AOX 6600H User manual

User’s Manual
AOX 6600H
World 1st HDST
Technology
Hot/Cold
Antioxidant
Alkaline Water
Dispenser
AOX Pte Ltd
28 Sin Ming Lane
#03-143 Midview City
Singapore 573972
www.AOX.com.sg
[email protected]
6456 4321
Multi-Award Winning Brand
Multi-Award Winning Brand

Thank you for choosing !
We are condent that you will benet much from your
Hot/Cold AOX-6600H health transforming drinking water.
These units are equipped with 4-stage lters for removing impurities,
bacteria and viruses from your water. In additional, it comes
with a super Heavy Duty Storage Tank Technology.
F12-U: 1 Micron Sediment Carbon Block Filter
Filters sediments such as rust, particles, sand and lead in the water. It
removes organic chemical substances such as chlorine, detergent,
THM, pigment and carcinogens. Hence, it alone acts like a 2-Stage
Sediment/Carbon lter. Foul smell is also eliminated, leaving fresh
tasting water for your consumption.
F3-U: AOX Antioxidant Alkaline Minerals Filter
Makes the water alkaline and antioxidant in nature. It supplies
essential minerals such as calcium, potassium, magnesium, sodium
and silica to promote healthy cells, bones, joints, organs and skin.
Furthermore, it decreases the size of water molecule clusters.
F4-U: Post Activated Carbon Filter with KDF-55
Made of high-grade granulated activated carbon and KDF-55 for
the elimination of algae and fungi, controlling bacteria growth. It
also removes chlorine, pesticides and other organic compounds,
eradicating unpleasant taste and odour.
DDMI : Dual Dynamic Microbial Intervention
Made with Dual Dynamic nanobers which consist of very small pore structure on a thin
sheet to ensure the removal of heavy metals such as colloidal and soluble lead.
Dangers of heavy metal consumption and accumulation of heavy metals are nausea,
vomiting, diarrhoea, abdominal pain, heart problems etc. In addition, the bres are
treated with microbial ltration, removing up to 99.99% of bacteria and viruses.

HOW TO CHANGE THE FILTERS?
1. Close the water valve (Photo A)
2. Turn off hot water switch (Photo B)
3. Lift up both lever and drain off excess
water (Photo E)
4. Turn anti-clockwise to remove the cover
and drain off any excess water (Photo F)
5. Pull up the tube (Photo G) and remove
the whole set of lters (Photo H)
6. Insert the new lters in the same
sequence (Photo H)
Notes:
It is normal to experience “popping” sound or to have lots of air bubble (that may cause the
water to look cloudy) when the lters are new. This is due to the air trapped in the new lters.
If you nd some particles in the water, please do not be alarmed. The particles are tested by
independent labs to be activated carbon or alkaline minerals which is safe for consumption.
The quality and taste of the water is dependent on the incoming water source and the lter’s
usage.
To ensure that you get optimal antioxidants and alkalinity,please follow the recommended lter
change schedule.You may refer to the date written on the sticker (pasted on the side of the
dispenser) or when you hear the FCT (Filter Change Timer) beeping.
Photo G
Use your nger to push
in the ring as shown in
direction (1) and hold it
while you pull out the tube
as shown in direction (2)
12
Photo E
Please lift up each lever
to dispense AOX water
Photo F
Turn anti-clockwise (as shown
above) to remove the cover.
Tighten back the cover by turning
clockwise after draining off water
Photo H
Insert the lters in the right
sequence by following
the colour code as shown
above
Photo I
Turn on the water
valve
7. Close the top cover and tighten the
2 nuts (Photo C)
8. Turn on the water valve (Photo I)
9. Wait for 15 minutes for the water to ll up
both Hot/Cold tanks inside the dispenser,
use a container and lift up each lever to
ush away 10 litres of water (Photo E)
10. Turn on hot water switch (Photo B) and
your AOX dispenser is now ready to serve
your family
Green
Blue Red

REPLACEMENT OF FILTERS
1. Please pay attention to the arrow mark of lters when you are changing your lters.
(Diagram 1)
2. Optimal Lifespan:
To ensure optimal antioxidant properties and alkalinity of the drinking water, it is
recommended that you change your lters on every 6 to 9 month or 3,500 litres of usage
(whichever comes rst).
The pH, antioxidant properties, taste and amount of water that produced by AOX lters
may vary in accordance with the quality, pressure and temperature of the water source. If
the incoming water has more suspended particles, it may “choke” the lter(s) before the
recommended date.
3. CAUTION:
DO NOT USE where the water is microbiologically unsafe or of unknown quality without
adequate disinfection.
SHUT OFF THE WATER VALVE – Whenever the water dispenser is left unattended overnight,
on weekends or during holiday.This will prevent water pressure built up over time, which
may cause accidental leakages.
4. Maximum Pressure:
120 PSI
Photo A
1. Turn off the
water valve
Photo C
3. Unscrew
the 2 nuts
Photo B
2. Turn off hot water
switch. (Please
take note that
there is no cold
water switch, the
LED light for cold
switch will be light
up by default)
Photo D
4. Lift up the
cover
HOW TO TURN OFF THE INLET WATER VALVE AND OPEN THE COVER?

t )%455FDIOPMPHZo)FBWZ%VUZ4UPSBHF5BOL
t "09'1BUFOU/P
t 5FNQFSFE(MBTT'SPOU1BOFM
t )JHI*NQBDU)JHI(MPTT"#43FTJO
t "VUPNBUJD$POUSPMGPS"098BUFS3FåMM
t 4BGFUZ'BVDFUGPS)PU8BUFS
t "MM4UBJOMFTT4UFFM5BOL$BQBDJUZ-)PU8BUFS8-$PME8BUFS8
t $IJMMJOH4ZTUFN-($PNQSFTTPS3BH3FGSJHFSBUJPO(BT
t 8BUFS5FNQFSBUVSF$PME%FHSFF$FMTJVT)PUEFHSFF$FMTJVT
t %JNFOTJPODN8Y%Y)DN
t /FU8FJHIULH
t (SPTT8FJHIULH
t 1PXFS$POTVNQUJPO$PNQSFTTPS8)FBUFS8
t 1PXFS"$_7)[
PARTS NAME
SPECIFICATION
Model No: AOX-6600H
)058"5&3
SAFETY
BUTTON
$0-%8"5&3
-&7&3
)058"5&3
-&7&3
8"5&3
53":
)058"5&3
ON/OFF
SWITCH
501$07&3
108&3
1-6(
8"5&3
%3"*/$"1
850W
0.7A ,

TROUBLESHOOTING GUIDE
PROBLEM
Indicator on the dispenser
is not lighting up
Hot or Cold water not
dispensing out from
dispenser.
Hot water not hot
Water is leaking from the
dispenser.
MEASURES TO TAKE
Try Off / On power
Turn on the main water
supply valve.
Call up our Customer
Service hotline.
Try resetting the heating
sensor
Or
Call up our Customer
Service hotline.
Turn off the water supply
valve from the tap water
pipe and unplug the power
cord. Call up our Customer
Service hotline.
CHECK
Check if the main switch
and Hot switch is switch on?
Did you turn on the main
water supply valve?
Did you change your lters
regularly?
Check if the Hot switch is
switch on?
Check if you have given
ample time for the Hot tank
to heat up
Hot water requires 5minutes
while Cold water is cold by
default
Check if the leakage could
be from the connectors
It could be due to
condensation.Try wiping
off the water from the
dispenser using a dry
cloth and see if there is still
leakage
t 1MFBTFDIFDLUIFGPMMPXJOHCFGPSFBTLJOHGPSTVQQPSU
t 5IFEJTQFOTFSNBZOPUPQFSBUFQSPQFSMZCFDBVTFUIFVTFSJTOPUGBNJMJBSXJUIUIFQSPEVDU
use even if it is not broken down.
t 1MFBTFUBLFUIFGPMMPXJOHNFBTVSFT*GUIFSFJTTUJMMBQSPCMFNQMFBTFDPOUBDU$VTUPNFS4FSWJDF

Manufacturer:
AOX PTE LTD
Made in KOREA
Customer Support
& Service Agent
6456-4321
