any H5CLR User manual

RESET
h
m
s
RESET
START
GATE
RUN
OUT
K/P
H5CLR
Operating voltage
Allowable operating
voltage range
Rated frequency
Contact rating
Reset time
Power consumption
Life
Ambient temperature
Ambient humidity
Weight
Mechanical : 5,000,000 times / Electrical : 100,000 times
85 ~ 110% of rated operating voltage
50 / 60Hz
MAX 0.1s
250VAC 5A (Resistive load)
Approx. 2.5VA
-10Д+50°C
MAX 85% RH
Approx. 120g(H5CLR) / 150g(ASY-4DR)
AC/DC : 12Д48V / AC/DC : 100Д240V
NAMES AND FUNCTIONS OF FACEPLATESPECIFICATIONS
SETTING PROCEDURE
CONNECTION
Product is subject to change without notice.
Upper display
Display PV values (current time, etc.) or
setup items.
Lower display
Display SV values (set time, etc.) and
other parameter values.
key :
Used for incrementing or decrementing
numeric values.
Performing arithmetic shift operations and
switches the display. Hold down for at least
3 seconds to enter setting modes.
LEDs
RUN: Timing indicator
OUT: Control output indicator
K/P: Key protection indicator
RESET: Reset indicator
START: Start indicator
GATE: Gate indicator
h: Time unit display (Hour)
m: Time unit display (Minute)
s: Time unit display (Second)
key :
Reset the output or save the value
of setting.(after save than back to
the operation mode)
key :
RESET
POWER ON or
RESET
Reset
SPECIAL FUNCTION KEY
TIME RANGE
9.999s
Select the
time range
Switch to output
setting mode
OUTPUT MODE
Select
output mode
Switch to count up/down
setting mode
UP / DOWN MODE
Select count up
or count down
Switch to input signal
time setting mode
INPUT SIGNAL TIME
Select input
signal time
ϡMode A1,A2,A3,B1,B2,C,D and F are not available on ASY-4DRϭand H5CLR-8
OUTPUT TIME
Select
output time
ϡNot functionable on MODE C,D,E and F
ϡNot available for ASY-4DRϭand H5CLR-8
Switch to key protection level
setting mode
KEY PROTECTION LEVEL
Select key
protection level
Switch to output contact
setting mode
OUTPUT CONTACT
Select output
contact
ϡAvailable on H5CLR-8/-11 and ASY-4DRϭʳtype only
Switch to time range
setting mode
4
3
2
18
7
6
5
SOURCE
RESET
START
H5CLR-8 & ASY-4DRϭH5CLR-8G & ASY-4DRGϭH5CLR-11 H5CLR-11M
T.D. INST.
4
3
2
18
7
6
5
SOURCE
3
21
8
9
10
11
7
6
5
4
SOURCE
T.D. INST.
RESET
START
3
21
8
9
10
11
7
6
5
4
SOURCE
START
GATE
K / P
(Sensor)
Common (0V)
12 VDC(50 mA)
Load
(-) (+)
RESET
H5CLR / ASY- 4DR
MULTI-FUNCTION DIGITAL TIMER
User's Manual
SAFETY PRECAUTION
This manual uses the following symbols to ensure safe operation of this timer.
WARNING
CAUTION
Warnings are indicated when mishandling this product might result in death or serious injury
Cautions are indicated when mishandling this product might result in minor injury to the user,
to user.
or only physical damage to the timer.
ΘNote this incorrect wiring of this product can damage it and lead to other hazards. Make sure the product has
been correctly wired before turning the power ON.
ΘBefore wiring, or removing / mounting the product, be sure to turn the power OFF. Failure to do so might cause
electric shock.
ΘDo not touch electrically charged parts such as the power terminals. Doing so might cause electric shock.
ΘDo not disassemble the product. Doing so might cause electric shock or faulty operation.
ΘUse the product within the operating ranges recommended in the specification (temperature, humidity, voltage,
shock, mounting direction, atmosphere and etc.). Failure to do so might cause fire or faulty operation.
ΘFirmly tighten the wires to the socket. Insufficient tightening of the wires to the socket might cause fire.
WARNING
CAUTION
When using this product in applications
that require particular safety or when
using this product in important facilities,
please pay attention to the safety of the
overall system and equipment. Install fail-
safe mechanisms, perform redundancy
checks and periodic inspections and
adopt other appropriate safety measures
when it is necessary.
RESTRICTIONS ON USE
RESET
99.99s
999.9s
Count up
Count down
9999s
999.9m
9999m
999.9h
9999h
99m59s
99h59m
Hold
0.1s
20ms
1ms
0.5s
1s
5s
10s
15s
20s
Mode A
Mode A1
Mode A2
Mode A3
Lock function key
Lock reset key
2C
1A1C
Lock preset value key
Lock all key
Mode B
Mode B1
Mode B2
Mode C
Mode D
Mode E
Mode F
See reverse page for more details
Switch ON / OFF Key
protection
PRESS FOR 3s PRESS FOR 3s
Switch to input setting mode
RESET
Switch to input setting mode
(1)Stop (2)Timing
PRESS
FOR 3s
PRESS
FOR 3s
or
Switch to input setting mode
RESET
RESET
Save and back to the
operation mode
or
RESET
Save and back to the
operation mode
or
RESET
Save and back to the
operation mode
or
RESET
Save and back to the
operation mode
or
RESET
Save and back to the
operation mode
or
RESET
Save and back to the
operation mode
or
Switch to output time
setting mode
RESET
Save and back to the
operation mode
or

http://www.relay.com.cn http://www.timer-relay.com
TIMING CHART(Output mode)
DIMENSION(mm)
M-H5CLR-C-A
ANY ELECTRONICS CO., LTD.
ASY-4DRN / ASY-4DRGN ASY-4DRY / ASY-4DRGY + US-08
H5CLR H5CLR + Y-50 + US-08
A: Signal ON delay 1 (Timer resets when power comes ON.)
A-1 : Signal ON delay 2 (Timer resets when power comes ON.)
A-2 : Power ON delay 1 (Timer resets when power comes ON.)
A-3 : Power ON delay 2 (Timer dose not reset when power comes ON.)
B-1 : Repeat cycle 2 (Timer dose not reset when power comes ON.)
B: Repeat cycle 1 (Timer resets when power comes ON.)
F: Cumulative (Timer does not reset when power comes ON.)
E: Interval (Timer resets when power comes ON.)
B-2 : Repeat cycle ON start (Timer resets when power comes ON.)
C: Signal ON/OFF delay (Timer resets when power comes ON.)
D: Signal OFF delay (Timer resets when power comes ON.)
RESET
h
m
s
RESET
START
GATE
RUN
OUT
K/P
H5CLR
45+0.5
-0
45+0.5
-0
RESET
h
m
s
RESET
START
GATE
RUN
OUT
K/P
ASY-4DR
ANLY ELECTRONICS CO.
RESET
h
m
s
RESET
START
GATE
RUN
OUT
K/P
ASY-4DR
ANLY ELECTRONICS CO.
45+0.5
-0
45+0.5
-0
RESET
h
m
s
RESET
START
GATE
RUN
OUT
K/P
H5CLR
Timing starts when the start signal goes ON. *Note1
The control output is controlled using a sustained or
one-shot time period.
Timing starts when the reset input goes OFF.
The start signal disables the timing function (ie., same
function as the gate input).
The control output is controlled using a sustained or
one-shot time period.
Timing starts when the reset input goes OFF.
The start signal disables the timing function (ie., same
function as the gate input).
The control output is controlled using a sustained or
one-shot time period.
Timing starts when the start signal goes ON. *Note1
The status of the control output is reversed when time is up
(OFF at start).
Timing starts when the start signal goes ON. *Note1
The status of the control output is reversed when time is up
(OFF at start).
Timing starts when the start signal goes ON. *Note1
The status of the control output is reversed when time
is up (OFF at start).
Timing starts when the start signal goes ON or OFF.
The status of the control output is ON when the start
signal goes ON or OFF.
The control output is ON when the start signal is ON
(except when the power is OFF or the reset is ON).
The timer is reset when the time is up.
Timing starts when the start signal comes ON. *Note1
The control output is reset when time is up.
Start signal enables timing (timing is stopped when the start
signal is OFF or when the power is OFF)
A sustained control output is used.
Timing starts when the start signal goes ON, and is reset
when the start signal goes OFF. *Note1
The control output is controlled using a sustained or one-
shot time period.
*Note1. While the start signal is ON, the timer starts when power
comes ON or when the reset input goes OFF.
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
tt
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
t
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
t t a t - a
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
t
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
SOURCE
Start signal
Gate
Reset
Control output
Set value
0
Set value
0
UP
DOWN
UP
DOWN
SOURCE
Start signal
Reset
Control output
Set value
0
Set value
0
UP
DOWN
SOURCE
Start signal
Reset
Control output
Set value
0
Set value
0
