OMNI-DIRECTIONAL ANTENNAS
FG24008 (2400 – 2500 MHz)
FEATURES
●Highly Stable PC Board
Matching Section
●High Performance
●Easy installation /w
optional FM2
●Special UV treated radome,
resists sun damage
●N Female industry standard
connector
●100% tested on a network
analyzer
ELECTRICAL SPECIFICATIONS
Frequency Range: 2400 - 2500 MHz
VSWR: < 1.5:1 Max
Nominal Gain: 8dBi
Maximum Power: 100 W
Nominal Impedance: 50Ω
Polarization: Vertical
Pattern: Omni-Directional
Half-Power Beamwidth: 30°x 360°
(Elevation°x Azimuth°)
Coaxial Cable Length & Type: None
Termination: N-Female connector
Lightning Protection: Lightning Arrestor
LABH350NN
(Sold Separately)
MECHANICAL SPECIFICATIONS
Height: 24-1/2”
Diameter: 1.310”
Weight: 0.5 lb
Rated Wind Velocity: 125mph (210kph)
Rated Wind Velocity (with 0.5” radial ice)
85mph (137kph)
Lateral Thrust @ 125mph WIND VELOCITY
57 lbs. (26kg)
Wind Resistance in Sq. Feet: 0.2229 Sq. Ft
Mounting Information: FM2 Mounting Kit
(Sold separately)
Elevation Pattern
(
Y
,
Z or H-
p
lane
)
0
80°
70°
60°
50°
40°
30°
20°
10°
350°
340°
330°
320°
310°
300°
290°
280°
270°
260°
250°
240°
230°
220°
210°
200°
190°
180°
170°
160°
150°
140°
130°
120°
110°
100°
90°
-2
-6
-8
-10
-20
-30
-40
-50
-4
Normalized to 8dBi
