AOC E2251FWU User guide

e2251Fwu
Cabinet Color
Piano-black Glossy Bezel and Base
Panel TFT Active Matrix, LED Backlight
22" Class, Widescreen 16:9 Aspect Ratio
21.5" Viewable Image Size, Diagonal
Pixel Pitch 0.248 x 0.248mm
Display Area 476.6mm x 268.1mm
Brightness 150 cd/m2 (typical)
Contrast Ratio 1,000:1 (typal)
Response Time 5ms (typical)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Scanning Frequency Horizontal: 67.5KHz
Vertical: 60Hz
Pixel Frequency 148.5MHz
Maximum Resolution
Recommended Resolution
1920x1080@60Hz
1920x1080@60Hz
Supported Resolutions 1920x1080@60Hz
Color 16.7M
Video Input USB 2.0
Connectors
USB 2.0
Power Source
USB 2.0 Powered
Universal 110~240VAC, 50/60Hz , External Power Brick (Optional)
Power Consumption 10 Watts ( Max. )
Plug & Play PC/MAC
Regulations cTUVus, FCC, TUV/S, ROHS, EPA 5.0, EPEAT Silver
Other Features
Ultra Slim and Ultra Light for Maximum Portability, No Power Cord or
VGA Cable Required, USB Cable Included, Mercury Free LED
Backlight, Low Power Consumption, Dual Function Stand (Normal or
Photoframe Style)
Dimensions (WxHxD mm) Monitor: 512.5x389.1x193.7, Carton: 566x392x111
Dimensions (WxHxD inches) Monitor: 20.2x15.3x7.6, Carton: 22.3x15.4x4.4
Weight 5.8 lbs (2.65 kgs) Net
9.5 lbs (4.3 kgs) Gross
Loading Qty w/pallet 20' = 1072 pcs.; 40' Std = 2200 pcs.
UPC Code 685417047680
Note: Specifications are subject to change without notice. Windows 7 and the Windows logo are trademarks or registered trademarks of Microsoft Corporation
in the United States and/or other countries.
A12/11
