E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
TABLE OF CONTENTS
1. INTRODUCTION.......................................................................................................................4
1.1. LC Display.............................................................................................................................................. 4
2. DEVICE DESCRIPTION.............................................................................................................6
2.1. Type E-ITN 30.2 EX (EXNR) with remote sensor...................................................................................6
2.2. Type E-ITN 30.4 EX (EXNR) with remote sensor...................................................................................6
2.3. Type E-ITN 30.6 EX (EXNR) with remote sensor..................................................................................6
3. TECHNICAL SPECIFICATIONS....................................................................................................7
3.1. Technical specifications of E-ITN 30.2 EX (EXNR) and E-ITN 30.4 EX (EXNR) with remote sensor.....7
3.2. Technical specifications of E-ITN 30.6 EX (EXNR) with remote sensor...............................................10
3.3. Design.................................................................................................................................................. 12
4. OPERATION MODES..............................................................................................................13
4.1. Operation modes.................................................................................................................................. 13
4.2. Navigation in the sub menu..................................................................................................................13
4.3. Sleeping mode.....................................................................................................................................13
4.3.1. Sub menu structure in sleeping mode...........................................................................................13
4.3.1.1. Allocator self test................................................................................................................ 14
4.4. Mode of waiting for start date...............................................................................................................15
4.4.1. Sub menu structure in mode of waiting for start date....................................................................15
4.5. Working mode...................................................................................................................................... 16
4.5.1. Menu structure in working mode................................................................................................... 16
4.5.1.1. Value for current billing period ........................................................................................... 19
4.5.1. . Value for the last billing period............................................................................................19
4.5.1.3. Alphanumeric code (fE-ITN 30. , 30.4 EX (EXNR) with remote sensor only).....................19
4.5.1.4. Value for the current billing month - only E-ITN 30.6 EX (EXNR) with remote sensor........19
4.5.1.5. Value for the last billing month - only E-ITN 30.6 EX (EXNR) with remote sensor.............19
4.5.1.6. Serial number..................................................................................................................... 19
4.5.1.7. Temperature of the radiator sensor ................................................................................... 0
4.5.1.8. Temperature of the surroundings sensor............................................................................ 0
4.5.1.9. Date of the billing period beginning.................................................................................... 0
4.5.1.10. Current date..................................................................................................................... 0
4.5.1.11. Current time...................................................................................................................... 0
4.5. . Last year of battery life.................................................................................................................. 0
4.6. Error mode........................................................................................................................................... 20
5. OTHER INFORMATION............................................................................................................21
5.1. Electronic seal reactivation...................................................................................................................21
5.2. Allocator parameters setting.................................................................................................................21
5. .1. List of adjustable parameters of E-ITN 30. EX (EXNR) with remote sensor
and E-ITN 30.4 EX (EXNR) with remote sensor ..................................................................................... 1
5. . . List of adjustable parameters of E-ITN 30.6 EX (EXNR) with remote sensor................................
5.3. Transportation...................................................................................................................................... 23
5.4. Storage................................................................................................................................................. 23
5.5. Application and disposal....................................................................................................................... 23
5.6. Defects and their elimination................................................................................................................23
5.7. Warranty............................................................................................................................................... 23
6. ACCOMPANYING DOCUMENTATION..........................................................................................24
6.1. Ordering............................................................................................................................................... 24
6.2. Packing................................................................................................................................................ 24
7. INSTALLATION METHODS.......................................................................................................27
7.1. Allocator installation.............................................................................................................................. 27
7.2. Sensor back plate................................................................................................................................. 27
7.3. List of installation material....................................................................................................................28
7.4. E-ITN 30 mounting place on segmented and panel radiators..............................................................29
2 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
7.4.1. Vertical position: ...................................................................................................................... 9
7.4. . Horizontal position:........................................................................................................................ 9
7.5. Installation on segmented radiators......................................................................................................30
7.5.1. Description of installation............................................................................................................... 30
7.5. . Installation differences................................................................................................................... 30
7.6. Installation on panel radiators..............................................................................................................32
7.6.1. Description of installation .............................................................................................................. 3
7.7. Model No. 1 – Cast iron radiators.........................................................................................................34
7.8. Model No. 2 – Cast iron radiators with flat vertical front panel.............................................................35
7.9. Model No. 6 – Panel radiators with shaped front side..........................................................................36
7.10. Model No. 7 – Panel radiators with a flat front panel..........................................................................37
7.11. Model No. 8 – Aluminium radiator with vertical ribs...........................................................................38
7.12. Model No. 13 – Radiator JAGA TEMPO.............................................................................................39
3 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
1. INTRODUCTION
E-ITN 30. EX (EXNR) serves for a ratio based allocation of heat cost in buildings with central heating. It
uses a the two-sensor measuring principle – integrates temperature difference between the radiator
temperature and the surrounding temperature. Using this principle, allocator ensures measurement of
consumption value only when the radiator really emits heat (i.e. it does not measure in the summer). The
heat co t allocator with the remote en or i by default equipped with a radio module (type E-ITN
30.xx EX), on reque t without the radio module (type E-ITN 30.xx EXNR).
E-ITN 30 is intended to be installed in one-tube horizontal/vertical and two-tube heating systems with the
lowest mean design heating medium temperature tmin ≥ 35 °C and highest mean design heating medium
temperature tma ≤ 105 °C.
Each radiator in billing unit with common invoicing heat meter must be equipped with a heat cost allocator of
the same type. Technical conditions of heating system must be fulfilled when using heat cost allocators E-
-ITN 30. EX (EXNR).
E-ITN 30. EX (EXNR) must not be used in heating systems where the temperature parameters are below
or above the temperature limits of the heat cost allocator and in such heating systems, where the evaluation
factor KQ can not be unambiguously determined. It usually concerns floor heating systems, ceiling radiant
heating, flap controlled radiators, radiators with fan, systems with steam heating medium and air heaters.
picture1: E-ITN 30.xx EX (EXNR) with remote sensor
1.1. LC DISPLAY
Basic allocator status and measured values can be displayed on LCD. LCD can display five alphanumeric
characters. These values are highlighted by underline and overline, e.g. oPEn.
Meaning of some values may be different if the additional symbol „SM“ at the right bottom corner is
displayed. These values are mentioned with „SM“ symbol in te t , e.g. 385 SM.
The last symbol on the display indicates end of the battery life, see chapter 4.5.5. Last year of battery life.
4 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
To save the battery, after longer period of inactivity (appro . 1 min.), energy-saving mode is activated and
display is switched off. Display can be activated by pushing the button. (picture1: E-ITN 30. EX (EXNR)
with remote sensor).
When pushing the button briefly, notice ----- on the display will appear. If the button is not pushed in 1 minute,
the display will switch off.
The data displayed on the LCD display may vary depending on the type of the allocator and also on the
active operating mode. For more information, see below.
5 / 39
picture :LC Display

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
2. DEVICE DESCRIPTION
Installation of allocator consists of placing the e ternal sensor on the alluminium alloy base plate (mounted to
radiator) and placing of allocator to a wall mountable plastic base plate. Due to integrated radio transmitter,
presence of flat occupant is not required when data are read. Data reading can be made by billing company
employee using mobile receiving unit RFU 35 from outside of the house.
Measured data are transmitted in a short ~ 5,9 ms radio telegrams and secured by encryption. Data are
transmitted in shorter intervals in the „reading period“, for the rest of the year data are transmitted in longer
intervals. Time interval between transmissions is not constant – is changed randomly in time frame. So the
situation when it would be impossible to read data (in reasonable time) from allocators transmitting in the
same time is prevented.
Both the allocator and the remote sensor are equipped with a mechanic and an electronic seal. The allocator
is delivered in sealed state with both electronic seals activated.
If either electronic seal is violated the allocator saves the date of breach of the electronic seal to its memory
and stops to show measured data on the display. Only the notice oPEn is displayed and indicates breach of
one or both electronic seals
The allocator continues in measuring and transmitting of measured data. Information about breach of the
electronic seal is available in data transmitted by radio module and in data transferred via IR interface.
The notice oPEn will disappear when electronic seal is activated again with reading unit IRU 10.00 via infra-
red interface.
The device is resistant to cheating. If any cheating is detected, allocator switches to the single sensor mode
inconvenient for the user – after cheating is finished, the allocator switches to standard mode.
2.1. TYPE E-ITN 30.2 EX (EXNR) WITH REMOTE SENSOR
Allocator is equipped with unified scale. No parameters (e.g. parameters related to radiator type, nominal
output or coefficient KC) are set before installation on the radiator. Billing period is year.
2.2. TYPE E-ITN 30.4 EX (EXNR) WITH REMOTE SENSOR
Allocator with remote sensor is equipped with unified scale. No parameters (e.g. parameters related to
radiator type, nominal output or coefficient KC) are set before installation on the radiator. Billing period is
month.
2.3. TYPE E-ITN 30.6 EX (EXNR) WITH REMOTE SENSOR
Allocator is equipped with individual scale. For proper evaluation of measured data, it is advisable to set:
•radiator type (Tot)
•radiator nominal output (M)
•evaluation coefficient (KC) describing heat transfer between radiator and the base plate of the
allocator
Parameter can be set by manufacturer or before installation with Programming unit for changing allocator
parameters of E-ITN 0.x, 30.x connected to PC. Radiator type (Tot) can be set in sleeping mode by
pressing the button. Billing period is both year and month.
6 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
3. TECHNICAL SPECIFICATIONS
3.1. TECHNICAL SPECIFICATIONS OF E-ITN 30.2 EX (EXNR) AND E-ITN 30.4 EX (EXNR) WITH
REMOTE SENSOR
Application tmin ≥ 35 °C
tma ≤ 105 °C
Measuring principle two-sensor measuring principle
Conditions for registration temperature of the sensor of the radiator temperature ≥ 23 °C
difference of mean temperature of heating medium and surroundings
temperature ≥ 4 °C
Billing period year E-ITN 30.2 EX (EXNR) with remote sensor
month E-ITN 30.4 EX (EXNR) with remote sensor
Resulting rating factor K unified scale, K = 1
Calendar functions E-ITN 30.2 EX (EXNR)
•consumption for current and last billing year
•consumption for current and last 11 months
•ma . radiator sensor temperatures for current and last 11
months
•min. radiator sensor temperatures for current and last 11
months
•number of billing days for current and last 11 months (1)
E-ITN 30.4 EX (EXNR)
•consumption for current and last 11 billing months (2)
•consumption for last billing year
•ma . radiator sensor temperatures for current and last 5
months
•min. radiator sensor temperatures for current and last 5
months
•average radiator temperatures for current and last 5 billing
months
•number of heating days for current and last 5 billing months (1)
Display 5 digits LCD + 2 special symbols
Protection against cheating continuous control, if thermal influence is detected, allocator is
switched to single-sensor mode
mechanical seals with billing company label
electronic seal – records manipulation date when uninstalled
electronic seal of the remote sensor – records manipulation date
when uninstalled
Data backup daily backup of measured values including real time
Function control automatic, can be activated and controlled by user
Dimensions Allocator 100 37 40 mm, sensor 21 37 45 mm
7 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
Power supply lithium battery 3,0 V
Material ABS + PC / Al – F22
IP code IP 42
Conformity EN 834
Operating frequency 868 MHz
Transmitting power < 5 mW
Class of working cycle 1 (duty cycle percentage <0,1 %)
Transmission length ~ 6 ms
Length of the cable to the remote
sensor
1.5 m, 2 m, 2,5 m (standard) and 3 m
Radio data transmission intervals E-ITN 30.2 EX (EXNR) with remote sensor
•30 [s] seconds first month after the billing period beginning
•240 [s] seconds rest of the year
E-ITN 30.4
•30 [s] seconds first 3 days after the billing period beginning
during all months e cept July and August
•240 [s] seconds rest of the year
Transmission range up to 250 m (outside the building, with additional panel antenna)
Rem.: all metal parts of construction (switch rooms, armouring, lifts,
etc.) can negatively affect the range of radio signal.
Data coding yes
Data available via radio interface
(for e act data structure see
manual for decoding software)
E-ITN 30.2 EX (EXNR) with remote sensor, E-ITN 30.4 EX (EXNR)
with remote sensor
•reading date
•serial number
•value for the last billing period
•alphanumeric code for the last billing period and its validity
•current value
•electronic seal status
•indication of the remote sensor
•billing period start date
Data available via IR interface (for
e act data structure see manual
for decoding software)
E-ITN 30.2 EX (EXNR) with remote sensor
•reading date
•serial number
•date of yearly billing period beginning
•value for the last billing period
•alphanumeric code for the last billing period and its validity
•consumption for current and last 11 months
•current consumption
•ma . radiator temperature in last 11 months
•min. radiator temperature in last 11 months
•average radiator temperature for current and last 11 months
8 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
•number of heating days for current and last 11 months (1)
•indication of the remote radiator sensor
•dates of violation of electronic seals
E-ITN 30.4 EX (EXNR) with remote sensor
•reading date
•serial number
•date of billing period beginning
•consumption for the current and the last 11 billing periods
•alphanumeric code for the last billing period and its validity
•alphanumeric for the penultimate and 3 previous monthly
billing periods
•consumption for the last billing year
•ma . radiator temperatures for current and last 5 billing
months
•min. radiator temperatures for current and last 5 billing
months
•average radiator temperature for current and last 5 billing
months
•number of heating days for current and last 5 billing months
•indication of the remote radiator sensor
•dates of electronic seals breakage
NOTE:
(1) ... a heating day is indicated if the consumption increment for that day is > 0.
9 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
3.2. TECHNICAL SPECIFICATIONS OF E-ITN 30.6 EX (EXNR) WITH REMOTE SENSOR
Communication protocol W-MBUS according to EN 13757-4
Mode T1
Application tmin ≥ 35 °C
tma ≤ 105 °C
Measuring principle two-sensor measuring principle
Conditions for registration temperature of the sensor of the radiator temperature ≥ 23 °C
difference of mean temperature of heating medium and surroundings
temperature ≥ 4 °C
Billing period Both yearly and monthly
Resulting rating factor K individual scale
Calendar functions •consumption value for the current and last two billing periods
•monthly consumption values for the current and last 11 biling
moths
•consumption values for previous billing months since the
beginnning of the billing year
•ma imum monthly radiator temperatures (current and 11
previous months)
•minimum monthly radiator temperatures (current and 11
previous months)
•average monthly radiator temperatures (current and 11
previous months)
•number of heating days for the current and last 11 billing
months (1)
•average surrounding temperatures (current and 3 previous
months)
Display 5 digits LCD + 2 special symbols
Protection against cheating •continuous control, if thermal influence is detected, allocator
is switched to single-sensor mode
•mechanical seals with billing company label
•electronic seal – records manipulation date when uninstalled
•electronic seal of the remote sensor – records manipulation
date when uninstalled
Data backup daily backup of measured values including real time
Function control automatic, can be activated and controlled by user
Dimensions Allocator 100 37 40 mm, sensor 21 37 45 mm
Power supply lithium battery 3,0 V
Material ABS + PC / Al – F
IP code IP 42
Conformity EN 834
10 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
Operating frequency 868,95 MHz
Transmitting power < 5 mW
Class of working cycle 1 (duty cycle percentage <0,1 %)
Transmission length ~ 4,5 ms (basic data format without encrytion)
~ 4,8 ms (basic data format with AES 128 encrytion)
~ 6,2 ms (e tended data format without encrytion)
~ 6,7 ms (e tended data format with AES 128 encrytion)
Length of the cable to the remote
sensor
1.5 m, 2 m, 2.5 m (standard) and 3 m
Transmission intervals Ba ic data format
~ 44 [s] for 30 days from the beginning of a billing year
~ 44 [s] for 6 days from the beginning of a billing month
~ 720 [s] in summer heating period (at least 3 months)
~ 250 [s] on other days of year without data encryption
~ 412 [s] on other days of year with data encryption
Extended data format
~ 44 [s] for 30 days from the beginning of a billing year
~ 44 [s] for 3 days from the beginning of a billing month
~ 720 [s] in summer heating period (at least 3 months)
~ 318 [s] on other days of year (without data encryption)
~ 480 [s] on other days of year (with data encryption)
Transmission range up to 250 m (outside the building, with additional panel antenna)
Note: all metal parts of construction (switch rooms, armouring, lifts,
etc.) can negatively affect the range of radio signal.
Data coding optional AES-128, (the size of a block of encrypted data is 16 Bytes,
the size of the key is 16 Bytes)
Data available via radio interface Ba ic data format:
•reading date
•serial number
•remote sensor present
•value for the current yearly billing period
•value for the last yearly billing period
•value for the current monthly billing period
•value for the last monthly billing period
•date of violating the electronic seal
•average surrounding temperature for the last billing period
Extended data format:
•reading date
•date of the beginning of the billing period
•serial number
•remote sensor
•value for the current yearly billing period
11 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
•value for the last yearly billing period
•value for the current billing month
•value for the last billing month
•date of violating the electronic seal (2)
•values for the current and last 8 billing months
•overall evaluation factor K = Kc . Kq
Data available via infra-red
interface (for e act data structure
see manual for the decoding
software)
•serial number
•date of billing period beginning
•remote sensor
•reading date
•values for the current and last two billing years
•values for the current and last 11 billing months
•ma . radiator temperatures for the current and last 11 billing
months
•min. radiator temperatures for the current and last 11 billing
months
•average radiator temperatures for the current and last 11
billing months
•number of heating days for the current and last 11 billing
months (1)
•dates of the allocator electronic seal violation
•dates of the remote sensor electronic seal violation
•average ambient temperature for the current and last 3
months
•radiator type TOT
•evaluation factor Kq for radiator output
•evaluation factor Kc for the thermal contact of the sensors
•transmision format
NOTE:
(2) ... if both electronic seals (allocator and remote sensor) have been violated, the earlier date is indicated
3.3. DESIGN
Electronic heat cost allocator E-ITN 30. EX (EXNR) with remote sensor complies with EN 834:1995.
The allocator consists of a housing and a printed circuit board covered with a mounting plate. The mounting
plate is bolted with housing and secured with latch and seal.
Housing, mounting plate, latch and seal are made from plastic material. There are marked values of the
lowest and highest heating medium temperature, manufacturer's mark, type of the allocator, serial number
(both as number and bar code) and optionally the partner's logo on the housing. The base plate is made of
aluminium alloy to ensure of a good thermal contact with the radiator.
The sensor consists of a housing, a printed circuit board, a mounting plated, a seal and a fastening screw.
The base plate is made of aluminium alloy and it cares for the thermal contact to the radiator.
To install the heat cost allocator, use suitable mounting material to mount the alluminium base plate to the
radiator click the sensor to the base plate and fasten it with a M3 12 screw. Now the heat cost allocator can
only be uninstall after breaking the seal.
The device has an electrical circuitry with a 16-Bit microprocessor with e tremely low current consumption, is
equipped with radio transmitter and powered by lithium battery. The accuracy of the measuring circuit is
independent of the battery voltage. The LCD-display has 5 large main digits separated by dots and special
symbols.
12 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
4. OPERATION MODES
4.1. OPERATION MODES
The allocator can be in four operation modes:
•sleeping mode
•mode of waiting for start date
•working mode
•error mode
4.2. NAVIGATION IN THE SUB MENU
The allocator with remote sensor contains simple sub menus (depending on current operation mode), that
allow to obtain additional information or perform other activities.
To switch between individual items of menu, push the button briefly. To enter the sub menu, choose relevant
item and hold the button (appro imately 2 seconds) until --A-- appears on LCD. When you release the
button, designation of the 1st sub menu item appears. Move in menu by short presses of the button. If the
button is not pushed for 20 seconds, the LCD returns to the main menu.
Activation process of item is the same as entering the sub menu. Find the relevant item and hold the button
(for appro imately two seconds), till notice --A -- on the LCD appears.
Movement between items follows the same pattern – briefly press the button. Selected option confirmation
as well – by long (appro . 4 s) press of the button, till notice --A-- appears on LCD.
4.3. SLEEPING MODE
Allocator consumption is reduced to a minimum since no measuring and no calculations are carried out and
furthermore allocator does not transmit the data. Sleeping mode is suitable for prolonged storage prior to
allocator use. The storage period should not e ceed one year.
In sleeping mode allocator allows the following operations:
•activation of working mode
•allocator self test
•temperature sensors accuracy test
•E-ITN 30.6 EX (EXNR) only: setting the radiator type
•E-ITN 30.6 EX (EXNR) only: displaying of parameters (radiator type, radiator output factor KQ,
thermal contact factor KC)
Sleeping mode is indicated with notice uPr on the display. If the display does not show any value or notice
(due power saving), press the button briefly to switch LCD on.
4.3.1. Sub menu structure in sleeping mode
↓
The down arrow represents a short button press, after which ---- appears and then the ne t sub menu item.
The horizontal arrow represents a long button press: Hold the button for appro . 4 seconds, first ---- appears
and then --A - -.
13 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
Sub menu in leeping mode for E-ITN 30.2, 30.4 EX (EXNR) with remote en or
Sub menu in leeping mode for E-ITN 30.6 EX (EXNR) with remote en or
4.3.1.1. Allocator self test
Allocator self test is used to check all LCD segments and to test A/D converter for temperature
measurement. We can run the test in sleeping mode, working mode and also in mode of waiting for start
date. Option is located in sub menu whose activation was described above.
To start the test:
1. Switch to sub menu item marked as ti (allocator test) with brief press of the button.
2. While ti is displayed, press and hold the button, till notice --A - - appears.
3. Allocator self test has three phases. 1st phase: all segments are turned on . 2nd phase:
radiator temperature is displayed, e.g. 36.4°C and in 3rd phase surrounding temperature appears.
e.g. 25.4°C SM. Every value is displayed for 2 seconds and LCD is automatically switched into the
main menu when self test is completed.
14 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
If A/D converter malfunction is detected, allocator switches to fault mode and notice Error is displayed on
LCD.
4.4. MODE OF WAITING FOR START DATE
This mode is suitable when you require to start multiple allocators on the same date. In this mode, the
allocator regularly updates real time and compares current date with start date. When the start date is
reached, the allocator will start measuring (switch to working mode).
Mode of waiting for start date is indicated with notice: e.g. o 1.12. (date indicates the date of start). If the
display does not show any indication (because of power saving), press the button briefly to switch it on.
In mode of waiting for start date, following actions can be performed:
•allocator self test
•E-ITN 30.6 EX (EXNR) only: displaying of parameters (radiator type, radiator output factor KQ,
thermal contact factor KC)
4.4.1. Sub menu structure in mode of waiting for start date
↓
The down arrow represents a short button press, after which ---- appears and then the ne t sub menu item.
The horizontal arrow represents a long button press: Hold the button for appro . 2 seconds, first ---- appears
and then --A - -.
Sub menu in the mode of waiting for tart date for E-ITN 30.2 EX (EXNR) with remote en or and
E-ITN 30.4 EX (EXNR) with remote en or
Sub menu in the mode of waiting for tart date for E-ITN 30.6 EX (EXNR) with remote en or
15 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
4.5. WORKING MODE
In working mode, allocator performs temperature measurement, calculates the increase of consumption
value (if measurement conditions are met), transmits measured data, updates real-time and makes some
other actions in regular intervals.
4.5.1. Menu structure in working mode
↓
The down arrow represents a short button press, after which ---- appears and then the ne t sub menu item.
The horizontal arrow represents a long button press: Hold the button for appro . 2 seconds, first ---- appears
and then --A - -.
Sub menu in working mode for E-ITN 30.2 EX (EXNR) with remote en or
16 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
Sub menu monthly value E-ITN 30.2 EX (EXNR)
Sub menu in working mode for E-ITN 30.4 EX (EXNR) with remote en or
17 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
Sub menu monthly value E-ITN 30.4 EX (EXNR)
Sub menu in working mode for E-ITN 30.6 EX (EXNR) with remote en or
18 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
Sub menu monthly value E-ITN 30.6 EX (EXNR)
4.5.1.1. Value for current billing period
Value for current billing period is displayed as 389 (without insignificant zeros). It is calculated from the
beginning of the current billing period.
4.5.1. . Value for the last billing period
Value for the last billing period is displayed as 3258 SM. Transfer of measured value for actual billing period
to value for the last billing period is performed, when new billing period is achieved in 00:00:00.
4.5.1.3. Alphanumeric code ( fE-ITN 30. , 30.4 EX (EXNR) with remote sensor only)
The five digit alphanumeric code consists of the following numbers and letters: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, b,
c, d, E, F, h, i, J, L, n, o, P, r, t, u.
On LCD it is displayed e.g. A.0.i.h.t. Alphanumerical code is created when transfer of measured value for
actual billing period to measured value for last billing period is performed. If transfer of measured value was
never done before, . .-.-. . appears on the display (alphanumeric code value is not available).
4.5.1.4. Value for the current billing month - only E-ITN 30.6 EX (EXNR) with remote sensor
Value for current billing month is displayed as ..4.6.9. (without insignificant zeros). It is calculated from the
beginning of the current billing month.
4.5.1.5. Value for the last billing month - only E-ITN 30.6 EX (EXNR) with remote sensor
Value for the last billing month is displayed as ..8.5.1.SM. Transfer of measured value for current billing
month to value for the last billing month is performed, when new billing month is achieved in 00:00:00.
4.5.1.6. Serial number
Serial number is 8 digit figure and it is also labelled on the housing. Serial number is divided in two parts.
E.g. serial number „32000015” is displayed as figure -3200 and 0015-. Symbol „ - “ distinguish between first
and second part of the serial number.
19 / 39

E-ITN 30.xx EX (EXNR) with remote
Installation, servicing and operatiion manual M2016/08b [EN]
4.5.1.7. Temperature of the radiator sensor
Temperature of the radiator sensor is displayed as 45.9°C with accuracy of one decimal place.
4.5.1.8. Temperature of the surroundings sensor
Temperature of the surroundings sensor is displayed as 26.7°C SM with accuracy of one decimal place.
4.5.1.9. Date of the billing period beginning
E-ITN 30.2 EX (EXNR)
The beginning of the billing year is displayed as u 1.2.. After the date is reached, the current consumption
value becomes the last consumption value, an alphanumeric code is generated at 00:00:00h. The value for
current billing period is set to 0. The beginning of the billing year can be set to any date e cept 29.2.
E-ITN 30.4 EX (EXNR)
The beginning of the billing month is displayed as dF 15 . . After the date is reached, the current consumption
value becomes the last consumption value, an alphanumeric code is generated at 00:00:00h. The value for
current billing period is set to 0. The beginning of the billing year can be any date within the interval from
<1;28>.
E-ITN 30.6 EX (EXNR)
The beginning of the billing period is displayed as u 1.2. (yearly billing) or dF 15 (monthly billing). After the
date is reached, the current consumption value becomes the last consumption value, an alphanumeric code
is generated at 00:00:00h. The value for current billing period is set to 0. The beginning of the billing month
can be set to any date e cept 29.2
The start of the billing period can be set by the manufacturer or by means of the Programming device
connected to a computer.
4.5.1.10. Current date
Current date is displayed as 3.12.. Calendar takes leap years into account.
4.5.1.11. Current time
Current time is displayed in 24 cycle, e.g. 8-56 (8:56 AM). Summer time is not distinguished.
4.5.2. Last year of battery life
Battery lifetime is programmed in the microprocessor memory and the last year of battery lifetime is indicated
on LCD by blinking of the special symbol: BAT. After finishing this time the symbol stays displayed
permanently. Calculated battery lifetime is 10 years + 1 year reserve.
4.6. ERROR MODE
In error mode the notice Error is permanently displayed and allocator does neither measure temperatures,
count the increase of consumption nor transmit measured data. Allocator just updates the real time. Allocator
switches from working mode to error mode automatically after registration of serious error (e.g. fault in A/D
converter, when the power supply of microprocessor was interrupted and loss of data in RAM memory
occurred, etc.).
Allocator backups important data to permanent memory daily. Data in this memory are saved even if the
power supply is interrupted. Even in the case of battery failure these data are not lost. Saved data could be
read by special tools.
20 / 39
Other manuals for E-ITN 30 EX Series
1
This manual suits for next models
1
Table of contents
Other Apator Metra Measuring Instrument manuals
