Antenex FG9023 User manual

OMNI-DIRECTIONAL ANTENNAS
FG9023 (902 – 928 MHz)
0
80°
70°
60°
50°
40°
30°
20°
10°
350°
340°
330°
320°
310°
300°
290°
280°
270°
260°
250°
240°
230°
220°
210°
200°
190°
180°
170°
160°
150°
140°
130°
120°
110°
100°
90°
-2
-6
-8
-10
-20
-30
-40
-50
-4
Normalized to 3dBd
FEATURES
●Highly Stable PC Board
Matching Section
●Superior quality design
Highest gain and best matching
efficiency in the industry.
●Special UV treated radome
Resists sun damage
●N Female industry standard
connector
●100% tested on a Network
Analyzer
Elevation Pattern (Y, Z or H-plane)
MECHANICAL SPECIFICATIONS
Height: 23 – 1/8”
Diameter: 1.310”
Weight: < 1lbs
Rated Wind Velocity: 125mph (210kph)
Rated Wind Velocity (with 0.5” radial ice)
85mph (137kph)
Lateral Thrust @ 125mph WIND VELOCITY
57 lbs. (26kg)
Wind Resistance: 0.2104 sq. ft.
Mounting Information: FM2 Mounting Kit
(Sold separately)
ELECTRICAL SPECIFICATIONS
Frequency Range: 902 – 928 MHz
VSWR: < 2.0:1
Nominal Gain: 3dBd
Maximum Power: 100 W
Nominal Impedance: 50Ω
Polarization: Vertical
Pattern: Omni-Directional
Half-Power Beamwidth: 70°x 360°
(Elevation°x Azimuth°)
Coaxial Cable Length & Type: None
Termination: N-Female connector
Lightning Protection: Lightning Arrestor
LABH350NN
(Sold Separately)
