AOC e1649Fwu User manual

1
USB Monitor User Manual

2
Safety........................................................................................................................................................................3
National Conventions.........................................................................................................................................3
Installation..........................................................................................................................................................4
Cleaning.............................................................................................................................................................5
Other..................................................................................................................................................................6
Setup ........................................................................................................................................................................7
Contents in Box .................................................................................................................................................7
Setup Stand.......................................................................................................................................................8
Adjusting Viewing Angle.....................................................................................................................................9
Connecting the Monitor....................................................................................................................................10
Installation of USB Graphic software on your computer..........................................................................................11
For Microsoft ® Windows® 7...........................................................................................................................11
For Microsoft® Windows Vista® ......................................................................................................................13
For Microsoft® Windows® XP .........................................................................................................................15
Setting the USB Monitor ..................................................................................................................................16
To Control the Display.............................................................................................................................................17
For Microsoft® Windows® 7 ............................................................................................................................17
For Microsoft® Windows® XP and Microsoft® Windows Vista® .....................................................................17
Disconnecting the LCD Monitor.......................................................................................................................17
Cleaning the LCD Monitor................................................................................................................................17
Supported Media Player ..................................................................................................................................18
PC Requirements ............................................................................................................................................19
Troubleshooting ......................................................................................................................................................22
Specification............................................................................................................................................................23
General Specification.......................................................................................................................................23
Regulation...............................................................................................................................................................24
FCC Notice......................................................................................................................................................24
WEEE Declaration...........................................................................................................................................25
EPA Energy Star ..............................................................................................................................................25
Service....................................................................................................................................................................26
Warranty Statement for Europe........................................................................................................................26
Warranty Statement for North & South America (excluding Brazil) ..................................................................28

3
Safety
National Conventions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in
bold type or in italic type. These blocks are notes, cautions, and warnings, and they
are used as follows:
NOTE: ANOTE indicates important information that helps you make better use of
your computer system.
CAUTION: ACAUTION indicates either potential damage to hardware or loss of
data and tells you how to avoid the problem.
WARNING: A WARNING indicates the potential for bodily harm and tells you how to
avoid the problem. Some warnings may appear in alternate formats and may be
unaccompanied by an icon. In such cases, the specific presentation of the warning is
mandated by regulatory authority.

4
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If
the monitor falls, it can injure a person and cause serious damage to this product. Use
only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold
with this product. Follow the manufacturer‟s instructions when installing the product
and use mounting accessories recommended by the manufacturer. A product and cart
combination should be moved with care.
Never push any object into the slot on the monitor cabinet. It could damage
circuit parts causing a fire or electric shock. Never spill liquids on the monitor.
Do not place the front of the product on the floor.
Leave some space around the monitor as shown below. Otherwise,
air-circulation may be inadequate hence overheating may cause a fire or damage to
the monitor.
See below the recommended ventilation areas around the monitor when the monitor is
installed on the wall or on the stand:

5
Cleaning
Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out
the stain, instead of strong-detergent which will cauterize the product cabinet.
When cleaning, make sure no detergent is leaked into the product. The cleaning
cloth should not be too rough as it will scratch the screen surface.

6
Other
If the product is emitting a strange smell, sound or smoke, disconnect the power
plug IMMEDIATELY and contact a Service Center.
Make sure that the ventilating openings are not blocked by a table or curtain.
Do not engage the LCD monitor in severe vibration or high impact conditions
during operation.
Do not knock or drop the monitor during operation or transportation.

7
Setup
Contents in Box
QSG CD Manual Carry Case
(Option)
USB Cable

8
Setup Stand
Please setup the stand following the steps as below.
Setup:
Caution:
Must put unit in flat surface. Any uneven or sloped surface may result in unit damage
or injury to user.

9
Adjusting Viewing Angle
For optimal viewing, it is recommended to look at the full face of the monitor, and then
adjust the monitor's angle to your own preference.
Hold the stand so you will not topple the monitor when you change the monitor's
angle.
You are able to adjust the monitor's angle as below.
NOTE:
Do not touch the LCD screen when you change the angle. It may cause damage or
break the LCD screen.
The AOC e1649Fwu monitor supports an auto-pivot function to keep the display
upright as the monitor is rotated between portrait and landscape position. The monitor
has to be rotated slowly and over 75∘with the tilt angle within 30∘to activate the
auto-pivot function. The default setting for auto-pivot is on. You need to disable the
auto-pivot function if you would like to manually rotate the display. If the auto-pivot is
not functioned, rotate the display using orientation menu, then set the auto-pivot to on
again.

10
Connecting the Monitor
Cable Connections In Rear of Monitor to Connect PC/Laptop:
Important!! Follow the software installation described on page 11 to 15 before
connecting the USB monitor to your Laptop/PC.
1 Connecting the LCD monitor to your computer
To protect the equipment, always turn off the computer before connecting.
- Connect one end of the USB cable to the LCD monitor and the end of USB
cable to the computer.
- Your computer should detect the USB Monitor automatically.
Follow the procedure described starting on page 16 to configure your USB Monitor.
Note: Some computers may not provide enough power to the LCD monitor from one
USB port.
If so, connect the other USB connector on the Y end of the cable into another USB on
your computer.
