Thank you for choosing AOpen AK77-400 / AK77-400N / AK77-400 Max. The AK77-400 / AK77-400N / AK77-400 Max is AMD®
Socket 462 motherboard (M/B) based on the ATX form factor featuring the VIA Apollo KT400A chipset. As high performance
chipset built in the M/B, the AK77-400 / AK77-400N / AK77-400 Max comes with AMD®Socket 462 series Athlon™ & Duron™
and AthlonXP™ processor (with CPU Overheat Protection circuit to Athlon™XP CPU only) and 200/266/333MHz EV6 system
bus. In the AGP performance, it has one AGP slot and supports AGP 8X/4X/2X mode and pipelined spilt-transaction long burst
transfer up to 2.1GB/sec. With high bandwidth 266/533MB/s 8-bit V-Link Host Controller, DDR400(PC3200), DDR333(PC2700)
and DDR266(PC2100) DDR RAM can be applied to
the AK77-400 / AK77-400N / AK77-400 Max and
DDR400 maximum memory size can be up to 2GB
and DDR333/266 up to 3GB. The on-board IDE
controller supports Ultra DMA 66/100/133 mode and
the transfer rate up to 133MB/s. With a Promise Serial
ATA (PDC20375) controller onboard, it aims to provide
you an even faster transfer rate of 150 Mbytes/second.
Beside, the AK77-400 / AK77-400N / AK77-400 Max
has an AC97 CODEC RealTek ALC650 chipset
onboard for provides high performance and magic
surround stereo sound to let people enjoy working
with it. More than that, this motherboard supports USB
2.0 function with a fancy speed of up to 480Mbps, and
IEEE 1394 controller to provides data transfer rate up
to 400Mbps. Now, enjoy all features from AOpen
AK77-400 / AK77-400N / AK77-400 Max.
