e2243Fw
Cabinet Color Piano-black Glossy Bezel, Glossy White Back Cover and Base
Panel TFT Active Matrix LCD, WLED Backlight
22" Class, Widescreen 16:9 Aspect Ratio
21.5" Viewable Image Size, Diagonal
Pixel Pitch 0.248 x 0.248mm
Display Area 476.6mm x 268.1mm
Brightness 250 cd/m2 (typ)
Contrast Ratio 50,000,000:1 (dynamic)
Response Time 5ms (typical)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Scanning Frequency Horizontal: 30K~83KHz
Vertical: 55~75 Hz
Pixel Frequency 148.5MHz
Maximum Resolution
Recommended Resolution 1920x1080x60Hz
1920x1080@60Hz
Supported Resolutions 640x480@60/72/75Hz, 800x600@56/60/72/75Hz,
1024x768@60/70/75Hz, 1280x1024@60/75Hz, 1440x900@60Hz,
1680x1050@60Hz, 1920x1080@60Hz
Color 16.7M
Analog Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Digital Input DVI-D with HDCP*
Connectors Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power Source Universal 110~240VAC, 50/60Hz , External Power Brick
Power Consumption 25 Watts ( Max. )
Plug & Play DDC/2B, DDC/CI
User Control Left, Right, Power, Source/Auto, Menu
OSD Languages 14 Languages including English, French and Spanish
Regulations cCSAus, FCC, CE, TUV/S, ROHS, EPA 5.0, EPEAT Silver
Other Features Ultra Slim (12.9mm), Illuminating Touch Key, Mercury Free WLED,
Low Power Consumption, Power Saving Mode, Off Timer, Eco
Package, User Friendly Graphical OSD Menu, includes e-Saver
Power Saving Software
Dimensions (WxHxD mm) Monitor: 514.2x386.1x182.0, Carton: 577x522x124
Dimensions (WxHxD inches) Monitor: 20.2x15.2x7.2, Carton: 22.7x20.6x4.9
Weight 5.5 lbs (2.5 kgs) Net
11.9 lbs (5.4 kgs) Gross
Loading Qty w/pallet 20' = 648 pcs.; 40' Std = 1440 pcs.
UPC Code 685417033386
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall
mount arm & bracket not included. Windows 7 and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States
and/or other countries.
A08/10
