AOC Q70S15 User manual
- 1 -
TableofContents
CHAPTER 1 PRODUCT OVERVIEW .............................................................................1
1.1 Functions overview.......................................................................................................... 1
1.2 Notes ................................................................................................................................. 1
1.3 Packaging list ................................................................................................................... 2
1.4 Technical specifications.................................................................................................. 2
CHAPTER 2 BUTTONS AND APPEARANCE................................................................5
CHAPTER 3 EASYCONFIG............................................................................................7
CHAPTER 4 BASIC OPERATIONS................................................................................9
4.1 Booting up ........................................................................................................................ 9
4.2 Shutdown.......................................................................................................................... 9
4.3 Network ............................................................................................................................. 9
4.4 Standby Mode................................................................................................................... 9
4.5 Reset.................................................................................................................................. 9
4.6 Connecting to PC and file transfer............................................................................... 10
4.7 Volume adjustment ........................................................................................................ 10
4.7.1 Adjusting the media volume............................................................................... 11
4.7.2 Adjusting the alarm volume ...............................................................................11
4.7.3 Adjusting the notification volume ..................................................................... 11
4.8 Charging.......................................................................................................................... 11
4.9 Touch screen operations .............................................................................................. 11
4.10 Search icon................................................................................................................... 12
CHAPTER 5 COMMON FEATURES ............................................................................13
5.1 Landscape/Portrait display switching ......................................................................... 13
5.2 Using virtual keyboard to type...................................................................................... 13
5.2.1 Android keyboard................................................................................................ 13
5.2.2 Editing text ........................................................................................................... 14
5.3 Notification bar............................................................................................................... 15
5.3.1 Opening notification bar..................................................................................... 15
5.3.2 Closing notification panel................................................................................... 15
- 2 -
5.4 Recently run apps.......................................................................................................... 15
5.5 Changing wallpaper ....................................................................................................... 16
5.6 Power control ................................................................................................................. 16
CHAPTER 6 MAIN INTERFACE...................................................................................17
6.1 Main interface ................................................................................................................. 17
6.2 Apps interface ................................................................................................................ 18
6.3 Browser........................................................................................................................... 18
6.3.1 Opening browser................................................................................................. 18
6.3.2 Going to a webpage ............................................................................................ 19
6.3.3 Setting a home page ........................................................................................... 20
6.3.4 Browsing a webpage........................................................................................... 20
6.3.5 Managing bookmarks.......................................................................................... 21
6.3.6 Other functions.................................................................................................... 22
6.4 Video player.................................................................................................................... 22
6.4.1 Video playing ....................................................................................................... 22
6.4.2 Delete video.......................................................................................................... 24
6.5 Audio player.................................................................................................................... 24
6.5.1 Playlist .................................................................................................................. 25
6.5.2 Playing audio ....................................................................................................... 25
6.5.3 Sound effects....................................................................................................... 27
6.6 Picture browser.............................................................................................................. 27
6.6.1 Browsing pictures ............................................................................................... 28
6.6.2 Picture file operation........................................................................................... 29
6.7 Camera ............................................................................................................................ 30
CHAPTER 7 APPS.......................................................................................................32
7.1 Moving a program icon to another interface............................................................... 32
7.2 Deleting a program icon................................................................................................ 32
7.3 Adding a Widget............................................................................................................. 32
7.4 Creating a folder............................................................................................................. 32
7.5 Renaming a folder.......................................................................................................... 33
CHAPTER 8 COMMON TOOLS...................................................................................34
8.1 E-mail............................................................................................................................... 34
- 3 -
8.1.1 Opening e-mail..................................................................................................... 35
8.1.2 Creating and sending e-mails ............................................................................ 35
8.1.3 Receiving and reading e-mail............................................................................. 36
8.1.4 Replying / Forwarding e-mail ............................................................................. 36
8.1.5 Managing e-mails ................................................................................................ 37
8.1.6 Email Settings...................................................................................................... 37
8.2 Recorder.......................................................................................................................... 38
8.3 Alarm ............................................................................................................................... 38
8.3.1 Set alarm............................................................................................................... 39
8.3.2 Delete alarm ......................................................................................................... 40
8.4 Calculator........................................................................................................................ 40
8.5 Explorer........................................................................................................................... 40
8.6 Installing apps................................................................................................................ 40
8.7 Uninstall app................................................................................................................... 40
1. In the apps interface, touch and hold the app you want to uninstall. ........................ 40
2. Move the app to trash can and touch “OK” to uninstall it........................................... 40
Tip: You cannot delete the pre-installed factory default app on this product............... 40
CHAPTER 9 SETTINGS...............................................................................................41
9.1 WIRELESS & NETWORK Settings................................................................................ 41
9.1.1 Wi-Fi network connection................................................................................... 41
9.1.2 Data usage............................................................................................................ 44
9.1.3 More ...................................................................................................................... 44
9.2 DEVICE Settings............................................................................................................. 44
9.2.1 Sound.................................................................................................................... 44
9.2.2 Display.................................................................................................................. 44
9.2.3 HDMI...................................................................................................................... 45
9.2.4 ScreenshotSetting............................................................................................... 45
9.2.5 Storage ................................................................................................................. 45
9.2.6 Battery .................................................................................................................. 46
9.2.7 Apps...................................................................................................................... 46
9.3 PERSONAL Settings...................................................................................................... 46
9.3.1 Location services ................................................................................................ 46
9.3.2 Security................................................................................................................. 46
9.3.3 Language & input ................................................................................................47
9.3.4 Backup & reset .................................................................................................... 47
- 4 -
9.4. Accounts & Sync........................................................................................................... 47
9.5 SYSTEM Settings ........................................................................................................... 47
9.5.1 Data & Time.......................................................................................................... 47
9.5.2 Accessibility......................................................................................................... 48
9.5.3 About Tablet......................................................................................................... 48
CHAPTER 10 USING MICRO SD (TF) CARD ..............................................................49
CHAPTER 11 CONNECTING TO USB DRIVE.............................................................50
CHAPTER 12 ABOUT THE BATTERY AND POWER..................................................51
CHAPTER 13 FIRMWARE UPDATING / RESETTING TO FACTORY.........................52
CHAPTER 14 FREQUENTLY ASKED QUESTIONS....................................................53
CHAPTER 15 TROUBLESHOOTING...........................................................................55
- 1 -
Chapter 1 Product Overview
1.1 Functions overview
z7 inch wide IPS LCD Capacitive Touch Screen with a high resolution of 1280*800 pixels.
zSurf the Internet wirelessly via Wi-Fi to enjoy the Internet on the go.
zSupport all mainstream e-mail services for more convenient e-mail sending and receiving.
zSwitching between portrait mode and landscape mode is possible through gravity sensing.
Four-direction rotation display is supported.
zShooting images or videos via .3 megapixel front camera and 2 megapixel rear camera.
zMultimedia applications: Video Player, Audio Player, Photo Browser, Camera and Shelves.
zEquipped with a built-in microphone, enabling audio-recording.
zEco settings enable the brightness to be freely adjusted.
1.2 Notes
zDo not use the unit in an overly hot, cold, wet, or dusty environment. Do not expose it to
sunlight.
zTry not to use this unit in an environment with a strong magnetic field or static electricity.
zAvoid dropping this unit or subjecting to strong impacts.
zThe adapter of this product should not be dropped nor splashed with liquid. Any object filled
with liquid, such as a vase, should not be placed on the top of it.
zThere are no user-serviceable parts inside the product. Do not dismantle this unit. Otherwise,
the warranty may be voided. Contact servicing personnel if you need assistance.
zThe battery life may vary depending on the use conditions and product age.
zReplacing the battery in this product by user is not recommended. Do not dismantle the unit
yourself. Explosion may occur if the battery is not properly handled or replaced. Suggest you
contact professional servicing personnel for such service. Also recommend to only use the
same brand of battery or equivalent for replacement. Any used lithium battery should not be
discarded, but should be collected to a sanitation sector for recycling.
zThe long life of a lithium battery is due to its much smaller memory effects than that of the
regular Nickel-Cadmium batteries. However, if the lithium battery is degrading, contact the
local Service Center.
- 2 -
zThe company is not liable for the data loss or deletion on machine resulting from the misuse of
software, improper operation of the battery, servicing, other accidents, or other indirect loss
thereof.
zThe device is assessed for typical body worn operation. The minimum distance between the
user and/or any bystander and the radiating structure of the transmitter is 20 cm.
zThe protection against exposure to excessive sound pressures from headphones or
earphones according to A12:2011 was tested.
zThe actual product may be different from that described in the Instructions due to the software
updates. These Instructions are for informational purposes only.
zThis being a highly mobile product, we recommend you back-up your data regularly.
1.3 Packaging list
AOC Breeze Tablet Unit X1
Micro USB cable X1
Micro USB Adapter X1
Micro USB Power Adapter X1
Quick Setup Guide X1
Warranty Statement X1
Note: The actual accessories provided with the product may vary.
1.4 Technical specifications
Basic specifications
Model no. AOC Tablet Q70S15
Installed OS Android OS 4.x
Processor (CPU) ARM Cortex A9 Quad core
Memory 1GB，DDR3
WLAN WI-FI IEEE 802.11b/g/n
Bluetooth Built-in 2.1 + EDR
Camera Front 0.3MP, Rear 2MP
Storage capacity Built-in 8GB Flash Memory
Expansion cards Micro SD (TF) card, up to 32 GB.
LCD 7 inch IPS LCD Capacitive Touch Screen with a high resolution
1280*800 pixels
- 3 -
Audio output Headset: Stereo output; internal speakers: Mixed output.
Power specifications
Voltage Supply voltage: 5V Charging voltage: 5V
CurrentMax. Current for playback is 1A DC.
Max. Current for charging is 1.2A DC.
Battery used Built-in lithium-ion polymer rechargeable battery, 3.7V,
3600mAh
Power adapter AC input：100-240V 50/60Hz DC input：5V 1.5A
Charging time
It takes about 3.5 hours for the battery to be fully charged when
the provided charger is used while powered-down. The
charging time may vary depending on the remaining battery
level.
Note: Do not charge the battery for more than 12 hours
continuously.
Battery use time
(Under the condition
that the battery is fully
charged in a normal
temperature)
Audio: About 12 hours
Video: About 4 hours
Web browsing: About 4 hours
External dimensions
Dimension (L×W×H) 5 ×7.5× 0.39inch (12.6×19.1×0.99cm)
Weight 0.73 lbs(0.330kgs)(with battery)
Ports Micro USB 2.0 high speed port, OTG,
3.5mm headset, Mini C type HDMI
Environmental conditions
Operating
Temperature 0°C ~ 45°C
Storage temperature -20°C ~ 55°C
Max. Humidity 90% RH (non-condensation)
Supported OS Windows2000/XP/Windows 7/Vista, Macintosh OS X
- 4 -
Note: Windows 2000＋SP1/SP2 is not supported by this product. The user should upgrade to SP3
or above. This product does not guarantee all video formats are playable. Even if some formats
are listed in the instructions, they may be not play properly, due to some video particularities.
- 5 -
Chapter 2 Buttons and Appearance
A. Front cameraB. Touch screen
C. Power button D. Volume +/- buttons
B
D
A
C
- 6 -
E. Rear camera F. Headphone jack
G. HDMI port H. Micro USB port (Power cable
jack/connecting to PC/
connecting to USB drive)
I. Built-in Microphone J. Micro SD (TF) card slot
K. Audio speaker
Note 1: During operation, sounds will be automatically output from the Audio speaker if there is
audio output.
Note 2: In the Instructions, “Press” means pressing a button while “Press and Hold” means
continuously pressing a button for 2 ~ 3 seconds.
FG IJ
H
E
K
- 7 -
Chapter 3 EasyConfig
When first using your Breeze tablet, the EasyConfig application will launch and walk you through
the basic setup where you will select your Language, Date/Time and Wi-Fi settings.
Touch "Next" to setup language, and then choose a language you want.
Touch "Next" to setup date, time zone and time.
Tap "Next" to go to the Wi-Fi settings interface.
- 8 -
Touch the menu icon ( ) and “Scan” icon to search for the available wireless networks in the
vicinity.
Touch the desired wireless network name to connect to it. You will be prompted, if a password is
required.
a) If static IP address needs to be entered, then click on “show advanced options” to show “IP
settings”. Touch the pop-up menu and select “static”. Then enter the IP address, gateway,
network mask, and DNS information required for such Wi-Fi network connections.
b) If you use dynamic IP address keep the default "DHCP" in the “IP settings” option.
Note: The word "Connected" displayed under the network name indicates a successful
connection.
Afterwards you can connect to the Internet, connect to email services, etc.
- 9 -
Chapter 4 Basic Operations
4.1 Booting up
Press and hold the Power button for a few seconds. After the boot screen is shown (for about 30
seconds), the unlock interface is shown. Touch and hold the unlock icon at the middle right of the
screen and drag it rightward to the “open lock” icon to unlock it. Once unlocked, the main Interface
will be shown.
4.2 Shutdown
In any mode, Press and hold the Power button for about 2 seconds. The device shutdown window
will appear:
a. Power off: Touch to turn off the product.
b. Airplane mode: Touch to turn on or turn off Airplane mode.
c. Silent mode: Touch to turn on or turn off sound.
Note 1: If the battery is low, the product will shutdown automatically.
Note 2: If the product freezes during operation, press and hold the Power button for 8 seconds to
force shutdown.
4.3 Network
To surf the Internet wirelessly, make sure the Wi-Fi wireless network signals are present and set
the Wi-Fi network connection. There are two ways of going to the “Wireless & Networks” settings
interface:
a. Touch the notification icon at the bottom right corner of the main interface, touch the popup
window and touch “Wi-Fi”.
b. In the “Apps” interface, touch “settings” icon to go to the settings interface, and then touch “Wi
-Fi”.
Note: For detailed settings, refer to “9.1 Wireless & Network Settings”.
4.4 Standby Mode
Standby: During use, you can press the power button to enter into standby mode to save battery
power and lock the key and screen.
Wake up: When the device is in standby mode, press the Power button. After the screen lights
up, touch and slide the “Lock” icon to the right towards to the “unlocked” icon.
4.5 Reset
- 10 -
If the product crashes during operation, you can press and hold the Power button for 8 seconds to
force shutdown.
4.6 Connecting to PC and file transfer
Connecting to PC:
1. While the product is on, plug the smaller end of the provided USB cable to the Micro USB port
on the side of it, and the larger end of it to a USB port on PC.
2. If the "Media device (MTP)" option is selected, (in Storage Settings / menu / USB computer
connection), the device is connected as a media device and you can transfer any files on
Windows PC, or using "Android File Transfer" on a Macintosh PC.
3. If the “Camera (PTP)” option is selected, device connected as a camera” and you can transfer
only photos.
4. If the “Mass Storage” option is selected, (in Storage Settings / menu / USB computer
connection), the USB connected interface will pop up on the tablet with the option to “Turn on USB
storage”. Tap the button "Turn on USB storage” to connect. When the message changes to “Turn
off USB storage”, the connection has successfully been established.
The tablet (and SD card if installed) will be mounted on your computer as mass storage devices.
You may access their data directly on your PC.
Disconnecting from PC:
Touch the "Safely Remove Hardware" icon at the bottom right corner of the Windows PC screen
to remove the device safely on PC. On a Macintosh, just "eject drives" from desktop.
Then tap “Turn off USB storage” button on the tablet to disconnect tablet from computer.
Note: File transfer requires: Windows XP system need Windows Media Player 11 or greater than
11 supported, while Mac system may need to install MTP software packages. (* "Android File
Transfer" for Mac OS X is available at www.android.com/filetransfer.)
4.7 Volume adjustment
Media volume: Adjust the volume for playing music and video.
Alarm：Adjust the volume of alarm.
Notification volume: Adjust the volume of notification ringtones.
- 11 -
4.7.1 Adjusting the media volume
There are two ways of going to the “Media Volume” adjustment interface:
·In any interface, press or press and hold the Volume +/- button on the top of the product to
adjust the media volume.
·In the apps interface, touch “Settings -> Sound -> Volume” , touch the media volume bar to
adjust the volume after the Volume window appears.
4.7.2 Adjusting the alarm volume
· In the apps interface, touch “Settings -> Sound -> Volume”. Touch the alarm volume bar to adjust
the volume after the Volume window appears.
4.7.3 Adjusting the notification volume
In the apps interface, touch “Settings -> Sound -> Volume”. Touch the notification volume bar to
adjust the volume after the Volume window appears.
4.8 Charging
When the battery is low, the provided adapter can be used to charge it.
1. If the product is powered on during charging, the status bar will show the charging icon ( ).
After the battery is fully charged, the bar will show the full battery icon ( ).
2. If the product is shutdown during charging, the large charging icon interface will be displayed.
After the battery is fully charged, the full battery icon ( ) will be shown; in the large charging
icon interface, press the Power button according to the prompts to turn on.
Note 1: When the product is charging, the charge indicator is always on. After the battery is fully
charged or power adapter is unplugged, the charge indicator goes out.
Note 2: Check the detailed charging percentage through “Settings -> About Tablet -> Status ->
Battery Level”.
Note 3: To extend battery life, avoid charging the battery frequently when it is in high level.
(Example: more than 90%) It is not recommended to charge the product at this time; if charging is
performed at this time, the percentage shown may not be 100%. This is normal.
Note 4: Once a “Low battery” message is displayed, the tablet should be charged as soon as
possible.
4.9 Touch screen operations
- 12 -
Tip: The display used in this product is a capacitive multi touch screen. When using, you can
operate it by using the buttons on its body or touching the corresponding icons on the display with
finger to enable the corresponding functions.
Touch
Touch the screen icons to select. When you want to use the on-screen keyboard to type, or press
an on-screen icons, just touch them using your finger.
Touch and hold
Touch the screen icons continuously until the option expands.
Slide
Place and slide your finger on the screen. Slide your finger up or down to scroll up or down; or if
the list has a scroll bar, slide your finger up or down in the list to page down or up; when you are
browsing pictures, slide your finger to the left or to the right to view the previous or next picture.
Multi Touch
While surfing the Internet or browsing pictures.
Zoom in: Touch the screen with two fingers, and slide two fingers together.
Zoom out: Touch the screen with two fingers, and slide two fingers together apart.
4.10 Search icon
In the main interface, touch the “Search” icon to search for the relevant information using the
browser.
- 13 -
Chapter 5 Common Features
5.1 Landscape/Portrait display switching
1. In the “Settings” interface, touch “Accessibility ->Auto-rotate screen.” When the “√” symbol
appeared, the Landscape/Portrait screen display switching is on; when the “√” symbol
disappeared, the Landscape/Portrait screen display switching is off.
2. Hold this product vertically with your hands and tilt it to the left or right. When it is tilted to a
position 90° to the horizontal plane, the gravity sensor built in the product senses the action and
the screen switches to Portrait mode from Landscape mode.
On the contrary, when it is tilted to a position 0° to the horizontal plane, the screen switches to
Landscape mode from Portrait mode.
Tip: This product supports 4-direction rotation display.
Note: For gravity sensing (display orientation), the screen orientation will not change if this product
is placed on the level and stationary surface, regardless of how you rotate the product.
5.2 Using virtual keyboard to type
Touch any text input box to pop up the virtual keyboard as shown below. Use this keyboard to type
any text or characters.
5.2.1 Android keyboard
- 14 -
A. Show box: Show the text typed. Touch and hold this box to display the Edit Text
menu for you to cut, copy, and paste the text.
B. Shift：Touch this key to switch between uppercase and lowercase text.
C. Touch this key to switch between numeric keypad and symbol keyboard;
For numeric keypad and symbol keyboard, touch the “~\{”key to display the
special symbols (such as ~, ±, ÷, ×, etc.).
D. Touch to delete the edited text.
E. Touch to ensure input and go to next step.
F. Touch this key to use voice recognition to input text.
G. Touch this key to hide the Android keyboard.
H. Touch this key to input space.
Tip: During the input process, you can move the cursor by touching a position.
5.2.2 Editing text
The typed text can be edited.
When there is text in the input field, touch and hold the input field (or touch and hold the show box
in the keyboard) to open the Edit Text menu. Touch the options in the menu to edit the text.
A
B
C
D
E
H
FG
- 15 -
Select all Select all text typed
Cut Cut text typed
Copy Copy text typed
Paste Paste cut or copied text
Share Share the selected text via Gmail or Email.
5.3 Notification bar
The notification icon appears when a message is received, PC is connected, or music is played.
You can open the notification bar to check for messages and played music.
5.3.1 Opening notification bar
After a new notification icon appears in the notification bar, touch the notification bar to open the
notification bar.
5.3.2 Closing notification panel
Touch any space except for notification bar to close it.
5.4 Recently run apps
Touch the recent apps icon in the main interface to go to show the background apps. Touch the
icon in the window to open the corresponding app.
- 16 -
Touch the app in the window and slide your finger towards right to close the corresponding app.
5.5 Changing wallpaper
In the main interface, touch and hold a blank space, choose the desire wallpaper from “Live
“Wallpapers”, “Gallery” or “Wallpapers”.
5.6 Power control
In the apps interface, slide your finger toward left to go to the Widgets interface, and then continue
sliding to the next widgets interface, find “Power control” widgets. Touch and hold the widgets icon
to move it to main interface, as the picture show below:
A. Wireless network on/off Touch to turn on or off the wireless network.
B. Bluetooth on/off Touch to turn on or off the Bluetooth.
C. Sync icon Touch to set whether the wireless network can be
used together with other programs.
D. Brightness adjustment
icon Touch to adjust the screen brightness.
A
C
B D
Table of contents
Other AOC Tablet manuals
