Instruction Manual
42959557
Adjustable Gaming Microphone

specification
01 02 Features
PRODUCT DATE
Polar Response
Microphone setup
Power socket
-1- -2-
Plug one of the USB cable into the power socket in the microphone, and
connect the other end to computer. The power indicator light will turn blue if it
is working properly.
Height and Width：150mm/40mm
Sensitivity：- 45±3dB
Output impedance：< 680 Ω
Operation voltage: DC5V, 800mA
Current consumption： 150uA ≤ IDDS ≥ 450uA
S/N ratio：68db
Max.Input Sound Pressure Lel：110dB
Turn the volume button
If you do not want to spread
the voice out, you could
directly connect the 3.5mm
port of headphone to the
microphone input port.
to a minimum to turn off
the microphone sound
!

General operation
1. The microphone is powered by your device’s USB port, meaning that in
most instances you can just plug the microphone in and get started right
away. For non-standard USB ports, a powered USB hub may be required.
An ideal starting point for the reference is to place microphone directly
in front of the lead singer 15 cm (6") distance. Moving the vocalist a little
closer will make the vocal sound more intimate and full, while moving
the vocalist back will give the vocal a little more ‘air’ or room sound,
and will reduce the proximity effect (increased bass or low frequency
response when the sound source is very close).
Placement of the microphone and relative to the vocalist may be varied on
several factors including room acoustics, the vocal performance, and
whether the vocalist has a high or deep voice.
Experimentation should be made with the angle from which the
microphone is addressed, as different results can be achieved when the
vocalist is ‘off-axis’ to the microphone (and the gold dot).
Setting your input level:
To adjust your input level from within your recording software, refer to
the manual provided by the software developer.
Microphone placement：
04
05 General operation
15cm (6”)
Diagram 4 - Positioning the microphone for vocals
-3- -4-
The microphone has been set to an ideal internal gain setting, without the
need for physical level adjustments on the microphone body. Any
necessary level adjustments to set the ideal recording level can be made
from within your recording program, or via your computer’s system
preferences.
2.It is a “Plug& Play” USB device, supports mac computer, Windows 7/8/10
or later.
30
Power requirements

Click on ‘Sound’ to open the sound options.2.
Open the ‘Input tab’. 3.
4.
From here, select the ‘STORM’ from the list of devices, and adjust the input
level using the slider.
1.
Preferences.
Click on the Apple symbol at the top left of your screen, and select System
Diagram 6 -Accessing Mac OS System Preferences
Diagram 7-1 - Opening ‘Sound’ options
Diagram 7-2 - Adjusting microphone input level
-5- -6-
Microphone
To manually adjust your input level via your computer's system preferences, use the
following instructions relevant to your device platform/operating system. Connect the
other end to computer and check if the power indicator light turn to blue to make sure
it works properly.
60 General operation 70 General operation
Adjusting the input level on a Mac OS computer:

Open the Start menu and click on ‘Control Panel’1.
2.
3.
Open the ‘Sound’ preferences from within the Control Panel folder.
90 General operation
devices.
Adjust the input level using the slider.
Adjusting the input level on a Windows computer:
4.
Diagram 8-1 -Accessing Windows Control Panel Diagram 9-1 - Selecting the microphone inputdevice
Diagram 9-2 - Selecting the microphone inputdevice
Open the ‘Recording’ tab and double click on ‘STORM’ from the list of
Diagram 8-2 - Opening ‘Sound’ options
-7- -8-
80 General operation

21 NOTE
Select the “Microphone" option in the category.6.
Figure10-2-Select the "Microphone" option in "Sound"
Diagram 11-1- Tick to listen to this device
-9- -10-
11 General operation
Choose Open Sound settings.5.
Figure10-1-Choose Open Sound settings.
10 General operation
Right click to open the sound panel
7.Open listening from Microphone Properties.
1. Do not cover the microphone grille with your hand.
2. Regular maintenance is recommended to avoid electricity erratic and acoustic
problems.
3. Do not disassemble or throw into fire or water, to avoid damage.
4. Wipe with a dry or slighty damp cloth.
5. To take care of the children, to ensure that they do not play the microphone
as a toy.
