LabSen 801 Pure Water Combination pH Electrode
User Manual
LabSen electrochemical sensors are premium pH electrode with manufacturing technology and key
components imported from Switzerland. LabSen801 pH electrode is suitable for pure water
measurement, such as drinking water, distilled water etc.
This probe has following features:
⚫ Impact-resist membrane (see the right picture), there is no danger of
electrode breakage during normal use.
⚫ Movable sleeve, able to adjust infiltration rate of electrolyte.
⚫ Blue gel inner solution, does not flow and will not cause bubble.
⚫ Silver ion trap reference prevents the contamination of the junction when
testing sample contains sulfides and proteins, which helps to improve the
stability and service life of the electrode.
1 Technical Data
Measuring Range
(0 ~ 11) pH
Electrolyte
3M KCl
Temperature Range
(0 ~ 80) °C
Soaking Solution
3M KCl
Shaft Material
Lead-free Glass
Membrane Resistance
<50MΩ
Membrane Type
L
Electrode Dimension
(Ø12×130) mm
Reference
Silver Ion Trap
Connector
BNC
Junction
Movable Sleeve
Cable
Ø3×1m
2 How to Use the Movable Sleeve
As shown on the right picture, reference solution flows out of the small hole,
seeps through the tapered surface of movable sleeve. You may adjust the
degree of firmness when use, push up the movable sleeve to loose. If it is
too tight to push, please referring to the right picture: insert the probe into
the round tube (the accessory comes with the probe), and push down the
probe, then the movable sleeve will be loosen. Please pay attention to
remove the rubber plug when adjusting the movable sleeve, enables
reference solution flowing out of the small hole; then slowly rotate and
tighten the movable sleeve, so that there will be no air remain in the tapered
surface of movable sleeve, which can greatly influence the correct
measurement of the probe.
3 Usage and Maintenance
3.1 When measuring, please unscrew the bottle cap, pull out the electrode and
rinse it with deionized water. After using, please put the electrode back into the
bottle and screw tight the cap.
Before pulling out or putting back the electrode, make sure
to fully loosen the blue cap on the storage sleeve so that
the electrode can move in and out smoothly.

3.2 Prior to measurement, remove the rubber plug to maintain pressure of the reference solution,
keep consistent flow rate of reference solution and stable potentials of junction.
3.3 After a period of usage, the reference solution will be running low. Whenever the level falls to
1/2 height of the electrode, add 3M KCL solution to the refilling hole by using syringe or pipette.
3.4 Reference solution refilling in cases of contamination; pull out plastic plug, loosen movable
sleeve, Electrolyte will drops out quickly. After cleaned with 3M KCL solution, tighten glass
sleeve (see section 3), refill 3M KCL solution after washing cavity with pure water and 3M KCL.
Then loosen movable sleeve and slowly twist it tighten, to avoid air remain in the tapered surface
of movable sleeve.
3.5 Drop speed of reference solution decides by the glass sleeve tightness, the tighter the slower.
Electrodes must recalibrate upon tightness adjusted. For viscous or low ion concentration
solution measuring, requires fast speed.
3.6 The connector of the electrode should keep clean and dry. If being contaminated, please clean
it with medical cotton and absolute alcohol and blow dry to prevent the short circuit of the
electrode and slow reaction of electrode.
3.7 The electrode’s measuring tip should be soaked in the soaking bottle containing certain amount
of storage solution to keep the membrane hydrated and junction unblocked. Clean the bottle
and replace the storage solution if the storage solution gets turbid and mildewed. The electrode
should never be sinked in pure water or buffer solution for long.
3.8 After 1-year of use, we recommend replacing the electrode to ensure the best accuracy.
4 Warranty
We warrant this electrode free from defects in material and workmanship and agrees to repair or
replace free of charge, at option of APERA INSTRUMENTS any malfunctioned or damaged product
attributable to responsibility of APERA INSTRUMENTS for a period of six months. Warranty period
is the time limit to provide free service for the products purchased by customers, not the service life
of the tester or electrodes.
This limited warranty does not cover any damages due to:
transportation; storage; improper use; failure to follow the product instructions or to perform any
preventive maintenance; modifications; combination or use with any products, materials, processes,
systems or other matter not provided or authorized in writing by us; unauthorized repair; normal wear
and tear; or external causes such as accidents, abuse, or other actions or events beyond our
reasonable control.
