Apacer Technology EFC-D Series User manual

Apacer In-Vehicle Networking Product
mPCIe CAN Module –EFC-D/EHC-D series
User’s Manual
August, 2017
Version 1.40
Apacer Technology Inc.
1F, No.32, Zhongcheng Rd., Tucheng Dist., New Taipei City, Taiwan, R.O.C
Tel: [phone] Fax: [phone]
www.apacer.com

Important User Information
Liability
Every care has been taken in the preparation of this document. Please inform Apacer
Technology Inc. in case of any inaccuracies or omissions. The data and illustrations
found in this document are not binding. Apacer Technology Inc. reserves the right to
modify our products in line with our policy of continuous product development. The
information in this document is subject to change without notice and therefore should
not be considered as a binding description of the range of functions (neither for future
product versions). Apacer Technology Inc. assumes no responsibility for any errors that
may appear in this document.
There are many applications of the described product. Those are responsible for the
use of this device must ensure that all the necessary steps have been taken to verify
that the applications meet all performance and safety requirements including any
applicable laws, regulations, codes, and standards.
Apacer Technology Inc. will under no circumstances assume liability or responsibility
for any problems that may arise as a result from improper use or use that is not in
accordance with the documented features of this product.
The examples and illustrations in this document are included solely for illustrative
purposes.
Intellectual Property Rights
Apacer Technology Inc. has intellectual property rights relating to technology
embodied in the product described in this document. These intellectual property rights
may include patents and pending patent applications in Taiwan and other countries.

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
1
© 2016 Apacer Technology Inc. Rev. 1.40
Table of Contents
1. Product Description.......................................................................2
1.1. Introduction ...................................................................................2
1.2. Revision History.............................................................................2
1.3. Hardware Specification.................................................................2
2. Connection Overview ....................................................................3
2.1. EHC-D series ..................................................................................3
2.2. EFC-D Series ..................................................................................3
2.3. Mini PCIe Pin Assignments ...........................................................4
3. Connecting the CAN Bus and J1708 .............................................5
3.1. CAN Bus Connector and Pin Assignment .....................................5
3.2. J1708 Connector............................................................................6
3.3. D-Sub Y-cable Connector Pin Assignment....................................6
4. CAN Function Switch.....................................................................7
5. Dimension Drawing........................................................................8
5.1. EHC-D Series ..................................................................................8
5.2. EFC-D Series ..................................................................................8
6. Installation .....................................................................................9
6.1. Driver Installation ..........................................................................9
6.2. Hardware Installation..................................................................14
7. Reliability Specifications ............................................................15
7.1. Environmental ..............................................................................15
7.2. Certification and Compliance .....................................................15
8. Ordering Information ...................................................................15
Appendix A Optional Cable & Accessory..............................................16

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
2
© 2016 Apacer Technology Inc. Rev. 1.40
1. Product Description
1.1.Introduction
Apacer CAN bus(Controller Area Network) solution is designed in Mini PCIe for both
full and half height form factor. Apacer CAN Bus series module can optionally support
different protocols (CAN 2.0 A/B, OBDII, J1939 & J1708 protocols) for Vehicle diagnostic
interface and offers an ideal CAN Bus solution for the In-vehicle computing system.
1.2.Revision History
Version
Date
Author
Description
1.1
20160701
Leo Chen
First version
1.2
20160707
Leo Chen
Second version
1.3
20160712
Leo Chen
Internal Release
1.37
20170116
Leo Chen
External Release
1.39
20170318
Leo Chen
Modify driver installation
1.40
20170817
Leo Chen
Modify ordering information
1.3.Hardware Specification
Specifications
Form Factor
Mini PCIe Full or Half Height Form Factor
Host Interface
USB 2.0 via Mini PCIe
CANbus Connector
1.25 mm, 5-pin, Male type Wafer Box
Protocol Support
Optionally support CAN 2.0 A/B ,OBDII, J1939 and J1708
Channel
CANbus*2 channels
J1708*1 channel (EFC-D series only)
Baud Rate support
125 / 250 / 500 / 800 / 1000 K bps
OS Supported
Windows 7 / 10
Linux kernel 3.13 and 2.6 (by project)
Operating Temperature
-40℃~ 85℃
Vibration
7.69G@ 20~2000Hz, compliant with MIL-STD-810G
ESD Protection
8kV Contact, 15kV air
Dimension (L x W x H)
EFC-D Series:Full Height Mini PCIe: 50.9 x 30 x 6.56mm
EHC-D Series:Half Height Mini PCIe: 26.8 x 30 x 6.56mm

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
3
© 2016 Apacer Technology Inc. Rev. 1.40
2. Connection Overview
2.1.EHC-D series
The positions of the CAN connector and Termination Resistor on the EHC-D series
card.
2.2.EFC-D Series
The positions of the CAN Connector, J1708 connector, Extension Connector and
Termination Resistor on the EFC-D series.
2-Channel CAN Connector
J1708 Connector
CAN Function Switch
Extension Connector
CAN Function Switch
2-Channel CAN Connector

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
4
© 2016 Apacer Technology Inc. Rev. 1.40
2.3.Mini PCIe Pin Assignments
Pin #
Name
Pin #
Name
51
UART1_RTS#
52
+3.3V
49
UART1_CTS#
50
GND
47
UART1_RXD
48
N/C
45
UART1_TXD
46
CAN1_RX_LED_WKUP
43
GND
44
N/C
41
+3.3V
42
CAN1_TX_LED
39
+3.3V
40
GND
37
GND
38
USB_D+
35
GND
36
USB_D-
33
N/C
34
GND
31
N/C
32
N/C
29
GND
30
N/C
27
GND
28
N/C
25
N/C
26
GND
23
N/C
24
+3.3V
21
GND
22
PERST#
19
N/C
20
N/C
17
N/C
18
GND
Mechanical Key
15
GND
16
N/C
13
N/C
14
N/C
11
N/C
12
N/C
9
GND
10
N/C
7
N/C
8
N/C
5
N/C
6
N/C
3
N/C
4
GND
1
N/C
2
+3.3V

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
5
© 2016 Apacer Technology Inc. Rev. 1.40
3. Connecting the CAN Bus and J1708
3.1.CAN Bus Connector and Pin Assignment
The pin assignment between the D-Sub port and the 5-pin CAN connector1on the EFC-D
and EHC-D series are as below:
1Connector type: MOLEX PicoBlade™ Wire-to-Wire and Wire-to-Board Housing.The part number of the matching plug: 51021-0500
Pin #1: CAN 1 CAN-L
Pin #2: CAN 1 CAN-H
Pin #3: GND
Pin #4: CAN 2 CAN-L
Pin #5: CAN 2 CAN-H
EFC-D Series
Pin #1: CAN 1 CAN-L
Pin #2: CAN 1 CAN-H
Pin #3: GND
Pin #4: CAN 2 CAN-L
Pin #5: CAN 2 CAN-H
EHC-D Series

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
6
© 2016 Apacer Technology Inc. Rev. 1.40
3.2. J1708 Connector
The pin assignment of the J1708 connector of the EFC-D Series is as following:
If you need the optional CANbus cable set for the development, please refer to Appendix A
Optional Cable & Accessory section for details.
3.3.D-Sub Y-cable Connector Pin Assignment
Pin #2: CAN-L
Pin #6: Ground
Pin #7: CAN-H
Pin #1: N/C
Pin #9: N/C
Pin #8: N/C
Pin #3: N/C
Pin #4: N/C
Pin #5: N/C
Pin #1:
D-
Pin #2:
GND
Pin #3:
D+
EFC-D Series
Pin #1

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
7
© 2016 Apacer Technology Inc. Rev. 1.40
4. CAN Function Switch
The Termination Resistor Switch enables the user to change the 120-ohm resistor
quickly. It does not require any specific cable.
EFC-D Series
EHC-D Series
SW #1: CAN 2 Terminator
SW #2: Reserved
SW #3: CAN 1 TX mode
SW #4: CAN 1 Terminator
OFF: Disable/ON: Enable
SW #1: CAN 2 Terminator
SW #2: Reserved
SW #3: CAN 1 TX mode
SW #4: CAN 1 Terminator
OFF: Disable/ON: Enable

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
8
© 2016 Apacer Technology Inc. Rev. 1.40
5. Dimension Drawing
5.1.EHC-D Series
5.2.EFC-D Series

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
9
© 2016 Apacer Technology Inc. Rev. 1.40
6. Installation
6.1.Driver Installation
For the operation of Apacer CAN modules , a driver is needed.
Please plug in Apacer EFC-D/EHC-D series CAN module into your
development desktop PC or laptop and follow below steps to install its
driver.
Step 1:
Insert Apacer EFC-D/EHC-D CAN module into miniPCIe-to-USB
adapter, and then plug in your development desktop PC or laptop USB
host socket.
Step 2:
Launch device manager and Apacer EFC-D/EHC-D CAN module
could be found in “Other devices” as Figure 1 or Figure 2.
EFC-D installation
EHC-D installation
Risk of ESD damages caused by improper handling!
Use ESD protective measures to avoid equipment damage.

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
10
© 2016 Apacer Technology Inc. Rev. 1.40
Step3:
The following steps show how to install the driver of Apacer CAN
EFC-D modules (Full size mPCIe) by Step 3 ~ 5.
Select the device name and press mouse right key to click “Update
Driver Software…” to do driver installation, as Figure 3.
EFC-D Device Selection
Step4:
Select “Browse my computer for driver software” to install driver
manually as Figure 4.
Browse for EFC-D series Driver

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
11
© 2016 Apacer Technology Inc. Rev. 1.40
Step5:
Browse to the Apacer EFC-D CAN bus module folder to do driver
installation.
EFC-D module be recognized when driver installed completely

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
12
© 2016 Apacer Technology Inc. Rev. 1.40
Step6:
The following steps show how to install the driver of Apacer CAN
EHC-D modules (Half size mPCIe) by Step 6 ~ 8.
Select the appropriate installation file (x64 or x86) and launch it.
Step7:
Follow the installation instructions to install EHC-D series driver.
EHC-D Driver Install successfully

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
13
© 2016 Apacer Technology Inc. Rev. 1.40
Step8:
Run EHC-D driver patching tool to complete the driver installation and it
will auto-reboot Windows system.
EHC-D Driver Patching Tool
Step9:
Your CAN module could be recognized when driver installed completely
EFC-D CAN (Full Size mPCIE)

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
14
© 2016 Apacer Technology Inc. Rev. 1.40
EHC-D CAN (Half Size mPCIE)
6.2.Hardware Installation
Make sure driver is installed.
Turn off computer.
Pull power cord.
Open computer case according to instructions of computer manufacturer.
Determine corresponding slot.
Plug PC connector in corresponding slot, without using force.
Make sure the interface is securely held in computer.
Close computer case.
Hardware installation is complete

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
15
© 2016 Apacer Technology Inc. Rev. 1.40
7. Reliability Specifications
7.1.Environmental
Apacer CAN Bus Mini PCIe module environmental specifications follow MIL-STD-810G,
as indicated in the following table.
Environment
Specifications
Temperature
Non-operating: -40°C to 100°C
Operating: -40°C to 85°C
Vibration
Operating: Random, 7.69(Grms), 20~2000(Hz)
7.2.Certification and Compliance
Apacer CAN Bus Mini PCIe module complies with the following standards:
CE
FCC
RoHS
MIL-STD-810G
8. Ordering Information
Product
Description
APEFC-D10
Full Height mPCIe CAN module-support CAN 2.0A/B with G-sensor,Gyroscope
APEHC-D10
Half Height mPCIe CAN module-support CAN 2.0A/B with G-sensor,Gyroscope
APEFC-D30
Full Height mPCIe CAN module-support CAN 2.0A/B + OBDII with G-sensor,Gyroscope
APEHC-D30
Half Height mPCIe CAN module-support CAN 2.0A/B + OBDII with G-sensor,Gyroscope
APEFC-D40
Full Height mPCIe CAN module-support CAN 2.0A/B +J1939+OBDII with G-sensor,Gyroscope
APEHC-D40
Half Height mPCIe CAN module-support CAN 2.0A/B+J1939+OBDII with G-sensor,Gyroscope
APEFC-D50
Full Height mPCIe CAN module-support CAN 2.0A/B +J1939+OBDII+J1708 with G-sensor,Gyroscope

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
16
© 2016 Apacer Technology Inc. Rev. 1.40
Appendix A Optional Cable & Accessory
1. 2-Ch CAN, Box Header 5P to DB9 Cable
2. 2-Ch CAN, Box Header 5P to 2 DB9 Cable
CONN1
CONN2
CONN3
PIN No.
PIN No.
FUNCTION
COLOR
PIN No.
2
CAN1_L
WHITE
1
7
CAN1_H
GREEN
2
6
GND
BLACK
3
2
CAN2_L
WHITE
4
7
CAN2_H
GREEN
5
6
GND
BLACK
3
CONN3
Box Header 5P
CONN2
DB-9
CONN1
DB-9
CONN1
CONN2
PIN No.
FUNCTION
COLOR
PIN No.
2
CAN1_L
WHITE
1
7
CAN1_H
GREEN
2
3
GND
BLACK
3
4
CAN2_L
WHITE
4
5
CAN2_H
BLUE
5
CONN2
Box Header 5P
CONN1
DB-9

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
17
© 2016 Apacer Technology Inc. Rev. 1.40
3. J1708, Box Header 3P to DB9 Cable
CONN1
CONN2
PIN No.
FUNCTION
COLOR
PIN No.
3
J1708_D-
WHITE
1
4
J1708_D+
BLUE
3
5
GND
BLACK
2
CONN2
Box Header 3P
CONN1
DB-9

Apacer In-Vehicle Networking Product
APEFC-D/APEHC-D
18
© 2016 Apacer Technology Inc. Rev. 1.40
Global Presence
Taiwan
(Headquarters)
Apacer Technology Inc.
1F., No.32, Zhongcheng Rd., Tucheng Dist.,
New Taipei City 236, Taiwan R.O.C.
Tel: [phone]
Fax: [phone]
[email protected]
U.S.A.
Apacer Memory America, Inc.
46732 Lakeview Blvd., Fremont, CA 94538
Tel: [phone]
Fax: [phone]
[email protected]
Japan
Apacer Technology Corp.
5F, Matsura Bldg., Shiba, Minato-Ku
Tokyo, 105-0014, Japan
Tel: [phone]
Fax: [phone]
[email protected]
Europe
Apacer Technology B.V.
Science Park Eindhoven 5051 5692 EB Son,
The Netherlands
Tel: [phone]
Fax:[phone]
[email protected]
China
Apacer Electronic (Shanghai) Co., Ltd
Room D, 22/FL, No.2, Lane 600, JieyunPlaza,
Tianshan RD, Shanghai, 200051, China
Tel: [phone]
Fax: [phone]
[email protected]
India
Apacer Technologies Pvt Ltd,
Unit No.201, “Brigade Corner”, 7th Block Jayanagar,
Yediyur Circle, Bangalore –560082, India
Tel: [phone]
Fax: [phone]
[email protected]
