AP574
AUDIO WIRELESS RECEIVER AND TRANSMITTER
Installation and Operating Instructions
IMPORTANT! PLEASE READ THESE INSTRUCTIONS CAREFULLY
1. Micro USB
charging port
2. 3.5mm AUX port
3. LED status light
4. Multi-function
button
5. RX/TX switch
Accessories:
1 x Micro USB Cable
1 x Audio Cable
Turn On: Press and hold the button 6s till the blue light is flashing in 1s intervals.
Turn Off: Press and hold the button for 3s till the light turns off.
Pairing and searching status: Choose the transmit or receive mode by sliding the switch, press and hold the button for 9s.
Transmit mode: Blue LED light will flash searching nearby Bluetooth device.
Receive mode: Red/Blue LED light will be flashing alternatively waiting to pair with the nearby Bluetooth device.
Clear the paired list: When the unit is OFF, long press the button for 16s until the red/blue LED flash
at the same time. This will clear all the previous paired memory.
Memory function: Each time the device is turned on, it will connect to the last paired device automatically.
Unconnected/standby status: Blue light flashing once 1s.
Connected/standby status: Blue light flashing once twice each 4s
Automatic turning off function: If no device connection is found in 5 mins, it will turn off automatically.
Low power status: Both receiver/transmitter mode status flashing slowly.
This product is built-in rechargeable battery. Please charge it fully before first use.
1. Insert the Micro USB charging cable into the product charging port and the other side into standard USB port .
2. Approximately 2 hours charging time
3. while the LED light is red, it is charging.
4. Product can be used while charging, although it might affect charging time.
5. Receive/Transmit mode LED status light flashes slowly when the battery is low.
PRODUCT DESCRIPTION SPECIFICATION
FUNCTION
CHARGING
CPIN006177A5 148 x 210mm
4
1
2
3
5
Bluetooth version 5.0
Supported protocol A2DP, AVRCP
Bluetooth distance 10m (in open space)
Operating time per
full charge Up to 6 hours
Charging time Up to 2 hours
Charging input voltage 5VDC 1A
Input/Output
connecting mode 3.5mm stereo audio port
Compatibility Bluetooth enabled
devices

CONNECTING INSTRUCTIONS
LED LIGHT STATUS
TROUBLESHOOTING
CPIN006177
CPIN006177A5 148 x 210mm
1. Receiver mode:
• Slide the switch to RX end. Press button for 9s to turn
the device on (Note: Ensure to slide switch to RX before
turning the device on).
• After the device is turned ON, the indicator status LED
light red/blue will flash alternatively waiting to be paired.
• Plug input 3.5mm cable to the AUX port into the device
and the other end to your home audio device such as
speakers, headphones etc.
• Open your phone or tablet and enable Bluetooth. Look
for device ‘AP574’ on the list and connect.
• Upon successful connection, the blue light on the device
will flash slowly (twice every 4s).
2. Transmitter mode:
• Slide the switch to TX end. Press button for 9s to turn
the device on (Note: Ensure to slide switch to TX before
turning the device on).
• After the device is turned ON, the indicator status LED
light blue will flash alternatively waiting to be paired.
• Plug input 3.5mm cable to your device such as phone,
tablet, computer etc. and the other end to the AUX port
into this device.
• Bluetooth status blue light will flash fast. Please put your
Bluetooth device close to connect.
• Upon successful connection, the blue light on the device
will flash slowly (twice every 4s).
Note: For faster connection, ensure that the Bluetooth
connecting devices (speakers, headphones) are turned on
first before
turning this device ON.
Charging:
This product has a built-in rechargeable battery.
It is recommended to fully charge the battery
before first time use.
• Insert micro-USB charging cable into the charging
port of the device. Plug another USB end to the
standard USB charging supply such as mobile
chargers, PC USB interface.
• Red light indicates charging state. Once the device is
fully charged, the red indicator light will turn off.
• The device can be operated (i.e. used as receiver/
transmitter) whilst charging.
• Low battery mode is shown by the indicator
light flashing slowly.
If connection fails or cannot connect for a long time, please turn the device off. Try to pair again. Alternatively, long press
the button for 16s to clear the pairing memory and then, try once again.
• Check the device you are trying to connect operates on its own.
• Different Bluetooth device can have different connecting protocol and varying search/pairing time.
Device Status Red light indicates charging state. Once the device is fully
charged, the red indicator light will turn off.
OFF All LED lights are OFF
Receiver mode Turning ON – Press and hold
the button for 9s
Red/blue LED light alternatively flashing fast
Low Battery Red light flashing
Waiting for a connection/
standby mode
Bluetooth status blue light flashing fast once every 1s
Successful connection Bluetooth status blue light flashing slow twice every 4s
Transmitter mode Turning ON – Press and hold
the button for 9s
Blue LED light fast flashing
Low Battery Red light flashing
Waiting for a connection/
standby mode
Bluetooth status blue light flashing fast once every 1s
Successful connection Bluetooth status blue light flashing slow twice every 4s
Compatibility Bluetooth enabled devices
