AOC 177S User manual

17” LCD Color Monitor AOC 177S
1
Service
Service
Service
Horizontal Frequency
30KHz-83KHz
TABLEOFCONTENTS
Description Page Description Page
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
Table Of Contents.......…….................……...........…........1
Important Safety Notice.………….…..................……......2
Revision List.…........................………................……......3
1.Product Feature...........................................………........4
2.LCD Monitor Description……………...……………….......5
3.Operation Instruction………….....................……...........6
3.1 General Instructions.......................................…...........6
3.2 Control Buttons………..…….…..............……...............6
3.3 Adjusting the Picture...........................…............8
4. Input/Output Specification..............……………............10
4.1 Input Signal Connector......….…..……........…….........10
4.2 Factory Preset Display Modes........…...............10
4.3 Power Supply Requirement…………………………....11
4.4 Panel Specification..............………………..................12
5.Block Diagram…….…...................…………................14
5.1 Software Flow Chart…………………………....….......14
5.2 Electrical Block Diagram…………..…..….......16
6.Schematic……………..................................….....18
6.1 Main Board..............................................................18
6.2 Power Board....…………..........……........................28
6.3 Key Board....…………….......……........................30
7. PCB Layout..…………...........……...........................31
7.1 Main Board………..................……........................31
7.2 Power Board…....................……………..................32
7.3 Key Board……….....…….............……….................35
8.Maintainability………............................……….........36
8.1 Equipments and Tools Requirement......……….......36
8.2 Trouble Shooting…………..……..............................36
9. White-Balance, Luminance adjustment.............40
10.Monitor Exploded View.…...……………….................41
11.BOM List….................……......................….............42
12.Different Parts List.........…….....................................60
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

17” LCD Color Monitor AOC 177S
2
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performing service
operations. Some of these service operations require the use of tools specially designed for the purpose. The special
tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service methods
may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE NOT
EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in which
service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics might create shock,
fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from AOC. AOC
assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may result
in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to the
panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)

17” LCD Color Monitor AOC 177S
3
Revision List
Version Date Revision History TPV Model Name
T76CNMNKF1ACNIP
A00 Sep-25-06 Initial Release
T76CNNMMF1UNNIP
A01 Jan-23-07 Add the BOM for PWB N/A

17” LCD Color Monitor AOC 177S
4
1. Monitor Specifications
Items Description
Driving system TFT Color LCD
Size 43.2cm (17.0")
Pixel pitch 0.264mm (H) x 0.264mm (V)
Viewable angle 150(H) 130(V) (CR≥10) （type）
Response time (type) 8 ms
Display Color 16.2M
Contrast Ratio 500:1
LCD Panel
White Luminance 300cd/m2
Sync. Type H/V TTL
Input Connector D-Sub 15pin
Input Video Signal Analog:0.7Vp-p(standard),75 OHM, Positive
H-Frequency 30kHz – 83kHz
Input
V-Frequency 55-75Hz
ON Mode ≤45W
Power Consumption
OFF Mode ≤2W
Dot Clock 135MHz
Max. Resolution 1280 x 1024
Plug & Play VESA DDC2BTM
Power Source 100~240VAC,47~63Hz
Maximum Screen Size Horizontal : 338.92mm
Vertical: 270.34mm
Dimensions 383.89(H) x375.45 mm (W) x209.60 mm (D)
Weight Monitor only: 3.7 Kg
Environmental
Considerations
Operating Temp: 5°C to 35°C
Storage Temp: -20°C to 60°C
Operating Humidity: 10% to 85%

17” LCD Color Monitor AOC 177S
5
2. LCD Monitor Description
The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic,
brightness control logic and DDC.
The Inverter board will drive the backlight of panel and DC-DC conversion.
Monitor Block Diagram
AC-IN
100V-240V
Power Board
Flat Panel and
CCFL Backlight
PANEL
（Include Main Board）
Key board
RS232 Connector
For white balance
adjustment in factory
mode
HOST Computer
CCFL Drive.
Video signal, DDC

17” LCD Color Monitor AOC 177S
6
3. Operating Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the
monitor. By changing these settings, the picture can be adjusted to your personal preferences.
•The power cord should be connected.
•Connect the video cable from the monitor to the video card.
•Press the power button to turn on the monitor position. The power indicator will light up.
3.2 Front Panel Control
External Controls
1. Power Button & Indicator 2. Menu / Enter
3. .+ / Contrast 4. - / Brightness
5. Auto Config / Exit

17” LCD Color Monitor AOC 177S
7
FRONT PANEL CONTROL
•Power Button & Indicator:
Press this button to turn the monitor ON or OFF.
Green — Power On mode.
Orange — Off mode.
•MENU / ENTER:
Activate OSD menu when OSD is OFF or activate/de-activate adjustment function when OSD is ON or Exit OSD
menu when in Volume Adjust OSD status.
•+ / Contrast
Activates the contrast control when the OSD is OFF or navigate through adjustment icons when OSD is ON or
adjust a function when function is activated.
•- / Brightness
Activates the Brightness control when the OSD is OFF or navigate through adjustment icons when OSD is ON or
adjust a function when function is activated.
•Auto Adjust button / Exit:
1. When OSD menu is in active status, this button will act as EXIT-KEY (EXIT OSD menu).
2. When OSD menu is in off status, press this button for 2 seconds to activate the Auto Adjustment function.
The Auto Adjustment function is used to set the HPos, VPos, Clock and Focus.
OSD Lock Function: To lock the OSD, press and hold the MENU button while the monitor is off and then press power
button to turn the monitor on. To un-lock the OSD - press and hold the MENU button while the monitor is off and then
press power button to turn the monitor on.
NOTES
•Do not install the monitor in a location near heat sources such as radiators or air ducts, or in a place subject to
direct sunlight, or excessive dust or mechanical vibration or shock.
•Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your
monitor.
•For maximum protection, repackage your monitor as it was originally packed at the factory.
•To keep the monitor looking new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth
lightly dampened with a mild detergent solution. Never use strong solvents such as thinner, benzene, or abrasive
cleaners, since these will damage the cabinet. As a safety precaution, always unplug the monitor before cleaning it.

17” LCD Color Monitor AOC 177S
8
3.3 Adjusting the Picture
1. Press the MENU-button to activate the OSD window.
2. Press - or + to navigate through the functions. Once the desired function is highlighted, press the MENU-button
to activate it. If the function selected has a sub-menu, press < or > again to navigate through the sub-menu
functions. Once the desired function is highlighted, press MENU-button to activate it.
3. Press < or > to change the settings of the selected function.
4. To exit and save, select the exit function. If you want to adjust any other function, repeat steps 2-3.
THE DESCRIPTION FOR CONTROL FUNCTION:
Main Menu
Item
Main
Menu
Icon
Sub Menu
Item
Sub Menu
Icon Description Adjust Range Reset Value
Contrast
Contrast from Digital-register. 0-100 Recall Cool
Contrast Value
Luminance
Brightness
Backlight Adjustment 0-100 Recall Cool
Brightness Value
Focus
Adjust Picture Phase to reduce
Horizontal-Line noise 0-100 Do Auto Config
Image Setup
Clock
Adjust picture Clock to reduce
Vertical-Line noise. 0-100 Do Auto Config
H. Position
Adjust the horizontal position of the
picture. 0-100 Do Auto Config
Position V. Position
Adjust the vertical position of the
picture. 0-100 Do Auto Config
Warm N/A
Recall warm Color Temperature
from EEPROM. N/A
Cool N/A
Recall cool Color Temperature from
EEPROM. N/A
Color Temp.
sRGB N/A
Recall sRGB Temperature from
EEPROM. N/A
The Color
Temperature will
be set to Cool.
The User R/G/B
value (default is

17” LCD Color Monitor AOC 177S
9
User / Red
Red Gain from Digital-register. 0-100
User /Green
Green Gain from Digital-register. 0-100
User / Blue
Blue Gain from Digital-register. 0-100
100) will not be
Modified by Reset
function.
Yes N/A
A
uto Adjust the H/V Position, Focus
and Clock of picture. N/A N/A
Auto Config
(Analog-Only
Model) No N/A
Do not execute Auto Config, return
to main menu. N/A N/A
H. Position
Adjust the horizontal position of the
OSD. 0-100 50
V. Position
Adjust the vertical position of the
OSD. 0-100 50
OSD Setup
OSD
Timeout
Adjust the OSD timeout. 10-120 10
Language
Language N/A Select the language you like N/A
The Language
will be set to
English.
Information
Information N/A
Show the resolution, H/V frequency
and input port of current input
timing.
N/A N/A
Yes N/A
Clear each old status of
Auto-configuration and set the color
temperature to Cool.
N/A N/A
Reset
No N/A
Do not execute reset, return to main
menu. N/A N/A
Exit
N/A N/A Exit OSD N/A N/A

17” LCD Color Monitor AOC 177S
10
4. Input/Output Specification
4.1 Input Signal Connector
Pin No. Description Pin No. Description
1. Red 9. +5V
2. Green 10. Detect Cable
3. Blue 11. N.C.
4. N.C. 12. DDC-Serial Data
5. GND 13. H-Sync
6. R-Ground 14. V-Sync
7. G-Ground 15. DDC-Serial Clock
8. B-Ground
VGA connector layout
15
610
11 15
4.2 Factory Preset Display Modes
Standard Resolution Horizontal
Frequency
Vertical
Frequency
Dos-mode 720 x 400 31.47kHz 70.0Hz
640 × 480 31.47kHz 60.0Hz
VGA
640 × 480 37.50kHz 75.0Hz
800 × 600 37.879kHz 60.0Hz
SVGA
800 × 600 46.875kHz 75.0Hz
1024 × 768 48.363kHz 60.0Hz
1024 × 768 56.476kHz 70.0Hz
1024 × 768 60.021kHz 75.0Hz
1024 × 768 48.780kHz 60.0 Hz
XGA
1024 × 768 60.241kHz 75.0 Hz
1280 × 1024 64.000kHz 60.0Hz
SXGA
1280 × 1024 80.000kHz 75.0Hz

17” LCD Color Monitor AOC 177S
11
4.3 Power Supply Requirement
A/C Line voltage range 100 V ~ 240 V
A/C Line frequency range 50 ±3Hz, 60 ±3Hz
Peak surge current < 55A peak at 240 VAC and cold starting
Leakage current < 3.5mA
Power line surge No advance effects (no loss of information or defect)
with a maximum of 1 half-wave missing per second
DC output Voltage 12VDC± 5％

17” LCD Color Monitor AOC 177S
12
4.4 Panel Specification
4.4.1 General Features
4.4.2 Optical Characteristics

17” LCD Color Monitor AOC 177S
13
4.4.3 Electrical Characteristics

17”LCDColorMonitor AOC 177S
14
5. Block Diagram
5.1Software Flow Chart
1
2
N
Y
5
Y
N
10
Y
N
12
Y
N
7
Y
N
6
4
3
8
9
14
11
13
Y
N
15
Y
N
16
17
19
Y
N
18

17”LCDColorMonitor AOC 177S
15
REMARK:
1) MCU initializes.
2) Is the EPROM blank?
3) Program the EPROM by default values.
4) Get the PWM value of brightness from EPROM.
5) Is the power key pressed?
6) Clear all global flags.
7) Are the AUTO and SELECT keys pressed?
8) Enter factory mode.
9) Save the power key status into EPROM.
Turn on the LED and set it to green color.
Scalar initializes.
10) In standby mode?
11) Update the lifetime of back light.
12) Check the analog port, are they’re any signals coming?
13) Does the scalar send out an interrupt request?
14) Wake up the scalar.
15) Are there any signals coming from analog port?
16) Display "No connection Check Signal Cable" message. And go into standby mode after the message
disappears.
17) Program the scalar to be able to show the coming mode.
18) Process the OSD display.
19) Read the keyboard. Is the power key pressed?

17”LCDColorMonitor AOC 177S
16
5.2 Electrical Block Diagram
5.2.1 Main Board
U2
NEVETEK
U1
24C16
W/B
U6
24C02
DDC
R
G
B
HS
VS
TXD
RXD
SD
A
U3
AIC108
U4
RT9164
Gray levels
B
u
ff
e
r
DC/DC
Converter
Vcom
Adapter 5V
Adapter 12V Inverter
Backlight
DC/DC
12MH
Scan driver
Data driver
Backlight
PWB

17”LCDColorMonitor AOC 177S
17
5.2.2 Power Board
CN902
EMI filter
Bridge
Rectifier
and Filter
Start Circuit: R903
PWM
Control IC
Transformer
Over
Voltage
Protect
Rectifier
diodes
AC input
12V
ON/OFF Control
PWM
Control IC
Feedback
Circuit
Output
Circuit
Transformer MOSFET
Q802、Q803
Lamp
ON/OFF
DIM
PWM
Feedback
Circuit 12V
5V

17”LCDColorMonitor AOC177S
18
6. Schematic
6.1 Main Board
IRQN
B_D10
+
C21
47uF/6.3V
C25
1u
R19 22 1/16W
C23 change for
T148 auto clock
不准
Klause 060307
KEY1
B_D17
+
C23
47uF/6.3V-->100uF/6. 3V
ADC_ VAA
GND
PWR _LEDO
TP87
F_D14
B_D8
LP
B_D11
C14 0.01uF
C69
NC
C8
0.1uF
B_D15
KEY1
B_D12
TP7 8
R11
4.7K 1/ 16W
SCL
C5
0.1uF
TO DEBUG
WP
KEY2
C9
0.1uF
R14 100 1/16W
3.3V
F_D4
R190
4.7 1/ 16W
C20 0.01uF
TP7 6
R30 4. 7K 1/ 16W
12M_OSC
TP9 6
F_D11
TP77
TP8 4
SDA
VSO
R17 22 1/16W
1.8V
R34 4.7K 1/16W-->NC
R20 22 1/16W
TP7 1
DDC_SDA
SDA
F_D13
G_IN-
VOLUME
CLKV
F_D5
R23
1K 1/16W
U7
NC/RN5VD45AA-TR-FA
1
2
34
5OUT
VDD
GNDNC
CD
BL_EN
C18
10u
TP7 3
C4
0.1uF
F_D15
DETECT
R33 100 1/ 16W
RSTN
DETECT
1.8V
B_D[0..19]
F_D3
TXD
R28 1k 1/16W
R173
4.7K 1/ 16W
PWR _LEDB C24
0.1uF
C28
22pF-->NC
VGA-VDD
B_IN -
F_D0
F_D2
Y1
12MHz
OE
R21 22 1/16W
C10
0.1uF
R15
4.7K 1/ 16W
5V
3.3V
SCL F_D9
C27,C28 change for
T127 32
灰阶水波纹
Klause 060307
24C02_WP
C6
0.1uF
SCALER
0.1
I-M O D E L
110Monday, April 17, 2006
Tit l e
Size Document Number Rev
Date: Sheet of
R12
4.7K 1/16W
F_D10
FB1
600 OHM
1 2
R24
4.7K 1/ 16W
3.3V
VSI
M_R XD
B_D2
TP7 5
TP7 4
MCU_VDD
F_D17
HSI
12M_OSC
HSO
F_D18
RXD
C3
0.1uF
R29
1M 1/16W
R13 100 1/16W
AMP_STBY
F_D12
R32 4. 7K 1/ 16W
M_TXD
3.3V
BL_BRIGHT
C15 0.01uF
F_D6
R5
100
C27
100pF-->22pF
D28
3.3V
1 2
STH_B
SCL
WP
IRQN
TP80
TP82
D25
1N4148
C26
1u
C13 0.01uF
R_IN-
PWR _EN
CN2
(NC)4PIN/2.0mm
1
2
3
4
R8 100 1/16W
B_IN +
C7
0.1uF
R6
100
B_D5
R26
15K 1/16W
CN1
(NC)3PIN/2.0mm
1
2
3
R184
6.8K 1/ 16W
R1 22 1/16W
TP83
B_D0
TP86
C151
0.1uF
R183
4.7K 1/ 16W
MCU_VDD
B_D1
VSO
R2 22 1/16W
5V
C19
0.1uF
R35 100 1/ 16W
3.3V
KEY1
R31 100 1/ 16W
B_D14
B_D3
5V
POL
B_D4
HSO
TP79
R175
10K 1/16W
F_D19
MCU_VDD
KEY2
F_D1
1.8V
TP8 1
AMP_MUTE
R16 22 1/16W
RXD
F_D[0..19]
B_D6
C16 0.01uF
F_D7
B_D7
NT68621-64/128
QFP128
U2
50 51 54 55 56 57 58 52 53
28
29
30
31
32
33
34
35
36
37
38
39 40 41 42 43 44 45 46 47 48 49
4
5
6
7
9
10
59 60
69
70
71
72
73
76
74
77
78
79
80
81
82
83
84
85
86
96
97
111 127 128
1
2
3
8
11
12
14
13
61 62 63 64
65
66
67
68
75
87
88
89
90
91
92
93
94
95
98
99
100
101
103
102
104 110 109 108 107 106 105 117 116 115 114 113 112 118 119 120 122 121 124 123 126 125
17
18
19
20
21
24
25
26
27
15
16
22
23
OSCO OSCI PB1/ADC1 PB4*/ SCL0* PB5*/ SDA0* PB6*/ SCL1* PB7*/ SDA1* GND PB0/ADC0
PC3/PWM0
PC2
PC1*
PC0*
VCC
PD0
PA0/PWM2
PA1/PWM3
PA2/PWM4
PA3/PWM5
PA4*/PWM6*
PA5*/ PWM 7* PA6*/ PWM 8* PA7*/ PWM 9* RSTB P30/RXD PD6 P31/TXD PB2/ADC2/INTE0 PB3/ADC3/INTE1 P34/T0 P35/T1
ARSGN[2]
ARSGP[2]
ARSGN[1]
ARSGP[1]
ARSBN [3]
ARSBP[ 3]
SCL IRQN
DVDD
VSYN CI
PLL_CVDD
OSCI
DGND
TOU TP
HSYNCI
BIN
BIN M
ADC_ VAA
ADC_GND
SOGI
GIN
GIN M
RIN
RINM
CGND
DVDD
CVDD
DVDD
ARSRN[1]
ARSR P[1]
DVDD
ARSGN[3]
ARSGP[3]
DGND
ARSBN [2]
ARSBP[ 2]
ARSBP[ 1]
ARSBN [1]
GPO9/MD 1 GPO8/MD 0 GPO7 GPO6/VSO
GPO5/HSO
GPO4/PWM1
GPO3/PWM0
GPO2
DVDD
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
YUV_CLK
BRSBP[ 1]
BRSBN [1]
BRSBP[ 2]
BRSBN [2]
BRSBN [3]
BRSBP[ 3]
DGND
BRSGN [3]
BRSGP[ 3]
BRSGN [2]
BRSGP[ 2]
BRSGN [1]
BRSGP[ 1]
BRSRN[3]
BRSR P[3]
BRSRN[2]
BRSR P[2]
BRSRN[1]
BRSR P[1]
BRSC LK_P
BRSCLK_N
DIS P_SPA
ARSC LK_P
ARSCLK_N
ARSR P[3]
ARSRN[3]
ARSR P[2]
ARSRN[2]
PD5/RSTN
PD4
PD3
NC
NC
PC7
PC6
PC5
PC4/PWM1
CVDD
DGND
PD2
PD1
G_IN+
B_D16
C29 22pF
C1
10u
3.3V
STH_F
KEY2
R27
2.2K 1/16W
TO RS232
R25
15K 1/16 W
C22
0.1uF
R7 100 1/16W
5V
SOGI
R37 100 1/ 16W
B_D9
FB2
1000 OHM
1 2
F_D16
R22 22 1/16W
MCU_VDD
5V
U1
AT24C16N -10SC -2.7
1
2
3
4 5
6
7
8
A0
A1
A2
GND SDA
SCL
WP
VCC
B_D18
SDA
R36 4.7K 1/16W-->NC
R18 22 1/16W
B_D13
R176
10K 1/16W
Cancel R34,R36 due to
SCL/SDA already pulled up
by R178,R179 Klause 060307
F_D8
B_D19
C17 0.01uF
DDC_SCL
TP85
R_IN+
PWR
STV1
TXD
C12 0.01uF
1.8V
VGA_DET

17”LCDColorMonitor AOC177S
19
H3
TP
1 2 3
4
5
6 7 8
9
1 2 3
4
5
6 7 8
9
AMP_MUTE
FB6
0 OHM
1 2
FB8
0 OHM
1 2
R174
NC-->10K
FB7
120 OHM/NC
1 2
PANEL_VD D
R39 22
C47
0.1uF
5V
POWER
0.1
I-M OD E L
210Monday , April 17, 2006
Tit le
Size Document Number Rev
Dat e: Sheet of
U4 RT9164A18PG
1 2 3
ADJ/GN D VOUT(TAB) VIN
H4
TP
1 2 3
4
5
6 7 8
9
1 2 3
4
5
6 7 8
9
5V
VOLUME
R50
NC/4.7K 1/16W
KEY 1
R9
3K 1/16W
5V
VCOM
R188
10K 1/16W
C36
0.1uF
R57
51K 1/16W
AMP_STBY
R49
NC
C34
0.1uF
C45
0.1uF-->N C
VOLUME
C33
0.1uF
C39
0.1uF
+
C31
100uF/16V
H1
TP
1 2 3
4
5
6 7 8
9
1 2 3
4
5
6 7 8
9
C37
0.1uF
C43
0.1uF
R48
NC /1K 1/16W
R38 100-->15K
Q4
PMBS3904
C41
0.1uF
PWR_LEDB
MU TE
R187
10K 1/16W
Q2
NC/PMBS3904
CN3
CONN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
C49
0.1uF-->1uF,X7R
3.3V
5V
PWR_LEDO
Q1
NC/PMBS3904
C44
0.1uF
5V
BK_PWM
R46
NC
R45
NC/10K 1/16W
C152
1uF/16V
FB9
120 OHM/NC
1 2
U3
AIC1084-33PM
3
1
2
VIN
GND
VOUT
5V
R51
10K-->47K 1/16W
R58
4.7K-->100K 1/16W
R59
10K 1/16W
+
C42
100uF/16V
R189
330 1/16W
C30
0.1uF
R185
100 1/16W
STBY
MUTE
R54
NC
5V
PWR
R43 1K
FB11
120 OHM/NC
1 2
1.8V
MU TE
BK_EN
KEY 2
R40 47
+ C48
10uF/16V
R44 1K
FB10
0 OHM
1 2
C153
1uF/16V
D26
1N4148-->61L0805000
Q3
AO3401
G
D
S
STBY
+
C40
100uF/16V
C35
0.1uF
AMP_STBY
PWR_EN
D27
1N4148
C38
0.1uF
R41 22
R186
100 1/16W
BL_BRIGHT
C46
0.1u-->NC
BL_EN
R47
NC/4.7K 1/16W
R42 1K
STBY
C32
0.1uF
R55
0 1/16W

17”LCDColorMonitor AOC177S
20
R71
4.7K 1/16W
DB_B-
M_TXD
R73 100 1/16W
R65 100 1/16W-->0 ohm
C54
NC
5V GHS
DB_B-
R68 100 1/16-->0 ohm
D13UDZS5.6B-->NC
1 2
R181 100 1/16W DDC_SDA
R76
NC
VGA INPUT
0.1
I- MO D E L
310Monday, April 17, 2006
Tit l e
Size Doc ument Number Rev
Date: Sheet of
U6
AT24C02
1
2
3
4 5
6
7
8
A0
A1
A2
GND SD A
SCLK
WP
VCC
D10
BAV99
3
1 2
FB4
30 OHM BEAD-->0 ohm
R177
4.7K 1/16W
GVS
DDC_SCL
24C02_WP
R62 100 1/16W
VGA_VS
C52
0.22uF
DB_R+
R_IN+
DDC_VDD
FB5
30 OHM BEAD-->0 ohm
D9
UDZS5.6B
1 2
D15UDZS5. 6B
1 2
C56
22pF
VGA-VDD
R70 100 1/16W
C55
22pF
DDC_SDA
DDC_SCL
DB_R-
R178
4.7k
C57
0.1uF
M_TXD
VSI
DB_G-
B_IN -
R75
2.2K 1/16W
VGA_CONN
VGA_VS
D7
UDZS5.6B
1 2
GHS
D8
UDZS5. 6B
1 2
C51
0.22uF
D6
BAV99
3
1 2
DDC_VDD
B_IN +
D16UDZS5. 6B
1 2
C50
0.22uF
M_TXD
VGA_HS
FB3
30 OHM BEAD-->0 ohm
R67 100 1/16W
DB_R-
SOGI
DDC_SCL
R60 100 1/16W-->0 ohm
D12UDZS5.6B-->NC
1 2
R77
NC
M_R XD
M_R XD
ADC_VAA
VGA_CON N
R66
75 1/16W
VGA_DET
DDC_SCL
D17
UDZS5. 6B
1 2
R74
2.2K 1/16W
C53
NC
24C02_WP
D14
BAV99
3
1 2
D24
BAV70
R179
4.7k
DB_B+
C148
NC
R180 100 1/16W
Change FB3,FB4,FB5 to 0 ohm to fix words
ghost on grey background problem Klause
060417
M_R XD
R_IN-
DB_G+
GVS
DB_G-
D11
UDZS5.6B
1 2
R64 100 1/16
VGA_HS
C149
0.1UF
DDC_SDA
G_IN-
C146
NC
HSI
DB_B+
DB_R+
CN4
CONN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
DB_G+DDC_SDA
R63
1K 1/16W
U5
74LCX14
1
2
3
4
5
6
7 8
9
10
11
12
13
14
A1
B1
A2
B2
A3
B3
GND B4
A4
B5
A5
B6
A6
VCC
R69
75 1/16W
C147
NC
R72 100 1/16W
3.3V
R61
75 1/16W
DDC_VDD
G_IN+
