Aoc Le32d5210_65 User manual

LE32D5210_65

1

English

This manual provides as an operational guide to user. All statements, technical information, and recommendations in

this manual and in any guides or related documents are believed reliable, but the accuracy and completeness thereof

are not guaranteed or warranted, and they are not intended to be,nor should they be understood to be, representations

or warranties concerning the products described.

English

2

Table of Contents

IMPORTANT INFORMATION ��3

WARNING...............................................................................................................................................................................................3

Note ........................................................................................................................................................................................................3

Disposal of your old product ...................................................................................................................................................................3

IMPORTANT SAFETY INFORMATION ��3

USAGE INSTRUCTIONS��4

Installation...............................................................................................................................................................................................4

AC Power Cable .....................................................................................................................................................................................4

LCD Screen ............................................................................................................................................................................................5

Wiring .....................................................................................................................................................................................................5

Electric Shock .........................................................................................................................................................................................5

ThunderStorms .......................................................................................................................................................................................5

When Not in Use.....................................................................................................................................................................................5

Overloading ............................................................................................................................................................................................5

Optional Equipment ................................................................................................................................................................................6

Small Accessories ..................................................................................................................................................................................6

Antennas.................................................................................................................................................................................................6

Batteries..................................................................................................................................................................................................6

Cleaning..................................................................................................................................................................................................6

Magnetic Inuence..................................................................................................................................................................................6

Sound......................................................................................................................................................................................................7

Carrying the TV.......................................................................................................................................................................................7

Ventilation ...............................................................................................................................................................................................7

Moisture ..................................................................................................................................................................................................7

Volume Adjustment .................................................................................................................................................................................8

Servicing .................................................................................................................................................................................................8

CONTENTS IN THE BOX ��9

CONTROLS & CONNECTIONS ��10

REMOTE CONTROLLER �� 11

TV INSTALLATION ��12

Inserting Batteries into the Remote control...........................................................................................................................................12

Attaching the Base................................................................................................................................................................................12

Wall-Mounting .......................................................................................................................................................................................12

CONNECTING TV��13

Cable System or VHF/UHF Antenna System........................................................................................................................................13

High Denition Interface........................................................................................................................................................................13

HDMI Connection..................................................................................................................................................................................13

Component Signal Connection .............................................................................................................................................................13

Composite Signal Connection...............................................................................................................................................................14

PC Connection......................................................................................................................................................................................14

Connecting USB drive...........................................................................................................................................................................14

PC INPUT SIGNAL REFERENCE CHART ��15

DVI/ PC HDMI INPUT SIGNAL REFERENCE CHART ��15

VIDEO INPUT SIGNAL REFERENCE CHART ��15

VIDEO SYSTEMS SUPPORTED BY THE TV,VIDEO MODES�� 15

HOW TO USE YOUR AOC TV SET��16

Power On And off..................................................................................................................................................................................16

Switch between input sources ..............................................................................................................................................................17

Picture Setup ........................................................................................................................................................................................18

Picture Setting(For PC source only) .....................................................................................................................................................19

Audio Setup ..........................................................................................................................................................................................20

Features Setup .....................................................................................................................................................................................21

Channel Setup ......................................................................................................................................................................................22

Manual search description ....................................................................................................................................................................23

Computer Setup....................................................................................................................................................................................24

USB MEDIA CENTER��25

1. Viewing JPEG les............................................................................................................................................................................25

2. Playing MP3 Files .............................................................................................................................................................................26

3. USB Media Center Settings ..............................................................................................................................................................28

DIMENSIONS & SPECIFICATIONS ��29

TROUBLESHOOTING�� 30

WEEE/E-WASTE DECLARATION FOR INDIA ��31

3

English

Important Information

WARNING

High voltage! No serviceable inside your TV

set. Consult qualified technician or authorized

personnel for any maintenance service.

To avoid electric shock please

disconnect the power line to your

device before moving its rear panel.

Be aware of high voltage

This symbol is intended to alert the user to the

presence of insinuated “dangerous voltage”

within the TV’s enclosure that may be of sufcient

magnitude to constitute a risk of electric shock to

persons.

This symbol is intended to alert the user to the

presence of important operating and maintenance

(servicing) instructions in the enclosed document

accompanying the TV.

To reduce the risk of re or electric shock, do not expose theTV

to rain or moisture, and no objects lled with liquids, such as

vases, shall be placed on the TV.

Note

To prevent electric shock, do not use AC power cord with

an extension cord. Insert the power cord fully into the power

socket.

Please use only the recommended wall mount rack or TV

stand and please consult your dealer for detailed information.

Using non-recommended wall mount rack or TV stand may

tamper the installation and result in personal injury.

Disposal of your old product

We have put special efforts in environment protection.Your

product contains materials that can be recycled. After its lifecycle

a professional service provider may take apart disposed TV sets

for re- usable materials and minimizes the amount of materials that

need disposal. Light tubes of your product contain mercury please

check local regulation for their disposing. Please dispose your old

products in accordance with the domestic regulations.

Important Safety Information

1 ) Read and keep these instructions.

2 ) Please be aware of any warning.

3 ) Please follow all the instructions being specified.

4 ) Make sure that only proper power supply is used.

5 ) Do not expose your product to high temperature and/or

humidity.Do not use your product in an area of dust and/or strong

shock vibration.

6 ) Do not block any ventilation openings to prevent internal

heat buildup. Install in accordance with the manufacturer’s

instructions.

7 ) Do not install near any heat sources such as radiators,heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

8 ) Do not use your product near water.

9 ) If the plug supplied with your TV does not fit with the socket

please consult an electrician to replace the old socket.

10 ) Protect the power cord from being walked on or pinched

particularly at plugs, receptacles and the point where they exit

from the apparatus.

11 ) Only use attachments/accessories specified by the

manufacturer.

12 ) Use only with a cart, stand, tripod, bracket, or table specified

by the manufacturer, or sold with the apparatus. When a cart is

used, use caution when moving the cart/apparatus combination

to avoid injury from tip-over.

13 ) Unplug the TV during lightening storms or when unused for

long period of time.

14 ) Refer all servicing to qualified service personnel. Servicing

is required when the TV has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled

and the TV has been exposed to rain or moisture or does not

operate normally, or has been dropped.

15 ) If there is any liquid and/or solid object fall on your product

please unplug the power cord immediately and consult qualified

service personnel for inspection before using your product again.

16 ) Do not use your TV in temperature below 0ºC.

17 ) When moving your product from a cool room or when

temperature fluctuate your TV may display vaguely and/or with

abnormal color because of water condensing. Please wait for

several hours until the condensed water is evaporated then you

can use your TV again.

AOC has created unique and exclusive sound technology-DSS

Dream Surround.

Function

1 ) Emulates and delivers surround sound ensures clear and

intelligible vocals.

2 ) Extremely broad sweet spot.

3 ) Optimizes low frenquency performance of small speakers.

4 ) Intelligent multi-band monitoring and analysic ensures

consistent volume while delivering a more natural listening

experience.

5 ) Optimizes low or middle speakers performance with rich bass.

English

4

Usage Instructions

Installation

Placement

It is recommended to watch the TV at a distance of 3 -7 times which

of the screen height, and in moderate brightness. Watching the TV

for too long or in a dark room may cause eye fatigue. To obtain a

clear picture, do not expose the screen to direct illumination or direct

sunlight. It is recommended to use spot lighting directed down from

the ceiling or to cover the windows that face the screen with opaque

drapery. It is desirable to install the TV in a room where the oor and

walls are not of a reective material.

3h~7h

h

To prevent the TV from toppling over and causing injury, take

measurement to secure the TV to a wall or stand.

The TV should be installed near an easily accessible AC power

outlet.

Observe the following in placing the TV. Otherwise the TV may fall

from the stand or Wall-Mount, causing damage or serious injury.

• Place the TV on a stable, level surface.

• Do not hang anything on the TV. Do not allow children to climb on

the TV.

• Do not install the TV in places subject to extreme temperatures,

such as in direct sunlight, near a radiator, or near a heating vent or

exposed to direct air conditioning.

• Never place the TV in hot, oily, humidor excessively dusty places.

• Do not install the TV where insects may enter.

• Do not install the TV where it may be exposed to mechanical

vibration.

• Do not install the TV in a location where it may protrude, such as

on or behind a pillar, or where you might bump your head on it.

Otherwise, it may result in injury.

Outdoor Use

Do not install this TV outdoors. If the TV is exposed to rain, it may

result in a re or an electric shock. Do not expose the TV to direct

sunlight, it may heat up and become damaged.

Vehicle, Ships and Other Vessels

• Do not install this TV in a vehicle.

• Bumping of the vehicle may cause the TV to fall down and cause

injury.

• Do not install this TV in a ship or vessel. If the TV is exposed to

seawater, it may cause a fire or damage the TV.

Medical institutions

• Do not place this TV in a place where medical equipment is in use.

• The interference may cause a malfunction of both TV and the

medical equipment.

Attachments

Do not use attachments not recommended by the manufacturer, as

they may cause hazards.

Wall-Mount

Wall-Mount installation requires the use of a Wall-Mount Bracket.

When installing or removing the TV, using a Wall-Mount Bracket,

be sure to use qualied contractors. If not properly secured during

installation or removal from the Wall-Mount Bracket, the TV may fall

and cause serious injury.

For use only with UL Listed Wall Mount Bracket with suitable weight/

load.please refer to page 29.

Observe the following when installing the TV using a Wall-Mount

bracket.

• Be sure to follow the operating instructions supplied with the Wall-

Mount bracket when installing the TV.

• Be sure to attach the brackets supplied with the Wall-Mount

bracket.

• Don’t hang the TV from the ceiling. It may fall and cause serious

injury.

AC Power Cable

• Use the AC power cord specified by AOC and suitable for the

voltage where you use it.

• The plug is designed, for safety purposes, to fit into the wall outlet

only one way. If you are unable to insert the plug fully into the

outlet, contact your dealer.

• If you will not be using the TV for several days, disconnect the

power by pulling the plug itself. Never pull on the cord.

• When disconnecting AC power cord, the power cord should be

easily accessible for disconnection.

TV should be installed near an easily accessible power outlet. Do

not use a poor fitting outlet. Insert the plug fully into the outlet. If

it is loose, it may cause arcing and result in a fire. Contact your

electrician to have the outlet changed.

Observe the followings to prevent the AC power cord from being

damaged. If the AC power cord is damaged, it may result in a re or

an electric shock. Stop using it and ask your dealer or AOC service

center to exchange it.

• Do not place the TV where the power cord is subject to wear or

abuse.

• Do not pinch, bend, or twist the cord excessively. The core lines

may be bared and cut, causing a short-circuit, and resulting in a fire

or an electric shock.

• Do not modify or damage the power cord.

• Do not allow anything to rest on or roll over the power cord.

• Do not move the TV with the power cord plugged in.

• Keep the power cord away from heat sources.

• To unplug power cord, disconnect it from the wall outlet first.

• Be sure to grasp the plug when disconnecting the power cord.

• Do not pull the power cord.

• Do not use the supplied AC power cord on any other equipment.

• Use only an original AOC AC power cord, not other brands.

5

English

LCD Screen

• Although the LCD screen is made with high-precision technology

and has effective pixels of 99.99% or more, black dots or bright

points of light (red, blue, or green) may appear constantly on the

LCD screen. This is a structural property of the LCD panel and is

not a malfunction.

• The LCD screen is made with high-precision technology and to

achieve a high level of performance and picture quality, this TV’s

backlight setting is set to maximize the brightness of the TV.

However, uneven brightness may be observed when the LCD TV is

viewed in a dark ambient without an input source or a blank screen.

This condition is normal and not a malfunction of the TV. Changing

the Picture mode, Backlight setting, enabling the Light Sensor, or

turning on the Power management will improve this condition.

• Do not expose the LCD screen surface to direct sunlight. Doing so

may damage the LCD panel.

• Do not push or scratch the LCD screen, or place objects on top

of the TV. The image may be uneven or the LCD panel may be

damaged.

• If the TV is used in a cold place, a smear may occur in the picture

or the picture may become dark. This does not indicate a failure.

These phenomena improve as the temperature rises.

• Ghosting may occur when still pictures are displayed continuously.

It should disappear after a few moments.

• The screen and cabinet get warm when the TV is in use. This is not

a malfunction.

• Avoid spraying insect repellent with volatile material on the screen.

• Avoid prolonged contact with rubber or plastic material.

Broken Pieces

Do not throw anything at the TV. The screen glass may break by the

impact and cause serious injury.

If the surface of the TV cracks, do not touch it until you have un-

plugged the AC power cord. Otherwise electric shock may result.

Handling of broken glass and liquid crystal leakage

If the LCD panel gets damaged, crystalline liquid leakage may occur,

or scattered broken glass may result. Do not touch broken glass or

crystalline liquid which is toxic, with bare hands as cuts, poisoning or

skin irritation may occur. Also, do not let glass fragments or leaked

crystalline liquid get into your eyes or mouth. Should either contact

your eyes or mouth, rinse the contacted area thoroughly with water

and consult your doctor.

Wiring

When connecting cables, be sure to unplug the AC power cord for

your safety. Take care not to catch your feet on the cables. It may

damage the TV set.

Electric Shock

Do not touch the AC power cord or the TV with a wet hand. If you

plug/unplug the AC power cord from the TV with a wet hand, it may

cause electric shock.

ThunderStorms

For added protection for this TV during a lightning storm, or when it

is left unattended and unused for long periods of time, unplug it from

the wall outlet and disconnect the antenna. This will prevent damage

to the TV due to lightning and power line surges.

When Not in Use

If you will not be using the TV set for several days, the TV set should

be disconnected from the AC power outlet for environmental and

safety reasons. The TV set is not disconnected from the AC power

source when the TV set is switched off. To disconnect the TV set

completely, pull the plug from the AC power outlet.

Overloading

This TV set is designed to operate on a 100-240V AC supply only.

Take care not to connect too many appliances to the same AC power

outlet as this could result in a re or an electric shock.

English

6

Optional Equipment

Do not install optional equipment too close to the TV set. Keep

optional equipment at least 11.875 inches (30 cm) away from the TV

set. If a VCR is installed in front of the TV set or beside the TV set,

the picture may become distorted. Picture distortion and/or noisy

sound may occur if the TV set is positioned in close proximity to any

equipment emitting electromagnetic radiation.

Small Accessories

Keep small accessories out of children’s reach.

Antennas

Keep an on following item if outdoor antenna is installed. Install the

outdoor antenna away from high voltage power lines or other light

and power lines. Avoid installing your antenna in places that have

the potential of contacting these lines. Always make sure that your

outdoor antenna is free from these lines as the consequences can be

deadly.

The antenna must be grounded to avoid power surge and static

electricity accumulation.

Clip for grounding wire

Power maintenance equipment

Clip for grounding wire

Grounding media

Grounding electrode system for power maintenance

Antenna

Antenna separation

device

Example of antenna grounding in accordance with national electricity

regulations

Batteries

• Do not dispose of batteries in a fire.

• Do not short circuit, disassemble or overheat the batteries.

• Danger of explosion if battery is incorrectly replaced. Replace only

with the same or equivalent type.

• The batteries (batteries installed) shall not be exposed to excessive

heat such as sunshine, fire or the like.

Disposal of used batteries

To preserve our environment, dispose of used batteries according to

your local laws or regulations.

Cleaning

Cleaning the AC power plug

Unplug the AC power plug and clean it regularly. If the plug is covered

with dust and it picks up moisture, its insulation may deteriorate and

result in a re.

Cleaning the screen surface/ cabinet of the TV set

• Unplug the AC power cord to avoid electric shock when cleaning.

• Clean the cabinet of the TV with a dry soft cloth. To remove dust

from the screen, wipe it gently with a soft cloth. Stubborn stains

may be removed with a cloth slightly dampened with a solution

of mild soap and warm water. Never use strong solvents such as

thinner or benzine for cleaning.

• If using a chemically pretreated cloth, please follow the instruction

provided on the package.

• The ventilation holes can accumulate dust over time. To

ensure proper ventilation, we recommend removing the

dust periodically (once a month) using a vacuum cleaner.

Magnetic Inuence

This TV contains a strong magnet in the speaker unit that generates

a magnetic eld. Keep any items susceptible to magnetic elds away

from the speaker.

7

English

Sound

If a snapping or popping sound from the TV is continuous or frequent

while the TV is operating, unplug the TV and consult your dealer or

service technician. It is normal for some TV’s to make occasional

snapping or popping sounds, particularly when being turned on or off.

?

ding~ Pong~

Carrying the TV

Carry the TV in the specied manner

To avoid dropping the TV and causing serious injury, be sure to follow

these guidelines:

• Before carrying the TV, disconnect all cables.

• Carrying the large size TV requires two or more people.

• When you carry the TV, place your hand as illustrated and hold it

securely. Do not put stress on the LCD panel.

• When lifting or moving the TV, hold it firmly from the bottom. Place

your palm directly under the panel.

• When carrying, do not subject the TV to shocks or vibration, or

excessive force.

Ventilation

The slots and openings in the TV are provided for necessary

ventilation. To ensure reliable operation of the TV and to protect it

from overheating, these slots and openings must never be blocked or

covered.

Unless proper ventilation is provided, the TV may gather dust and get

dirty. For proper ventilation, observe the following:

• Do not install the TV face up, down or sideways.

• Do not install the TV turned over or upside down.

• Never cover the slots and openings with a cloth or other materials.

• Never block the slots and openings by placing the TV on a bed,

sofa, rug or other similar surface.

• Never place the TV in a confined space, such as a bookcase or

built-in cabinet, unless proper ventilation is provided.

Leave some space around the TV set as shown below. Otherwise,

air-circulation may be inadequate and will cause overheating, which

may cause a re or damage to the TV set.

Install on the wall

4 inches

10 cm

4 inches

10 cm

4 inches

10 cm

Leave at least this space

around the set.

11 7/8 inches

30 cm

Installed with stand

4 inches

10 cm

4 inches

10 cm

Leave at least this space

around the set.

11 7/8 inches

30 cm

4 inches

10 cm

Never install the TV set where Air circulation is blocked.

Objects and ventilation holes

Never push objects of any kind into the TV through the cabinet slots

as they may touch dangerous voltage points or short out parts that

could result in a re or an electric shock. Do not place any objects on

the TV.

Moisture

Moisture and ammable objects

• The TV must not be exposed to dripping or splashing. Do not place

objects filled with liquids, such as vases, on the TV.

• Do not use power-line operated TV sets near water— for example,

near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet

basement, or near a swimming pool, etc. It may result in a fire or an

electric shock.

• Do not let this TV get wet. Never spill liquid of any kind on the TV. If

any liquid or solid object does fall through, do not operate the TV. It

may result in electric shock or damage to the TV. Have it checked

immediately by qualified personnel.

• To prevent fire, keep flammable objects or open flame (e.g.

candles) away from the TV.

English

8

Volume Adjustment

Adjust the volume so as not to trouble your neighbors. Sound

carries very easily at night. Therefore, closing the windows or using

headphones is suggested.

When using headphones, adjust the volume so as to avoid excessive

levels, as hearing damage may result.

Servicing

Do not attempt to service the TV by yourself since opening the

cabinet may expose you to dangerous voltage or other hazards.

Refer all servicing to qualied service personnel.

Replacement Parts

When replacement parts are required, be sure the service technician

certies in writing that he/she has used replacement parts specied

by the manufacturer that have the same characteristics as the

original parts.

Unauthorized substitutions may result in a re, an electric shock or

other hazards.

Safety Check

Upon completion of any service or repairs to the TV, ask the service

technician to perform routine safety checks (as specified by the

manufacturer) to determine that the TV is in safe operating condition,

and to so certify. Ask a qualied service technician to dispose of the

TV.

Thank you for purchasing this AOC high-definition television. The

quality of the image you see on your AOC TV is only as good as the

quality of the signal it receives. To experience the stunning detail of

your new AOC TV, you need access to HD programming. Your AOC

TV can receive and display HD programming from:

• Over-the-air broadcasting via HD-quality antenna

• HD cable subscription

• HD satellite subscription

• Blu-ray Disc™ player or other external equipment

Contact your cable or satellite provider for information on upgrading

to HD programming.

Mobile telephone warning

To avoid disturbances in picture and sound, malfunctioning of your

TV or even damage to the TV, keep away your mobile telephone

from the TV.

End of life directive

We are paying a lot of attention to produce environmental friendly in

green focal areas.

Your new receiver contains materials, which can be recycled and

reused.

At the end of its life, specialized companies can dismantle the

discarded receiver to concentrate the reusable materials and to

minimize the amount of materials to be disposed of.

Please ensure you dispose of your old receiver according to local

regulations.

9

English

Contents In The Box

After unpack the TV box, please check the TV and all accessories are well presented and undamaged.

User Manual

User

Manual

Base

Remote Control

Q4 Screw x 4

Batteries for

remote control

Warranty

Card

Warranty Card

AOC TV

Ypbpr

Back

Source

VOL C H

Mute

Display

Zoom

Freeze Picture Sound Nicam

Menu

Sleep

TV AV HDMI

PC

Cover

AOC LE32D5210_65 User manual

Popular LED TV manuals by other brands
