Antik MINI 3 User manual

MINI 3
IPTV Set-top Box
Detailed user manual download
from www.antiktech.com
S/S2
T/T2
C

- 2 -
Dolby Digital:
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDMI:
Transferring uncompressed video data and compressed or uncompressed dig-
ital audio data from a HDMI-compliant source device.
MPEG2:
Audio and video compression and transmission.
Note:
Set-top Box ´s rmware is subject of ongoing software development therefore
not all the functionalities described in the manual respont to the current status.

- 3 -
Content
Content
Important safety instructions and warnings
Connecting of Set-top box to your local network
Connecting of Set-top box to satellite set
Connecting of Set-top box to terrestrial antenna
Connecting of Set-top box to your Wi-Fi network
Connecting of Set-top box to a television
Connecting of Set-top box to a television using analogue AV cable
Controlling of Set-top box by IR2
Connecting of Set-top box to the mains supply
Identication of parts
The remote control (RC) functionality
The remote control (RC) functionality- learning / universal buttons- settings
Main menu
Other optional Set-top box features
Channel Browsing
Settings- TV outputs
Frequently asked questions (FAQ)
Technical Specication
3
4
5
6
7
8
9
10
10
11
11
12
13
14
14
16
17
18
19

- 4 -
IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS
POZOR!
Nebezpečenstvo úrazu
elektrickým prúdom!
Neotvárajte zariadenie!
WARNING! To reduce the risk of re or electric shock, do not expose the device to rain or moisture.
• Do not remove device covers as this may result in personal injury or mechanical damage. There are no user serviceable
parts inside
• Position the cables so that they cannot be walked on or pinched by items placed on or against them
• Use only power cables provided in the box.
• Make sure that the voltage of your electricity supply is the same as that indicated on the rear of your set-top box
• Do not place it on soft or slippery surface.
• Do not place any objects on top of the set-top box or near it.
• Do not block any ventilation openings.
• Put the device in a properly ventilated area, away from direct sunlight or any source of heat.
• Do not install it near any electrical device.
• Do not expose the device to inuence of magnetic eld
• Protect it from chemicals, dust and humid environment.
• Unplug this set-top box during lightning storms
• Clean only with dry cloth while set-top box is powered off
• Do not use any detergent to clean it.
• Keep it away from the rooms with high humidity.
• Use only certied remote control batteries.
• Under any circumstances do not dispose of this product with your normal household waste.
• Refer all servicing to qualied service personnel only at your provider
• Your provider will not accept liability for any damage caused by not following these safety instructions and warnings
- Read these instructions carefully!
- Follow these instructions!
- Mind all the warnings!

- 5 -
CONNECTING OF SET-TOP BOX TO YOUR LOCAL NETWORK
868MHz MODEM
868MHz INTERNET/MODEM
RJ 45 cable
Router
1. Connect a set-top in your service provider’s own network.
RJ 45 cable- Computer / VoIP telephone
RJ 45 cable
2. Connect your set-top box outside of your television service provider’s own network.
RJ 45 cable
In case of connecting your set-top box outside
of your television provider’s own network, due to
internet data saving the Set-top Box is automat-
ically shut down after 2 hours of remote control
inactivity.
Number of RJ45 connectors on the back panel depends on the
version of Mini 3 Set-top Box.

- 6 -
CONNECTING OF SET-TOP BOX TO SATELLITE SET
868MHz INTERNET/MODEM
RF cable with F connector
RF cable
How to connect a STB with satellite set to receive satellite broadcast.

- 7 -
868MHz INTERNET/MODEM
CONNECTING OF SET-TOP BOX TO TERRESTRIAL ANTENNA
RF cable with F connector
RF cable
How to connect a STB with terrestrial antenna to receive DVB-T/T2 broadcast.

- 8 -
CONNECTING OF SET-TOP BOX TO YOUR Wi-Fi NETWORK
1. Place your Set-Top Box within the reach of wireless network
2. Connect Set-Top Box to wireless network
3. Use the following steps to set the connection in Menu:
Settings > Wi > Scan AP > Select AP > Insert password > Connection
InternetRouter
RJ 45 kábel
The recommended wireless network signal strength for stable service functionality over a
wireless network is at least 80%.
*Wi available only on selected models. Possibilty of adding external Wi antenna.

- 9 -
CONNECTING OF SET-TOP BOX TO A TELEVISION
Connecting to a Television by a HDMI cable.
868MHz MODEM
HDMI cable - TV/Set-top Box
Using this type of connection set in Menu:
1. Settings / TV Outputs / Type of connection – HDMI / HD resolution – 1080i,720p
or 576i (480i for NTSC) depending on type of TV.
2. Conrm it by pressing the Use button. Set-top box will restart.

- 10 -
CONNECTING OF SET-TOP
BOX TO A TELEVISION USING
ANALOGUE AV CABLE
Connecting to a Television by a
AV adaptor cable.
CONTROLLING OF
SET-TOP BOX BY IR2
Controling a STB by a IR2 sensor,
if STB is hidden ( e.g. in furniture).
IR2 cable (1,2m) - connected to Set-top Box
IR2 sensor
- to be placed in visible area
AV cable adapter
868MHz MODEM 868MHz MODEM
AV cable

- 11 -
868MHz MODEM
868MHz MODEM
After connecting of a Set-top box to a
Television or PC screen by one of the
mentioned options, plug the set-top box
into the mains supply.
In order to put Set-top box into standby
mode use standby button on remote
control. Do not unplug the Set-top box
from the mains supply.
CONNECTING OF SET-TOP
BOX TO THE MAINS SUPPLY
12V DC 2A
IDENTIFICATION
OF PARTS
Front panel
Back panel
LED
standby
controler
DC 12V
LAN AV
HDMI
USB
SPDIF
IR2
IR sensor
WAN
DVB-T/T2/C
Smart Home
DVB-S/S2
or

- 12 -
THE REMOTE CONTROL (RC) FUNCTIONALITY
*Remote control can vary according to actual remote control offer
TV
STB
VOL -VOL +SOURCE
EPG
BACK EXIT
INFO
OK
VOLCH
SEARCH
MENU
2 ABC1 .,?! 3 DEF
5 JKL4 GHI 6 MNO
8 TUV7 PQRS 9 WXYZ
0 +
-/-- *a/A #
1
**26
10
24
11
9
7
12
2
3
*4
8
20
25**
22
23
17
21
9
19
18
16*
13
14
*5 15*
6
On/O󰀨- Standby
Numeric Keys 0-9 switching the channels
Switching the channels for 2 and 3 digits program number
* TV
* Radio
MENU- to display or exit the menu
Volume settings
Play/Pause
Forward/Rewind- during Play by 0,5 min., during Pause by 2 min.
EPG- Electronic Program Guide- to display program list of
channels
Time display
MUTE- disable or enable the sound
The last watched channel
Settings
* Recording
* Channel selection
Information about current program, time remaining to its end
-information about following programs
-bu󰀨er- amount of downloaded audio and video segments
STOP - Press Stop + Play/Pause to move to the start and play,
Record button
Selected option conrmation
Navigation keys- for moving within the menu
-for switching the channels in channel list in 1 position- Up/
Down arrows
-for switching the channels in channel list in 5 position- Right/
Left arrows
Exit button
Turn on /Turn o󰀨 the TV
Learning / Universal buttons
One step back
** Channel menu- its content depends on your TV service provider
For example
- Display Mode
- Audio track change
- PIP- picture in picture- On/O󰀨
- Teletext (only on supported channels)
-Subtitles (only on supported channels)
Searching of media content within STB’s Video / EPG content
*Color coded buttons- buttons of various functionalities based
on chosen menu.
**Buttons of various functionalities- depends on your television
service provider
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.

- 13 -
Krok 1
Položte 2 DO oproti sebe
IR diódou na vzdialenosť 1 cm
.
Krok 2
Zatlačte spoločne tlačidlá
Standby TV a OK, pokiaľ
neostane rozsvietená
červená LED.
Krok 3
Zatlačte tlačidlo Standby TV
na ovládači k STB a následne
Standby tlačidlo na ovládači
k TV. Opakujte postupne
pre ostatné tlačidlá.
Krok 4
Po ukončení kroku 3 zatlačte
tlačidlo OK pre uloženie.
THE REMOTE CONTROL (RC) FUNCTIONALITY
-Learning / universal buttons- settings
Step 1 – Put 2 Remote Controls IR
facing in 1 cm.
Step 2 – Keep pressing Stanby TV and
OK buttons together until LED keeps on.
Step 3 – Press Set-top Box RC Stanby
TV button and then press TV RC Stanby
button. Repeat with other buttons.
Step 4 – After nishing step 3, press OK
to save these settings.

- 14 -
Archive- Archive by genre Media player (music, pictures, movies)
OTHER OPTIONAL SET-TOP BOX FEATURES
Detailed user manual on www.antiktech.com
MAIN MENU
Move through the Main Menu to the left or to the right by using direction arrows
on remote control.

- 15 -
Multi EPG
Weather
Youtube
Video on Demand
Mosaic Internet Browser
Other optional features of Set-top Box depends on the actual STB rmware developement.

- 16 -
CHANNEL BROWSING
Move by 1 channel a time using up and down arrows on remote control.
Move by 8 channels by using CH a CH
The numerical position
of the channel in the list Following program
Use the right arrow
button on RC to move
to Multi EPG
The name of the
program service Current time
EPG Electronic
Program Guide (for
selected channels)
Use the left arrow
button on RC to move
to Mosaic
<
<

- 17 -
SETTINGS - TV OUTPUTS
Use right arrow to enter the right side of Settings. Use Menu button to return to the left side
of Settings.
When Type of con-
nection is HDMI or
DVI monitor or *YPbPr
you may choose HD
resolution
1080i / 720p / 576i -
(480i for NTSC).
Conrming of the
selected choice.Set-top
box will restart.
Return to the
left side of Settings
TV aspect ratio:
Switching the formats
16:9 / 4:3
HDMI- CEC set TV and
STB to turn on/ turn o
simultaneously
Image stretching /
cropping settings:
Fullscreen / LetterBox/
PanScan
Broadcast system
PAL / NTSC

- 18 -
FREQUENTLY ASKED QUESTIONS (FAQ)
Before you contact your provider regarding any troubles with your set-top box, check these
Frequently Asked Questions. You might nd your answer right here.
• double check Menu/Settings/TV Outputs – if all selected options are in compli-
ance with connection of set-top box to your TV (depending on type of your TV)
• check the connection of AV cable (if you are connected via AV cable or AV cable
adaptor)
• volume is down or MUTE button on remote control of set-top box or TV is pressed
Picture on the screen is OK
but there is no sound
No picture
Channel list is empty
No response to remote
control
Picture freezes
Square blocks picture
Quality of Picture is not
satisfactory
Everything seems to be set
correctly, but there are no
channels in Channel list
• incorrect setting of TV Outputs on your TV (depending on type of your TV)
• channel list is downloaded automatically once per 24 hours or by unplugging of
set-top box from mains lead and plugging it in straight after
• double check if set-top box is connected to internet network
• no remote control batteries in or remote control batteries exhausted
• front panel obstructed
• try to switch to another channel or restart set-top box by unplugging / plugging in
from/to mains lead or unsufcient internet bandwidth
• check if internet cable was not for some reason interrupted or damaged
• restart set-top box
• check if Menu/Settings/TV Outputs are correctly set (depending on type of your
TV)
• it could be causing by connection of a router between set-top box and internet
cable – restart router and set-top box at the same time
• check if diode on WAN port is lit (if it is not, disconnect/connect internet cable)
PROBLEM POSSIBLE SOLUTION

- 19 -
To save up internet datas, Set-top box switches o automatically after 2 hours of remote control inac-
tivity. Number of RJ45 connectors on back panel depends on STB version.
TECHNICAL SPECIFICATION
Dimensions: 183 x 137 x 47 (mm)
Power Supply: 12V/2A (external power supply adaptor 100-240V, 50/60Hz)
Connectors:
HDMI 2.0a
AV connector (CVBS, L+R audio)
TOSLINK (S/PDIF digital optical audio output)
antenna RF input (optional)
Hardware:
CPU: HiSilicon Hi3798CV200 4xCortex A53 (15000 DMIPS)
GPU: MALI - T720
DRAM: 2GB (DDR3 - 1866)
Flash: eMMC 8GB
Embedded Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz, 2x2, 867M) (Only on selected models.)
1xRJ45 / 4xRJ45 (10/100/1000M) VLAN supported
DVB-T/T2/C tuner DVB-S/S2 tuner (Tuners available only on selected models.)
1xUSB 3.0 (back panel) + 1xUSB 2.0 (side panel)
external IR sensor
Modem
Video:
MPEG-1/2, MPEG-4 part 2 (DivX, XviD)
4kp60 10-bit HEVC, 4kp30 8-bit VP9
H.264 (AVC)
VC-1 (WMV9)
Flash (VP6, Sorenson)
Audio:
MPEG-1/2 (layer I/II)
MP3
Dolby Digital (AC-3)
AAC (HE-AAC v2 Prole)
FLAC
Vorbis
Operating system: Linux
Accessories: Remote control, AV Cable adaptor, Power supply adaptor, HDMI cable, Batteries, Manual, IR 2
extended cable (only on selected models)

- 20 -
