Antennas Direct ClearStream 2 User manual

C2 - ClearStream 2
Antenna Assembly
1. The ClearStream 2 antenna comes with:
 • 1reector
 • 1setoftaperedloopelements
 • 75ohmtransformer(internal)
 • 1threadedbolt
 • 1adjustablemastclamp
2. FeedthesuppliedboltthroughholeinU
clampassembly.
2.
4. Assembly complete.AttachtheC2
antennatoanykindofmastormount
(upto2”indiameter)withtheadjustableU
boltclamp.The75ohmcoaxconnectoris
inthecenterfront.
3.
3. Alignthetwohalvesoftheseparatingcolumnandattach
thereector(grid)totheantennaelements(Taperedloops)
bythreadingtheboltthroughthecenterofthecolumn.
Tighten.
1.
4.

877-825-5572
1699WestFifthStreet
Eureka,MO63025
www.antennasdirect.com
6.
Helpful Tips:
• Ifyourcablerunisgreaterthan75’,Apre-ampliermayberequired.
• UHFsignalsarelineofsight.Getasmuchelevationaspractical.
• AtticInstallationswillcut40%-50%ofyoursignalstrength.
• KEEP ANTENNA AWAY FROM POWER LINES
5. ClearStream 2
Gain and VSWR vs Frequency
Gain is a measure of an antenna’s ability
to concentrate radiated power from a
particular direction. Unlike other anten-
nas that claim high peak values,The gain
of the C2 is not only extremely high but
nearly uniform across the DTV spectrum
VSWR ( Voltage Standing Wave Ratio).
The method used to compute losses from
impedance mismatches. The lower the
number the better. If the VSWR = 1 then
there is no loss.
The efficiency of an antenna is how much
signal received by the antenna actually
makes it to the cable.
The C2 is an extremely efficient antenna.
At its optimum frequency, the mismatch
loss for the C2 is very low - less than .1 dB.
6. ClearStream 2
Horizontal Plane Reception
Patterns
The ClearStream 2 has very forgiving
aiming characteristics with more than 70
degrees of beamwidth across the main
lobe as well as a powerful secondary
rear lobe.This allows the C2 to receive
signals from multiple directions with a
single fixed installation.
Performance 5.
7
8
9
11
10
6
1
2
3
4
5
VSWR
Gain
Ch27
Ch14 Ch52 Ch43
Ch35
Ch19
dB
400MHz 750MHz
CoreDTVspectrum470MHZ-698MHz
