Avigilon H6SL Series User manual

IP Camera Web Interface
User Guide
Avigilon High Definition H6, H5, and H4 IP Camera Models:
H6SL-xx H6M-Dx-IR H5EX-xx-BO1 H4A-ETD-KIT
H5A-xx H6M-Dx H5EX-xx-CO1 H4A-THC-BO
H5A-xx-IR H5A-CR1-IR-xx H4A-xx(-B) H4A-G-B(-B)
H5SL-xx H5A-CR2-IR-xx H4M-D H3A-xx
H5SL-xx-IR H4A-G-xx-IR(-B) H4F-DO H3A-BO-IR
H5M-DO H4A-xx-IR(-B) H4SL-xx(-IR) 

Copyright
©2016 -2023,Avigilon Corporation. All rights reserved. AVIGILON, the AVIGILON logo, HDSM SmartCodec,
AVIGILONCONTROL CENTER, ACC, ACCESS CONTROL MANAGER, and ACM are trademarks of Avigilon
Corporation. Android is a trademark of Google LLC. Apple, Safari and Mac are trademarks of Apple Inc,
registered in the US and other countries. Firefox is a registered trademark of the Mozilla Foundation in the US
and other countries. Other names or logos mentioned herein may be the trademarks of their respective
owners. The absence of the symbols ™ and ® in proximity to each trademark in this document or at all is not a
disclaimer of ownership of the related trademark. Covered by one or more claims of the patents listed at
patentlist.hevcadvance.com.
This document has been compiled and published using product descriptions and specifications available at
the time of publication. The contents of this document and the specifications of the products discussed
herein are subject to change without notice. Avigilon Corporation reserves the right to make any such
changes without notice. Neither Avigilon Corporation nor any of its affiliated companies: (1) guarantees the
completeness or accuracy of the information contained in this document; or (2) is responsible for your use of,
or reliance on, the information. Avigilon Corporation shall not be responsible for any losses or damages
(including consequential damages) caused by reliance on the information presented herein.
Avigilon Corporation
avigilon.com
PDF-H4WebUI-G
Revision: 3 - EN
20230420
ii

Table of Contents
Introduction 1
System Requirements 1
Other Web Interface Guides 1
Accessing the Camera Web Interface 2
Creating the Initial User and Logging In 2
Logging In 3
Live View 4
Saving a Still Image 4
Setup 5
General 6
Network 7
Configuring 802.1x Port-Based Authentication 10
Switching 802.1x Authentication Profiles 10
Deleting an 802.1x Authentication Profile 10
Configuring SNMP 11
IP Filter 12
Security Settings 12
Image and Display 14
Adjustments 18
Compression and Image Rate 20
Enabling HDSMSmartCodec™ Technology Settings 21
Viewing the RTSP Stream URI 21
Accessing the Still Image URI 22
HDSMSmartCodec Technology Advanced Settings 22
Motion Detection 23
Tamper Detection 24
Analytics 24
Privacy Zones 24
Setting a Privacy Zone 25
Deleting a Privacy Zone 25
Setting a Removable Privacy Zone for Specific Users 25
Storage 26
Enabling Onboard Storage 27
ONVIFProfile G 27
Downloading Recorded Video from the Web Interface 28
iii

Downloading Recorded Video from the SD Card 28
Deleting Recorded Video 29
SD Card Failures 29
Digital Inputs and Outputs 30
Washer 31
Audio 32
Users 32
Adding a User 32
Editing Users and Passwords 33
Removing a User 33
Keeping Usernames and Passwords After Firmware Revert 33
System 34
Upgrading the Camera Firmware 34
Device Log 34
Disable WebUI 35
About 36
Checking a Camera's Power Source 36
ACC™ ES Camera 37
Checking the ACC ES Camera Status 37
Configuring the ACC ES Camera Administration Settings 37
Restarting the ACC Software 37
Formatting the Recorded Video Drive 37
Changing the Communication Ports 38
Overriding the Login Limit 38
Enabling Storage Management 38
Reviewing ACC Software Logs 39
iv

Introduction
Avigilon High Definition IP cameras include a web interface that allows you to view the live video and
configure the camera through a web browser.
Before you access the web interface, make sure all the procedures described in the camera installation guide
have been completed.
Tip: Features and options are disabled if they are not supported by the camera.
System Requirements
The following browsers are recommended when accessing the web interface from any Windows, Mac, or
mobile device:
lMozilla Firefox version 96.0.2 (64-bit) or later
lGoogle Chrome™ version 97.0.4692.71 (64-bit, official build) or later
lMicrosoft Edge version 97.0.1072.76 (64-bit, official build) or later
Note: The web interface may work with older or unsupported browsers, but this has not been tested.
Other Web Interface Guides
Check out these other Web Interface Guides for other types of Avigilon cameras:
lPTZCamera Web Interface Guide — for pan, tilt, and zoom cameras.
lMulti-HeadCamera Web Interface Guide — for dual head and multisensor cameras.
lH4and H5 Pro Camera Web Interface Guide — for high resolution Pro cameras.
lH5AFisheye Camera Web Interface Guide — for H5A fisheye cameras.
lVideo Intercom Web Interface Guide — for H4 Video Intercoms.
lAPD Sensor Web Interface Guide — for Avigilon presence detectors.
Introduction 1

Accessing the Camera Web Interface
After the camera has been installed, you need the camera's IP address to access the web interface. The IP
address can be found in the following:
lThe Avigilon Control Center (ACC) software — Open the Setup tab to see the details of the selected
camera.
lMotorola Solutions' Camera Configuration Tool (CCT) — Go to the Network tab to see the details of the
selected cameras.
Once you have the IP address, complete the following procedure to access the web interface:
Note: The web browser must be configured to accept cookies or the camera web interface will not
function correctly.
1. On a computer with access to the same network as the camera, enter the camera's IP address into a
web browser:
http://<camera IP address>/
For example: http://192.168.1.40/
2. You will automatically be prompted to enter your username and password to access the camera. If the
device is in the factory default state and was manufactured after January 1, 2020, you will be asked to
create a user with administrator privileges before the device will be operational. For more information,
see Creating the Initial User and Logging In below.
Creating the Initial User and Logging In
Cameras manufactured after January 1, 2020, do not have a default username and password and will be in a
factory default state.
Important: You must create a user with administrator privileges before the camera is operational.
Tip: Cameras manufactured before January 1, 2020, have a default username and password you can
use to log in. For more information, see Logging In on the next page.
If the camera is in the factory default state, you will be redirected to the Add User page to create an
administrator user:
Accessing the Camera Web Interface 2

1. Enter a new User Name or keep the default administrator name.
2. Enter a new Password for the user. We recommend using a complex and unique password. Avoid
using an empty password as they are not supported across all platforms and devices.
3. Confirm the new password.
4. For the first user, Administrator must be selected in the Security Group drop-down menu.
5. Click Apply. After creating the user, you will be asked to login.
Logging In
You will automatically be prompted to enter your username and password to access the camera.
lIf the camera is in the factory default state and was manufactured after January 1, 2020, you will be
asked to create a user with administrator privileges before the camera will be operational. Use these
credentials when logging in.
lThe default username for most cameras is administrator with no password.
Tip: It is recommended that you add a password after your first login. For more information, see
Editing Users and Passwords on page33.
Logging In 3

Live View
After you log in, the first page you see is the Live View. The Live View contains an image panel that displays
the live video stream.
Use the menu links in the top-left corner to navigate through the web interface. Click Live View any time to
return to this page.
Tip: Features and options are disabled if they are not supported by the camera.
Saving a Still Image
If you see the Save Still to SDCard button from the Live View page, the camera supports the ability to take
snapshots of live video from the web interface.
To use this feature, the following settings are required for the camera:
lThere is an SD card inserted in the camera. For more information, see the camera's installation guide.
Saving an image to the SD card is not supported if you are using FIPS Level 3 encryption with a CryptR
micro card inserted in the SD slot.
lThe camera's onboard storage settings are enabled on the Storage page. For more information, see
Storage on page26.
lThe camera's video format must be set to MJPEG in the Compression and Image Rate page. For more
information, see Compression and Image Rate on page20.
Once all the requirements have been met, you can click Save Still to SDCard and the image that is displayed
in the Live View page is automatically saved to the SD card.
To download the snapshot, see Downloading Recorded Video from the Web Interface on page28.
Live View 4

Setup
Note: Certain options are not displayed if they are not supported by the camera model you are using
or if you do not have the required user permissions.
The factory default settings allow you to use the camera or encoder immediately after installation. If you have
special requirements, you can customize the settings through the web interface. In the top-left menu area,
click Setup to display all the available setup pages.
A Restore Defaults button is available on each setup page to restore the factory default settings.
Be aware that some settings are only available through the camera's web interface and cannot be changed in
the network video management software.
For information specific to H4 Edge Solution (ES) cameras, see ACC™ ES Camera on page37.
For settings that are specific to the H4 Thermal Elevated Temperature Detection cameras, see the H4
Thermal Elevated Temperature Detection Camera User Guide.
Setup 5

General
When you select Setup, the first page you see is the General page. The General page allows you to set the
camera's identity.
Tip: Features and options are disabled if they are not supported by the camera.
Note: If a camera with video analytics or unusual motion detection is physically moved or adjusted,
or if the focus or zoom level is changed, reset the learning progress to provide accurate results. If the
camera's image rate and compression or display settings are updated, the learning progress may
reset automatically.
1. In the Name field, give the camera a meaningful name.
2. In the Location field, describe the camera's location.
3. Select the Disable device status LEDs check box to disable the LED indicators located on the camera.
4. Select the Lens Distortion Correction check box to enable an algorithm-based automatic correction
of lens distortion. The camera will reboot when applying this setting.
5. From the Mode drop-down list, select the mode that the camera will operate in.
This option is only displayed for higher bandwidth usage cameras.
lFull Feature — This is the standard operating mode. Offers the full functionality of the camera.
lHigh Framerate — This mode will use the maximum image rate possible but will disable self-
learning video analytics, Unusual Motion Detection (UMD), and tamper detection and WDR on
EScameras.
Models Features Impacted by High Framerate
4K (8 MP) H4 HD Analytic
Cameras:
8.0-H4A-x
oIncreased maximum frame rate
oSelf-learning video analytics and tamper disabled
oUnusual Motion Detection (UMD) disabled
oLower resolution tertiary video stream
oSecondary video stream disabled
H4 HD ES Analytic Cameras:
xx-H4A-xG-x
oIncreased maximum frame rate
oWDR disabled
General 6
