AP O3 Desktop Instruction manual
Sep. 18
Automatikprodukter
Ozone Monitor, Temperature and Humidity
Modbus, Analog, Relay Outputs
1
db_ozone_wall_duct_ap_uk
O3
Technical Data
Gas Detected Ozone - O3
Sensing Element Electrochemical gas sensor
Sensor lifeme >2 years, removable and easy to
replace
Temperature Sensor NTC 5K
Humidity Sensor
Power Supply 24Vac/dc (power adaptor selectable)
Power Consumpon 2.8W
Response Time <50s @T90
Signal Update 1s
Warm up Time <60 seconds
Ozone Measuring Range 0 to 5000ppb (0-5ppm)
(0 to 9.81mg/m3)
Display Resoluon 0 to 1000ppb (0 to 1 ppm)
(0.01mg/m3)
1ppb (0,001ppm) (0,01mg/m3)
Accuracy ±0.01ppm + 10% reading
Nonlinear <1%FS
Repeatability <0.5%
Zero Dri <1%
Sound When LCD backlight is red the inner
Display, LCD backlight Green - ozone level < 1500 ppb,
Yellow - 1500 ppb <ozone level
< 3500 ppb,
Red - 3500ppb < ozone level (default)
Temperature
measurement
-20 to 50C (-4 to 140F)
Humidity measurement 5 to 99% rH
Analog Output 0 to 10Vdc (default) or 4 to 20mA
linear output selectable
Analog Output Resoluon 16Bit
Relay dry contact Output Two dry-contact outputs
Max, switching current 3A
(220Vac/30Vdc), resistance Load
Features
-Real me detecon and monitoring ambiant ozone level
-Design for real me detecng and monitoring ambiance
ozone level and temperature
-Electrochemical ozone sensor with high sensivity
-Parcular LCD display with three color backlights (Green/
Yellow/Red)
-Maximum ozone measuring range:
0 to 5000ppb (0 to 9.81mg/m3)
-Enables reset of measurement range by end user
-2 x On/O dry contact outputs for two stages alarm device,
or control a ozone generator or a venlator
-Buzzer alarm and 3-color backlight LCD indicaon
-Preset two stage alarm points for ozone measurement
-Provide 1 x analog output (0,2 to 10Vdc/4 to 20mA) (can be
used as transmier)
-Modbus RS485 communicaon interface, 15 kV anstac
protecon, individual IP address
-Easy way for calibraon and setup alarm points via the RS
485 interface
-Temperature measurement and display
-Humidity measurement and display oponal
-Mulple applicaon, wall mounng type and desktop type
-Great performance with high quality
Ordering Codes
O3-5000 Ozone Monitor 0 - 5000ppb (0 - 5ppm), incl.
remote control, desktop bracket and power
supply.
O3WallO3Desktop
Applicaon
-
-
alarm when ozone level is over proof, control ozone
a certain level in some special places
-
-
-O3-5000 is the best device used to detect and analyze ozone
Sep. 18
Automatikprodukter
Ozone Monitor, Temperature and Humidity
Modbus, Analog, Relay Outputs
2
db_ozone_wall_duct_ap_uk
O3
Modbus Communicaon
Interface
Modbus RTU protocol with
19200bps(default)
Other bps rate selectable in order
Working Condion -20 to 45C (-4 to 113F) /
0 to 95% rH
Storage Condions -40 to 70C (-40 to 158F)/
0 to 95% rH
Net Weight 190g
Dimensions 130 × 85 × 36.5mm (H x W x D)
Mounng height
Installaon Standard 65 × 65 mm or 85 x 85 mm or 2”×4”
wire box
Interface Connecon
(Max)
9 terminals
Wiring Standard 2
Manufacturing Process
Housing and IP class
Compliance
Version A038
Analog output 0 to 10Vdc
output, or 4 to 20mA output)
Voltage or current output is selected by
jumpers
Relay output 2 dry contact output
Modbus RS485 RS485 with Modbus interface of RTU
protocol
Ozone range 0 to 5000ppb
Control Output
0-5000ppb.
O3-5000 indicates the ozone detector with 1X 0 to 10Vdc output and
a Modbus RS485 interface, LCD display. Humidity sensor included.
Mounng and Wiring Diagrams
Wiring Diagram
24Vac
Transformer
Line
Voltage
Common
Transformer
GND
4-20mA/0-10Vdc
COM
ON1
ON2
RS 485
A
B
Ordering Codes - Alarm Units
AAW Warning Siren 24Vdc, 98 - 108 dB
AAW 230 Warning Siren 230Vac, 98 - 108 dB
OA 24 Red Flash Light, 24Vdc
OAW 24 Combined Warning Siren and Flash Light, 24Vdc
OAW 230 Combined Warning Siren and Flash Light, 240Vac
Warning Sign
Gas Alarm Warning Sign “GAS ALARM” 24Vac/dc
Sep. 18
Automatikprodukter
Ozone Monitor, Temperature and Humidity
Modbus, Analog, Relay Outputs
3
db_ozone_wall_duct_ap_uk
O3
For wall mounng:
Follow steps 1 - 3 in Figure 2.
slightly to remove the face plate from the wall plate.
Move the top of the house apart. Mount the unit on the wall.
Fig. 2
Fig. 1 Adaptor power supply
Fig. 3 - LCD Display
Humidity Temperature
Ozone
Important Safety Informaon
-
Mounng and Wire Connecon
- any steam
source or in direct sunlight.
-If the monitor uses the power adaptor to supply the 24Vac/dc power, plug the output end of
the adaptor into the power socket.
Operaon
Analog output selecon
a.
Connect the right two pins of the S1 and S2 - the analog output is voltage output.
b.
When the J1 is connected the analog output is 2-10Vdc or 4-20mA output.
When the J1 is disconnected, the analog output is 0-10Vdc or 0-20mA output.
c.
The default is 4-20mA. Do not change them!
1 2 3 4 5
Sep. 18
Automatikprodukter
Ozone Monitor, Temperature and Humidity
Modbus, Analog, Relay Outputs
4
db_ozone_wall_duct_ap_uk
O3
Parameter Setup
DIP 1
DIP 2 OFF - Celcius ON - Fahrenheit
DIP 3
ON - Relay 1 control valid at the second setppoint
DIP 4
ON - Relay 2 control valid at the second setpoint
(make sure the ozone level in the space is zero).
Parameter Setup:
1. Parameters can be set through RS485 OR
2. Connect J1 & J2
Parameters can be set through infrared remote controller
( keys to adjust values,
MODE key to switch items)
◀
◀
Sep. 18
Automatikprodukter
Ozone Monitor, Temperature and Humidity
Modbus, Analog, Relay Outputs
5
db_ozone_wall_duct_ap_uk
O3
LCD Display Parameter Seng Range Default
-01 ±3.0C/±6F 0
-02 5~99%rH 50
-03
0~ upper limit of measuring
range as 16ppm
e.g. if set this value at 16
through RS485 or remote con-
troller, the sensor will take the
present ozone level"
0
-04 First setpoint of relay 1 1~ upper limit of measuring
range
1000
-05 Second setpoint of relay 1 1~ upper limit of measuring
range
2000
-06 First setpoint of relay 2 1~ upper limit of measuring
range
3000
-07 Second setpoint of relay 2 1~ upper limit of measuring
range
4000
-08 1~1000 100
-09 Relay control mode -
1
-10
backlight and yellow backlight
1~ upper limit of measuring
range
1500
-11
backlight and red backlight
1~ upper limit of measuring
range
3500
-12 Buzzer alarm 1
-13 Alarm setpoint 1~ upper limit of measuring
range
3500
-14 1~1000 100
-15 Alarm song album
0
-16 1~ 600 seconds 120
-17 Display in ppm or ppb 2
-18 1~ 255 1
-19 RS485 Baud rate
14400bps
4
-20 RS485 Parity bits and Stop bits
selectable
1
-21 1~ upper limit of measuring
range
5000
-22 1
-23 -
able
Adjust the setpoint from 0 to
1, the present ozone level is
deemed as 0ppm
0
-24
available
Adjust the setpoint from 0 to
1, the present ozone level is
deemed as the value in -26
0
-25 -
-9999~ 9999 --
Modbus Register
Sep. 18
Automatikprodukter
Ozone Monitor, Temperature and Humidity
Modbus, Analog, Relay Outputs
6
db_ozone_wall_duct_ap_uk
O3
LCD
Display
Parameter Seng Range Default
-26
0ppb~ upper limit of measuring
range
0
-27 0 ~ 32767 --
-28
0ppb~ upper limit of measuring
range
2500
-29 0 ~ 32767 --
-30
0ppb~ upper limit of measuring
range
5000
-31 0 ~ 32767 --
ON will showON will not show on the LCD
