 Introduction ......................................................................................................................................... 5
1.2 Features.............................................................................................................................................. 6
1.3 Applications......................................................................................................................................... 6
1.4 Functional Block Diagram................................................................................................................... 7
1.5 Simplified Block Diagram.................................................................................................................... 8
1.6 Card front-edge layout ........................................................................................................................ 8
2Installation ............................................................................................................................... 9
2.1 Unpacking........................................................................................................................................... 9
2.2 Installation in the Densité frame.......................................................................................................... 9
2.2.1 Rear Panel Options.............................................................................................................. 10
3Local control using the Densité frame control panel.......................................................... 12
3.1 Status LED and Report..................................................................................................................... 12
3.2 Menu for local control........................................................................................................................ 16
4Remote control using Miranda’s iControl system............................................................... 24
4.1 Audio Processing.............................................................................................................................. 26
4.1.1 Audio Processing - CH 1-4 to CH 13-16 tabs...................................................................... 26
4.1.2 Audio Processing - CONFIG tab.......................................................................................... 28
4.1.3 Dolby-E Alignment sub-tab.................................................................................................. 28
4.2 Audio Output..................................................................................................................................... 29
4.2.1 Audio Output - CH 1-2 to CH 7-8 tabs................................................................................. 29
4.2.2 Audio Output – Auto-Mix...................................................................................................... 31
4.3 Dolby................................................................................................................................................. 32
4.3.1 Dolby Decoder tab ............................................................................................................... 32
4.3.2 Dolby-E Encoder tab............................................................................................................ 35
4.3.3 Dolby Digital (AC-3) Encoder tab......................................................................................... 36
4.4 Metadata ........................................................................................................................................... 38
4.4.1 Input Status.......................................................................................................................... 38
4.4.2 Source.................................................................................................................................. 38
4.4.3 Control tab............................................................................................................................ 38
4.4.4 Input tab............................................................................................................................... 40
4.4.5 Generator tab....................................................................................................................... 40
4.4.6 Loudness tab........................................................................................................................ 41
4.5 Dynamic Processing ......................................................................................................................... 43
4.5.1 CH 1 to CH 8 tabs................................................................................................................ 43
4.5.2 CH 9 to CH 16 tabs.............................................................................................................. 44
4.6 UPMIX/DOWNMIX............................................................................................................................ 45
4.6.1 UPMIX/DOWNMIX – Config tab .......................................................................................... 45
4.6.2 UPMIX/DOWNMIX – UPMIX tab ......................................................................................... 45
4.6.3UPMIX/DOWNMIX – DOWNMIX tab................................................................................... 46
4.7 upMAXTM Linear Acoustics Upmixer Option ..................................................................................... 49
4.8 Channel Status.................................................................................................................................. 51
4.8.1 Channel Status - Status AES1-4 & Status AES5-8 tabs ..................................................... 51
4.8.2 Channel Status – Src/Dest ID tab........................................................................................ 51

GUIDE TO INSTALLATION AND OPERATION
4 | DAP-1781
4.9 Audio Type........................................................................................................................................ 52
4.10 RALM tab.......................................................................................................................................... 53
4.10.1 RALM Connections tab........................................................................................................ 53
4.10.2 RALM – Meter Ballistics Config tab ..................................................................................... 53
4.11 A-BUS ............................................................................................................................................... 54
4.12 Reference Input................................................................................................................................. 55
4.13 Rear Type ......................................................................................................................................... 56
4.14 Factory / Presets............................................................................................................................... 56
4.14.1 Factory................................................................................................................................. 56
4.14.2 User Presets ........................................................................................................................ 56
4.14.3 GPI....................................................................................................................................... 56
4.14.4 Profiles ................................................................................................................................. 57
4.15 Options.............................................................................................................................................. 58
4.16 Alarms Configuration......................................................................................................................... 59
4.17 Info .................................................................................................................................................... 60
5Specifications........................................................................................................................ 61
6Document History.................................................................................................................. 63
Appendix A – Dolby Digital Main Channel Output Functions .................................................. 64
Appendix B – Default Dolby-E Metadata Parameters ............................................................... 65
Appendix C – Metadata Input/Output Serial Port...................................................................... 66
Appendix D – Examples of Applications with Optional Cards................................................. 67

DAP-1781 | 5
1 DAP-1781 8 Channel Digital Audio Processor
1.1 Introduction
The DAP-1781 is an eight-channel high quality digital audio processor designed to work alone or with a
wide range of video converters, frame synchronizer proc/amps of the Densité series.
The card features two distinct processing blocks: Input and Output. The input processing includes Dolby
detection, Tone generator, delay adjustments, level controls and phase correction. Delay components
include a fixed delay of up to 2 seconds as well as a video tracking delay that will automatically track the
varying saw tooth delay introduced by an associated video frame synchronizer.
The output processing block includes full channel shuffling, an additional gain/attenuation stage and
mixing. Each odd output channel is a mix of any two input channels, and a 4-channel mixing is available
on the even output channels.
Additional audio functions such as a 16 channel dynamic processing (compressor/limiter and expander)
and/or Downmixing (5.1 to LtRt) and Upmixing (2.0 to 5.1) are available as options.
The DAP-1781 offers the possibility to integrate a Dolby-E encoder, a Dolby-E and AC-3 decoder, a Dolby
Digital AC-3 encoder or an upMAXTM Upmixer module. One module at a time can be installed on the card.
The use of a 16 channel card-to-card audio bus allows the DAP-1781 to work with one video card and one
other audio processor card. When connected to a video card, the DAP-1781 can process 8 channels of
audio originating from the video card; once processed, the signals are sent back to be embedded, and are
also available at the digital outputs.
Along with the audio channels, the Audio bus carries the timing, delay signaling and Dolby Metadata.
When combining cards together all audio processing is synchronous and in phase, ensuring proper
alignment and matched delay.
User-defined channel identification data may be encoded in the AES status bits. An input audio signal
status is also available indicating input signal presence or overload.
The card is housed in a (DENSITÉ) frame, with a single or double width rear connector panel. Based on
the rear module installed, the DAP-1781 is compatible with the AES3 or AES-3id digital audio standard.

GUIDE TO INSTALLATION AND OPERATION
6| DAP-1781
1.2 Features
•Stand-alone 8 channel audio processor and delay.
•8 channel processing of embedded audio signals.
•Fixed delay and up to 8 video frames tracking delay
•Full channel shuffling on the outputs
•2 and 4 channel mix-down
•Audio metering data for audio levels and phase over IP.
•Dolby-E compatibility
•Dolby-E/AC-3 decoder, Dolby-E encoder or Dolby AC-3 encoder option
•Dolby-E placement correction
•Dolby Metadata insertion or extraction
•Control and modification of the Dialnorm value.
•Digital audio inputs and outputs
•Balanced AES3 or unbalanced AES3-id I/Os
•-96 to +12 dB of input and output level adjustments (0.5 dB steps)
•Locks to video card, URS frame reference or AES1 input
•Internal digital EBU tone generator
•Absence signal delay and threshold adjustable per channel
•Input and output Overload detection
•All settings through frame control panel or remotely
•Status LED and alarms remote reporting
1.3 Applications
•With an FRS-1xxx in incoming feeds applications with a SDI input signal and discreet audio.
•With an XVP-18xx or other processing card to provide audio upmix as well as discreet I/O’s.
•With a video card to decode Dolby-E and feed it back for embedding.
•With a video card to encode Dolby-E and feed it back for embedding.
•Stand alone or with a video card to encode Dolby-AC3 after master control.
•Stand alone Dolby-E/AC3 decoder,
•Stand alone Dolby-E encoder,
•Stand alone Dolby AC3 encoder,
•Stand alone 4 AES audio processor.

GUIDE TO INSTALLATION AND OPERATION
DAP-1781 |
7
Clko
ABUS IN 16 Channels
Swap
L-R
ABUS
SELECT
1 - 8
or
9 - 16
Shuffler 64 > 16
Level Level
A B
Level Level
A B
C D
Level
Level
A B
Level
Level
A B
C D
Level
Level
A B
Level Level
A B
C D
Level
Level
A B
Level Level
A B
C D
1
2
3 4
5
6 7
8
8 Ch
ALM
2 Ch.
MSB.
1-2
3-4
DIT
5-6 7-8
ABUS OUT 64 Channels
Dolby Detection
Fixed Delay + Tracking Delay
16
9 8
1
8 1
From Video Card To/From Video Card
To 2nd Audio Card To/From 2nd Audio Card
and/or 2nd Video Card
MetaData
Lock
Circuit
Video Tracking Delay
V-Out Clock
URS
Slt 20
URS
Slt10
AES
N°1
DAP-1781
DIR
SRC
DIT
DIT DIT
DIR
SRC
DIR
SRC
DIR
SRC
DBE
&
AC3
DEC
*
6 1
6 1
7
8
7
8
16
9
2Ch
AUX
OUT
16
9
RS422
receiver
MetaData
V-in-Clock
Clock Out
Clock Out
Output Time
Input Time
Dolby Detection
Dolby Detection
Clki
Internal
Inputs
Sel 16>2
Inputs
Sel 16>6
UP Mixer
Tone
9 to 14
8
78
1
6
1
16
9
16
9
Inputs
Sel 16>8
Inputs
Sel 16>6
16
9
9 to 14 & 15-16
16
9
8
1
Outputs Router 2 > 2
* Only one of these options can be installed at a time.
8
1
Outputs Router 2 > 2
Downmixer DBE/AC3 Enc*
DUP-701*
MetaData
GPI x4
input
Phase + Level + OVLD + NSD
Dynamics : Lim + Comp + Exp
Leq Loudness Measurement
Dolby-E Guard Band
1.4 Functional Block Diagram

GUIDE TO INSTALLATION AND OPERATION
8| DAP-1781
1.5 Simplified Block Diagram
1.6 Card front-edge layout
STATUS
D1
SELECT
SW1
Select
Button
Status Led
DAP-1781
ABUS connector
DAP-1781 BLOCK DIAGRAM
Remote
Control
Select
Status
Monitor
OUT
AES Outputs
(110/75 Ω)
8
16
48 x 16 Shuffler
48 16
Microcontroller
1
21
2
Reference
From DIR1
16 x Overload 8 x Peak meters, 4 x Phase meters
ABUS Video card / Audio cards link
VIDEO
Intra Frame
OUTPUT
PROCESSOR
INPUT PROCESSOR
16 x No Signal
Ref. IN
ABUS Select
Compressor - Limiter - Expander
Up or Down Mixer
16
16x Level
ABUS IN
ABUS OUT
3
4
4x DIR & SRC
Opt. Dolby Decoder or DUP-701
L & R Swap
Dolby Detection
Tone
AES Inputs
(110/75 Ω)
Metadata
Input
(RS422)
3
4
Metadata
Output
(RS422)
4x DIT
Optional Dolby Encoder
Metadata
Fixed & Variable Delay
Ext/Int
Leq Loudness Measurement
Dolby-E Guard Band
Phase & Level

GUIDE TO INSTALLATION AND OPERATION
DAP-1781 |
9
2 Installation
2.1 Unpacking
Make sure you have ordered and received the DAP-1781 and its associated rear panel. If any of the
following items are missing, contact your distributor or Miranda Technologies Inc.
•DAP-1781 8-Channel Digital Audio Processor
•One of the DAP-1781 Rear Panels (see figures on page 6)
•An A-BUS flat cable
2.2 Installation in the Densité frame
The DAP-1781 must be mounted in a DENSITÉ frame. The installation includes both the DAP-1781
module, and the rear panel module. It is not necessary to switch off the frame’s power when installing or
removing the card.
Detailed instructions for installing cards and their associated rear panels in the Densité frame are given in
the Densité Frame manual.
When the DAP-1781 is used in conjunction with a video module such as XVP-1801 and/or another DAP-
1781, the A-BUS flat cable must be installed between the A-BUS connectors on the front card edges.
•Note: for a two card installation, use the two end connectors of the flat cable and leave the
middle one unplugged.
XVP-1801
UAP-XXXX
DAP-1781

GUIDE TO INSTALLATION AND OPERATION
10 | DAP-1781
2.2.1 Rear Panel Options
Single rear panels AES3 or AES3-id compatible:
HD15-pin Female
DSUB Connector Connection
1 AES 1 Signal
2 AES 2 Signal
3 AES 3 Signal
6 AES 1 Shield
7 AES 2 Shield
8 AES 3 Shield
10 AES 4 Shield
13 AES 4 Signal
A choice of HD-15 adapters sold by Miranda:
•A cable adapter SUB-HD15 male to four
female 75 Ohm BNC coaxial connectors is
available from Miranda product number
"BOC-DE15-4BNC-1".
•A HD-15 to terminal block adapter is available
from Miranda product number "NSH15M".
Dual rear panels AES3 or AES3-id compatible:
METADATA:
The Metadata input and output are provided through two
RS422 asynchronous serial ports.
If a termination is needed at the Metadata input, it should
be placed on the Weco connector with the cable (there is
no termination on the rear panel or on the DAP-1781).
For a direct connection of the Metadata output to a
Dolby DP571 (Dolby-E encoder), use the following
wiring:
9-pin female
D-connector Connection Weco
1 Shield
2 NC
3 TX B Metadata OUT +
4 Ground Ground
5 NC
6 Ground
7 NC
8 TX A Metadata OUT -
9 Shield
DAP-1781-DEC-110-SRP
+ G - + G -
AES OUT
1A
+ G -
2
+ G -
1
4
3
+G -
+ G -
AES IN
META OUT
DAP-1781-ENC-110-SRP
+ G- + G-
AES IN
1A
+ G -
2
+ G -
1
4
3
+G -
+G -
AES OUT
META IN
DAP-1781-110-DRP
AES OUT
+ G - + G -
+ G - + G -
2 RIGHT
2A
AES IN IN
1A
+ G -
2
+G -
14
3
+ G -
OUT
+ G -
+ G -
2R
+ G -
METADATA
DAP-1781-75-DRP
+ G -
+ G -
IN
OUT
METADATA
AES IN
AES OUT
2
1
3
4
2
1
3
4
DAP-1781-DEC-75-SRP
+ G - + G -
4 x AES OUT
AES IN
+ G -
1R
1L
2L
+ G -
META OUT
AES
IN
DAP-1781-ENC-75-SRP
+ G - + G -
4 x AES IN
AES IN
+ G -
1R
1L
2L
+G-
META IN
AES
OUT
1
5
611
15
10
1
5
611
15
10
