andrews L32/143 User manual

PROPANE & BUTANE
GAS FIRED STORAGE
WATER HEATERS
HI-FLO RANGE
Models
L32/143, L65/169,
L81/251, L62/309,
L54/399,
Permanent Pilot,
Piezo Ignition
‘E’/‘F’ Series
STANDARD RANGE
Models
L24/31, L32/35, L40/36,
L63/71, L84/74
Permanent Pilot,
Auto Ignition ‘G’ Series
INSTALLATION
GUIDE,
OPERATION
AND SERVICE
MANUAL
THIS MANUAL MUST BE KEPT WITH THE APPLIANCE
