ANEP BOX-C User manual

ANEP BOX-C
www.anepstore.com
PIT EMERGENCY TELEPHONE SYSTEM FOR LIFT

ANEP BOX-C Version #1 09/22/2014 2
SUMMARY
TECHNICAL CHARACTERISTICS PAGE 4
1.1 - Technical characteristics
1.2 - Factory settings
1.3 - Connecting ANEP BOX-C module
RECOMMANDATIONS PAGE 6
PROGRAMMING MODE PAGE 7
3.1 - Enter programming mode
3.1.1 - Exit programming mode
3.1.2 - Addressing
3.1.3 - Simplified programming
3.2 - GSM Mode
3.3 - Programming numbers
3.3.1 - Programming memories 101/102/103
3.3.2 - Programming a pause
3.3.3 - Erase a number
3.4 - Memory attribution
3.4.1 - Transfer method
3.4.2 - Programming table for a single call
3.5 - Enabling and adjustment of parameters
3.5.1 - Conversation timeout
3.5.2 - Listen to call identification
3.5.3 - Cyclic test / periodicity
3.5.4 - Listen data transfer
3.5.5 - Changing the access code programming
3.5.6 - Gain setting in intercom machinery and firefighter modes
3.5.7 - Conguration of the dual call mode
3.6 - Selection of communication protocol
3.6.1 - ANEP protocol
3.6.2 - P100 protocol
3.7 - Adjusting the level of emissions of DTMF codes
CONNECTING THE FLOOD SENSOR (OPTION) PAGE 15
4.1 - Flood sensor input
4.2 - Flood sensor installation
4.3 - Detection timeout
1
2
3
4

ANEP BOX-C Version #1 09/22//2014 3
OPERATION PAGE 16
5.1 - Technician call from the pit
5.2 - Automatically hang up (voice mode)
CALL TO ANEP’S VOICE SERVER (SVA) PAGE17
6.1 - Enable call to SVA
6.2 - Making the call to SVA
6.3 - Tests made
6.3.1 - Audio reception test
6.3.2 - ANEP BOX-C serial number verification
6.3.3 - Installation telephone number check
6.3.4 - Audio test
6.3.5 - End of test
KEYPAD PROGRAMMING PAGE 19
5
6
7

ANEP BOX-C Version #1 09/22/2014 4
TECHNICAL CHARACTERISTICS
1.1 - Technical characteristics
• Conforms to european standards EN81-28 and EN81-70*
• Voice module integrated
• Powered by analogue phone line.
• Multifrequency dialing
• Automatic Hook
• Automatic answer
• Automatic or manual calibration of volume and gains
• Recognition of the call location
• Installation identification sent to ANEPCenter®or website anepanywhere.com
• Programmable by 12 key keypad
• 2 inputs from the pit flooding detector
• 1 dual fonction key : passenger trapped acknowledge and test call to ANEP voice server
• 1 key for technician alarm
• Up to 6 telephone numbers may be stored
• Automatic calling of a 2nd number if the 1st is engaged or doesn’t answer
• EEPROM memories without battery nor maintenance
• Programmable remotely via ANEPCenter®
1.2 - Factory settings
• Access code : * 1 2 3
• Call timeout : 3 minutes
• Periodic calls : 3 jours
*Specication EN81-28 Emergency alarm for new lifts since october 2003.
Specication EN 81-70 security rules for the construction and installation of lifts
Part 70 ; accessibility to lifts for all people including the handicaped.
1

ANEP BOX-C Version #1 09/22//2014 5
1.3 - Connecting ANEP BOX-C module
phone line
Dry contact ood
sensor
Powered ood
sensor

ANEP BOX-C Version #1 09/22/2014 6
RECOMMANDATIONS
before handling any ANEP products, ensure the equipement has been
disconnected from all power supplies.
The performance of telephone line equipement depends largely upon the characteristics of the
telephone line.
Particular care must be taken when cabling the phone line to avoid damaging the standard line
characteristics.
Check cabling (especially if they link several motor rooms).
• Type of cable,
• cable passage ( Hight / Low voltage ),
• Parasites ( Ventilators, generators ),
• Etc ...
2

ANEP BOX-C Version #1 09/22//2014 7
PROGRAMMING MODE
Important :
• Access to the programming mode is only possible if the phone line is hung up.
( Beware if several modules share the same line )
• The BOX-C keypad is used to program all the parameters.
• To avoid unwanted modifications, the programming mode is protected by an access
code : *1 2 3
• This code may be modified by the technician ( 1 to 7 digits ) (See page 14)
3.1 - Enter programming mode
Enter * followed by the access code to enter programming mode
Example : using the factory default code
*1 2 3
The unit plays a melody
... Then 2 beeps are made every 20 seconds
3.1.1 - Exit programming mode
when the unit has been programmed
 Press the key « *»
Finish programming, the unit plays a melody
Nota: If no key is pressed for over 3 minutes, the unit will automatically exit the
programming mode.
The unit plays a melody
3

ANEP BOX-C Version #1 09/22/2014 8
3.1.2 - Addressing
Several BOX-C modules may be installed on the same telephone line (max 8).
The address of EVERY module must be configured.
After entering the acces code to enter programming mode, enter the following sequences :
# 303 then 1 # if module 1 ( lift 1 ) or
# 303 then 2 # if module 2 ( lift 2 ) or
# 303 then 3 # if module 3 ( lift 3 ) or
# 303 then 4 # if module 4 ( lift 4 ).
Note : Module = ANEP BOX-C
Configuration example
Ligne téléphonique ( RTC )
BOX 1 BOX 2 BOX 3 BOX 4
BOX-C 1 BOX-C 2 BOX-C 3 BOX-C 4
BOX 1 BOX 2
BOX-C 1 BOX-C 2
GSM
Lift
Lift
Pit
Pit
Phone line

ANEP BOX-C Version #1 09/22//2014 9
3.1.3 - Simplified programming
BOX-C automatically detects wheter the call button is NO or NC. It is
therefore necessary to connect the call button BEFORE connecting inputs
and the telephone line
KEYS SEQUENCE COMMENTS
Access code to enter programming mode (Factory default : *123)
#001# Erasing of configuration and
telephone numbers
#101 Telephone number + #1st Call center phone number
#102 Telephone number + #2nd Call center phone number
#103 Telephone number + #3rd Call center phone number
#104 Telephone number + #Data
#105 Telephone number + #Periodics calls
#303 Module number + #n° module
from 1 to 4
Exit programming mode
FACTORY SETTINGS
• Access code to programming mode : *1 2 3
• Call timeout : 3 minutes
• Hang up : Automatic
• Periodic test call : 3 days
*
*

ANEP BOX-C Version #1 09/22/2014 10
3.2 - GSM mode
The GSM mode should be activated when BOX-C is connected to a GSM gateway.
To activate this mode:
In programming mode:
Enter the sequence #405#
To come back to normal mode (PSTN)
In programming mode:
Enter the sequence #406#
3.3 - Programming numbers
NOTE : 101 = Principal emergency call number / 102 = Secondary emergency call number
103 = Third emergency call number
3.3.1 - Programmaming memories 101/102/103
In programming mode :
- example for the principle call number
 Enter the sequence « #1 0 1 »
 Enter the telephone number followed by the key « # »
3.3.2 - Programming a pause
When installed behind a PABX, a prefix and a pause may be necessary before getting a
external line
To program a PAUSE (2 seconds), press the key « *»
Example : Pause after a prefix 0(for memory 101)
# 101 0 *0 1 4 5 6 9 2 8 0 0
 press the « #» key to validate the number

ANEP BOX-C Version #1 09/22//2014 11
3.3.3 - Erase a number
 Enter the sequence : « # » then, the memory number, then « #»
Example : Erase the number and memory 101 # 101 #
Nota : If no key is pressed for over 20 seconds, the unit plays a «BEEP» and returns to the
start of the memory selection part of the programming mode.
3.4 - Memory attribution
3.4.1 - Transfer method
The BOX-C may be programmed to interface with the call center, utilizing the available software and
specifications.
To communicate with call centers, ANEP unit can transfer its ID information and establish a two-way
voice communication either :
• In a single calls,
• or two seperate call.
The recommanded method (with respect to European specifications), is to make a single call
(the delay time is optimized.
3.4.2 - Programming table for a single call.
Telephone N° Type of data Type of communication Call center
Memory # 101 Passenger and tech alarm Data & audio Main call center
Memory # 102 Passenger and tech alarm Data & audio Backup call center
Memory # 103 Passenger and tech alarm Data & audio Backup call center
Memory # 104 Remote end of alarm Data Main call center
Memory # 105 Periodic call Data Call center for periodics calls
Memory # 106 Alarm data Data ANEPanywhere or client call center

ANEP BOX-C Version #1 09/22/2014 12
3.5 - Enabling and adjustment of parameters
3.5.1 - Conversation Timeout
Conversation timeout from 1to 99 minutes (factory default = 3minutes)
En mode programmation :
 Enter the sequence : # 2 0 1
Then enter the conversation timeout (from 1to 99) followed by « # »
3.5.2 - Listen to call identification
In programming mode :
 Enter the sequence #105
 Enter the phone number for receiving data by the central reception with a FT 2008 , FT
1001 or FT 4004 modem and software ANEPCENTER® or compatible frontal.
 Press the key « #»
A «site record» must first be established in the software ANEPCENTER®
(refer to the manual ANEPCENTER®)
During programmation mode exit, BOX-C performs a periodic call immediately
NOTE: During cyclic call, the central (AnepCenter or compatible) receiving the call can
reprogram the clock of the C-BOX.
3.5.3 - Cyclic test / Periodicity
In programming mode :
 Enter the sequence #301
 Dial the number of days for the periodicity of the cyclic call 1, 2 or 3.
Default: 3 days. example: 2 days = 301 # 2 #
3.5.4 - Listen data transfer
To enable the technician working on the lift to know that the C-BOX module is in communication with
a reception central, all data exchanges are audible (low level).
NOTE: access to the programming mode is not possible during a phone call.

ANEP BOX-C Version #1 09/22//2014 13
3.5.5 - Changing the access code programming
In programming mode :
Enter the sequence #002
Enter the new programming code (1 to 7 digits) and «#»
Confirm new programming code (1 to 7 digits) and «#»
It is important to carefully note the new code.
The loss of this code imposes the mandatory return of the unit at the factory.
3.5.6 - Gain Setting in intercom machinery and reghter modes
Ability to independently adjust the Speaker and microphone gains used for
Intercom machinery and reghter module modes.
These settings do not change the settings for the cabin alarm functions.
Microphone gain settings:
After entering the access code programming
Press the # 407 and a value of 1 to 15, then #
(1 = min / 15 = max gain)
Loudspeaker gain settings:
After entering the access code programming
Press the # 408 and a value of 1 to 15, then #
(1 = min / 15 = max gain )

ANEP BOX-C Version #1 09/22/2014 14
3.5.7 - Conguration of the dual call mode
The dual call mode allows a call to a caretaker post (voice only), before making a call to
the call center(data and voice). In addition, if the function « Acknowledgement of a
trapped passenger call « is enabled, the caretaker will have to acknowledge the call by
entering the sequence « #1 « on his phone keypad. Without this acknowledgment, BOX-C
will call back to the call center up to 6 times.
Conguration of the dual call mode :
To congure the dual call mode, enter in programming mode and dial the sequence #206#
The « telephone « memories should be programmed as follows :
memory 101 : phone number of the caretaker
memory 102 : phone number of the call center
Sequence of an alarm call :
When the emergency elevator telephone button is pushed, BOX-C calls the number in
memory 101 (caretaker).
Then it calls the number in memory 102 (call center).
If the number called by memory 101 (caretaker) or 102 (call center) is (are) busy,
the corresponding numbers are called back up to 6 times.
Disabling dual call mode :
To disable the dual call mode, enter in programming mode and dial the sequence #207#
3.6 - Selection of communication protocol
3.6.1 - ANEP Protocol
Default protocol, or set by the following key sequence :
After entering the access code programming, press # 200 then 0, then #.
3.6.2 - P100 Protocol
P100 protocol is set by the following key sequence :
After entering the access programming, press # 200 then 1, then #.
3.7 - Adjusting the level of emissions of DTMF codes
Ability to adjust the transmission power DTMF codes to avoid echo phenomena when the
BOX-C is connected to a GSM gateway.
By default power is set to -8 dBm.
After entering the access code programming
Press # 409 then a value of N 0-12 then #
Powser (dBm).

ANEP BOX-C Version #1 09/22//2014 15
CONNECTING THE FLOOD SENSOR (OPTION)
4.1 - Flood sensor input
ANEP BOX-C possesses a function which allows the detections of water in the pit.
An optional kit consisting of a sensor and bracket may be connected to the corresponding input.
Two types of flood sensor can be connected:
- A flood sensor having a free dry contact potential to connect to the input :
- A flood sensor with a powered output (230V max) to be connected to the input:
ANEP BOX-C automatically detects whether the water sensor
is NO or NC, it is therefore necessary to connect the sensor
BEFORE the telephone line.
4.2 - Flood sensor installation
The sensor may be NO or NC.
The sensor ( option) must be installed
in the following way in the pit :
- The floaters at lower extremity above water level.
- The connection and programming
must be done in « ... » conditions,
i.e. no water , condition « normal ».
Water will be detected when floater rises (see diagram).
The start and the end of the event
are transmitted to the call center (memory 104).
4.3 - Detection tiemout
The time before the information is taken
into account for the start and end of the event
can be programmed between 1to 99 minutes.
In programming mode :
 Enter the sequence « # » et « 3 » « 0 » « 2 » followed by the time in minutes
(from 0 to 99 minutes)
The unit plays a melody
Enable by pressing #when the timeout is 0, then the event «FLOOD» is disabled
DÉTECTIONNORMAL
OU
FLOTTEUR
Sonde
contact sec
Sonde avec
sortie alimentée
(max 230V)
4
Flood sensor
input
Dry contact ood
sensor
Powered ood
sensor
OR
DETECTION

ANEP BOX-C Version #1 09/22/2014 16
OPERATION
5.1 - Technician call from the pit
4 Push the BOX-C alarm button.
ANEP BOX-C call the call center.
During silent periods, beeps are made every 6 seconds to indicate that the unit is still on line
5.2 - Automatically Hang Up (Voice mode)
The unit automatically Hang Up if an eng aged signal is detected or if the call timeout is reached.
ANEP BOX-C plays a melody 10 seconds before hanging up at the timeout limit.
Note : If the called number is eng.gd or does not answers = (10 rings), the unit calls the secondary
telephone number in its memory. Each number is clled alternatelly 6 lines maximum.
5

ANEP BOX-C Version #1 09/22//2014 17
CALL TO ANEP’S VOICE SERVER (SVA)
6.1 - Enable call to SVA
Enter the access code to programming mode then press the SVA button (green key).
Special case : make a call to SVA from from behind a PABX :
Pressing the «0» key at the end of the sequence means that the prexe «0» will be dialled
before the SVA number.
Direct line : *1 2 3 (Factory code) « SVA » then *
FABX. : *1 2 3 (Factory code) « SVA » puis 0
6.2 - Making the call to SVA
Start the call from the car, car roof or under car unit within 2 minutes of enabling the call to SVA.
6

ANEP BOX-C Version #1 09/22/2014 18
6.3 - Tests made
6.3.1 - Audio reception test
- The dialling and data transmission are audible in the loud-speaker.
6.3.2 - ANEP BOX-C serial number verification
- The serial number of the unit is annouced by the SVA.
6.3.3 - Installation telephone number check
- The telephone number of the caller is annonced by SVA.
6.3.4 - Audio test
- A vocal message can be recorded and play back immediately by the SVA
so that the microphone and speaker of the unit are tested.
6.3.5 - End of test
The end of the test is indicated by a series of beeps.
To perform another test, it is necessary. to go trough the SVA call enable procedure again.

ANEP BOX-C Version #1 09/22//2014 19
KEYPAD PROGRAMMING
Programming parameters
Enter & exit programming mode
*+ <Access code > Enter programming mode
* Exit programming mode
#0... Programming of parameters
#001# Erasing parameters and phone numbers
#002...# New acces code
#1... Telephone numbers.
#101...# Main telephone number for Emergency elevator telephone calls
#102...# Secondary telephone number for Emergency elevator telephone calls
#103...# Third telephone number for Emergency elevator telephone calls
#104...# Call center telephone number to transfer data after voice
#105...# Telephone number for periodic calls
#106...# Telephone number for internet server
#2... Communication
#200...# Selection of communication protocol
#201...# Voice call timeout (1 to 99 minutes)
#202# Call acknowledge by operator function enabled
#203# Call acknowledge by operator function disabled
#206# Dual calling mode (call to a caretaker) enabled
#207# Dual calling mode (call to a caretaker) disabled
#3... Configuration
#301...# Test call period (1,2 or 3 days)
#302...# Alarm button recognition time (10 to 64 in 1/10 s)
#303...# Module address (1 to 8)
#4... Configuration
#403# Line voltage low ( > = 20V)
#404# Line voltage normal ( > = 28V)
#405# GSM enabled
#406# Analog phone line mode enabled
#407...# Microphone volume adjustment (De 1 à 15).
#408...# Loudspeaker volume adjustement(De 1 à 15).
#409...# Adjusting the level of emissions of DTMF codes
7

ANEP BOX-C Version #1 09/22/2014 20
NOTE
