e943Fws
Cabinet Color Piano-black Glossy Bezel, Glossy White Back Cover and Base
Panel TFT Active Matrix LCD, WLED Backlight
19" Class, Widescreen 16:9 Aspect Ratio
18.5" Viewable Image Size, Diagonal
Pixel Pitch 0.3 x 0.3mm
Display Area 409.8mm x 230.4mm
Brightness 250 cd/m2 (typ)
Contrast Ratio 50,000,000:1 (dynamic)
Response Time 5ms (typical)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Scanning Frequency Horizontal: 30K~83KHz
Vertical: 55~75 Hz
Pixel Frequency 90MHz
Maximum Resolution
Recommended Resolution 1366x768x60Hz
1366x768@60Hz
Supported Resolutions 640x480@60/72/75Hz, 800x600@56/60/72/75Hz,
1024x768@60/70/75Hz, 1366x768@60Hz
Color 16.7M
Signal Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Connectors Analog RGB Signal: 15-pin D-sub Male
Power Source Universal 110~240VAC, 50/60Hz , External Power Brick
Power Consumption 22 Watts ( Max. )
Plug & Play DDC/2B, DDC/CI
User Control Left, Right, Power, Exit, Menu
OSD Languages 14 Languages including English, French and Spanish
Regulations cCSAus, FCC, CE, TUV/S, ROHS, EPA 5.0, EPEAT Silver
Other Features Ultra Slim (12.9mm), Illuminating Touch Key, Mercury Free WLED,
Low Power Consumption, Power Saving Mode, Off Timer, Eco
Package, User Friendly Graphical OSD Menu, includes e-Saver
Power Saving Software
Dimensions (WxHxD mm) Monitor: 447.2x350.9x182.4, Carton: 506x474x124
Dimensions (WxHxD inches) Monitor: 17.6x13.8x7.2, Carton: 22.2x17.4x5.2
Weight 4.62 lbs (2.1 kgs) Net
9.5 lbs (4.3 kgs) Gross
Loading Qty w/pallet 20' = 880 pcs.; 40' Std = 1840 pcs.
UPC Code 685417032983
Note: Specifications are subject to change without notice.
A08/10
