Antennair BATC DTX1 User manual

‘BATC DTX1’
DVB-S Encoder / Modulator
USER GUIDE Issue 1.1
This Guide should be used in connection with firmware 01.00.00
Copyright 2013 Antennair Limited, Neo House, Shaw Road, OLDHAM OL1 4AW

Contents
Table of Contents
Foreword..............................................................................................................................4
Hardware Installation – Boxed Version.................................................................................4
Bare Board Version..............................................................................................................5
BATC DTX1 – A Quick Guide to Getting Started!.................................................................5
Some words of Caution....................................................................................................5
Housing the Board...........................................................................................................5
Powering the Board..........................................................................................................6
Controlling the Board.......................................................................................................6
Keyboard Connector P1...................................................................................................6
RF Output P3...................................................................................................................7
Audio and Video Inputs....................................................................................................7
Serial Port P16.................................................................................................................7
Getting on Air...................................................................................................................8
Pre-sets............................................................................................................................8
Load from Pre-set........................................................................................................8
Save to Pre-set............................................................................................................8
Menu Navigation..................................................................................................................9
Menu Structure...................................................................................................................10
General Notes on Menu Options and Usage......................................................................14
LED Indicators....................................................................................................................15
Configuration......................................................................................................................15
General..........................................................................................................................15
Time...........................................................................................................................15
Date...........................................................................................................................15
LCD Contrast.............................................................................................................15
Input...............................................................................................................................15
Video Source.............................................................................................................16
Video Signal...............................................................................................................16
Aspect Ratio...............................................................................................................16
Contrast.....................................................................................................................16
Colour........................................................................................................................16
Brightness..................................................................................................................16
Modulator.......................................................................................................................16
RF Frequency............................................................................................................16
RF Level.....................................................................................................................16
RF Mode....................................................................................................................17
FEC............................................................................................................................17
Symbol Rate..............................................................................................................17
Spectral Inversion......................................................................................................17
Encoder..........................................................................................................................18
System Bit-rate Mode................................................................................................18
System Bit-rate..........................................................................................................18
Avg System Bit-rate...................................................................................................18
Audio Bit-rate.............................................................................................................18
Audio Sample-rate.....................................................................................................18
Audio ES Mode..........................................................................................................18
Video Filter.................................................................................................................18
2 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)

GOP Structure...........................................................................................................19
Names............................................................................................................................19
Channel Names.........................................................................................................19
Network Name...........................................................................................................19
Provider Name...........................................................................................................19
Service...........................................................................................................................19
PMT PID....................................................................................................................19
Video PID...................................................................................................................19
Audio PID...................................................................................................................19
AUX PID.....................................................................................................................19
LCN............................................................................................................................20
Program Number.......................................................................................................20
Trans Stream ID.........................................................................................................20
Network..........................................................................................................................20
Network ID.................................................................................................................20
Orig Network ID.........................................................................................................20
Status.............................................................................................................................20
Program Stream.........................................................................................................20
Table..........................................................................................................................20
Stuffing.......................................................................................................................20
Serial port settings..............................................................................................................21
Serial Command Set..........................................................................................................21
Flashing new firmware via the Bootloader..........................................................................25
Product Support.................................................................................................................26
Appendix 1.........................................................................................................................27
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 3

Foreword
This user guide contains basic instructions for installation and operation of both Single and
Dual Channel DTX1 Modulators.
Please read through this document to determine how best to deploy the unit (location,
connections & settings) to suit your intended application.
1. Hardware Installation – Boxed Version
The boxed unit should be located indoors, in a reasonably well ventilated location and
away from direct sources of heat such as radiators, direct sunlight, or excessively hot
electronic equipment. The rear of a dual unit is arranged like this:
(Figure 1) Rear Panel
Connections are arranged in two horizontal rows. The lower row is always present on
both Single and Dual units, whereas the upper row is only present on Dual units. On the
bottom row, connections from left to right are as follows:
1 ‘F’ Connector UHF Output into 50 Ohms coaxial cable.
2 Barrel ROKA Plug 12V 1A DC PSU Input, Centre Positive (+).
3 Yellow PHONO socket Composite Video Input, PAL/ NTSC 75 Ohms
4 Mini DIN Socket S-Video Input, PAL/ NTSC 75 Ohms
5 White PHONO Socket Audio Channel LEFT input 10K Ohms
6 Red PHONO Socket Audio Channel RIGHT input 10K Ohms
7 RJ45 Socket Serial Connection to host - reserved.
(Table 1) Connectors Main
N.B. The group AV1 are the primary input feed.
4 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)

On the top row from left to right connections are the secondary feed AV2 as follows:
1 Yellow PHONO socket Composite Video Input, PAL/ NTSC 75 Ohms
2 Mini DIN Socket S-Video Input, PAL/ NTSC 75 Ohms
3 White PHONO Socket Audio Channel LEFT input 10K Ohms
4 Red PHONO Socket Audio Channel RIGHT input 10K Ohms
(Table 2) Connectors (Expansion)
In the majority of cases, the only connections used will be DC Power, UHF RF output, and
Video and Sound inputs. You may select whether to use S Video or PHONO video inputs
in the menu options (see later). If a Stereo sound source is not available, using just one of
the two inputs for a Mono source will automatically feed audio to both LEFT and RIGHT
channels of the modulated output, but with reduced input impedance. For best picture
quality choose an S-Video picture source as opposed to composite video where possible.
In all cases use good quality screened leads. Make all connections before powering up
the unit.
The RF Output can be fed directly to a PA or depending on sensitivity you may require an
intermediate amplifier such as a MMIC block. Nominal full power out is -6dBm.
2. Bare Board Version
If you have purchased the 'bare bones' DTX1 board from BATC you will have to provide a
5 button keypad to operate it, or a serial cable to a host PC running a terminal program.
For more details of hardware connections and the serial command set, refer to
http://www.dtx1.info/ where you can also obtain the latest firmware upgrades and other
information.
2.1. BATC DTX1 – A Quick Guide to Getting Started!
2.1.1. Some words of Caution
Please note – the DTX1 PCB contains static sensitive devices. You should take
appropriate care to make sure you don’t damage it. Always work with an ant-static wrist
strap to discharge any static before touching the card even if it’s unpowered. Also, there
are switching power supply circuits on the board which convert the 12V DC input to
various low voltages, which should not be touched during operation (e.g. to see how warm
they might be!) as this might upset the sensitive feedback circuitry, and so cause
excessive voltages and damage to components. The general rule is – don’t touch the
board while it’s working, and don’t zap it while it isn’t!
2.1.2. Housing the Board.
The DTX1 PCB is made up of 6 layers, and contains quite a lot of copper to dissipate
unwanted heat from the various IC’s on it. When fitted in the extruded aluminium case
(also available from BATC) this heat is dealt with by conduction to the slide-in grooves at
the side of the case, and by conduction from the F connector to the rear panel to which it
should be affixed. We aren’t talking about a lot of heat here – the whole thing only takes
about 6 watts – but anything which can be done to reduce the operating temperature
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 5

makes for more stable and reliable electronics. So if you are using your own metalwork
(preferred over an ABS box) use metal stand-offs, bolts or whatever to mount the PCB,
and make use of conduction through the F connector, which will help keep the modulator
IC temperature down.
2.1.3. Powering the Board
Supply voltage is +12 Volts nominal, with the CENTRE PIN POSITIVE.
The board will operate reliably from 10 to 15V DC. We recommend a 1A PSU to have
something in reserve, especially you might be adding a secondary encoder at some point.
2.1.4. Controlling the Board
Either a simple keypad, or RS-232 serial commands, may be used. If the cased option is
being built up, this comes with an ‘Antennair Quadrant’ front panel membrane (the DTX1 is
a derivative of a commercially available unit). Simply plug the membrane ribbon connector
into the 6 pin connector on the PCB. If you are making up your own case, connect up 5
buttons (press to make switches) so that they all have one end in common. Wire as per
table below.
2.1.5. Keyboard Connector P1
(Pin 1 is the nearest to the corner of the board)
PIN No. SIGNAL
1 RIGHT
2 DOWN
3 LEFT
4 ENTER
5 UP
6 COMMON
(Table 3) Keypad Connector
6 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)

2.1.6. RF Output P3
Output is approx -5dBm into 50 Ohms from the 'F' connector at the rear of the board. Do
not short circuit, or allow static charges to damage the output circuit.
2.1.7. Audio and Video Inputs
1V Stereo Audio into 10K Ohms Red and White PHONO, and 1V Video into 75 Ohms
PHONO, or Y/C into 75 Ohms S Video Mini DIN connector. PAL and NTSC supported.
2.1.8. Serial Port P16
(Pin 1 is the furthest from the corner of the board
PIN No. SIGNAL
1 GROUND (via. 10 Ohms)
2 CTS
3 TXD
4 RTS
5 RXD
6 DSR
(Table 4) Serial Connector
For the serial option, make up a cable to your PC, the DTX1 end is wired as follows to an
RJ11 connector. Set your terminal to 115K, N,8,1.
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 7

2.2. Getting on Air
2.2.1. Pre-sets
The units has three pre-set locations (memories) where the whole configuration of the unit
can be stored or recalled for quick access to different configurations. As shipped, there
are 3 useful pre-sets already stored in non-volatile memory, called P1 P2 and P3, as
follows:
PRESET
P1 – for 70cms P2 – for 1248 MHz P3 – for 1275 MHz
AV1 AV2 AV1 AV2 AV1 AV2
Frequency 437 MHz 1248 MHz 1275 MHz
Symbol Rate 2 Ms / second 4 Ms / Second 4 Ms / second
FEC 1/2 1/2 3/4
Video in Composite Composite Composite Composite Composite Composite
RF 100% 100% 100%
Provider
name BATC BATC BATC
Network
name DTX1 DTX1 DTX1
Channel
name Call sign
CH1
Call sign
CH2
Call sign
CH1
Call sign
Ch2
Call sign
CH1
Call sign
CH2
PMT PID 0x102 = 258 0x202 = 514 0x102 = 258 0x202 = 514 0x102 = 258 0x202 = 514
Video PID 0x100 = 256 0x200 = 512 0x100 = 256 0x200 = 512 0x100 = 256 0x200 = 512
Audio PID 0x101 = 257 0x201 = 513 0x101 = 257 0x201 = 513 0x101 = 257 0x201 = 513
Aux PID 0x103 = 259 0x203 = 515 0x103 = 259 0x203 = 515 0x103 = 259 0x203 = 515
(Table 5) Pre-sets
2.2.2. Load from Pre-set
Choose the configuration that best suits your requirements from the above table.
Select P1 / P2 / P3 to load the current configuration from that pre-set location.
(Factory default is set to be P1).
2.2.3. Save to Pre-set
If you edit a configuration you may save it to keep the new values. Select P1 / P2 /
P3 to save the current configuration to that pre-set location.
8 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)

3. Menu Navigation
The menu system allows the user to set up various operating details such as Operating
Frequency, Logical Channel Number (e.g. 555), Time and Date, Video Source type and
Channel Name and so on.
The menu is navigated by a simple 5-button arrangement, whilst observing the LCD at the
left of the front panel. The centre key is the ‘OK’ or ‘Enter’ function.
The left, right, up and down buttons will be referred to as <, >, ^ & vrespectively.
The menu structure for the 'BATC DTX1' (and Antennair 'Quadrant', of which it is a
derivative) is shown in the next 3 pages.
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 9

3.1. Menu Structure
10 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)
GENERAL
** EXIT SETUP **
INPUT
MODULATOR
DATE
LCD CONTRAST
AV Input 1
AV Input 2
VIDEO SOURCE
VIDEO SIGNAL
ASPECT RATIO
COLOUR
BRIGHTNESS
RF CHANNEL
RF LEVEL
SPECTRAL INV
VIDEO SOURCE
VIDEO SIGNAL
ASPECT RATIO
COLOUR
BRIGHTNESS
TIME
RF MODE
FEC
SYMBOL RATE
Standard Menu
If Daughter
Board Present

BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 11
ENCODER AV Input 1
AV Input 2 VID BITRATE MODE
VIDEO BITRATE
AVG VID BITRATE
AUDIO BITRATE
AUDIO SAMPLERATE
AUDIO ES MODE
VIDEO FILTER
VID BITRATE MODE
VIDEO BITRATE
AVG VID BITRATE
AUDIO BITRATE
AUDIO SAMPLERATE
AUDIO ES MODE
VIDEO FILTER
GOP STRUCTURE
GOP STRUCTURE
Standard Menu
If Daughter
Board Present

12 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)
NAMES
SERVICE
NETWORK
STATUS
CHANNEL NAME
NETWORK NAME
PROVIDER NAME
AV Input 1
AV Input2
AV Input 1
AV Input 2
TRANS STREAM ID
PMT PID
VIDEO PID
AUDIO PID
AUX PID
LCN
PROG NUMBER
NETWORK ID
ORIG NETWORK ID
PROGRAM STREAM
TABLE
STUFFING
TOTAL
PMT PID
VIDEO PID
AUDIO PID
AUX PID
LCN
PROG NUMBER
PRESETS SAVE TO PRESET
LOAD FROM PRESET
P1 P2 P QUIT
P1 P2 P QUIT
Standard Menu
If Daughter
Board Present

When you first power up the unit, the RED LED will be illuminated and there will be a delay
of 10 seconds or more before any display appears. This is normal. After the internal
firmware has loaded you should see the default display:
N.B. The final part of this screen shows whether you have a single or dual channel unit.
Single channel units show a single arrow in the middle of the char on the display, the dual
channel unit will show two arrows (one above the other) in the char on the display. This
means the unit is up and running, (on a frequency less than UHF Channel 21) at a
frequency of 437.0 MHz. The GREEN LED will be illuminated.
Note: the LCD font depends on the panel used, and so may vary somewhat.
You can set up the unit using a 5 button keypad, or by means of commands over the
serial port (the serial commands are documented in section 5.1). For now we presume a
keypad is being used.
To change any parameter, press the OK button, which will invoke the menu system as per
previous diagram. The message
will appear, which invites you to cancel, either by doing nothing (time-out 20 seconds) or
by pressing the OK button once more. In this case the message
will be displayed momentarily before returning to the default display.
Let’s assume you want to change the default RF frequency. Press the OK button then
press the v (= down!) button until you get
Then press the OK button again which will take you to the menu section dealing with
modulator parameters.
You should see:
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 13
BATC DTX1 DVB-S
4 7.0MHz [<21]-
** EXIT SETUP **
<Leaving Setup>
MODULATOR
MODULATOR
4 7.0MHz [<21]

Press the OK button once more; the 1
st
digit of the frequency will flash, inviting you to alter
it. Use the ^ or vbuttons to increment or decrement this digit of the frequency, use the < &
> keys to select other digits of the frequency or UHF channel number to select the
frequency you want to use, then press the OK button followed by the < button to take you
back to the Modulator menu, and < once more then OK to return to the default display,
which will now show the new RF frequency and channel of your choice.
The above example demonstrates the way the menu system can be navigated. Up and
Down buttons change parameters, and Left and Right buttons select various options within
sub-menus, with the OK button confirming actions.
After using it a few times you should find it quite straightforward. Don’t be put off by all the
various modulator and encoder options, which are provided for specialist users; the factory
defaults will provide a viable system out of the box.
Furthermore, if you suspect that you have made some unwanted changes but aren’t sure
what they were, you have the option of returning the unit to factory defaults. This will undo
all the changes you have made, so use with caution.
To invoke factory reset, switch off power to the unit. Now press and hold the ^ and v
buttons at once, while re-applying power. Keep these two buttons pressed until the default
display shows, then release them. You should see the message
then eventually
N.B. For Dual units, there will be two arrows shown!
3.2. General Notes on Menu Options and Usage
Under GENERAL, set the unit's time to the time of day in GMT, and date to the present
date.
Under INPUT, choose the VIDEO SOURCE i.e. S Video or PHONO, for each AV input.
The DTX1 cannot auto detect which input to use. Also select whether you have a PAL or
NTSC source (the DTX1 cannot auto detect TV Standards, but it can have different
standards set on the two AV inputs, which is rather neat). For ASPECT RATIO the usual
(default) is AUTO. This will read the wide screen signalling information (WSS, where
present) in the video input and set up the picture accordingly. If you source has no WSS
present (half a line of dashes at the picture top left) then set manually to 4:3 or 16:9 as
required.
Under MODULATOR, set the required RF frequency or output channel, and adjust the RF
level setting to suit your PA and any intermediate MMIC amplifier stage.
Note: Outside of the menu structure, the UP key toggles RF ON and RF OFF.
Leave all ENCODER settings alone, unless for any reason you have a picture which is
14 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)
Defaults Loaded
BATC DTX1 DVB-S
4 7.0MHz [<21]-

noisy at source in which case you can try lower VIDEO FILTER settings, which affect
picture sharpness.
Under NAMES, choose and enter the displayed CHANNEL NAME for each video input
(AV1, AV2) and if required the common NETWORK NAME.
Under SERVICE, only edit the LCN as described above, for each AV input. (Just to re-cap,
these are the channel numbers as shown on a DVB TV).
Under NETWORK make sure this is not the same as any broadcast networks.
STATUS is an engineering readout of system performance and can be ignored.
3.3. LED Indicators
RED LED Power ON
GREEN LED STATUS OK (encoder running)
YELLOW LED RF ON
(Table 5) LED Indicators
4. Configuration
This section defines the various settings that can be changed within the modulator either
from the on-board LCD display & keypad or via the RS232 interface.
4.1. General
General unit settings
4.1.1. Time
Allows the setting of the DTX1 on-board Real Time Clock.
4.1.2. Date
Allows the setting of the DTX1 on-board RTC
4.1.3. LCD Contrast
This parameter sets the bias voltage, in order to control the contrast of the on-board LCD
Display.
4.2. Input
(AV Input 1 & AV input 2 [if fitted]) This parameter specifies the characteristics of the video
input signal.
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 15

4.2.1. Video Source
This parameter allows the Video source for encoding
Video Source = COMP : Composite PHONO input
Video Source = S-VID : S-video Mini DIN Input
4.2.2. Video Signal
This parameter allows the selection of the video standard
Video Signal = PAL : PAL 625 line 50Hz Video standard
Video Signal = NTSC : NTSC 525 line 60Hz Video standard
4.2.3. Aspect Ratio
This parameter controls the aspect ratio of the encoder video
Aspect ratio = AUTO : Aspect switched by video
Aspect ratio = 16:9 : Aspect fixed at 16:9
Aspect ratio = 4:3 : Aspect fixed at 4:3
4.2.4. Contrast
This parameter allows for the adjustment of video contrast in the encoded video
Contrast = (0 →255) : Video input contrast adjust
4.2.5. Colour
This parameter allows for the adjustment of video colour saturation in the encoded video.
Colour = (0 →255) : Video input colour adjust
4.2.6. Brightness
This parameter allows for the adjustment of video brightness in the encoded video.
Brightness = (0 →255) : Video input brightness adjust
4.3. Modulator
4.3.1. RF Frequency
These parameters controls the output transmission frequency and are selectable in
100Khz steps or as a UHF channel number.
4.3.2. RF Level
This parameter control the output level of the modulator between 0 and 100%.
Rf-level = 0 : RF level = 0 %
Rf-level =100 : RF level = 100 %
16 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)

4.3.3. RF Mode
This parameter control the default state of the RF output at power on.
RF Mode = ON : RF active on power on.
RF Mode = OFF : RF inactive at power on.
4.3.4. FEC
This parameter selects the required Forward Error Correction code rate.
FEC = 1/2 : Maximum error correction
FEC = 2/3 :
FEC = 3/4 :
FEC = 5/6 :
FEC = 7/8 : Minimum error correction
4.3.5. Symbol Rate
This parameter allows the adjustment of the DVB-S symbol-rate, as such this also
controls the bandwidth of modulated signal as the bandwidth is directly proportional to the
symbol rate.
SYMBOLRATE (1.0 →30.0) MSym / s
SR = Symbol Rate
DR = Data Rate
CRv = Viterbi Forward Error Correction e.g.1/2, 2/3, 3/4, 5/6, 7/8
CRrs = Reed Solomon FEC e.g. 188/204
m = modulation factor (transmission rate bits per symbol). QPSK=2
Formula: SR = DR / (m x CRv x CRrs)
4.3.6. Spectral Inversion
This parameter controls whether the I&Q signals in the baseband constellation should be
swapped, this is only required for very special applications.
SPECTRAL INV = NO : Output is non inverted spectrum
SPECTRAL INV = YES : Output is inverted spectrum
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 17

4.4. Encoder
4.4.1. System Bit-rate Mode
This parameter allows the selection of Constant Bit-rate or Variable bit-rate modes for the
encoder output.
SYS BITRATE MODE = CBR : Constant Bit-rate
SYS BITRATE MODE = VBR : Variable Bit-rate
4.4.2. System Bit-rate
This parameter selects the total system bit-rate of the MPEG stream.
SYSTEM BITRATE (512 →12800) kbit/s
4.4.3. Avg System Bit-rate
This parameter selects the average target system bit rate while running in variable bit-rate
mode, while in VBR mode this value must be set less than the total system bit-rate as
defined by SYSTEM BITRATE above.
SYSTEM BITRATE (512 →12800) kbit/s
4.4.4. Audio Bit-rate
This parameter controls the audio encoder bit-rate
AUDIO BITRATE = (64 / 128 / 192 / 256 / 320 / 384) kbit/s
4.4.5. Audio Sample-rate
This parameter controls the sampling rate of the analogue audio input
AUDIO SAMPLE RATE = (32000 / 44100 / 48000) bit/s
4.4.6. Audio ES Mode
This parameter controls the encoding mode of the audio encoder.
AUDIO ES MODE = stereo : Standard stereo input
AUDIO ES MODE = Single Channel : Mono audio
AUDIO ES MODE = Dual Channel : Two independent Channels
AUDIO ES MODE = Joint Stereo : Joint differential encoding
4.4.7. Video Filter
This parameter select the spatial video filter mode
VIDEO FILTER = SOFT : Soft video filter
VIDEO FILTER = NORM : Normal video filter
VIDEO FILTER = SHARP : Sharp video filter
18 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)

4.4.8. GOP Structure
These parameters defines the encoding sequence of the frames from the encoder and
the size of the encoding structure.
SIZE = (1 →30), STRUCTURE = (IIII / IPPP / IBPB / IBBP)
4.5. Names
4.5.1. Channel Names - ( AV Input 1 [AV Input 2 if fitted] )
This parameter defines channel name. (can be set to user call sign)
4.5.2. Network Name
This parameter defined the Network Name.
4.5.3. Provider Name
This Parameter defines the provider name.
4.6. Service
4.6.1. PMT PID - ( AV Input 1 [AV Input 2 if fitted] )
The parameter defines the PMT (Program Map Table) which defines all the elements that
make up the individual program within the transport stream, it is important that this PMT
PID is unique and is not set the same as any other PID within this multiplex.
PMT PID = (0x0020 →0x1FFE)
4.6.2. Video PID - ( AV Input 1 [AV Input 2 if fitted] )
This parameter defines the PID of the Video stream within the Transport stream, it is
important that this Video PID is unique and is not set the same as any other PID within
this multiplex.
VIDEO PID = (0x0020 →0x1FFE)
4.6.3. Audio PID - ( AV input 1 [AV Input 2 if fitted] )
This parameter defines the PID of the Audio Stream within the Transport stream, it is
important that this Audio PID is unique and is not set the same as any other PID within
this multiplex.
AUDIO PID = (0x0020 →0x1FFE)
4.6.4. AUX PID - (AV Input 1 [AV Input 2 if fitted])
This parameter defines the PID of the auxiliary stream with the Transport Stream, it is
important that this AUX PID is unique and is not set the same as any other PID within this
multiplex.
AUX PID = (0x0020 →0x1FFE)
BATC DTX1 (Iss 1.1) Copyright 2013 Antennair Ltd 19

4.6.5. LCN - (AV Input 1 [AV Input 2 if fitted])
This parameter defines the Logical Channel number of this program.
LCN = (001 →999)
4.6.6. Program Number
This parameter defines the Transport stream program number and must be unique within
the transport stream.
PROG NUMBER = (00001 →65535)
4.6.7. Trans Stream ID
This parameter defined the transport stream ID
TRANS STREAM ID = (0x0000 →0xFFFF)
4.7. Network
4.7.1. Network ID
This parameter defines the network ID
NETWORK ID = (0x0000 →0xFFFF)
4.7.2. Orig Network ID
This parameter defines the original network ID
ORIG NETWORK ID = (0x0000 →0xFFFF)
4.8. Status
4.8.1. Program Stream
This status display show the number of bytes transferred per second and percentage
utilisation within the whole transport stream.
4.8.2. Table
This status display show the number of bytes transferred per second and percentage
utilisation of SI tables within the current transport stream.
4.8.3. Stuffing
This status display show the number of bytes transferred per second and percentage of
stuffing packets inserted within the current transport stream.
20 Copyright 2013 Antennair Ltd BATC DTX1 (Iss 1.1)
