APOINT C-360 User manual

NexusPub has been realized with technological contribution of 0 rev.10.2_010717
www.nexuspub.net
APOINT S.R.L.
TechnicalManual:ApointVideo
ConferenceCamera
rev.10.2 (01/07/2017)

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 1 rev.10.2_010717
www.nexuspub.net
Summary
APOINT VIDEO CONFERENCE CAMERA
GENERAL SAFETY INFORMATION
3
PRELIMINARY INFORMATION
4
TECHNICAL SPECIFICATIONS
4
CONNECTIONS
6
INSTALLATION PRECAUTIONS
6
COMMUNICATION PROTOCOL AND IR CHANNEL SETUP
6
ID ADDRESS SETUP
7
RS485 WIRING DIAGRAM
8
MOUNTING AND ORIENTATION
9
MENU FUNCTIONS LIST
10
SAVE PRESETS
11
COMMON TROUBLESHOOTING
12

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 2 rev.10.2_010717
www.nexuspub.net
APOINT VIDEO CONFERENCE CAMERA
SD VERSION MODEL C-360 CODE ACNP0026C
HD VERSION MODEL 380-K2 CODE ACNP0120C
Technical data and contents of this manual are subject to change without notice

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 3 rev.10.2_010717
www.nexuspub.net
General safety information
WARNING INDICATIONS FOR USE
Read and follow carefully instructions about installation and connection in this manual
Do not try to unmount the camera: to avoid risk of electric shock, do not remove any screw or cover;
no user serviceable parts inside. Refer to qualified service personnel in case of need
SAFETY PRECAUTIONS
Handle carefully: do not drop or subject the camera to shock and vibration as this can damage camera;
conserve properly the product
Do not try to rotate manually the camera. Never expose the camera directly in the sun
Do not point the camera at bright light sources, even with camera off may cause stains or excess
brightness
Never expose the camera to heat for a long time; heat sources such as neon signs can burn inside the
display, part of the image may suffer discoloration of the filter leading to deterioration of color
Do not use the camera outside the power parameters provided
Refer to qualified service personnel in case of need for maintenance or replacement
ENVIRONMENTAL PROTECTION
Inform about the collection of electrical and electronic products, in force in the area where you want
to dispose of this material
Follow local regulations for disposal of waste and do not throw your old products as generic waste
Leaving the product in the environment may cause serious environmental damages
Proper disposal of products helps prevent environmental pollution and damage to health

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 4 rev.10.2_010717
www.nexuspub.net
Technical Specifications
SD VERSION MODEL C-360
Sensor
1/4” SONY CCD
S/N Ration
>50db
Horizontal Resolution
650 TVL
Focal length
f =3.8-38 mm
Zoom
Optical zoom 10X
Min. Lux
0.01 Lux
Focus
Auto
Iris
Auto / Manual
Shutter Speed
1/50-1/10,000s
AGC
Auto
White Balance
AUTO/Manual
BLC
ON/OFF
Range
Pan: 360° endless
Tilt: +90° -45°
Pan/Tilt Speed
Pan Speed 1° - 280° / sec
Tilt Speed 1° - 100° / sec
Presets
64
Other functions
Auto flip, saving state at power off, etc.
Communication
RS485 (recommended) or RS232
Baud Rate
4800/9600 bps
Protocol
PELCO-D and VISCA
OSD Menu
Supported
Power Supply
DC 12V+-10%; 1.2A
Video Output
CVBS：1.0Vpp at 75 ohm
Operating Temperature
-0 ℃～60℃
Dimensions
124 x 120 x 145 mm
Weight
800 g
Equipment
SD Camera
Power Adapter 12V/2.0A DC
Brackets and mounting accessories (for wall, ceiling and tripod installation)
Video Composite cable (3 meters)
RS232 cable
IR Remote Controller
Preliminary information
The Apoint Video Conference Camera -available in its SD and HD versions- is an indoor PTZ color
camera equipped with varifocal lens that allows getting a 10x optical zoom. PTZ control occurs through
RS485 with PELCO-D protocol; it is possible to set up to 64 presets easily selectable in each. Through the
Control Station equipped with NexusPub Video Controller, it is possible to set presets, to make functional
choices and to move manually the Mini Dome; the cameras are also supplied complete with IR remote
controller, whose use is recommended only during the setting of the cameras

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 5 rev.10.2_010717
www.nexuspub.net
HD VERSION MODEL 380-K2
Sensor
1/3” Sony CMOS, 2.1 M
Video Resolutions
1080P@30, 1080P@25, 1080i@60, 1080i@50,
720P@60, 720P@50, 720P@30, 720P@25
S/N Ration
>50db
Focal length
f=5-50 mm
Zoom
Optical zoom 10X
Min. Lux
0.1 Lux
Focus
Auto / Manual
Iris
Auto / Manual
Shutter Speed
1/30～1/10000S
AGC
Auto
White Balance
AUTO/Manual
BLC
ON/OFF
SSNR
Low / Middle / High / Off
Range
Pan: 359°
Tilt: +90° -45°
Pan/Tilt Speed
Preset: Pan 120°/sec; Tilt 100° / sec
Pan Speed 1° - 200° / sec
Tilt Speed 1° - 150° / sec
Presets
64
Other functions
Image flip, saving state at power off, etc.
Communication
RS485 (recommended) or RS232
Baud Rate
9600/38400 bps
Protocol
PELCO-D and VISCA
OSD Menu
Support
Power Supply
DC12V ±10% 2A
Video Output
HDMI and HD-SDI
Operating Temperature
-0 ℃～45℃
Dimensions
124 x 120 x 145 mm
Weight
800 g
Equipment
HD Camera
Power Adapter 12V/2.0A DC
Brackets and mounting accessories (for ceiling and tripod installation)
RS232 cable
Break-out cable for RS-485 connection
IR Remote Controller

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 6 rev.10.2_010717
www.nexuspub.net
Connections
SD Camera
1. Composite Video Output
2. IR Receiver
3. VISCA IN connector (not used in NexusPub)
4. VISCA OUT connector (not used in NexusPub)
5. S-Video (provisional)
6. DC IN 12V Connector
7. Terminal for RS-422 and RS-485
HD Camera
1. HDMI and HD-SDI Video Output
2. IR Receiver
3. VISCA IN connector (not used in NexusPub)
4. VISCA OUT connector (RS485 connection in NexusPub)
5. DC IN 12V connector
Installation precautions
Check if the installation location is of sufficient height. Make sure installation spots (ceiling or wall) is of
sufficient strength to support camera and bracket without immediate danger of falling.
Avoid, during both the installation and the normal use, to rotate the camera with the hands and do not
move up and down manually the camera lens; this may damage the normal behaviour of the engine.
Please comply with RS485 wiring standards and select proper RS485 cable. Improper cable may result in
RS485 communication transmission error, which may cause an improper functioning of the camera itself.
Communication protocol and IR channel setup
To set communications parameters, dip switches of the block SW2 are available at the bottom of the
camera. Remembered that the standard use with NexusPub requires to set PELCO D protocol with baud
rate 9600 and that the use of the IR remote controller is recommended during the setup phase, here
there are the instruction for acting on the dip switches of block SW2
SD Camera
1. PIN 1 OFF AND PIN 2 OFF= IR ADD. 0;
PIN 1 ON AND PIN 2 OFF= IR ADD. 1;
PIN 1 OFF AND PIN 2 ON= IR ADD. 2;
PIN 1 ON AND PIN 2 ON= IR ADD. 3
2. PIN 3 OFF AND PIN 4 OFF= PELCO P;
PIN 3 ON AND PIN 4 OFF= PELCO P;
PIN 3 OFF AND PIN 4 ON= PELCO D;
PIN 3 ON AND PIN 4 ON= VISCA
3. PIN 5: OFF= baud rate 4800 bps; ON=
baud rate 9600 bps
4. PIN 6: OFF= RS-422 and RS-485; ON=
RS-232C

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 7 rev.10.2_010717
www.nexuspub.net
HD Camera
1. PIN 1: OFF= baud rate 9600 bps; ON=
baud rate 38400 bps
2. PIN 2: OFF= RS-232C; ON= RS-485
3. PIN 3: OFF= VISCA; ON= PELCO-D
4. PIN 4 OFF AND PIN 5 OFF= IR ADD. 0;
PIN 4 OFF AND PIN 5 ON= IR ADD. 1;
PIN 4 ON AND PIN 5 OFF= IR ADD. 2;
PIN 4 ON AND PIN 5 ON= IR ADD. 3
5. PIN 6: IR OUT ON/OFF
ID address setup
The camera can take a unique identification address (ID) between 1
and 255; to set the ID use the dip switches of the block SW1
available at the bottom of the camera; the setting is the same both
for SD and for HD camera
ID - SWITCHES CORRESPONDENCE TABLE

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 8 rev.10.2_010717
www.nexuspub.net
RS-485 wiring diagram
The connection between one or more cameras, the Control Station and the optional joystick is sequential
with two wires, with the first camera that connects with the second, the second with the third and so on;
the connection of the proper RS-485 wire to the camera and to the Control Station has to be done through
the supplied installation accessories
SD Camera
In the five pins terminal for RS-422 and RS-485 connection supplied with the
camera, connect the RS485+ wire to PIN 3 and the RS485- wire to the PIN 4
HD Camera
In the four pins terminal supplied with the camera -in combination with
the breakout cable that needs to be connected to the VISCA OUT
connector in the rear of the camera-, connect the RS485+ wire to PIN
R+ and the RS485- wire to PIN R-
Control Station
In the Moxa connector supplied with the Control Station, connect the RS485+ wire to
PIN 1 and the RS485- to PIN 2

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 9 rev.10.2_010717
www.nexuspub.net
Mounting and orientation
In this section are reported images and exemplifying schemes for wall, desk / ceiling and tripod mounting;
it is recalled that the wall bracket is not available for the HD version of the camera and it may be realized
independently using the supplied ceiling bracket
Wall / Desk / Ceiling mounting
Tripod Mounting
The SD camera is equipped with Autoflip function so it is enough to orientate correctly the shot and save
the presets according to the type of installation; in the setup configuration of NexusPub Video Controller,
for desk installation it is recommended to flag the box “Camera upside down” for a proper management
of the jog direction of the camera
In the HD camera, according to the type of installation, for a proper orientation of the shot it may be
necessary operate on the function “Auto Rev” available in the Dome OSD menu (recallable from the IR
remote controller or by selecting the preset 91 in NexusPub Video Controller, see the following section)

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 10 rev.10.2_010717
www.nexuspub.net
Menu functions list
Premise: some of the voices reported below are not operating or dedicated to the use with VISCA
protocol here not explained; furthermore, the Apoint Video Conference camera is predisposed to be used
in combination with the Control Station and then is supplied with a configuration dedicated to that use
In this section are reported summary tables of the functions present in the menu; to operate within the
menu, use the up and down directional arrows to move between the voices, the left and right directional
arrows to modify the desired value
SD Camera
There is a unique menu on two different screens, recallable in sequence by pushing the Dome OSD or the
Lens OSD buttons on the IR remote controller or by recalling the preset 95 through NexusPub Video
Controller; repeat again the operation to exit the menu
Function
Values
LANGUAGE
English / Chinese
CAMERA ID
0~100
BAUD RATE
38400
ASYNCHRONOUS
8-N-1
ZOOM DISPLAY
OFF / ON
ID DISPLAY
OFF / ON
FOCUS MODE
AUTO
DAY / NIGHT
AUTO / COLOR / NIGHT
SWITCH SPEED
LOW / MID / HIGH
BACKLIGHT COMP
OFF / ON
MIRROR
OFF
ATR
OFF / LOW /MID / HIGH
GAIN CONTROL
0~255
NR
OFF / LOW /MID / HIGH
LIGHT INHITION
0~13
BRIGHT
0~255
SATURATION
0~255
CHROMA
0~255
SHARPNESS
0~255
RESET

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 11 rev.10.2_010717
www.nexuspub.net
HD Camera
There are two different menus, Dome OSD and Lens OSD, recallable through their dedicated buttons on
the IR remote controller or by selecting respectively the preset 91 and 95 through NexusPub Video
Controller; repeat again the operation to exit the menu
Dome OSD
Function
Values
PAN SPEED
1~63 (default 30)
TILT SPEED
1~63 (default 30)
SCAN SPEED
1~63 (default 6)
TOUR PATH
1~4
TOUR DWELL
1~60 (default 5)
PROPORTION
ON / OFF
AUTO REV
P / OFF / N
FRAME
720P60 / 720P50 / 720P30 / 720P25 / 1080I60 / 1080I50 / 1080P30 / 1080P25
OUTPUT TYPE
DVI / HDMI
Lens OSD
Function
Values
BL COMP
OFF / ON
SHARPNESS
LOW / NORMAL / HIGH
SATURATION
LOW / NORMAL / HIGH
NR
0~5
WB
AUTO / INDOOR / OUTDOOR / ONEPUSH / ATW / MANUAL
RGAIN
0~255
BGAIN
0~255
AE
AUTO / MANUAL / SHUTTER / IRIS / BRIGHT
SHUTTER
1/1~1/10000
IRIS
CLOSE / F1.4~F22
BRIGHT
0~31
Save presets
The Apoint Video Conference camera is predisposed to be used in combination with the Control Station
and is supplied with a configuration dedicated to that use
The only basic operation delegated to the user is the preset creation that can be performed with the
following procedure:
move the camera and set the desired level of zoom through NexusPub Video Controller
select a number of preset (with the incremental arrows or typing the number) in
the dedicated section of the NexusPub Video Controller mask
click on Save Preset

APOINT VIDEO CONFERENCE CAMERA SECTION
NexusPub has been realized with technological contribution of 12 rev.10.2_010717
www.nexuspub.net
Common troubleshooting
PROBLEM
POSSIBILE CAUSES
SOLUTIONS
Correct
functioning test
at boot, but the
camera does not
communicate
Communication protocol set in
NexusPub Video Controller is not
consistent with camera’s one
Alter protocols for consistency
Baud rate set in NexusPub Video
Controller is not consistent with
camera’s one
Alter baud rates for consistency
RS485 polarity error
Switch polarity of RS485 pins
RS485 bad wire connection
Re-check RS485 wiring
Control of
camera is
working, but
not smoothly
The Control Station is too far from
the camera
Re-check cameras wiring
RS 485 wiring damaged
Replace or repair RS485 wiring
Power-on but
no video output
BNC connector or cable damaged
Re-check video wiring
The le selected resolution is not
compatible with the used output
device
Select a compatible video resolution
Power supply voltage is too low
Check that power supply voltage is correct
