Digital Repeater Compass
Operator and Service Manual
Type: 133-811.NG001
Edition: 001
10000001258

Copyright
Dieses Dokument sowie dessen Inhalt sind urheberrechtlich
geschützt. Die Weitergabe,Vervielfältigung und Speicherung sowie
die Übersetzung wie auch Verwendung dieses Dokuments oder
dessen Inhalts, als Ganzes oder in Teilen und egal in welcher Form
ist ohne vorherige ausdrückliche schriftliche Genehmigung nicht
gestattet. Zuwiderhandlungen verpflichten zu Schadenersatz.
This document and its content are copyright protected. Distribution,
reproduction and storage as well as translation and exploitation of
this document and its content, in whole or in parts and regardless of
what form, are prohibited without prior express written permission.
Offenders will be held liable for the payment of damages.
Änderungen dieses Dokuments und dessen Inhalt bleiben vorbehal-
ten.
Changes and modification to this document and its content re-
served.

Table of Contents
Edition: 001 I 10000001258
Table of Contents
List of Figures......................................................................................................................................................III
List of Tables........................................................................................................................................................ V
List of Abbreviations......................................................................................................................................... VII
Introduction........................................................................................................................................................ 1
Preliminary Remarks..................................................................................................................................... 1
Change History..............................................................................................................................................1
Safety.............................................................................................................................................................1
General Safety Regulations.....................................................................................................................2
General Safety Instructions..................................................................................................................... 3
Electrostatic Discharge............................................................................................................................ 3
List of Further Documents.............................................................................................................................4
List of Annex Documents..............................................................................................................................4
1 Description....................................................................................................................................................... 5
1.1 Purpose.....................................................................................................................................................5
1.2 Development Status................................................................................................................................. 5
1.3 Technical Data..........................................................................................................................................5
1.4 Technical Description............................................................................................................................... 5
1.5 Operating Elements and Indicators..........................................................................................................6
1.5.1 Indications during Operation............................................................................................................7
1.6 Outfit and Accessories............................................................................................................................. 9
2 Operation........................................................................................................................................................10
2.1 Preliminary Remarks.............................................................................................................................. 10
2.2 Safety Instructions for Operation........................................................................................................... 10
2.3 System Configuration............................................................................................................................. 10
2.3.1 Development Status E01...............................................................................................................11
2.3.1.1 Select Heading Source......................................................................................................... 11
2.3.1.2 Activate / Deactivate Heading Offset....................................................................................11
2.3.1.3 Display Current Interface...................................................................................................... 12
2.3.1.4 Activate / Deactivate LED Ring............................................................................................ 12
2.3.2 Development Status E02...............................................................................................................12
2.3.2.1 Display the Configuration......................................................................................................12
2.3.2.2 Select Heading Source......................................................................................................... 13
2.3.2.2.1 Select Heading Source Gyro or Magnetic................................................................... 14
2.3.2.2.2 Select Heading Source Gyro....................................................................................... 14
2.3.2.2.3 Select Heading Source Magnetic................................................................................ 14
2.3.2.3 Activate / Deactivate Heading Offset....................................................................................15
2.3.2.4 Activate / Deactivate Alternating Heading Source................................................................15
2.3.2.5 Activate / Deactivate LED Rate of Turn Indicator.................................................................16
2.3.2.6 NMEA Telegram Formats..................................................................................................... 16
2.3.2.6.1 Activate / Deactivate NMEA Telegram Formats.......................................................... 17
2.4 Setting into Operation.............................................................................................................................17
2.4.1 Pre-Operation Procedures after Longer Time Setting out of Operation........................................17
2.4.2 Setting into Operation....................................................................................................................18

Table of Contents
10000001258 II Edition: 001
2.5 Normal Operation Procedures................................................................................................................18
2.5.1 Adjust the Brightness.....................................................................................................................18
2.5.2 Freeze Heading Indication.............................................................................................................18
2.5.3 Test Illumination.............................................................................................................................18
2.6 Emergency Operation Procedures.........................................................................................................19
2.7 Setting out of Operation.........................................................................................................................19
2.7.1 Procedures for Longer Time Setting out of Operation..................................................................19
3 Troubleshooting.............................................................................................................................................20
3.1 Troubleshooting Table............................................................................................................................20
4 Maintenance and Repair...............................................................................................................................22
5 Installation and Maintenance....................................................................................................................... 23
5.1 Safety Instructions for Installation and Maintenance............................................................................. 23
5.2 Installation...............................................................................................................................................23
5.2.1 Installation Procedure.................................................................................................................... 23
5.2.2 Initial Operation Procedures.......................................................................................................... 24
5.3 Maintenance and Repair........................................................................................................................ 24
6 Transport and Storage..................................................................................................................................25
6.1 Preservation, Packing and Storage....................................................................................................... 25
6.2 Transport.................................................................................................................................................26
7 Spare Parts Catalog......................................................................................................................................27
7.1 General Remarks................................................................................................................................... 27
7.2 Definitions............................................................................................................................................... 27
7.3 Digital Repeater Compass..................................................................................................................... 27
8 Annex.............................................................................................................................................................. 29

List of Figures
Edition: 001 III 10000001258
List of Figures
Fig. 1: Electrostatic Discharge, Protected Area..................................................................................................... 3
Fig. 2: Digital Repeater Compass, Equipment Overview.......................................................................................6
Fig. 3: Operating Elements and Indicators.............................................................................................................7
Fig. 4: NMEA Connection Diagram...................................................................................................................... 24
Fig. 5: 00-0000......................................................................................................................................................28

List of Figures
10000001258 IV Edition: 001

List of Tables
Edition: 001 V 10000001258
List of Tables
Tab. 1: Change History...........................................................................................................................................1
Tab. 2: List of Further Documents......................................................................................................................... 4
Tab. 3: Dimensional Drawings................................................................................................................................4
Tab. 4: Available NMEA Telegram Formats.........................................................................................................16

List of Tables
10000001258 VI Edition: 001

List of Abbreviations
Edition: 001 VII 10000001258
List of Abbreviations
EPA ESD Protected Area
ESD Electrostatic Discharge
ISPC Illustrated Spare Parts Catalog
NMEA National Marine Electronics Association

List of Abbreviations
10000001258 VIII Edition: 001

Introduction
Edition: 001 1 10000001258
Introduction
Preliminary Remarks
The present manual is a description and reference book only. It is intended to answer
questions and to solve problems in the quickest possible manner.
Read and follow the instructions and notes in this manual before operating the equipment.
For this purpose, refer to the table of contents and read the corresponding chapters
thoroughly.
If you have any further questions, contact us under the following address:
Anschütz GmbH Tel. +49 431 / 3019 - 0
Zeyestr. 16 - 24
24106 Kiel Email: [email protected]
Germany www.anschuetz.com
All rights reserved. It is not allowed to copy any part of this manual, neither mechanically,
electronically, magnetically, manually nor otherwise. It is not allowed to store it in a
database, or distribute or forward it without written permission of Anschütz GmbH.
Copyright:
Anschütz GmbH
Zeyestr. 16 - 24
24106 Kiel
Germany
Errors can hardly be avoided in the documentation despite all efforts. Therefore, we
appreciate any remarks and suggestions.
Subject to alterations.
Change History
Tab. 1: Change History
Change Remarks
Edition: 001 Replaces Document 3194

Introduction
10000001258 2 Edition: 001
Safety
General Safety Regulations
The following safety symbols are used in this manual:
WARNING!
Warning statements indicate a hazardous situation that, if not avoided,
could result in minor, moderate or serious injury, or death
Consequence
• Preventive action
CAUTION!
Caution statements indicate a hazardous situation that, if not avoided,
could result in material damage
Consequence
• Preventive action
Note
Notes indicate information considered important but not hazard-related.

Introduction
Edition: 001 3 10000001258
General Safety Instructions
Electrostatic Discharge
Fig. 1: Electrostatic Discharge, Protected Area
1 Table Mat
2 Ground Cord
3 Dissipative Shoes
4 Floor Mat
5 Wrist Band
6 Wrist Strap
7 Common Ground
8 Ground Point
Any product which is labeled as shown is electrostatic sensitive.
If proper Electrostatic Discharge (ESD) precautions are not taken, handling or working on
this product results in damage. Every action must be done under ESD protection.
The product and all electronic parts of the product are susceptible to ESD. The product
must be handled with ESD protection especially when removing the covers, touching the
connectors or handling the product components.
All ESD sensitive parts must be packed in metallized protective bags during shipping and
handling outside any ESD Protected Area (EPA). ESD protected spare parts packages
must not be opened / closed out of an EPA.
All necessary equipment for these protective measures can be supplied (on special order)
by Anschütz.

Introduction
10000001258 4 Edition: 001
List of Further Documents
Tab. 2: List of Further Documents
Documentation No. Designation
4423 Magnetic Sonde 108-010.NG001-NG004 E01 OP SE
List of Annex Documents
Tab. 3: Dimensional Drawings
Drawing No. Designation
133-811.HP005 Digital Repeater Compass
133-811.HP015 Digital Repeater Compass 133-811.NG011 E02

1 Description
Edition: 001 5 10000001258
1 Description
1.1 Purpose
The Digital Repeater Compass is designed to indicate the ship’s heading referred to
north, which has been ascertained by the gyro/magnetic compass (GPS/SAT compass for
development status E02 only).
1.2 Development Status
The Digital Repeater Compass exists in 2 development statuses, E01 and E02. Depending
on the development status, the configuration and operation of the unit might differ. The
differences are highlighted in this manual.
The development status of the Digital Repeater Compass is shown on the type plate,
which is placed on the side of the housing.
1.3 Technical Data
Height 96 mm
Width 192 mmDimensions
Depth 66 mm
Approx. 1 kg
Weight Approx. 3 kg with enclosure
IP56 after installation
Protection Class IP44 with enclosure
Voltage Supply 24 V DC (8 to 36 V )
Power Consumption Max. 4 W
Accuracy of Indication ± 0.05°
Resolution of the Tendency Indicator 0.1°/s
Input Interfaces NMEA RS 232C / RS 422 or Coursebus
(heading serial)
NMEA Specification
4800 baud, 1 start bit, 1 stop bit
Transmission Mode (Also 9600, 19200 and 38400 baud)
Frame Clock Pulse 1 s/100 ms
(All information transmitted in accordance to IEC 61162-1; for development status E02
IEC 61162-2, repetition rate)

1 Description
10000001258 6 Edition: 001
1.4 Technical Description
The heading is read at a 7-segment LCD display (luminous numerals). The numerals are
recognizable from up to 10 m, even when viewed at different angles. The gyro heading is
shown in degrees and decimal degrees. The decimal digit is displayed smaller to prevent
erroneous reading. Heading changes are indicated by a tendency indicator. Depending
on the speed of the heading change, a ring consisting of bi-color LCDs indicate a turn to
starboard by green light and a turn to port by red light. The rate of turn in the LED ring is
proportional to the ship’s rate of turn.
Further characteristics of the Digital Repeater Compass:
• Recognition of a RS 422 interface according to National Marine Electronics Association
(NMEA) and therefore automatic changeover of the operation mode when heading
serial is detected
• Brightness control of all indication elements by pushbuttons
• Synchronisation unnecessary because of transmission of absolute values
• Equipment is ready for assembly in desks and steering stands or for mounting in
bulkhead, desk and ceiling with a bracket
• Connection for a central dimmer
• Connection for a pushbutton to execute the function Freeze to take bearings with a
bearing disc
Fig. 2: Digital Repeater Compass, Equipment Overview

1 Description
Edition: 001 7 10000001258
1.5 Operating Elements and Indicators
Fig. 3: Operating Elements and Indicators
Position Area/Element Description
1 Display Shows the current heading
2 LED Ring Shows rate of turn and direction of turn
3 Pushbuttons
Brightness Down: Reduces the brightness of the illu-
mination
Brightness Up: Increases the brightness of the illumi-
nation
1.5.1 Indications during Operation
Development Status E01
Indication Description
Valid Heading from Gyro Compass
The current heading is indicated with a gradua-
tion of a tenth of a degree.

1 Description
10000001258 8 Edition: 001
Indication Description
The LEDs in the LED ring light up green (turn to
starboard) or red (turn to port).
Valid Heading from Magnetic Compass
The current heading is indicated without a grad-
uation of a tenth of a degree. A degree sign is
shown instead.
The LEDs in the LED ring light up green (turn to
starboard) or red (turn to port).
No Valid Heading
Horizontal lines are displayed instead of a
heading.
The LEDs in the LED ring stay dark.
Development Status E02
Indication Description
Valid Heading from Gyro Compass
The current heading is indicated with a gradua-
tion of a tenth of a degree.
The current heading alternates with the indica-
tion Gyro.
The LEDs in the LED ring light up green (turn to
starboard) or red (turn to port).
Valid Heading from Magnetic Compass
(Models earlier year 2010)
The current heading is indicated without a grad-
uation of a tenth of a degree. A degree sign is
shown instead.
The current heading alternates with the indica-
tion MAG.
The LEDs in the LED ring light up green (turn to
starboard) or red (turn to port).
Valid Heading from Magnetic Compass
(Model from year 2010 and later)
The current heading is indicated with a gradua-
tion of a tenth of a degree.
The current heading alternates with the indica-
tion MAG.
The LEDs in the LED ring light up green (turn to
starboard) or red (turn to port).

1 Description
Edition: 001 9 10000001258
Indication Description
Valid Heading from GPS/SAT Compass
The current heading is indicated with a gradua-
tion of a tenth of a degree.
The current heading alternates with the indica-
tion GPS.
The LEDs in the LED ring light up green (turn to
starboard) or red (turn to port).
No Valid Heading
Horizontal lines are displayed instead of a
heading.
The LEDs in the LED ring stay dark.
1.6 Outfit and Accessories
This system or equipment comprises no outfit or accessories.

2 Operation
10000001258 10 Edition: 001
2 Operation
2.1 Preliminary Remarks
User Rights
The manual is a complete documentation of the system or equipment. Some functions may
not be accessible depending on user rights.
All functions or operations are described irrespective of the actual user rights of the user.
Markup Elements
The manual uses different markup elements for hardware and software.
Markup Element Description
Bold
This markup is used for the following elements:
• Pushbuttons / Switches
• Softkeys
• Labeling
• Defined areas
Italic
This markup is used for the following elements:
• Menus
• Dialogs
2.2 Safety Instructions for Operation
WARNING!
Danger due to improper operation and use for other than the intended
purpose
Risk of serious injury and material damage
• Use the product only for the intended purpose.
• The system must not be used for navigation.
• Perform operation steps according to this manual.
• Do not make any product modifications without authorization.
WARNING!
Danger due to operation by unskilled personnel
Risk of serious injury and material damage
• Keep all unskilled personnel away from the operation area.
• Perform all operation only by skilled personnel.
