AOpen MK73LE Setup guide

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
MK73LE
DOC. NO.: MK73LE-OL-E0201C
1

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
2
W
Wh ha at t’ ’s s i in n t th hi is s m ma an nu ua al l
MK73LE ....................................................................................................1
What’s in this manual ...........................................................................................................2
You Must Notice ...................................................................................................................9
Before You Start .................................................................................................................10
Overview ............................................................................................................................ 11
Feature Highlight ................................................................................................................12
Quick Installation Procedure............................................................................................... 16
Motherboard Map ...............................................................................................................17
Hardware Installation ..........................................................................18
JP14 Clear CMOS Data......................................................................................................19
CPU Installation .................................................................................................................20
JP21 Adjust FSB/PCI Clock................................................................................................21
CPU Jumper-less Design ...................................................................................................25
Setting CPU Core Voltage ..................................................................................................26
CPU and Housing Fan Connector (With H/W Monitoring)...................................................27

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
3
DIMM Socket......................................................................................................................28
Front Panel Connector .......................................................................................................29
ATX Power Connector ........................................................................................................31
AC Power Auto Recovery ...................................................................................................32
IDE and Floppy Connector .................................................................................................33
IrDA Connector...................................................................................................................36
WOM (Zero Voltage Wake on Modem) Connector ..............................................................37
WOL (Wake on LAN) ..........................................................................................................40
CNR Expansion Slot...........................................................................................................42
PC99 Color Coded Back Panel...........................................................................................43
COM2 Connector................................................................................................................44
Support 2nd USB Port .........................................................................................................45
CD Audio Connector........................................................................................................... 46
Modem Audio Connector ....................................................................................................47
AUX-IN Connector..............................................................................................................48
Front Audio Connector .......................................................................................................49

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
4
Battery-less and Long Life Design......................................................................................50
Over-current Protection ......................................................................................................51
Hardware Monitoring ..........................................................................................................53
Resettable Fuse .................................................................................................................54
Year 2000 (Y2K).................................................................................................................55
Low ESR Capacitor ............................................................................................................57
Layout (Frequency Isolation Wall) ......................................................................................59
Driver and Utility ..................................................................................60
Autorun Menu from Bonus CD Disc ....................................................................................61
Installing Windows 95.........................................................................................................62
Installing Windows 98.........................................................................................................63
Installing Windows 98 SE, Windows ME & Windows2000 .................................................. 64
Installing VIA 4 in 1 Driver ..................................................................................................65
Installing Onboard Sound Driver.........................................................................................66
Installing Onboard Creative Sound Driver (Optional)..........................................................67
Installing Onboard AGP Driver............................................................................................68

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
5
Installing Hardware Monitoring Utility ................................................................................. 69
ACPI Suspend to Hard Drive .............................................................................................. 70
ACPI Suspend to RAM (STR).............................................................................................77
AWARD BIOS ........................................................................................79
How To Use Award™ BIOS Setup Program........................................................................80
How To Enter BIOS Setup ..................................................................................................82
BIOS Upgrade ....................................................................................................................83
Overclocking ........................................................................................85
VGA Card & Hard Disk .......................................................................................................87
Glossary ...............................................................................................88
AC97 ..................................................................................................................................88
ACPI (Advanced Configuration & Power Interface)............................................................. 88
AGP (Accelerated Graphic Port).........................................................................................89
AMR (Audio/Modem Riser) .................................................................................................89
AOpen Bonus Pack CD ......................................................................................................89
APM (Advanced Power Management) ................................................................................90

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
6
ATA (AT Attachment) ..........................................................................................................90
ATA/66................................................................................................................................90
ATA/100..............................................................................................................................90
BIOS (Basic Input/Output System) .....................................................................................91
Bus Master IDE (DMA mode) .............................................................................................91
CNR (Communication and Networking Riser).....................................................................91
CODEC (Coding and Decoding) .........................................................................................92
DIMM (Dual In Line Memory Module) .................................................................................92
ECC (Error Checking and Correction) ................................................................................92
EDO (Extended Data Output) Memory ...............................................................................93
EEPROM (Electronic Erasable Programmable ROM) .........................................................93
EPROM (Erasable Programmable ROM)............................................................................93
EV6 Bus .............................................................................................................................94
FCC DoC (Declaration of Conformity) ................................................................................94
FC-PGA (Flip Chip-Pin Grid Array) .....................................................................................94
Flash ROM .........................................................................................................................95

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
7
FSB (Front Side Bus) Clock ...............................................................................................95
I2C Bus ...............................................................................................................................95
IEEE 1394 ..........................................................................................................................96
Parity Bit.............................................................................................................................96
PBSRAM (Pipelined Burst SRAM) ...................................................................................... 97
PC-100 DIMM.....................................................................................................................97
PC-133 DIMM.....................................................................................................................97
PCI (Peripheral Component Interface) Bus ........................................................................97
PDF Format ........................................................................................................................98
PnP (Plug and Play) ...........................................................................................................98
POST (Power-On Self Test)................................................................................................98
RDRAM (Rambus DRAM)...................................................................................................99
RIMM (Rambus Inline Memory Module) .............................................................................99
SDRAM (Synchronous DRAM) ...........................................................................................99
Shadow E2PROM ............................................................................................................. 100
SIMM (Single In Line Memory Module)............................................................................. 100

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
8
SMBus (System Management Bus) ..................................................................................100
SPD (Serial Presence Detect) ..........................................................................................101
UltraATA ...........................................................................................................................101
USB (Universal Serial Bus) ..............................................................................................102
VCM (Virtual Channel Memory) ........................................................................................102
ZIP file..............................................................................................................................102
Troubleshooting .................................................................................103
Technical Support ..............................................................................107
Product Registration ..........................................................................111

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
Y
Yo ou u M Mu us st t N No ot ti ic ce e
Adobe, the Adobe logo, Acrobat is trademarks of Adobe Systems Incorporated.
AMD, the AMD logo, Athlon and Duron are trademarks of Advanced Micro Devices, Inc.
Intel, the Intel logo, Intel Celeron, Pentium II, Pentium III are trademarks of Intel Corporation.
Microsoft, Windows, and Windows logo are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
All product and brand names used on this manual are used for identification purposes only and
may be the registered trademarks of their respective owners.
All of the specifications and information contained in this manual are subject to change without
notice. AOpen reserves the right to revise this publication and to make reasonable changes.
AOpen assumes no responsibility for any errors or inaccuracies that may appear in this manual,
including the products and software described in it.
This documentation is protected by copyright law. All rights are reserved.
No part of this document may be used or reproduced in any form or by any means, or
stored in a database or retrieval system without prior written permission from AOpen
Corporation.
Copyright©1996-2000, AOpen Inc. All Rights Reserved.
9

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
B
Be ef fo or re e Y Yo ou u S St ta ar rt t
This Online Manual will introduce to the user how this product is installed. All useful information
will be described in later chapters. Please keep this manual carefully for future upgrades or
system configuration changes. This Online Manual is saved in PDF format, we recommend using
Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD disc or you can get free
download from Adobe web site.
Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy
printing, you can print it by A4 paper size and set 2 pages per A4 sheet on your printer. To do so,
choose File > Page Setup and follow the instruction of your printer driver.
Thanks for the help of saving our earth.
10

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
11
O
Ov ve er rv vi ie ew w
Thank you very much for choosing AOpen MK73LE. It is an
AMD®Socket 462 motherboard based on the Micro ATX
form factor featuring the VIA KLE133 chipset. As high
performance chipset built in the M/B, the MK73LE supports
both AMD®Socket 462 series Athlon™ & Duron™
processor in 200MHz Front Side bus (FSB). As to the AGP
performance, it integrates a Trident Blade3D AGP graphics
engine to deliver rich graphics capabilities for running 2D/3D software and Internet applications.
Through its advanced memory controller architecture, this motherboard supports up to 1.0GB of
PC133 SDRAM. The on-board IDE controller supports UltraATA 33/66/100 mode and the
transfer rate up to the latest high-speed 100MB/s. Further flexibility can be achieved by taking
advantage of the Communication and Network Riser (CNR) card option that allows audio or
modem configuration on a single baseboard design. Besides, on the strength of built in AC97
CODEC controller, it can bring you the high quality multimedia capabilities with the magic stereo
surround. Now, enjoy all features from AOpen MK73LE.

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
12
F
Fe ea at tu ur re e H Hi ig gh hl li ig gh ht t
CPU
Supports AMD® Socket 462 Athlon®& Duron®600MHz~950MHz+ with 100/133MHz Front Side
Bus designed for Socket 462 technology.
Chipset
The VIA Apollo KLE133 is a high performance, cost-effective and energy efficient chipset for the
implementation of computer system with 100MHz CPU FSB frequencies and based on 64-bit
Socket 462 CPU. The VIA Apollo KLE133 integrates Trident Blade 2D/3D graphic accelerator
into a single BGA package, which provides you the better capabilities for demanding software
and Internet multimedia applications with comprehensive driver support. The VIA Apollo KLE133
provides superior performance between the CPU, DRAM, AGP bus and PCI bus.
Expansion Slots
Including three 32-bit / 33MHz PCI and CNR slots. The PCI local bus throughput can be up to
132MB/s. The CNR (Communication and Networking Riser) slot provided by MK73LE can
support Audio/Modem card CNR interface.

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
13
Memory
The MK73LE supports both PC100 and PC133 SDRAM, which allows zero wait state bursting
between the DRAM and the data buffers at 100/133MHz. The two banks of DIMM slots can be
composed of an arbitrary mixture of 1M/2M/4M/8M/16M/32MxN DRAMs. The DRAM controller
can run at either the host CPU bus frequency (66/100/133MHz) or pseudo-synchronous to the
CPU bus frequency.
Onboard Trident Blade3D Graphics Engine
This motherboard integrates the rich AGP graphics capabilities of the Trident Blade3D graphics
engine, which provides full AGP 2.0 capability for maximum bus utilization including 1X/2X/4X
mode transfers, SBA (Side Band Addressing), Flush/Fence commands, and pipelined grants.
The AGP 4X specification provides a new level of video display sophistication and speed. The
AGP 4X video cards support data transfer rates up to 533MB/s.
Ultra ATA 33/66/100 Enhanced IDE
Ultra ATA/100 is the latest version of the ATA hard drive data transfer protocol. This motherboard
comes with an on-board PCI Bus Master IDE controller with two connectors that supports four
IDE devices in two channels, supports Ultra ATA 33/66/100, PIO Modes 3 and 4 and Bus Master
IDE DMA Mode 4, and supports Enhanced IDE devices.

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
14
On-board AC97 Sound
This motherboard uses AC97 sound chip which includes the complete capability of audio
recording and playback system.
Power Management/Plug and Play
Supports the power management function that confirms to the power-saving standards of the
U.S. Environmental Protection Agency (EPA) Energy Star program. It also offers Plug-and-Play,
which helps save users from configuration problems, thus making system user-friendly.
Hardware Monitoring Management
Supports CPU or system fans status, temperature, voltage monitoring and alert through the
on-board hardware monitor module and AOpen Hardware Monitoring Utility.
Enhanced ACPI
Fully implements the ACPI standard for Windows®95/98/ME/NT/2000 series compatibility, and
supports Soft-Off, STR (Suspend to RAM, S3), STD (Suspend to Disk, S4), WOM (Wake On
Modem), and WOL (Wake On LAN) features.

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
15
Super Multi-I/O
Provides two high-speed UART compatible serial ports and one parallel port with EPP and ECP
capabilities. UART2 can also be directed from COM2 to the Infrared Module for the wireless
connections.

M
MK K7 73 3L LE E O On nl li in ne eM Ma an nu ua al l
16
Q
Qu ui ic ck k I In ns st ta al ll la at ti io on n P Pr ro oc ce ed du ur re e
This page gives you a quick procedure on how to install your system. Follow each step
accordingly.
1Installing CPU and Fan
2 Installing System Memory (DIMM)
3 Connecting Front Panel Cable
4 Connecting IDE and Floppy Cable
5 Connecting ATX Power Cable
6 Connecting Back Panel Cable
7 Power-on and Load BIOS Setup Default
8 Setting CPU Frequency
9 Reboot
10 Installing Operating System (such as Windows 98)
11 Installing Driver and Utility

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
Motherboard Map
17
MODEM-CN Connector (Red)
AUX-IN Connector (Green)
Onboard AC’97 CODEC PC99 Colored Back Connector
CD-IN Connector (Black)
32-bit PCI Slot x3
A
TX Power Connector
CNR Expansion Slot
WOL Connecto
r
(Wake On LAN)
Creative CT5880 Audio
Controller (Optional)
Front Audio Connecto
r
WOM Connector
(Wake On MODEM)
IrDA Connector
GPO Connector
FAN3 Connector
Resettable F
use
Low ESR Capacitors
462-pin CPU Socket
Supports 200MHz FSB
for AMD Duron / Athlon
VIA Apollo KLE133 Chipset
COM2 Connector
CPUFAN Connector
PC-100/133 DIMM Socket x2
FAN2 Connecto
r
Ultra ATA/100 IDE Connector
Front Panel Connecto
r
JP21 FSB Select
2MB Flash ROM BIOS
Support 2nd USB ports FDD Connector
JP14 Clear CMOS

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
18
H
Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
This chapter describes jumpers, connectors and hardware devices of this motherboard.
Note: Electrostatic discharge (ESD) can damage your processor, disk
drives, expansion boards, and other components. Always observe the
following precautions before you install a system component.
1. Do not remove a component from its protective packaging until
you are ready to install it.
2. Wear a wrist ground strap and attach it to a metal part of the
system unit before handling a component. If a wrist strap is not
available, maintain contact with the system unit throughout any
procedure requiring ESD protection.

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
19
J
JP P1 14 4 C Cl le ea ar r C CM MO OS S D Da at ta a
Pin 1
You can clear CMOS to restore system default setting.
To clear the CMOS, follow the procedure below.
1. Turn off the system and unplug the AC power.
2. Remove ATX power cable from connector PWR2.
3. Locate JP14 and short both pin 2 and pin 3 for a
few seconds.
4
. Return JP14 to its normal setting by shorting pins 1
and pin2.
Tip: When should I Clear CMOS?
1. Boot fail because of overclocking…
2. Forget password…
3. Troubleshooting…
1
1
Clear CMOS
Normal Operation
(default)

M
MK K7 73 3L LE E
O
On nl li in ne eM Ma an nu ua al l
20
C
CP PU U I In ns st ta al ll la at ti io on n
This motherboard supports AMD®Athlon and Duron Socket 462 CPU. Beware of CPU orientation
when you plug it into CPU socket.
CPU socket
Lever
CPU Pin1
and cut edge
1. Pull CPU socket lever and up to 90-degree
angle.
2. Locate Pin 1 on the socket and look for a black
dot or cut edge on the CPU upper left. Match Pin
1 and cut edge. Then insert CPU into the socket.
3. Press down CPU socket lever to finish CPU
installation.
Note: If you do not match CPU socke
t
Pin 1 and cut edge well, you ma
y
dama
g
e the CPU.
