RICE COOKER
INSTRUCTION MANUAL
MODEL NO: RC-10CD003
Please read the User Manual carefully before use and keep it in a safe place for
future reference.

2 | P a g e
IMPORTANT SAFETGUARDS
READ ALL INSTRUCTIONS CAREFULLY BEFORE FIRST USE.
1. To reduce electric shock, risk of fire or injury, please read the operating instructions carefully
before using the appliance for the first time and keep them for future reference.
2. Never immerse the appliance in water or other liquids.
3. Never operate the appliance if any cable or part has been damaged or malfunctioned.
4. For electrical safety, appliance should only to be repaired by a qualified electrical person.
5. Children and infirm person are not aware of the hazards of an electric appliance. Therefore,
never allow them to operate the appliance unless they are properly supervised.
6. Please turn OFF and unplug the appliance before cleaning, maintenance or relocation, and
whenever it is not in use
7. This appliance is for household use only.
8. Do not place any objects on the appliance.
9. Please place the power cord in the right place in order to avoid tripping the unit over.
10. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instructions concerning use of the appliance by a person responsible for
their safety.
11. Children should be supervised to ensure that they do not play with the appliance.
12. When the supply cord is damaged, it must be replaced by manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
13. The appliance should be installed at minimum distance of 10cm from the wall or other
obstacles.
14. Do not use bug sprays or other flammable cleaners on the unit and keep away from any fire
and heat sources.
15. This appliance is for household use only. Do not use outdoors.
16. The power cord must be plugged into the wall outlet with earthing.
17. Always keep the rice cooker unplugged when not in use.
18. Do not put the cooker on a wet or unstable place, or near a heating range to avoid deformity.
19. To prevent damage to the inner cooking pot, do not heat the pot on a stove. Never use other
containers in the rice cooker.
20. Do not cover the cooker with a cloth, as this may warp or discolor the outer lid.
21. The steam vent is very hot during cooking. Keep face and hands away from outer lid and
steam vent.
22. To protect against electric shock, do not immerse the appliance and electric cord in water or
any liquid, do not allow any liquid to fall on the electric parts.
23. If the power cord and damaged, DO NOT USE. The supply cord must be replaced with the
same type and size only. If unsure, consult a qualified electrical person for advice.

3 | P a g e
24. This appliance is intended to be used in household and similar applications such as:
- Staff kitchen areas in shops, offices and other working environments;
- Farm houses;
- By clients in hotels, motels and other residential type environments;
- Bed and breakfast type environments
25. Do not use this appliance for any other purpose but its intended use. Do not use in moving
vehicles or boats. Do not use outdoors. Do not use on a sink drain board. Misuse may cause
injury.
26. Do not operate the appliance without water, as it may damage the heating element.
WARNING: The heating element surface is subjected to residual heat after use.
27. Do not use attachments or accessories which are not recommended by the manufacturer.
They may cause malfunction or injury
28. The rice cooker should be operated in a separate electrical circuit from other operating
appliances. If the electrical circuit is overloaded with other appliances, the appliance may not
operate properly or activate the household circuit breaker/fuse.
29. Always make sure the outside of the inner cooking pot is dry prior to use. If the inner pot is
place in the cooker when wet, it may damage or cause the product to malfunction.
IMPORTANT! Rice should not be left in the inner pot with the Keep-Warm function for more
than 12hrs.
30. This appliance is not intended to be operated by means of an external timer or a separate
remote-control system.
WARNING: Electric Shock Hazard. Avoid spillage on the power connector.
NOTE: To avoid injury, malfunction or damage, do not tilt or move the unit during
operation.

4 | P a g e
PRODUCT PARTS
CONTROL PANEL
a. Digital Display
b. White Rice Button
c. Saute Button
d. Brown Rice Button
e. Keep Warm/ Power Button
f. Steam Button

5 | P a g e
BEFORE FIRST USE
Remove all packaging from the rice cooker.
Wash the inner pot, spoon, measuring cup, steam tray and glass lid in hot soapy water. Rinse
well in clear water and dry carefully.
Wipe the cooker body with a damp cloth. Dry thoroughly.
Check that the voltage of your electricity supply is the same as that indicated on the rating plate
of the appliance.
Ensure the appliance is stable and well-supported.
Check the lid has no cracks or other visible signs of damage,
Ensure there are no objects in the rice cooker.
Do not use abrasive cleaners or scouring pads
Do not immerse the rice cooker body, cord or plug in water at any time.
TO COOK RICE
1. Measure the desired amount of rice with the measuring cup supplied with this rice cooker.
Rinse the rice several times until the water in the bowl shows relatively clear.
One cup of rice weigh approximately 0.8L (About 150g)
IMPORTANT! DO NOT rinse rice in the inner pot. If the pot is used for washing rice, the
non-stick coating may be damaged, or the bottom may be deformed which will result in
malfunction due to poor contact with the heating plate.
2. Put rice into the inner pot, fill with water up to the suitable water level mark according the
amount of rice being cooked.
The scale mark on the inner pot is the scale mark for cup of rice.
For example: when cooking 4 cups of rice, put the uncooked rice into the inner pot, and
then add water to the scale mark “4CUP”.
You may need to slightly adjust the amount of water due to variations between brands and
grain of rice and to suit personal taste.
IMPORTANT! DO NOT exceed the max. scale mark, otherwise it may cause overflow or
cause a short circuit.
3. Before placing the inner pot into cooker body, check that the pot is dry and free of
debris. Place the inner pot into the cooker, turn it slightly from left to right, and ensure the pot is
perfectly contact with the heating plate. Level the rice inside the pot
4. Place the glass lid on the pot and check it is firmly seated.
5. Insert the power plug into socket and turn the rice cooker on by pressing the Warm/ button.
Indicator lights will flash for 15 seconds.
6. To begin cooking, press the White Rice or Brown Rice button, depending upon the type of rice
to be cooked. The selected function’s indicator light and cook time will flash for 5s. After that a
long “beep” sound will be heard, and the rice cooker will begin cooking.
NOTE: If the function button is not pressed, the cooker will return to OFF mode automatically.
7. The digital display will begin with count down in one-minute decrements until 8 minutes left for
“White Rice” mode and 12 minutes left for “Brown Rice” mode.
8. Countdown will restart once the rice reaches the temperature.

6 | P a g e
9. The rice cooker will beep to indicate that cooking has completed, and automatically switch to
“Keep-Warm” mode.
10. The rice cooker is now in keep warm status. The “WARM” indicator will light up and the time in
keep warm mode will be displayed.
Keep the lid closed in keep warm status for about 10-15min. The rice will be cooked and
vapored completely, this will make it fluffy and tasty.
After the rice is steamed, open the lid and stir the rice gently with the supplied spatula.
NEVER use metal spoons or it will damage the non-stick surface.
The rice may now be served or left to keep warm in the cooker.
11. When rice is ready to serve, press the Warm/ button to turn OFF the rice cooker, then
disconnect the appliance from mains before serving.
To avoid a loss of steam and longer cooking time, do not open the lid at any point
during the cooking process
RICE/WATER MEASUREMENT TABLE
UNCOOKED RICE
RICE WATER LINE
INSIDE POT
APPROX. COOKED
RICE YIELD
APPROX.
COOKING TIME
2 Rice Cooker Cups
Line 2
4 Rice Cooker Cups
WHITE RICE: 30-35 Min.
BROWN RICE: 65-70Min.
3 Rice Cooker Cups
Line 3
6 Rice Cooker Cups
WHITE RICE: 33-38 Min.
BROWN RICE: 75-80Min.
4 Rice Cooker Cups
Line 4
8 Rice Cooker Cups
WHITE RICE: 38-43 Min.
BROWN RICE: 80-85Min.
5 Rice Cooker Cups
Line 5
10 Rice Cooker Cups
WHITE RICE: 40-45 Min.
BROWN RICE: 85-90Min.
6 Rice Cooker Cups
Line 6
12 Rice Cooker Cups
WHITE RICE: 42-48 Min.
BROWN RICE: 88-93Min.
7 Rice Cooker Cups
Line 7
14 Rice Cooker Cups
WHITE RICE: 44-50 Min.
BROWN RICE: 90-95Min.
8 Rice Cooker Cups
Line 8
16 Rice Cooker Cups
WHITE RICE: 45-52 Min.
BROWN RICE: 92-97Min.
9 Rice Cooker Cups
Line 9
18 Rice Cooker Cups
WHITE RICE: 47-53 Min.
BROWN RICE: 95-100Min.
10 Rice Cooker Cups
Line 10
20 Rice Cooker Cups
WHITE RICE: 48-55 Min.
BROWN RICE: 100-105Min.
Cups referenced are with the included measuring cup.
Rinse rice before placing it into the inner pot to remove excess bran and starch.
This will help reduce browning and sticking to the bottom of the pot.
The chart is only a general measuring guide.As there are many types of rice
brands and grains available, rice/water measurements may vary.

7 | P a g e
TO STEAM FOOD
1. When steaming only, add the appropriate amount of water (i.e. 2 to 3 cups of water) to the inner
pot. Avoid overflowing the steam tray when water is boiled.
2. Place food on the steam tray or place food in a heatproof bowl and then place the bowl on the
steam tray.
3. Put steam tray on top of inner pot, then place the glass lid on the steam tray and check it is firmly
seated.
4. Insert the power plug into mains power, turn ON the rice cooker, then press the Steam button. The
Digital Display with show a flashing “10” representing ten minutes of steam time.
5. Each addition press of the Steam button with increase the steaming time by one minute. The
steam time will cycle up to 60 minutes, after which it will cycle back to 1 minute.
6. Press the Warm/ button once at any time to cancel and to reset.
7. Once the desired time is selected, the steam mode indicator light and cook time will flash for 5s.
After that a long “beep” sound will be heard, and the rice cooker will begin steaming.
8. The Digital Display will begin with until water has boiled, then count down will commence in
one-minute decrements from the selected time.
9. Take care to check food for the readiness. When steaming is complete, the rice cooker will beep
to indicate that cooking has completed and will automatically switch OFF.
10.Disconnect the appliance from mains power before serving.
TO STEAM FOOD AND COOK RICE SIMUTANEOUSLY
1. Follow Steps 1-6 of “TO COOK RICE” on p.5.
2. Refer to the STEAMING TABLE on p.8, for approximate steaming times. It is best to insert the food
to be steamed towards the end of the rice cooking cycle.
3. Place your choice of vegetables and/or meat into the steam tray.
4. Use caution to avoid escaping steam when opening the lid. Place the steam tray into the rice
cooker. Close the lid securely.
5. Use caution when opening the lid to check the food.
6. If food has finished steaming, carefully remove the steam tray. CAUTION: It will be hot!
7. Allow the rice cooker to continue cooking rice.
8. When the display reaches “0”, the rice cooker will beep to indicate that cooking has completed
and will automatically switch to “Keep-Warm” mode.
9. For best results, stir the rice with the serving spatula to distribute any remaining moisture.
10. When the rice is ready to serve, press the Warm/ button to turn OFF the rice cooker, then
disconnect the appliance from mains power before serving.
Do not attempt to cook more than 8 cups (uncooked) of rice if steaming and cooking
rice simultaneously.
Food can be steamed at any time while rice is cooking. However, for best results, food
should be steamed toward the end of rice cooking cycle. This will allow for rice and
steamed food to be ready at the same time.

8 | P a g e
STEAMING TABLES
Meat Steaming Table
Vegetable Steaming Table
MEAT
STEAMING TIME
SAFE INTERNAL
TEMPERATURE
VEGETABLE
STEAMING TIME
Fish
25 Min.
60°C
Asparagus
20 Minutes
Chicken
30 Min.
74°C
Broccoli
15 Minutes
Pork
30 Min.
71°C
Cabbage
25 Minutes
Beef
Medium = 25 Min.
71°C
Carrots
25 Minutes
Medium-Well = 30 Min.
Cauliflower
25 Minutes
Well = 33 Min.
Corn
25 Minutes
Since most vegetables only absorb a small
amount of water, there is no need to increase
the amount of water with a larger serving of
vegetables.
Steaming times may vary depending on the cut
of meat being used.
To ensure meat tastes its best, and to prevent
possible illness, check that meat is completely
cooked prior to serving. If it is not, simply place
more water in the inner pot and repeat the
cooking process until the meat is adequately
cooked.
Eggplant
30 Minutes
Green Beans
15 Minutes
Peas
20 Minutes
Spinach
20 Minutes
Squash
20 Minutes
Zucchini
20 Minutes
These steaming times are for
reference only. Actual cooking times may
vary.
To Sauté
1. Turn on the rice cooker, then press the Saute Button. The Digital Display will show a flashing “30”
representing thirty minutes of sauté time.
2. Each addition press of the Saute Button with increase the steaming time by one minute. The steam
time will cycle up to 60 minutes, after which it will cycle back to 1 minute.
3. Press the Warm/ button once at any time to cancel or to reset.
4. Once the desired time is selected, the selected function’s indicator light and cook time will flash
for 5s. After that a long “beep” sound will be heard, and the rice cooker will begin to sauté.
5. The digital display will begin with until inner pot had heated up.
6. All oil or butter to the cooking pot and allow the rice cooker to preheat for approximate 3-6 minutes.
7. Add ingredients to be sautéed/ browned to the inner cooking pot. Using a long-handled wooden or
heat-safe spoon, stir ingredients until sautéed/ browned to desired level.
8. The Saute program will turn OFF automatically after the preset cook time had finished.
9. Press the Warm/ button before time is up, to manually turn the appliance OFF.
10.If adding white rice or brown rice, follow instruction of “TO COOK RICE” on page 5-6.
11.Disconnect the appliance from mains power before serving.
CAUTION!
Do not use the provided serving spatula to sauté. It is not intended to be used
in contact with high temperature. Use a long-handled wooden or heat-safe
spoon to stir food while sautéing.

9 | P a g e
CARE AND MAINTENANCE
1. Unplug the appliance from mains power socket.
2. Allow the appliance and inner pot to cool before cleaning.
3. Wash the inner pot, lid, steam tray in warm and soapy water using a sponge or cloth and rinse
with water properly, then wipe dry with cloth. Do not clean with abrasive brushes to avoid
damaging the non-stick coating.
4. Residual food can be removed with a rubber spatula, a cleaning sponge or a cloth. Soak
stubborn food deposits in warm soapy water before cleaning.
5. Wipe the body of the rice cooker with a damp cloth. Dry thoroughly.
6. Store the assembled cooker away from sources of heat and moisture and out of the reach of
children and pets.
IMPORTANT! Parts are not dishwasher safe.
TECHNICAL INFORMATION
Rated voltage: 220-240V ~ 50-60Hz
Rated power: 700W
TROUBLESHOOTING
Rice is too dry/ Hard
after cooking
If your rice is dry or hard/chewy when the rice cooker switches to “Keep-Warm”
mode, additional water and cooking time will soften the rice. Depending on how
dry your rice is, add ½ to 1 cup of water and stir through. Repeat the COOK
RICE steps.
When rice cooker switches to “Keep-Warm” mode, open the lid and stir the rice
to check the consistency. Repeat as necessary until rice is soft and moist.
Rice is too moist/
soggy after cooking
If your rice is still too moist or soggy when the rice cooker switches to
“Keep-Warm” mode, use the serving spatula to stir the rice. This will redistribute
the bottom (moistest) part of the rice as well as release excess moisture. Close
the lid and allow to remain on “Keep-Warm” mode for 10-30 minutes as needed,
opening the lid and stirring periodically to release excess moisture.
The bottom layer of
rice is browned/
caramelized.
The bottom layer of cooked rice may become slightly browned and/or
caramelized during cooking. To reduce browning, rice should be rinsed before
cooking to remove any excess starch. Stirring rice once it switches to
“Keep-Warm” will also help to reduce browning/ caramelizing

10 | P a g e
12 MONTH WARRANTY
Thank you for your purchase from Kmart.
Kmart Australia Ltd warrants your new product to be free from defects in materials and
workmanship for the period stated above, from the date of purchase, provided that the product is
used in accordance with accompanying recommendations or instructions where provided. This
warranty is in addition to your rights under theAustralian Consumer Law.
Kmart will provide you with your choice of a refund, repair or exchange (where possible) for this
product if it becomes defective within the warranty period. Kmart will bear the reasonable
expense of claiming the warranty. This warranty will no longer apply where the defect is a result
of alteration, accident, misuse, abuse or neglect.
Please retain your receipt as proof of purchase and contact our Customer Service Centre on
1800 124 125 (Australia) or 0800 945 995 (New Zealand) or alternatively, via Customer Help at
Kmart.com.au for any difficulties with your product. Warranty claims and claims for expense
incurred in returning this product can be addressed to our Customer Service Centre at 690
Springvale Rd, Mulgrave Vic 3170.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
For New Zealand customers, this warranty is in addition to statutory rights observed under New
Zealand legislation.
