Apera Instruments LabSen 753 User manual

LabSen 753 Stainless Steel Sheath Spear pH Electrode
User Manual
LabSen electrochemical sensors are premium pH electrode with manufacturing technology and key
components imported from Switzerland. LabSen753 spear pH electrode adopts spear membrane,
which can easily pierce into solid or semi-solid medium. This probe is suitable for pH measuring of
cheese, flour products, meat and fruits.
This probe has following features:
Adopts food grade stainless steel sheath, offers strong protection, comply with food hygiene
requirements, suitable for food pH testing.
Blue gel inner solution, does not flow and will not cause bubble.
Maintenance-free polymer electrolyte, non-diaphragm structure.
Long life reference system, has better stability and service life.
1 Technical Data
Measuring Range
(0 ~ 14) pH
Electrolyte
Polymer
Temperature Range
(0 ~ 80)°C
Soaking Solution
3M KCl
Shaft Material
Stainless Steel
Electrode
Dimension
Electrode (Ø12×115) mm
Measuring Tip (Ø6×50) mm
Membrane Shape
Tapered
Reference
Long Life
Connector
BNC/RCA
Junction
Ceramic+Single Pore
Cable
Ø5×1m
2 Usage and Maintenance
2.1 Connect BNC & RCA plug to the input on the pH meter.
2.2 When measuring, please unscrew the bottle cap, pull out the electrode and rinse it with
deionized water. After using, please put the electrode back into the bottle and screw tight the
cap.
2.3 The electrode must be soaked in 3M KCl solution for storage. Because after long time
exposure in air, Polymer electrolyte will cause shrinkage.
2.4 The electrode’s measuring tip should be soaked in the soaking bottle containing certain
amount of 3M KCl soaking solution to keep the membrane hydrated and junction unblocked.
Before pulling out or putting back the electrode,
make sure to fully loosen the blue cap on the
storage sleeve so that the electrode can move in
and out smoothly.

Clean the bottle and replace the storage solution if the storage solution gets turbid and
mildewed. The electrode should never be sinked in pure water or buffer solution for long.
2.5 The connector of the electrode should keep clean and dry. If being contaminated, please clean
it with medical cotton and absolute alcohol and blow dry to prevent the short circuit of the
electrode and slow reaction of electrode.
2.6 Spear pH Electrode is suitable for measure wet solid or semi-solid medium. Please forcibly
even when piercing, to prevent damage of the electrode. In case the sample medium is too
hard (such as meat and fruit); please cut a small hole before piercing the electrode into it.
2.7 After 1-year of use, we recommend replacing the electrode to ensure the best accuracy.
3 Warranty
We warrant this electrode free from defects in material and workmanship and agrees to repair or
replace free of charge, at option of APERA INSTRUMENTS any malfunctioned or damaged product
attributable to responsibility of APERA INSTRUMENTS for a period of six months. Warranty period
is the time limit to provide free service for the products purchased by customers, not the service life
of the tester or electrodes.
This limited warranty does not cover any damages due to:
transportation; storage; improper use; failure to follow the product instructions or to perform any
preventive maintenance; modifications; combination or use with any products, materials, processes,
systems or other matter not provided or authorized in writing by us; unauthorized repair; normal wear
and tear; or external causes such as accidents, abuse, or other actions or events beyond our
reasonable control.
APERA INSTRUMENTS (Europe) GmbH
Address: Wilhelm-Muthmann-Str.15,
42329 Wuppertal, Germany
Phone: [phone]
Website: www.aperainst.de
Email: [e-mail]
