iWave iW-RainboW-G21M Installation manual

REL1.1
Page 1 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
iW-RainboW-G21M
RZ/G1H Qseven SOM
Hardware User Guide

REL1.1
Page 2 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Document Revision History
Document Number
iW-PREXZ-UM-01-R4.0-REL1.1-Hardware
Revision
Date
Description
1.0
19th Oct 2016
Official Release Version
1.1
23rd May 2018
Updated Release for Production Version SOM
(Substantive changes throughout the document)
PROPRIETARY NOTICE: This document contains proprietary material for the sole use of the intended recipient(s). Do
not read this document if you are not the intended recipient. Any review, use, distribution or disclosure by others is
strictly prohibited. If you are not the intended recipient (or authorized to receive for the recipient), you are hereby
notified that any disclosure, copying distribution or use of any of the information contained within this document is
STRICTLY PROHIBITED. Thank you. “iWave Systems Tech. Pvt. Ltd.”

REL1.1
Page 3 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Disclaimer
iWave Systems reserves the right to change details in this publication including but not limited to any Product
specification without notice.
No warranty of accuracy is given concerning the contents of the information contained in this publication. To the
extent permitted by law no liability (including liability to any person by reason of negligence) will be accepted by iWave
Systems, its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or
inaccuracies in this document.
CPU and other major components used in this product may have several silicon errata associated with it. Under no
circumstances, iWave Systems shall be liable for the silicon errata and associated issues.
Trademarks
All registered trademarks, product names mentioned in this publication are the property of their respective owners
and used for identification purposes only.
Certification
iWave Systems Technologies Pvt. Ltd. is an ISO 9001:2015 Certified Company.
Warranty & RMA
Warranty support for Hardware: 1 Year from iWave or iWave's EMS partner.
For warranty terms, go through the below web link,
http://www.iwavesystems.com/support/warranty.html
For Return Merchandise Authorization (RMA), go through the below web link,
http://www.iwavesystems.com/support/rma.html
Technical Support
iWave Systems technical support team is committed to provide the best possible support for our customers so that
our Hardware and Software can be easily migrated and used.
For assistance, contact our Technical Support team at,
Email : [e-mail]
Website : www.iwavesystems.com
Address : iWave Systems Technologies Pvt. Ltd.
# 7/B, 29th Main, BTM Layout 2nd Stage,
Bangalore, Karnataka,
India –560076

REL1.1
Page 4 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Table of Contents
1. INTRODUCTION ............................................................................................................................................7
1.1 Purpose .............................................................................................................................................................7
1.2 Qseven SOM Overview .....................................................................................................................................7
1.3 List of Acronyms................................................................................................................................................7
1.4 Terminlogy Description.....................................................................................................................................9
1.5 References ........................................................................................................................................................9
1.6 Important Note ...............................................................................................................................................10
2. ARCHITECTURE AND DESIGN....................................................................................................................... 11
2.1 RZ/G1H QevenSOM Block Diagram ................................................................................................................11
2.2 RZ/G1H QsevenSOM Features ........................................................................................................................12
2.3 RZ/G1H CPU ....................................................................................................................................................15
2.4 Memory...........................................................................................................................................................16
2.4.1 DDR3 SDRAM ..............................................................................................................................................16
2.4.2 SPI NOR Flash ..............................................................................................................................................16
2.4.3 eMMC Flash ................................................................................................................................................17
2.5 RTC Controller.................................................................................................................................................17
2.6 Qseven PCB Edge Connector...........................................................................................................................18
2.6.1 Gigabit Ethernet..........................................................................................................................................19
2.6.2 USB 3.0 Host Interface ................................................................................................................................20
2.6.3 PCIe Interface ..............................................................................................................................................20
2.6.4 SATA Interface (Optional)............................................................................................................................21
2.6.5 USB 2.0 OTG Interface.................................................................................................................................21
2.6.6 USB 2.0 Host Interface ................................................................................................................................21
2.6.7 SD Interface.................................................................................................................................................22
2.6.8 LVDS Display Interface ................................................................................................................................22
2.6.9 HDMI Interface (Optional)...........................................................................................................................23
2.6.10 I2S Audio Interface ......................................................................................................................................23
2.6.11 DATA UART Interface ..................................................................................................................................24
2.6.12 CAN Interface ..............................................................................................................................................24
2.6.13 SPI Interface ................................................................................................................................................24
2.6.14 I2C Interface................................................................................................................................................25
2.6.15 PWM Interface ............................................................................................................................................25
2.6.16 GPIO Interface.............................................................................................................................................25
2.6.17 Manufacturing/Debug UART Interface.......................................................................................................26
2.6.18 Power Input.................................................................................................................................................26
2.6.19 Power Control Signal...................................................................................................................................26
2.6.20 Reset Signal.................................................................................................................................................26
2.7 Expansion Connector1 Interfaces ...................................................................................................................42
2.7.1 Parallel Camera Interfaces..........................................................................................................................43
2.8 Expansion Connector2 Interfaces ...................................................................................................................50
2.8.1 10/100Mbps Ethernet .................................................................................................................................51

REL1.1
Page 5 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.8.2 I2S Audio Interface ......................................................................................................................................51
2.8.3 Data UART Interface ...................................................................................................................................52
2.8.4 CAN Interface ..............................................................................................................................................52
2.8.5 SPI Interface ................................................................................................................................................53
2.8.6 PWM Interface ............................................................................................................................................53
2.9 Other Features ................................................................................................................................................60
2.9.1 JTAG Header................................................................................................................................................60
2.9.2 SPI Programming Header............................................................................................................................62
2.9.3 Power IN Connector (Optional) ...................................................................................................................63
2.10 RZ/G1H Pin Multiplexing on Qseven Edge and Expansion Connectors ..........................................................64
2.11 RZ/G1H CPU Reference Schematic .................................................................................................................74
3. TECHNICAL SPECIFICATION.......................................................................................................................... 79
3.1 Electrical Characteristics .................................................................................................................................79
3.1.1 Power Input Requirement ...........................................................................................................................79
3.1.2 Power Input Sequencing..............................................................................................................................80
3.1.3 Power Consumption ....................................................................................................................................81
3.2 Environmental Characteristics........................................................................................................................82
3.2.1 Environmental Specification........................................................................................................................82
3.2.2 Heat Sink/Spreader .....................................................................................................................................82
3.2.3 RoHS Compliance ........................................................................................................................................84
3.2.4 Electrostatic Discharge................................................................................................................................84
3.3 Mechanical Characteristics .............................................................................................................................85
3.3.1 Qseven SOM Mechanical Dimensions.........................................................................................................85
3.3.2 Guidelines to insert the Qseven SOM into Carrier board ............................................................................87
4. ORDERING INFORMATION .......................................................................................................................... 88
5. APPENDIX I................................................................................................................................................. 89
5.1 RZ/G1H Qseven SOM Configuration Switches................................................................................................89
6. APPENDIX II................................................................................................................................................ 90
6.1 RZ/G1H SPI Programmer Board ......................................................................................................................90
7. APPENDIX III............................................................................................................................................... 91
7.1 RZ/G1H Qseven SOM Development Platform ................................................................................................91

REL1.1
Page 6 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
List of Figures
Figure 1: RZ/G1H Qseven SOM Block Diagram...............................................................................................................11
Figure 2: RZ/G1H CPU Simplified Block Diagram ............................................................................................................15
Figure 3: Qseven PCB Edge Connector............................................................................................................................18
Figure 4: Expansion Connector1 .....................................................................................................................................42
Figure 5: Expansion Connector2 .....................................................................................................................................50
Figure 6: JTAG Header.....................................................................................................................................................60
Figure 7: SPI Programming Header.................................................................................................................................62
Figure 8: 2Pin Power Connector .....................................................................................................................................63
Figure 9: Qseven SOM Power Sequence.........................................................................................................................80
Figure 10: Heat Sink Dimensions ....................................................................................................................................83
Figure 11: Heat Spreader Dimensions ............................................................................................................................84
Figure 12: Mechanical dimension of Qseven SOM- Top View........................................................................................85
Figure 13: Mechanical dimension of RZ/G1H Qseven SOM- Bottom View ....................................................................86
Figure 14: Mechanical dimension of RZ/G1H Qseven SOM- Side View..........................................................................86
Figure 15: Qseven Module Insertion procedure.............................................................................................................87
Figure 16: Configuration Switches ..................................................................................................................................89
Figure 17: RZ/G1H SPI Programming Board....................................................................................................................90
Figure 18: RZ/G1H Qseven SOM Development Platform with Add on Module .............................................................91
List of Tables
Table 1: Acronyms & Abbreviations.................................................................................................................................. 7
Table 2: Terminology ........................................................................................................................................................9
Table 3: Compatible Magnetics ......................................................................................................................................19
Table 4: Qseven PCB Edge Connector Pin Assignment...................................................................................................27
Table 5: Parallel Camera Interface Pin Assignment on Expansion connector1 ..............................................................43
Table 6: Expansion Connector1 Pin Assignment.............................................................................................................44
Table 7: Compatible Magnetics ......................................................................................................................................51
Table 8: Expansion Connector2 Pin Assignment.............................................................................................................54
Table 9: JTAG Header Pin Assignment ............................................................................................................................61
Table 10: SPI Programming Header Pin Assignment ......................................................................................................62
Table 11: Power IN Connector - BOM.............................................................................................................................63
Table 12: RZ/G1H CPU IOMUX for Qseven Edge Connector interfaces..........................................................................64
Table 13: RZ/G1H CPU IOMUX for Expansion Connector1 interfaces ............................................................................69
Table 14: RZ/G1H CPU IOMUX for Expansion Connector2 interfaces ............................................................................72
Table 15: Power Input Requirement...............................................................................................................................79
Table 16: Power Sequence Timing..................................................................................................................................80
Table 17: Power Consumption........................................................................................................................................81
Table 18: Environmental Specification ...........................................................................................................................82
Table 19: Orderable Product Part Numbers ...................................................................................................................88
Table 20: SOM Configuration Switches...........................................................................................................................89

REL1.1
Page 7 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
1. INTRODUCTION
1.1 Purpose
This document is the Hardware User Guide for the RZ/G1H Qseven System On Module based on the Renesas’s RZ/G1H
Application processor. This board is fully supported by iWave Systems Technologies Pvt. Ltd. This Guide provides
detailed information on the overall design and usage of the RZ/G1H Qseven System On Module from a Hardware
Systems perspective.
1.2 Qseven SOM Overview
The RZ/G1H Qseven SOM is an extension of RZ/G1H CPU. The Qseven concept is an off-the-shelf, multi-vendor, Single-
Board-Computer that integrates all the core components of a common PC and is mounted onto an application specific
carrier board. Qseven modules have a standardized form factor of 70mm x 70mm and have specified pin outs based
on the high speed MXM system connector that has a standardized pin out regardless of the vendor. A single ruggedized
MXM connector provides the carrier board interface to carry all the I/O signals to and from the Qseven module.
1.3 List of Acronyms
The following acronyms will be used throughout this document.
Table 1: Acronyms & Abbreviations
Acronyms
Abbreviations
ARM
Advanced RISC Machine
BOM
Bill of Material
BPP
Bits Per Pixel
BSP
Board Support Package
CAN
Controller Area Network
CMOS
Complementary Metal-Oxide Semiconductor
CPU
Central Processing Unit
DDR3
Double Data Rate 3
DMA
Direct Memory Access
DVI
Digital Visual Interface
EDID
Extended Display Identification Data
eMMC
Enhanced Multi Media Card
GB
Giga Byte
Gbps
Gigabits per sec
GPIO
General Purpose Input Output
HDMI
High-Definition Multimedia Interface
HSCIF
High Speed Serial Communication Interface with FIFO
I2C
Inter-Integrated Circuit
IC
Integrated Circuit

REL1.1
Page 8 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Acronyms
Abbreviations
JTAG
Joint Test Action Group
Kbps
Kilobits per second
LCD
Liquid Crystal Display
LVDS
Low-Voltage Differential Signal
MAC
Media Access Controller
MB
Mega Byte
Mbps
Megabits per sec
MHz
Mega Hertz
MSIOF
Clock-Synchronized Serial Interface with FIFO
NPTH
Non Plated Through hole
PCB
Printed Circuit Board
PCIe
Peripheral Component Interconnect Express
PTH
Plated Through hole
PWM
Pulse Width Modulation
QSPI
Quad Serial Peripheral Interface
RoHS
Restriction on Hazardous Substances
RTC
Real Time Clock
SATA
Serial Advanced Technology Attachment
SCIF
Serial Communication Interface with FIFO
SD
Secure Digital
SDHI
SD Card Host Interface
SSI
Serial Sound Interface
SDRAM
Synchronous Dynamic Random Access Memory
SOM
System On Module
TDM
Time Division Multiplexing
TPU
Time Pulse Unit
UART
Universal Asynchronous Receiver/Transmitter
USB
Universal Serial Bus
USB OTG
USB On The Go

REL1.1
Page 9 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
1.4 Terminlogy Description
In this document, wherever Signal Type is mentioned, below terminology is used.
Table 2: Terminology
Terminology
Description
I
Input Signal
O
Output Signal
IO
Bidirectional Input/output Signal
CMOS
Complementary Metal Oxide Semiconductor Signal
DIFF
Differential Signal
LVDS
Low Voltage Differential Signal
OD
Open Drain Signal
OC
Open Collector Signal
Power
Power Pin
PU
Pull Up
PD
Pull Down
NA
Not Applicable
NC
Not Connected
Note: Signal Type does not include internal pull-ups or pull-downs implemented by the chip vendors and only includes
the pull-ups or pull-downs implemented On-SOM.
1.5 References
•RZ/G1H CPU Hardware User Manuals
•Qseven® Specification Version 2.0
•Qseven® Design Guide

REL1.1
Page 10 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
1.6 Important Note
RZ/G1H Qseven Edge connector signal name mentioned in Pinout Tables is followed as per below format for easy
understanding.
•If CPU pin has multiplexing option and selected particular function, then the signal name is mentioned as
“Selected Function Name (GPIO Number)”
Example: CAN0_RX(GP4_26)
In this signal, CAN0_RX is the functionality which we are using and GP4_26 is the GPIO number.
•If CPU pin has multiplexing option and selected as GPIO function, then the signal name is mentioned as
“GPIO_Functionality Description(GPIO Number)”
Example: GPIO_PCIe_RST/MD4(GP4_31)
In this signal, PCIe_RST is the GPIO functionality which we are using and GP4_31 is the GPIO number.
•If CPU pin doesn’t have multiplexing option, then the signal name is mentioned as,
“Function name”
Example: I2C3_SDA
In this signal, functionality which we are using I2C3_SDA
Note: The above naming is not applicable for other signals which are not connected to CPU.

REL1.1
Page 11 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2. ARCHITECTURE AND DESIGN
This section provides detailed information about the RZ/G1H Qseven SOM features and Hardware architecture with
high level block diagram. Also this section provides detailed information about Qseven edge connector & Expansion
connector’s pin assignment and usage.
2.1 RZ/G1H QevenSOM Block Diagram
CPU
RZ/G1H
DDR3 -1GB
(Upgradable)
SPI Flash -
16MB
(Upgradable)
QSEVEN
PCB Edge
Connector
(230Pin)
Gigabit
Ethernet 4
SDHI2
I2C x 3
SPI x 1 (2 Chip selects)
CAN x 1
8 GPIOs, Status & Control Signals
PCIe/
SATA1
USB3.0/
SATA0
EtherAVB/
VI0
I2C0, I2C2
I2C3
MSIOF0
CAN1
GPIOs
QSPI
DDR3 (32bit)
Expansion
Connector1
(80Pin header)
Gigabit
Ethernet
PHY
DBSC3–CH0
I2S x 1
SSI3/
SSI4
SCIF2
SSI/I2S x 1
JTAG
iW-RainboW-G21M - RZ/G1H Qseven SOM Block Diagram
UART x 1
2Pin Power In
(Optional)
JTAG
Power to
Peripherals
5V
Debug
VI1
JTAG (Optional)
(20 Pin Header)
On-Board
Regulators
Dual SPDT
Switch IC
(Optional)
Expansion
Connector2
(80Pin header)
CAN0
CAN x 1
DDR3 -1GB
(Upgradable)
DDR3 (32bit) DBSC3–CH1
PWM x 2
TPU0TO0,
TPU0TO1
UART (with CTS & RTS) x 1
SCIFB1
¹ SATA0 & SATA1 is not supported by default.
² VI2 camera interface supports only Embedded Sync.
³ Through DIP switch, either MMC1-8bit (Since MMC_DATA7 line is shared with VI1_CLK) or VI1 can be selected at a time. If VI1 is used in 16bit, then VI2 cannot be used.
4 Through DIP switch, either EtherAVB (or) 4th Camera (VI0-8/16bit) can be selected at a time. If VI0 is used in 16bit, then VI3 cannot be used
USB1
MSIOF3
PWM x 3 PWM0,3,4
USB2.0 HUB
(2 Ports)
USB Host x 2
USB Host
USB Host x 1
USB2
EtherMAC
RMII x 1
SPI x 1 (2 Chip selects)
10/100Mbps
Ethernet PHY
SCIFA2
SCIF1,SCIF0
HSCIF0
SSI0
UART x 3
UART (with CTS & RTS) x 1
eMMC - 8GB
(Upgradable)
MMC1 (7bit) MMC1/
SDHI3
VI2/QSPI
Camera (8bit) x 1²
SDHI2
Bus
Switch VI0 (8/16bit)4
MMC1(1bit)3
Camera (8bit) x 1 VI3
Bus Switch
MMC1(1bit)3
VI1(8/16bit)x1 3
VI0 (8/16bit) x 14
SCIFB2
UART (with CTS & RTS) x 1
USB3.0 x 1²
PCIe x 1¹
SATA x 1¹
LVDS x 1, PWM x 1
DU_LVDS0,
TPU0TO2
DU_LVDS1 HDMI X 1
HDMI
Transmitter
(Optional)
RTC Controller VRTC
I2C0
SPI
Programming
Header
USB OTG x 1
USB0
Figure 1: RZ/G1H Qseven SOM Block Diagram

REL1.1
Page 12 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.2 RZ/G1H QsevenSOM Features
The RZ/G1H Qseven SOM supports the following features.
CPU
•Renesas’s RZ/G1H CPU: Quad ARM Cortex®-A15 MPCore® @ 1.4GHz and Quad ARM Cortex®-A7
MPCore® @ 780MHz
Memory
•DDR3 SDRAM - 2GB (Expandable)
•SPI Flash - 16MB (Expandable) 1
•eMMC Flash - 8GB (Expandable) 2
Other On-SOM Features
•Gigabit Ethernet PHY Transceiver
•10/100 Ethernet PHY Transceiver
•USB 2.0 High Speed 2-Port Hub
•RTC controller
•SPI Programming Header
•JTAG Header (Optional)
•HDMI Transmitter(Optional)
Qseven PCB Edge Interfaces
•Gigabit Ethernet x 1 Port (through On-SOM Gigabit Ethernet PHY transceiver) 3
•USB 3.0 Host x 1 Port 4
•PCIe x 1 Port5
•SATA x 1 Port (Optional) 4,5
•USB 2.0 OTG x 1 Port
•USB 2.0 Host x 1 Ports
•USB 2.0 Host x 2 Ports (through On-SOM USB 2.0 High Speed 2-Port Hub)
•SD (4bit) x 1 Port
•LVDS x 2 Ports 6
•HDMI x 1 Port 6
•SSI/I2S (Audio Interface) x 1 Port
•Debug UART
•Data UART (with CTS & RTS) x 1 Port

REL1.1
Page 13 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
•CAN x 1 Port
•SPI x 1 Port (with 2 Chip selects)
•I2C x 3 Ports
•PWM x 3 Ports
•8 GPIOs
Expansion Connector1 Interfaces
•Parallel Camera Interface x 4 Ports
➢VIN0 –8bit/16bit 3,7
➢VIN1 –8bit/16bit 2,8
➢VIN2 –8bit1,8
➢VIN3 –8bit7
Expansion Connector2 Interfaces
•10/100 Ethernet x 1 Port (through On-SOM Ethernet PHY transceiver)
•SSI/I2S x 1 Port
•Data UART x 3 Ports
•CAN x 1 Port
•SPI x 1 Port
•PWM x 3 Port
General Specification
•Power Supply : 5V,2A
•Power IN connector for Standalone usage (Optional)
•Form Factor :70mm x 70mm
1 In RZ/G1H CPU, SPI and VIN2 signals are multiplexed in same pins and so either one interface only can be used at a
time.
2 In RZ/G1H CPU, eMMC Data7 and VIN1 clock is multiplexed in same pin and so eMMC will operate only in 4bit mode
when VIN1 is supported. If VIN1 is not supported, then eMMC can operate in 8bit mode. A DIP switch (SW3) is provided
on SOM to select either eMMC 8bit mode or VIN1.
3 In RZ/G1H CPU, EtherAVB and VIN0 are multiplexed in same pins and so either one interface only can be used at a
time. A DIP switch (SW2) is provided on SOM to select either EtherAVB or VIN0.

REL1.1
Page 14 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
4 In RZ/G1H CPU, USB3.0 and SATA0 are multiplexed in same pins and so either one interface only can be used at a
time. By default, USB3.0 is supported.
5 In RZ/G1H CPU, PCIe and SATA1 are multiplexed in same pins and so either one interface only can be used at a time.
By default, PCIe is supported.
6In RZ/G1H SOM, RZ/G1H CPU’s DU_LVDS1 output can be connected to either HDMI transmitter or Secondary LVDS
port of Qseven Edge. By default, it is connected to Secondary LVDS port of Qseven Edge.
7In RZ/G1H CPU, VIN0 2nd 8bit and VIN3 are multiplexed in same pins and so VIN3 cannot be supported when VIN0 is
supported in 16bit mode. If VIN0 is supported in 8bit mode, then VIN3 also can be supported in 8bit mode.
8 In RZ/G1H CPU, VIN1 2nd 8bit and VIN2 are multiplexed in same pins and so VIN2 cannot be supported when VIN1 is
supported in 16bit mode. If VIN1 is supported in 8bit mode, then VIN2 also can be supported in 8bit mode.

REL1.1
Page 15 of 92
RZ/G1H Qseven SOM Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.3 RZ/G1H CPU
