USER’S MANUAL
PRESSURE TRANSMITTERS
PCE-28, PCE-28.Smart, PCE-28 Ex Safety
PC-29A, PC-29B, PCE-28.Modbus
DIFFERENTIAL PRESSURE TRANSMITTERS
PRE-28, PRE-28.Smart, PRE-28 Ex Safety
PR-29A, PR-29B, PRE-28.Modbus
Flameproof (Exd) version
IO.PCE-28….PC-29.Exd
MARCH 2019
APLISENS S.A., 03-192 Warszawa, ul. Morelowa 7
tel. [phone]; fax [phone]
www.aplisens.pl, e-mail: ap[email protected]
04.A.004

Symbols used
Symbol
Description
Warning to proceed strictly in accordance with the information contained in the
documentation in order to ensure the safety and full functionality of the device
Information particularly useful during installation and operation of the device
Information particularly useful during installation and operation of Ex
versions
Information on disposal of used equipment
BASIC REQUIREMENTS AND SAFE USE
The manufacturer will not be liable for damage resulting from incorrect
installation, failure to maintain the device in a suitably functional condition, or
use of the device other than for its intended purpose.
Installation should be carried out by qualified personnel having the necessary
authorisation to install electrical and pressure measuring devices. The
installer is responsible for performing the installation in accordance with these
instructions and with the electromagnetic compatibility and safety regulations
and standards applicable to the type of installation.
In the installation with control and measurement instruments exists, in case of
leakage, a risk to personnel on the side where the medium is under pressure.
All safety and protection requirements must be observed during installation,
operation and inspections.
If a device is not functioning correctly, disconnect it and send it for repair to
the manufacturer or to a firm authorised by the manufacturer.
In order to minimise the risk of malfunction and associated risks to personnel, the
device is not to be installed or used in particularly hostile conditions, where the
following risks occur:
Possibility of mechanical impacts, excessive shocks and vibration;
Excessive temperature fluctuation;
Condensation of water vapour, dust, icing.
When using the device in potentially explosive areas, observe technical
requirements specified in this manual and applicable local (national) regulations.
Changes in the manufacture of transmitters can overtake the update's paper documentation.
Current manuals can be found on the manufacturer's website at www.aplisens.com

IO.PCE-28….PC-29.Exd
1
04.A.004
CONTENTS
1. INTRODUCTION.......................................................................................... 3
2. SAFETY PROCEDURES ............................................................................. 4
3. USER INFORMATION ................................................................................. 4
4. TRANSPORT AND STORAGE.................................................................... 4
4.1. Transport.....................................................................................................................4
4.2. Storage ....................................................................................................................... 4
5. WARRANTY ................................................................................................ 5
6. CONSTRUCTION ........................................................................................ 5
6.1. Intended use and functions .........................................................................................5
6.2. Construction and dimensions......................................................................................5
6.3. Identification ................................................................................................................8
7. USING OF PCE-28…PC-29 TRANSMITTERS IN HAZARDOUS AREAS... 9
7.1. Exd versions in accordance with ATEX.......................................................................9
7.2. Exd versions in accordance with IECEx......................................................................9
7.3. Electrostatic hazards................................................................................................. 10
8. INSTALLATION......................................................................................... 10
8.1. General recommendation..........................................................................................10
8.2. Installation in areas with dust explosion hazard ........................................................10
9. ELECTRICAL CONNECTIONS ................................................................. 11
9.1. How to connect different types of transmitters .......................................................... 11
9.2. How to connect transmitters in potentially explosive areas ....................................... 12
9.3. Grounding ................................................................................................................. 15
10. TECHNICAL DATA.................................................................................... 15
10.1. Electrical parameters ................................................................................................ 15
10.2. Metrological parameters............................................................................................15
10.3. Permitted environmental conditions ..........................................................................15
10.3.1. Electromagnetic compatibility, immunity............................................................. 15
10.3.2. Electromagnetic compatibility, emissions ...........................................................16
10.3.3. Mechanical immunity..........................................................................................16
10.3.4. Electrical Isolation .............................................................................................. 16
10.3.5. Insulation strength..............................................................................................16
10.3.6. IP protection ratings ........................................................................................... 16
11. INSPECTIONS. SPARE PARTS................................................................ 17
11.1. Periodic inspections .................................................................................................. 17
11.2. Unscheduled inspections ..........................................................................................17
12. SCRAPPING, DISPOSAL.......................................................................... 17
12.1. Additional information................................................................................................ 17

IO.PCE-28….PC-29.Exd
2
04.A.004
LIST OF FIGURES
Figure 1. Pressure transmitter PCE-28, PCE-28 Ex Safety, PCE-28.Smart, PC-29A, PC-
29B, PCE-28.Modbus. Dimensions........................................................................6
Figure 2. Pressure transmitter PRE-28, PRE-28 Ex Safety PRE-28.Smart, PR-29A, PR-
29B, PRE-28.Modbus. Dimensions.........................................................................6
Figure 3. Electrical connections of the transmitters PC(R)E-28, PC(R)E-28 Ex Safety,
PC(R)E-28.Smart, PC(R)-29A, PC(R)-29B, PC(R)E-28.Modbus ............................7
Figure 4. PC(R)E-28, PC(R)E-28.Smart, PC(R)-29A, PC(R)-29B, PC(R)E-28.Modbus
rating plate (example) .............................................................................................8
Figure 5. Transmitter installed in the hazard zones.................................................................9
Figure 6. Wiring diagram transmitters PCE-28, PRE-28, PCE-28 Ex Safety, PRE-28 Ex
Safety....................................................................................................................13
Figure 7. Wiring diagram transmitters PCE-28.Smart, PRE-28.Smart. .................................13
Figure 8. Wiring diagram transmitters PC-29A, PR-29A, PC-29B, PR-29B ..........................13
Figure 9. PCE-28.Modbus, PRE-28.Mobdus electrical connection .......................................14

IO.PCE-28….PC-29.Exd
3
04.A.004
1. INTRODUCTION
The subject of this manual are:
Pressure transmitters PCE-28;
Pressure transmitters PCE-28 Ex Safety;
Smart pressure transmitters PCE-28.Smart;
Pressure transmitters PC-28E.Modbus;
Pressure transmitters PC-29A, PC-29B;
Differential pressure transmitters PRE-28;
Differential pressure transmitters PRE-28 Ex Safety;
Smart differential pressure transmitters PRE-28.Smart;
Differential pressure transmitters PRE-28.Modbus
Differential pressure transmitters PR-29A, PR-29B
This manual contains data, information and recommendations concerning installation and
use of the transmitter, as well as troubleshooting procedures.
Transmitters are designed and manufactured in accordance with the other requirements
provided with the rating plate and Declarations of Conformity. Transmitters comply with EU
directives:
ATEX
ATEX directive, Exd version, certificate KDB 18 ATEX 0077X
Additional information about transmitters: PCE–28, PRE–28, PCE–28.Smart,
PRE–28.Smart, PCE–28.Modbus, PRE–28.Modbus, PCE-28 Ex Safety;
PRE-28 Ex Safety and PC–29A, PC–29B, PR–29A, PR–29B Exd versions
according to ATEX, see p. 7.1.
IECEx
IECEx system, Exd version,certificateIECEx KDB 18.0005X
Additional information about transmitters: PC–28, PR–28, PC–28.Smart,
PR–28.Smart, PC–28.Modbus, PR–28.Modbus, PC-28 Ex Safety; PR-28 Ex
Safety and PC–29A, PC–29B, PR–29A, PR–29B Exd versions according to IECEx,
see p. 7.2.
EMC
EMC directive.
Pressure and differential pressure transmitters: PC–28, PR–28, PC–28.Smart,
PR–28.Smart, PC–28.Modbus, PR–28.Modbus and PC–29A, PC–29B, PR–29A,
PR–29B in all versions comply with EMC directive according to:
PN-EN 61326-1:2013-06.
RoHS
RoHS directive.
Pressure and differential pressure transmitters: PC–28, PR–28, PC–28.Smart,
PR–28.Smart, PC–28.Modbus, PR–28.Modbus and PC–29A, PC–29B, PR–29A,
PR–29B in all versions comply with RoHS directive according to:
PN-EN 50581 :2013-03.

IO.PCE-28….PC-29.Exd
4
04.A.004
2. SAFETY PROCEDURES
The installation and commissioning of the transmitter and any activities related
to the operation should be performed only after careful examination of the
contents of this manual.
Installation and maintenance should be carried out by qualified personnel
having necessary authorisation to install electrical equipment and measuring
instruments.
The transmitter should be used according to its intended purpose (section 6.1)
with permissible parameters.
Before assembly or disassembly of the transmitter, one must absolutely
disconnect the power source.
Under no circumstances may the electrical system of the transmitter be
repaired or otherwise handled by the user. Damage assessments and repairs
may only be carried out by the manufacturer or its authorised dealer.
Do not use damaged device. If a device is not functioning correctly, disconnect
it.
When using the device in potentially explosive areas, observe technical
requirements specified in this manual and applicable local (national)
regulations.
3. USER INFORMATION
The user receives together with the transmitter:
a) Product Certificate, which is also a warranty card;
b) Declaration of Conformity;
c) Copy of the certificate (on request);
d) User Manual ref. No. IO.PCE-28…PC-29(ENG).
Items b), c) and d) are available on the website www.aplisens.com
4. TRANSPORT AND STORAGE
4.1. Transport
Transmitters should be transported in multi- or/and single-unit packaging. The packaging
should be protected against displacement and direct weathering effect.
4.2. Storage
The transmitter should be stored in the original packaging, indoor rooms, free of vapours
and corrosive substances, the temperature and relative humidity should not exceed the
permitted conditions (see individual transmitters data sheet).

IO.PCE-28….PC-29.Exd
5
04.A.004
5. WARRANTY
Manufacturer warrants to the conditions specified in the Product Certificate which is also
a guarantee card.
Warranty is in full force under the condition of using the devices properly along
with the purpose determined in the manual.
6. CONSTRUCTION
6.1. Intended use and functions
Pressure transmitters are designed to measure overpressure, vacuum pressure and
absolute pressure of gases, vapours and liquids (including corrosive).
Differential pressure transmitters are designed to measure the level in closed tanks
and to measure differential pressure at accumulating elements such as filters and
measuring orifices.
Differential pressure transmitters with P-type tubes may operate at static pressures of up
to 4 MPa.
Pressure and differential pressure transmitters may also be equipped with a number
of process connectors, which make it possible to use them with different media such as
dense or aggressive media and for low and high medium temperatures. Examples of
process connectors are listed in point 6.2.
6.2. Construction and dimensions
The main units of transmitters include: measuring head in which a pressure signal is
converted into an electric signal; electronic unit that converts the measuring head signal
into a unified transmission signal; housing and type SGM or FL Exd electrical connector.
Made of a ⌀27 pipe, the transmitter casing is inseparably connected to the measuring
head and electric connector.
Male thread in the electrical connection allows the transmitter to be screwed into an
element such as a flameproof housing, strengthened housing, etc.

IO.PCE-28….PC-29.Exd
6
04.A.004
Figure 1. Pressure transmitter PCE-28, PCE-28 Ex Safety, PCE-28.Smart, PC-29A, PC-29B,
PCE-28.Modbus. Dimensions
Figure 2. Pressure transmitter PRE-28, PRE-28 Ex Safety PRE-28.Smart, PR-29A, PR-29B,
PRE-28.Modbus. Dimensions

IO.PCE-28….PC-29.Exd
7
04.A.004
Transmitter can be equipped with:
“M” process connection, thread M20x1,5;
“P” process connection, thread M20x1,5 and 12 hole;
“CM30x2” process connection, thread M30x2 with flush diaphragm;
“G 1/2” process connection, thread G1/2’’ and 4 hole;
“GP” process connection, thread G1/2’’ with flush diaphragm;
“CG1” process connection, thread G1’’ with flush diaphragm;
“RM” process connection, thread M20x1,5 with 4 hole and radiator;
“RP” process connection, thread M20x1,5 with 12 hole and radiator;
“G 1/4” process connection, thread G1/4’’ male;
“1/2NPT” process connection, thread 1/2NPT male;
“R 1/2” process connection, thread R ½ and 4 hole;
“CG 1/2” process connection, thread G1/2’’ with flush diaphragm;
”9/16-18 UNF” process connection autoclave F-250 compatible;
”1/4NPTF” process connection, thread 1/4NPT female;
”1/2NPTF” process connection, thread 1/2NPT female;
Other on request.
Differential pressure transmitter measuring head can be equipped with :
P type with M20x1,5 thread process connection;
Diaphragm seals: see Diaphragm Seals Data Sheets;
Other on request.
SGM type electrical connection has hermetically sealed cable with poliurethane sheath
and is equipped with M20x1,5 or 1/2”NPT male thread.
FL type electrical connection has hermetically sealed wires with PVC insulation and
M20x1,5 or 1/2”NPT male thread.
Electrical connection designations:
FL (M20x1,5), FL (1/2”NPT) –2, 3 or 4 according to 9.1 0,5mm2PVC insulated loose wires
length: 180cm
SGM (M20x1,5), SGM (1/2”NPT) –PUR (polyurethane) cable length: 350cm
Figure 3. Electrical connections of the transmitters PC(R)E-28, PC(R)E-28 Ex Safety,
PC(R)E-28.Smart, PC(R)-29A, PC(R)-29B, PC(R)E-28.Modbus

IO.PCE-28….PC-29.Exd
8
04.A.004
6.3. Identification
Transmitters are provided with a rating plate containing:
1. Manufacturer name and/or logotype;
2. CE marking;
3. Number of notified body;
4. Product code;
5. Type of transmitter: „Pressure transmitter” or „Differential pressure transmitter”;
6. Transmitter type designation;
7a.Process connection designation;
7b.Electrical connection designation;
8. Measuring range;
9a.Permissible ambient temperature range;
9b.Permissible process temperature range;
10.Output signal;
11.Serial number;
12.Maximum static pressure (only for differential pressure transmitters);
13.Supply voltage;
14.Year of production;
15.Diaphragm seal material;
16.IP code;
17.Symbol „Notice”. See relevant information contained in the manual;
18.Ex mark;
19.Kind of flameproof housing designation, certificate designation;
20.Address of the manufacturer.
Figure 4. PC(R)E-28, PC(R)E-28.Smart, PC(R)-29A, PC(R)-29B, PC(R)E-28.Modbus rating plate
(example)
