APP SBX 175 Series User manual

SBX® Connectors
Assembly instruction for SBX®175 and SBX®350 Series
two pole battery connector with option for two auxiliary contacts.
Contains one (1) housing and two (2) contacts.
1. CONNECTOR RATINGS
SBX350 series: 350 AMPS with max cable size 300MCM
SBX175 series: 175 AMPS with max cable size 1/0
2. RECOMMENDED CONTACT CRIMPING
RECOMMENDED CRIMP OUTLINE:
3. REDUCING BUSHINGS: recommended for fitting small cables to STD contacts assuring proper
crimp connection
CAUTION:
When using cable with jacket diameter less than 0.423 inches (11mm) on the SBX175 and less than 0.709 inches (18mm) on the SBX350
thin wall heat shrink insulation should be evenly applied across the cable and contact barrel junction to insure finger protection.
4. CABLE STRIPPING DIMENSIONS
Connector Series Bushing Size (AWG) Catalog Number
SBX350 2/0 to 1/0 5918
SBX175 1/0 to 1 5687
1/0 to 2 5690
1/0 to 4 5693
1/0 to 6 5663
1/0 to 10 5648
Connector Series Contact Portable Hydraulic Tool Pneumatic Tool
SBX350 2/0, 3/0, 4/0, 300MCM 1368 1387G1 & 1387G2
Heat Shrink Insulation Specifications
Connector Nominal Minimum Maximum
Series Tubing Size Length Wall Thickness
SBX350 .75 in (19mm) 2.0 in (51mm) .030 in (.76mm)
SBX175 .50 in (12.7mm) 2.0 in (51mm) .025 in (.63mm)
Connector Strip “X” To
Series Inches m m
SBX350 1 3/8 35
SBX175 1 1/8 29
FOR INSTALLATION BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH
NATIONAL AND LOCAL ELECTRICAL CODES AND THE FOLLOWING INSTRUC-
TIONS. THE SUITABILITY OF THIS TYPE OF TERMINATION MUST BE EVALU-
ATED BY UNDERWRITERS’ LABORATORIES, INC. AND CANADIAN STANDARDS
ASSOCIATION FOR THE END USE APPLICATION.
Assemble contacts to the cables according to the equipment manufacturer’s as-
sembly instructions. The following instructions are supplied as a reference. Please
note: instructions are included with each crimp tool for terminating specific contacts.
[19.0] 0.75 MIN
[3.2] 0.12 MIN [3.2] 0.12 MIN
X
7. Cable ties are supplied to secure the auxiliary leads or cable to one of the main power cables.
Leave slack or loop in leads to Powerpole contacts when applying cable ties, figure1. Wraps to
be placed approximately 1 inch (25.4mm) apart as shown in figure 1.
8. To remove auxiliaries, punch out pins from bottom with .06 inch (1.5mm) diameter steel rod or
pin driver. Also available: contact insertion-extraction tool kit (cat. #111038G2).
WARNING
UTMOST CAUTION SHOULD BE USED WHEN WORKING ON LIVE CONNECTOR CONTACTS
UL and CSA Reference - These connectors are recognized under the component program of Underwriters’
Laboratories, File E26226, as well as Canadian Standards Association, Report LR25154.
PATENTS AND TRADEMARKS
This product is covered by the following patents: U.S. 3,794,957; U.K. 1,443,819; France 73,44153; Italy
1,000442; Japan 885,802; South Africa 74/0939; Canada 990,821. Other U.S. and foreign patents pending.
“SBX, Powerpole and Anderson Power Products” are registered U.S. and foreign trademarks of Anderson
Power Products, 13 Pratts Junction Road, P.O. Box 579, Sterling, MA 01564 USA
1S1094 REV10 14162 ASM-SBX
HEADQUARTERS: 13 Pratts Junction Road, P.O. Box 579, Sterling, MA 01564 T:978-422-3600 F:978-422-3700
EUROPE: Rathealy Road, Fermoy Co. Cork, Ireland T:353-(0)25-32277 F:353-(0)25-32296
ASIA/PACIFIC: IDEAL Anderson Asia Pacific Ltd., Unit 922-928 Topsail Plaza, 11 On Sum Street, Shatin N.T., Hong Kong
T:852-2636-0836 F:852-2635-9036
CHINA: IDEAL Anderson Technologies (Shenzhen) Ltd., Block A8 Tantou W. Ind. Par, Songgang Baoan District, Shenzhen, PR. China 51810
T: 86-755-2768-2118 F: 86-755-2768-2218
TAIWAN: IDEAL Anderson Asia Pacific Ltd., Taiwan Branch, 4F.-2, No.116, Dadun 20th St., Situn District, Taichung City 407, Taiwan (R.O.C.)
T: 886-4-2310-6451 F:886-4-2310-6460
www.andersonpower.com
Figure 2
Loop Wire
[25]
1.0

SBX® Auxiliary Contact
Assembling Instructions
Contains two each of: housings, contacts, retaining pins, & cable ties.
1. Single conductors use #12 to #18 AWG wore only. Strip to 0.31 inch (7.9mm) off end of
insulation.
2. Twin conductor cable #12 to #18. Strip back outer jacket 5.50 inches (139 mm). (See
illustration). Then strip conductor insulation as in 1.
3a. To crimp: use the recommended tool. Crimping by other means may disturb contact position in
housing and or produce high resistance joints.
Crimp Tool Catalog Number
Manual - cycle controlled 1309G2
Pneumatic - cycle controlled 1367G1
3b. To Solder: Not recommended.
4. Thread or push one or two auxiliary contacts and wires through the rear of the SBX connector
before inserting into auxiliary housings. Push into auxiliary housings through rear until notched
side of contact tip snaps over spring. Tug wires to make sure wires are secure.
5. Slide two auxiliary Powerpole housings together by dovetails to stack vertically. They cannot
be inserted separately into SBX housing. The rear of each of the Powerpoles housings must
be flush.
6. Slide tacked auxiliaries back into SBX connector hosing until seated. The male dovetail should
be on top as shown in figure 1. Make sure side grooves of auxiliaries are aligned for retaining
pins B insert tubular pins. Hammer pins in holes from top, as shown in figure 1.
5. RECOMMENDED SOLDERING TECHNIQUES
(Use rosin flux solder only). Wrap cable strands, melt solder into well; heat and insert stripped
cable. Continue heating well until solder flows into wire being careful not to over flow onto
contact surfaces. DO NOT SOLDER DIP CONTACTS when contacts are soldered to
unsupported lead. Underwriters’ Laboratories, Inc. requires use of cable clamps, listed in table
below.
6. CABLE / CONTACT & HOUSING ASSEMBLY
Observing polarity of markings, push each contact into rear of housing until notched side snaps
over spring, tug on cable to make sure contact is locked into place.
DISASSEMBLING SBX CONNECTORS (see illustration)
Switch off power first. Remove contact by inserting extraction tool (cat. no. SBX175 - 969P1, SBX350 -
970P1) as shown below (steps 1, 2, & 3).
CAUTION: Replace contacts individually on battery leads to reduce potential danger of shorting.
1. Insert extraction tool as shown between contact and housing to point A.
2. Press down to release contact from spring.
3. Pull cable to remove contact.
Table A
Connector Ampere Rating For Two Single Conductor Cables
SBX350 911G2
SBX175 945G2
Top
Male Dovetail
Figure 1
Retaining Pin
Extraction Tool
2
3
Point A
Extraction Tool
[7.9]
0.31
[139]
5.5
Catalog
Number Application Contact Wire Size Pin Length
6344 SBE80, SBE160, SBO60, SBX175 1331 #12/16 0.85
6305G1 SBE320, SBX350 1331 #12/16 1.00
6310G1 SBE320, SBX350 1332 #16/20 1.00
