AOG L series User manual

Outdoor Stand Alone
Gas Grill
Quick Start Guide
INSTALLER: Leave these instructions with consumer. CONSUMER: Retain for future reference.
CAUTION: For your safety read the installation instructions and owner’s manual provided with the grill.
This grill must be installed in accordance with local codes and ordinances, or, in the absence of local codes, with either the latest National Fuel Gas Code (ANSI
Z223.1/NFPA 54), and Natural Gas and Propane Storage and Handling Installation Code (CSA-B149.1).
This appliance and its individual shutoff valves must be disconnected from the gas-supply piping system when testing the system at pressures in excess of ½ psig.
This appliance must be isolated from the gas-supply piping system by closing its dedicated manual shutoff valve during any pressure testing of the gas-supply
system at pressures up to and including ½ psig.
WHEN INSTALLING AND OPERATING THIS APPLIANCE WITH PROPANE (L.P.) GAS, ALL INSTRUCTIONS AND WARNINGS INYOUR OWNER’S MANUAL
MUST BE OBSERVED. FAILURE TO DO SO MAY RESULT IN A FIRE OR EXPLOSION CAUSING SERIOUS INJURY OR DEATH.
This grill is designed for outdoor use only. DO NOT use this grill inside a building, garage, enclosed area, or under any overhead construction. DO NOT
use this grill in or on a recreational vehicle or boat.
2-Unpacking
Carefully unpack the grill, removing all packing material and protective film.Verify that all
parts have arrived undamaged by consulting the parts list in the owner’s manual. Remove
foam packed hardware from oven area. (See Fig. 2-1.)
Consult the parts list in the owner’s manual. If any parts are missing or damaged,
immediately contact the AOG dealer before beginning installation.
Fig. 2-1
1-Safety
Lift out foam packed hardware
Remove plastic
zip-ties
3-Installation
Location
Locate the grill on a flat level surface. Refer to the INSTALLATION
REQUIREMENTS section of your grill owner’s manual for complete details.
CAUTION: Wind blowing into or across the rear oven lid vent (Fig.
3-1) can cause poor performance and/or dangerous
overheating. Orient the grill so that the prevailing wind
blows toward the front of the grill (Fig. 3-2).
CAUTION: To prevent dangerous overheating, the rear of the unit must have
a minimum clearance of 4” from any non-combustible wall.
To connect the regulator/
hose assembly to the
propane-gas cylinder
valve fitting: Press the
hand nut on the regulator
over the Acme thread fitting
on the cylinder valve. Turn
the hand nut clockwise to
engage the threads and
tighten until snug.
UL
Fig. 3-4 Type I Acme thread quick coupler
Vent
QCC
Type 1
valve
Brass Acme
thread fitting
Liquid level
indicator
(optional)
Hand nut with
Acme thread
Regulator
Hose
Hand wheel
Pressure
relief
valve
Connect Gas supply
These quick start instructions assume a
propane cylinder configured unit. See main
instructions for natural gas or household
propane configured units.
Place approved propane 20lb cylinder in tank
tray and secure in position (Fig. 3-3).
Connect quick coupler hose and regulator
supplied with unit to propane cylinder (Fig.
3-4).
Set all burner control valves to OFF and
open gas source control valve.
Follow the lighting instructions on the
reverse side of this guide.
Proper grill airflow must be maintained as
shown in Fig. 3-5.
Fig. 3-3
Quick
coupler
Propane
cylinder (tank)
Sideburner
shelf (if
equipped)
Backburner
(if equipped)
Tank support sleeve
Installation must be performed by a qualified professional service technician.
"L" Series
Fig. 3-2
CORRECT
PLACE GRILL SO PREVAILING WIND
BLOWS TOWARD FRONT OF GRILL
YOU MUST PROTECT REAR OVEN
VENT FROM PREVAILING WIND
Rear oven lid vent
INCORRECT
Fig. 3-1
Maintain proper
ventilation airflow
Fig. 3-5
REV 0 - 1602080910 L-C2-482

4-Grill Setup
Parts Placement Checklist
Place the following items according to their position and orientation in
Fig. 4-1:
Vaporizer panels, cooking grids, and warming rack.
Leave pre-installed burners in place to maintain proper alignment.
Vaporizer Panels
Place the vaporizer panels directly onto the studs on the burners. The
panels allow heat from the burners to be evenly directly throughout the
cooking area.
Cooking Grids
Place the cooking grids (over the burners) onto the grid frame.
Warming Rack
The warming rack comes pre-installed. Remove zip ties before use.
Consult the owner’s manual to remove or replace.
Shelf/Sideburner (if equipped)
Align the four (4) holes in the shelf with the four (4) holes in the side of
the cart while aligning and engaging the burner venturi with the orifice
(Fig. 4-2). Insert the four (4) screws (provided) into the holes and tighten.
Make the igniter wire connection as shown in Fig. 4-2. Open sideburner
lid, set cap on burner, and set grid into shelf.
IMPORTANT: See your grill owner’s manual for complete
installation details.
Screws Air shutter
Orifice
Igniter wire
Fig. 4-2
Venturi
Lights
Ignition
Side Burner
Fig. 5-2
Fig. 4-1
Cooking Grid
Vaporizer panel
(not with IR)
Main burner
Warming
rack
Rotisserie kit
(if equipped)
Sideburner shelf
(if equipped)
Note: For infrared burner (IR) equipped
grills; see detailed instructions
included in your owner’s manual.
Power
supply
Drip tray
Drip tray
heatshield
6-Propane Safety
Gas Cylinders
IMPORTANT: READ AND FOLLOW ALL WARNINGS PROVIDED WITH THE PROPANE-GAS CYLINDER.
READ ALL SAFETY INSTRUCTIONS AND WARNINGS REGARDING THE USE OF PROPANE GAS FOUND IN
YOUR OWNER’S MANUAL.
5-Test
WHEN OPERATING THIS
APPLIANCE WITH PROPANE,
ALL INSTRUCTIONS AND
WARNINGS MUST BE
OBSERVED. FAILURE TO DO
SO MAY RESULT IN A FIRE
OR EXPLOSION CAUSING
SERIOUS INJURY OR DEATH.
Light
switch
Grill lights
(not shown)
Connect
Note: Grill must be connected to 120VAC power for electronic lighting.
1. Open lid(s) or remove cover(s) from burner(s) to be lit.
2. Turn all gas control knob(s) to their OFF position(s).
3. Turn on the gas at its source.
Note: DO NOT turn on more than one valve at a time for either electronic or manual lighting.
4. Depress the control knob for the burner to be lit and turn it to the HI LIGHT position, then
press the ignition button. Once the burner lights, release the ignition button.
CAUTION: If a burner does not light within five (5) seconds of turning on the control knob,
depress the knob and turn it to the OFF position.WAIT FIVE (5) MINUTES before
repeating step 4. If you smell gas, follow the instructions on the cover of the grill
owner’s manual. If the burners still do not light after several attempts, refer to the
grill owner’s manual for manual lighting.
5. Repeat step 4 for each additional burner to be lit.
Fig. 5-1 - Burner valve control knob
OFF
HI
LIGHT
LOW
TO
TURN OFF
T O TURN ON
Read setting
here
HIGH to
LIGHT
To Turn OFF
To Turn ON
High to
light
Read setting here
Igniter
switch
Backburner
(if equipped)
Replacement parts can
be ordered from your
local AOG dealer.
IR burner
(if equipped)
IR cover
(if equipped)
30"and 36"model controls
Center main burner
control knob
Left
main burner
control knob
Right
main burner
control knob Backburner
control knob
(if equipped)
Control panel
screw(s)
Drip
tray Light switch
Igniter
switch
Sideburner
control knob
(if equipped)
REV 0 - 1602080910 L-C2-482
The burner ports and
carry-over ports must
be kept clean to ensure
proper ignition and
operation.
