AOC AG322QC4 User manual

LCD Monitor User Manual
AG322QC4 LED backlight
www.aoc.com
©2019 AOC. All Rights Reserved.

2
Safety........................................................................................................................................................................3
National Conventions.........................................................................................................................................3
Power ................................................................................................................................................................4
Installation..........................................................................................................................................................5
Cleaning.............................................................................................................................................................6
Other..................................................................................................................................................................7
Setup ........................................................................................................................................................................8
Contents in Box .................................................................................................................................................8
Setup Stand & Base...........................................................................................................................................9
Adjusting Viewing Angle...................................................................................................................................10
Connecting the Monitor....................................................................................................................................11
FreeSync2 function..........................................................................................................................................12
HDR.................................................................................................................................................................14
Hotkeys............................................................................................................................................................15
Quick Switch....................................................................................................................................................16
OSD Key Guide (Menu)...................................................................................................................................17
OSD Setting.....................................................................................................................................................19
Game Setting............................................................................................................................................20
Luminance................................................................................................................................................21
Image Setup.............................................................................................................................................22
Color Setup...............................................................................................................................................23
Extra.........................................................................................................................................................24
OSD Setup ...............................................................................................................................................25
LED Indicator...................................................................................................................................................26
Troubleshoot...........................................................................................................................................................27
Specification............................................................................................................................................................28
General Specification.......................................................................................................................................28
Preset Display Modes......................................................................................................................................29
Pin Assignments ..............................................................................................................................................30
Plug and Play...................................................................................................................................................32

3
Safety
National Conventions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type.
These blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: A NOTE indicates important information that helps you make better use of your computer system.
CAUTION: ACAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates the potential for bodily harm and tells you how to avoid the problem.Some
warnings may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specific
presentation of the warning is mandated by regulatory authority.

4
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure
of the type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will
fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug,
have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the
safety purpose of the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate
configured receptacles marked between 100-240VAC, Min. 5A.
The wall socket shall be installed near the equipment and shall be easily accessible.
For use only with the attached power adapter (Output: 20Vdc, 6.0A)
Manufacturers: TPV ELECTRONICS（FUJIAN）CO., LTD. Model: ADPC20120

5
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and
use mounting accessories recommended by the manufacturer. A product and cart combination should be moved
with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a fire or
electric shock. Never spill liquids on the monitor.
Do not place the front of the product on the floor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a fire or damage to the monitor.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or on
the stand:
Installed with stand
Leave at lease this space
around the set
10cm
4英寸
10cm
4英寸
30cm
11 7/8 英寸
10cm
4英寸

6
Cleaning
Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of
strong-detergent which will cauterize the product cabinet.
When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough
as it will scratch the screen surface.
Please disconnect the power cord before cleaning the product.

7
Other
If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and
contact a Service Center.
Make sure that the ventilating openings are not blocked by a table or curtain.
Do not engage the LCD monitor in severe vibration or high impact conditions during operation.
Do not knock or drop the monitor during operation or transportation.

8
Setup
Contents in Box
Not all signal cables (Audio, Analog, DP, HDMI, USB and Micphone cables) will be provided for all countries and
regions. Please check with the local dealer or AOC branch office for confirmation.
CD Manual Warranty card Adapter Stand Screws Base Hand Screw
Power Cable Audio Cable Analog Cable DP Cable HDMI Cable USB Cable Micphone Cable Quick Switch Keypad
Monitor

9
Setup Stand & Base
Please setup or remove the base following the steps as below.
Setup:
Remove:

10
Adjusting Viewing Angle
For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your
own preference.
Hold the stand so you will not topple the monitor when you change the monitor's angle.
You are able to adjust the monitor as below:
Tilt angle:-5.5°~28°
NOTE:
Do not adjust the viewing angle over 28 degrees in order to avoid damage.

11
Connecting the Monitor
Cable Connections In Back of Monitor and Computer:
1 Microphone in
2 Earphone (Combined with Microphone)
3 USB3.0 downstream + fast charging(BC1.2)
4 USB3.0 downstream
5 USB3.0 upstream
6 HDMI-2
7 HDMI-1
8 DP-2
9 DP-1
10 VGA
11 Line in
12 Microphone out (Connect to PC)
13 Quick Switch Keypad
14 DC in
To protect equipment, always turn off the PC and LCD monitor before connecting.
1 Connect the power cable to the DC port on the back of the monitor.
2 Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the
computer's D-Sub port.
3 (Optional –Requires a video card with HDMI port) - Connect one end of the HDMI cable to the back of the
monitor and connect the other end to the computer’s HDMI port.
4 (Optional –Requires a video card with Audio port) - Connect one end of theAudio cable to the back of the
monitor and connect the other end to the computer’s Audio port.
5 (Optional–Requires a video card with DP port) –Connect one end of the DP cable to the back of the monitor
and connect the other end to the computer’s DP port.
6 Turn on your monitor and computer.
7 Video content supporting resolution:
VGA: 1920 x1080@60Hz (Maximum)
HDMI/DP: 2560x1440@144Hz (Maximum)
If your monitor displays an image, installation is complete. If it does not display an image, please refer
Troubleshooting.

12
FreeSync2 function
1. FreeSync2 function is working with DP/HDMI
2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting
www.AMD.com
Graphics Cards
RadeonTM RX Vega series
RadeonTM RX 500 series
RadeonTM RX 400 series
RadeonTM R9/R7 300 series (excluding R9 370/X)
RadeonTM Pro Duo (2016 edition)
RadeonTM R9 Nano
RadeonTM R9 Fury series
RadeonTM R9/R7 200 series (excluding R9 270/X, R9 280/X)
Processors
AMD RyzenTM 7 2700U
AMD RyzenTM 5 2500U
AMD RyzenTM 5 2400G
AMD RyzenTM 3 2300U
AMD RyzenTM 3 2200G
AMD PRO A12-9800
AMD PRO A12-9800E
AMD PRO A10-9700
AMD PRO A10-9700E
AMD PRO A8-9600
AMD PRO A6-9500
AMD PRO A6-9500E
AMD PRO A12-8870
AMD PRO A12-8870E
AMD PRO A10-8770
AMD PRO A10-8770E
AMD PRO A10-8750B
AMD PRO A8-8650B
AMD PRO A6-8570
AMD PRO A6-8570E
AMD PRO A4-8350B
AMD A10-7890K
AMD A10-7870K
AMD A10-7850K
AMD A10-7800
AMD A10-7700K
AMD A8-7670K

13
AMD A8-7650K
AMD A8-7600
AMD A6-7400K
Freesync2
AMD’s FreeSync2 HDR content visualization improvement involves defining a panel characteristics requirement
that produces twice the color volume of standard SDR panel and a protocol requiring the Sink Device to report the
panel’s true color chromaticities, min/max luminance, peak luminance, and supported transfer function.
Common HDR10 displays requires an application to map into generic luminance range and use industry standard
color space that can be signaled through AVI and HDR Info Frame. This in turn requires Sink to perform tone
mapping to map GPU output to actual luminance range and color gamut of the physical panel. Tone mapping by the
monitor may increases post processing latency .
The FreeSync2 can allow content to be mapped directly to the display’s native color gamut and luminance range to
preserve HDR image quality while avoiding multiple inefficient tone mapping and preserving low latencies image
update.

14
HDR
It is compatible with input signals in HDR10 format.
The display may automatically activate the HDR function if the player and content are compatible. Please contact
the device manufacturer and the content provider for information on the compatibility of your device and content.
Please select “OFF” for the HDR function when you have no need for automatical activation function.
Note:
1. No special setting is needed for the DisplayPort/HDMI interface in WIN10 versions lower (older) than V1703.
2. Only the HDMI interface is available and the DisplayPort interface cannot function in WIN10 version V1703.
3. 3840x2160 @50Hz /60Hz not suggestion used in PC device only for UHD player or Xbox-ones / PS4-Pro.
a. The display resolution is set to 3840*2160, and HDR is preset to ON. Under these conditions, the screen may
slightly dim, indicating HDR has been activated.
b. After entering an application, the best HDR effect can be achieved when the resolution is changed to
3840*2160 (if available).

15
Hotkeys
1
Source/Auto/Exit
2
Dial Point
3
Game Mode/Left
4
LED color/Right
5
Power/ Menu/Enter
Power/Menu/Enter
Press the Power button to turn on the monitor.
When there is no OSD, Press to display the OSD or confirm the selection. Press about 2 seconds to turn off the
monitor.
Dial Point
When there is no OSD, press Dial Point button to show / hide Dial Point.
Game Mode/Left
When there is no OSD, press ”Left”key to open game mode function, then press ”Left”or “Right”key to select
game mode (FPS, RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the different game types.
LED Light Effects Control/Right
When there is no OSD, press “Right”key to active LED Light Effects Control function.
Source/Auto/Exit
When the OSD is closed, press Source/Auto/Exit button will be Source hot key function. When the OSD is closed,
press Source/Auto/Exit button continuously about 2 seconds to do auto configure (Only for the models with D-Sub).

16
Quick Switch
◀:
When there is no OSD, press the ◀button to open game mode function, then press ◀or ▶key to select game
mode (FPS, RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the different game types.
▶:
When there is no OSD, press “Right” key to active LED Light Effects Control function.
Menu/OK:
When there is no OSD, Press to display the OSD or confirm the selection.
▲:
When the OSD is closed, press ▲button will be Source hot key function. When the OSD is closed, press
Source/Auto/Exit button continuously about 2 seconds to do auto configure (Only for the models with D-Sub).
▼:
When there is no OSD, press Dial Point button to show / hide Dial Point.
1:
Press the 1 button to select Gamer 1 mode
2:
Press the 2 button to select Gamer 2 mode
3:
Press the 3 button to select Gamer 3 mode

17
OSD Key Guide (Menu)
Enter : Use Enter key to enter the next OSD level
Move : Use Left /Up / Down key to move OSD selection
Exit : Use Right key to exit OSD
Enter : Use Enter key to enter the next OSD level
Move : Use Right / Up / Down key to move OSD selection
Exit : Use Left key to exit OSD
Enter : Use Enter key to enter the next OSD level
Move : Use Up / Down key to move OSD selection
Exit : Use Left key to exit OSD
Move : Use Left / Right / Up / Down Key to move OSD selection
Exit : Use Left key to exit OSD to previous OSD level
Enter : Use Right key to enter next OSD level
Select : Use Up / Down key to move OSD selection

18
Enter : Use Enter key to apply the OSD setting and back to previous OSD level
Select : Use Down key to adjust OSD setting
Select : Use Up / Down key to adjust OSD setting
Enter : Use Enter key to exit OSD to previous OSD level
Select : Use Left / Right key to adjust OSD setting

19
OSD Setting
Basic and simple instruction on the control keys.
1) Press the MENU-button to activate the OSD window.
2) Follow Key Guide to move or select (adjust) OSD settings
3) OSD Lock/Unlock Function: To lock or unlock the OSD, press and hold the Down–button for 10s while OSD
function is not active.
Notes:
1) If the product has only one signal input, the item of "Input Select" is disable to adjust.
2) ECO modes (except Standard mode), DCR, DCB mode and Picture Boost, for these four states that only one
state can exist.

20
Game Setting
Game Mode
FPS
For playing FPS (first Person Shooters) games. Improves
dark theme black level details.
RTS
For playing RTS (Real Time Strategy). Improves the image
quality.
Racing
For playing Racing games, Provides fastest response time
and high color saturation.
Gamer 1
User’s preference settings saved as Gamer 1.
Gamer 2
User’s preference settings saved as Gamer 2.
Gamer 3
User’s preference settings saved as Gamer 3.
off
No optimization by Smart image game
Shadow Control
0-100
Shadow Control Default is 50, then end-user can adjust from
50 to 100 or 0 to increase contrast for clear picture.
1. If picture is too dark to be saw the detail clearly, adjusting
from 50 to100 for clear picture..
2. If picture is too white to be saw the detail clearly,
adjusting from 50 to0 for clear picture
Low Input Lag
On/off
Turn off frame buffer to decrease input lag
Game Color
0-20
Game Color will provide 0-20 level for adjusting saturation to
get better picture.
Overdrive
Weak/Medium/
Strong/Off
Adjust the response time.
Volume
0-100
Volume Adjustment
Dial Point
On/off
The“Dial Point”function places an aiming indicator in the
center of screen for helping gamers to play First Person
Shooter (FPS) games with an accurate and precise aiming.
Frame Counter
Off / Right-Up /
Right-Down /
Left-Down /
Left-Up
Display V frequency on the corner selected
