1
www.aoc.com
©2020 AOC. All Rights Reserved.
LCD Monitor
User Manual
Q32E2N

i
Safety ................................................................................................................................................................................... 1
National Conventions ................................................................................................................................................ 1
Power ........................................................................................................................................................................ 2
Installation ................................................................................................................................................................. 3
Cleaning .................................................................................................................................................................... 4
Other ......................................................................................................................................................................... 5
Setup .................................................................................................................................................................................... 6
Contents in Box......................................................................................................................................................... 6
Setup Stand & Base.................................................................................................................................................. 7
Adjusting Viewing Angle............................................................................................................................................ 8
Connecting the Monitor ............................................................................................................................................. 9
Wall Mounting.......................................................................................................................................................... 10
Adaptive-Sync function ............................................................................................................................................11
Adjusting............................................................................................................................................................................. 12
Hotkeys ................................................................................................................................................................... 12
OSD Setting ............................................................................................................................................................ 14
Luminance ................................................................................................................................................... 15
Color Setup.................................................................................................................................................. 16
Picture Boost ............................................................................................................................................... 17
OSD Setup................................................................................................................................................... 18
Game Setting............................................................................................................................................... 19
Extra ............................................................................................................................................................ 20
Exit............................................................................................................................................................... 21
LED Indicator .......................................................................................................................................................... 22
Troubleshoot....................................................................................................................................................................... 23
Specication ....................................................................................................................................................................... 24
General Specication .............................................................................................................................................. 24
Preset Display Modes ............................................................................................................................................. 25
Pin Assignments...................................................................................................................................................... 26
Plug and Play .......................................................................................................................................................... 27

1
Safety
National Conventions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These
blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: A NOTE indicates important information that helps you make better use of your computer system.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates the potential for bodily harm and tells you how to avoid the problem. Some warnings
may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specic presentation of the
warning is mandated by regulatory authority.

2
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the
type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will t
only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an
electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of
the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in re or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate congured
receptacles marked between 100-240V AC, Min. 5A.
The wall socket shall be installed near the equipment and shall be easily accessible.

3
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use
mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a re or electric
shock. Never spill liquids on the monitor.
Do not place the front of the product on the oor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a re or damage to the monitor.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or on the
stand:

4
Cleaning
Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent
which will cauterize the product cabinet.
When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it
will scratch the screen surface.
Please disconnect the power cord before cleaning the product.

5
Other
If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a
Service Center.
Make sure that the ventilating openings are not blocked by a table or curtain.
Do not engage the LCD monitor in severe vibration or high impact conditions during operation.
Do not knock or drop the monitor during operation or transportation.
The power cords shall be safety approved. For Germany, it shall be H03VV-F, 3G, 0.75 mm2, or better. For other
countries, the suitable types shall be used accordingly.
Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the equalizer to
maximum increases the earphones and headphones output voltage and therefore the sound pressure level.

6
Setup
Contents in Box
*
*
*
*
HDMI CablePower Cable DP Cable
CD Manual Warranty Card Stand Base
Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch
o󰀩ce for conrmation.

7
Setup Stand & Base
Please setup or remove the base following the steps as below.
Setup:
1
2
3
4
5
Remove:
1
2
5
4
3

8
Adjusting Viewing Angle
For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own
preference.
Hold the stand so you will not topple the monitor when you change the monitor’s angle.
You are able to adjust the monitor as below:
-5° 23°
NOTE:
Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.

9
Connecting the Monitor
Cable Connections In Back of Monitor and Computer:
1 2 3 4
1. Power
2. HDMI
3. DP
4. Earphone
Connect to PC
1. Connect the power cord to the back of the display rmly.
2. Turn o󰀨 your computer and unplug its power cable.
3. Connect the display signal cable to the video connector on the back of your computer.
4. Plug the power cord of your computer and your display into a nearby outlet.
5. Turn on your computer and display.
If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.
To protect equipment, always turn o󰀨 the PC and LCD monitor before connecting.

10
Wall Mounting
Preparing to Install An Optional Wall Mounting Arm.
1
2
5
4
3
This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure.
Follow these steps:
1. Remove the base.
2. Follow the manufacturer’s instructions to assemble the wall mounting arm.
3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back of the
monitor.
4. Insert the 4 screws into the holes and tighten.
5. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions on
attaching it to the wall.
Noted: VESA mounting screw holes are not available for all models, please check with the dealer or o󰀩cial department of
AOC.

11
Adaptive-Sync function
1. Adaptive-Sync function is working with DP/HDMI
2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD.com
• Radeon™ RX Vega series
• Radeon™ RX 500 series
• Radeon™ RX 400 series
• Radeon™ R9/R7 300 series （R9 370/X, R7 370/X, R7 265 except）
• Radeon™ Pro Duo (2016)
• Radeon™ R9 Nano series
• Radeon™ R9 Fury series
• Radeon™ R9/R7 200 series (R9 270/X, R9 280/X except)

12
Adjusting
Hotkeys
1 2 3 4 5
1 Source/Exit
2 Clear Vision/<
3 Volume/>
4 Menu/Enter
5 Power
Menu/Enter
When there is no OSD, Press to display the OSD or conrm the selection.
Power
Press the Power button to turn on the monitor.
Volume
When there is no OSD, Press > Volume button to active volume adjustment bar, Press < or > to adjust volume.
Source/Exit
When the OSD is closed, press Source/Exit button will be Source hot key function.

13
Clear Vision
1. When there is no OSD, Press the “ <” button to activate Clear Vision.
2. Use the “ > ” or “>” buttons to select between weak, medium, strong, or o󰀨 settings. Default setting is always “o󰀨”.
3. Press and hold “ <” button for 5 seconds to activate the Clear Vision Demo, and a message of “Clear Vision Demo: on”
will be display on the screen for a duration of 5 seconds. Press Menu or Exit button, the message will disappear. Press
and hold “ <” button for 5 seconds again, Clear Vision Demo will be o󰀨.
Clear Vision function provides the best image viewing experience by converting low resolution and blurry images into
clear and vivid images.

14
OSD Setting
Basic and simple instruction on the control keys.
Luminance Color Setup Picture Boost OSD Setup ExitExtra
Contrast 50
Brightness 90
Eco mode Standard
Gamma Gamma1
DCR Off
HDR Mode Off
Game Setting
1). Press the MENU-button to activate the OSD window.
2). Press Left or Right to navigate through the functions. Once the desired function is highlighted, press the
MENU-button to activate it, press Left or Right to navigate through the sub-menu functions. Once the desired
function is highlighted, press MENU-button to activate it.
3). Press Left or to change the settings of the selected function. Press to exit. If you want to adjust any other
function, repeat steps 2-3.
4). OSD Lock Function: To lock the OSD, press and hold the MENU-button while the monitor is o󰀨 and then press
power button to turn the monitor on. To un-lock the OSD - press and hold the MENU-button while the monitor is
o󰀨 and then press power button to turn the monitor on.
Notes:
1). If the product has only one signal input, the item of “Input Select” is disable to adjust.
2). ECO modes (except Standard mode), DCR, DCB mode and Picture Boost, for these four states that only one state
can exist.

15
Luminance
Luminance Color Setup Picture Boost OSD Setup ExitExtra
Contrast 50
Brightness 90
Eco mode Standard
Gamma Gamma1
DCR Off
HDR Mode Off
Game Setting
Contrast 0-100 Contrast from Digital-register.
Brightness 0-100 Backlight Adjustment.
Eco mode
Standard Standard Mode.
Text Text Mode.
Internet Internet Mode.
Game Game Mode.
Movie Movie Mode.
Sports Sports Mode.
Reading Reading Mode.
Uniformity Uniformity Mode
Gamma
Gamma1 Adjust to Gamma 1.
Gamma2 Adjust to Gamma 2.
Gamma3 Adjust to Gamma 3.
DCR
On Enable dynamic contrast ratio.
O󰀨 Disable dynamic contrast ratio.
HDR Mode
O󰀨
Select HDR Mode.
HDR Picture
HDR Movie
HDR Game
Note:
When “HDR Mode” is set to “non-o󰀨”, the items “Contrast”, “Brightness”, “Gamma” cannot be adjusted.

16
Color Setup
Luminance
Red 50
Green 50
Blue 50DCB Demo Off
Color Temp. Warm LowBlue Mode Off
DCB Mode Off
Color Setup
Picture Boost OSD Setup ExitExtra Game Setting
Color Temp.
Warm Recall Warm Color Temperature from EEPROM.
Normal Recall Normal Color Temperature from EEPROM.
Cool Recall Cool Color Temperature from EEPROM.
sRGB Recall SRGB Color Temperature from EEPROM.
User Restore Color Temperature from EEPROM.
DCB Mode
Full Enhance On or O󰀨 Disable or Enable Full Enhance Mode
Nature Skin On or O󰀨 Disable or Enable Nature Skin Mode
Green Field On or O󰀨 Disable or Enable Green Field Mode
Sky-blue On or O󰀨 Disable or Enable Sky-blue Mode
AutoDetect On or O󰀨 Disable or Enable AutoDetect Mode
O󰀨 On or O󰀨 Disable or Enable O󰀨 Mode
DCB Demo On or O󰀨 Disable or Enable Demo
Red 0-100 Red gain from Digital-register.
Green 0-100 Green gain from Digital-register.
Blue 0-100 Blue gain from Digital-register.
LowBlue
Mode
Reading
/ O󰀩ce /
Internet /
Multimedia /
O󰀨
Decrease blue light wave by controlling color
temperature.
Note:
When “HDR Mode” under “Luminance” is set to “non-o󰀨”, all items under “Color Setup” cannot be adjusted.

17
Picture Boost
Luminance
Brightness 50
Contrast 50
H. Position 0
V. Position 0
Bright Frame Off
Frame Size 14
Picture Boost Color Setup
OSD Setup ExitExtra
Game Setting
Bright Frame on or o󰀨 Disable or Enable Bright Frame
Frame Size 14-100 Adjust Frame Size
Brightness 0-100 Adjust Frame Brightness
Contrast 0-100 Adjust Frame Contrast
H. position 0-100 Adjust Frame horizontal Position
V. position 0-100 Adjust Frame vertical Position
Note:
Adjust the brightness, contrast, and position of the Bright Frame for better viewing experience.
When “HDR Mode” under “Luminance” is set to “non-o󰀨”, all items under “Picture Boost” cannot be adjusted.

18
OSD Setup
ExitExtra
Luminance Color Setup
H. Position 50
V. Position 0
Transparence 25
Language English
Timeout 10 Break Reminder Off
OSD Setup Picture Boost
Game Setting
DP Capability 1.2
Language Select the OSD language
Timeout 5-120 Adjust the OSD Timeout
DP Capability
(only for certain models) 1.1/1.2
If the DP video content supports DP1.2, please select
DP1.2 for DP Capability; otherwise, please select
DP1.1.
Please be noted that only DP1.2 support
Adaptive-Sync function
H. Position 0-100 Adjust the horizontal position of OSD
V. Position 0-100 Adjust the vertical position of OSD
Transparence 0-100 Adjust the transparence of OSD
Break Reminder on or o󰀨 Break reminder if the user continuously work for more
than 1hrs
