Appareo STRATUS ESG User manual

Stratus ESG to Portable Receiver
Connector Plate
Installation Guide
Revision 1.2
Disclaimer
This document and its contents are not certified. Installation of this system in a certified aircraft
will require additional approval.

Stratus ESG to Portable Receiver Connector Plate Installation Guide
Revision 1.2
Last Revised: April 27, 2016
Document Number: 600890-000054
Page 2 of 5
STRATUS ESG
©2015-2016 Appareo Systems, LLC. All Rights Reserved.
Stratus ESG to Portable Receiver Connector Plate Installation Guidance. All content within is
copyrighted by Appareo Systems, LLC, and may not be reprinted without permission.
The content of this guide is furnished for informational use only, is subject to change without
notice, and should not be construed as a commitment by Appareo Systems, LLC. Appareo
assumes no responsibility or liability for any errors or inaccuracies that may appear in the
information content contained in this guide. Unauthorized replication of this guide is prohibited.
Appareo, Appareo Systems, Stratus ESG, and the Appareo and Stratus ESG logos are either
registered trademarks or trademarks of Appareo Systems, LLC. All other trademarks and
registered trademarks are the sole property of their respective owners.
Appareo Systems, LLC, 1830 NDSU Research Circle North, Fargo, ND 58102 USA.
To view the most current version of this document, go to www.appareo.com/dealer-portal or
www.appareo.com/experimental.
Record of Revision
Revision
Number
Change Description Revision Date Inserted By
1.0 Initial release 1/22/16 AAL
1.1 Updated wiring diagram 2/24/16 AAL
1.2 Updated wiring diagram 4/27/16 AAL

Stratus ESG to Portable Receiver Connector Plate Installation Guide
Revision 1.2
Last Revised: April 27, 2016
Document Number: 600890-000054
Page 3 of 5
Installing the connector plate
This document is intended to help you determine the best method for installing the Stratus ESG
connector plate in an aircraft and connecting it to a portable ADS-B In receiver.
Supplied Components
Part Name Appareo Part
Number Quantity Needed
9 Pin D-Sub Connector with mounting hardware
251015-000094
1
BNC Connector
251015-000078
1
BNC-BNC Connector
251015-000089
1
Connector Plate
353070-000043
1
Additional Components
•RF cabling: RG 400 (Stratus ESG to connector plate RF connector)
•D-Sub cabling: 20 AWG wire (Stratus ESG to connector plate D-Sub)
Tools needed
•Screwdriver
•Retaining ring pliers
•Standard wrenches
Installing the connector plate
1. Mount the connectors onto the connector plate, as shown in the diagram above.
NOTE: The D-Sub and BNC-BNC connector are mounted to the connector plate. The
BNC connector and retaining ring are installed onto the transponder backplate.
2. Find a location to secure the connector plate within the maximum cable length of 3 feet.
The connector plate measures approximately 1.5” x 3” and can be secured in any
orientation in any available space in the cockpit. Orient the connector plate so that the
Stratus logo is visible and readable.

Stratus ESG to Portable Receiver Connector Plate Installation Guide
Revision 1.2
Last Revised: April 27, 2016
Document Number: 600890-000054
Page 4 of 5
3. Wire the connector plate from the transponder to the connector plate following the wiring
diagram on the next page and using the cabling specified under “Additional
Components” above. There is a 3 foot maximum cable length.
4. Connect the ADS-B In receiver to the connector plate. If you are connecting a Stratus
portable receiver, an interface cable kit is available for purchase through approved
Appareo dealers.
Configuring the transponder
The transponder must be configured to allow for ADS-B In receiver information from the cockpit.
1. Enter into configuration mode on the transponder (while holding the FUNC key, press
and release the PWR key).
2. Press FUNC or the arrow keys to navigate to the “ADS-B In Capability” screen and press
ENT.
3. Use the arrow keys to select the frequency that the ADS-B receiver being used in the
aircraft is capable of.
•If you are using a Stratus 1 or 1S set the capability to UAT.
•If you are using a Stratus 2 or 2S set the capability to UAT and 1090 ES.
•If you do not know the frequency, select UAT.
4. Press ENT.

Stratus ESG to Portable Receiver Connector Plate Installation Guide
Revision 1.2
Last Revised: April 27, 2016
Document Number: 600890-000054
Page 5 of 5
Stratus ESG to Stratus Portable Wiring Diagram
PIN DESCRIPTION I/O
1AIRCRAFT GROUND
2AIRCRAFT POWER
3RS232-RX MAINTENANCE IN
4 -
5RS232-RX ALTITUDE IN
6RS232-TX GPS 1PPS OUT
7EXTERNAL STANDBY IN
8SOFTWARE UPDATE ENABLE IN
9ALTITUDE A1IN
10 ALTITUDE A4IN
11 ALTITUDE B2IN
12 ALTITUDE C1IN
13 ALTITUDE C4IN
14 EXTERNAL SUPPRESS IN IN
15 28V LIGHTING BUS HI IN
16 -
17 AUX +5V POWER OUT
18 AUX GROUND
19 AUX +5V POWER OUT
PIN
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
DESCRIPTION I/O
AIRCRAFT GROUND
AIRCRAFT POWER
RS232-TX MAINTENANCE OUT
RS232-TX AUX OUT
RS232-TX ALTITUDE OUT
EXTERNAL IDENT IN
EXTERNAL SQUAT SWITCH IN
ALTITUDE D4IN
ALTITUDE A2IN
ALTITUDE B1IN
ALTITUDE B4IN
ALTITUDE C2IN
EXTERNAL SUPPRESS I/O I/O
14V LIGHTING BUS HI IN
-
-
AUX +5V POWER OUT
ALTITUDE COMMON (GND)
P1001 – ESG 37-DSUB
PIN DESCRIPTION PIN
19 SWITCHED POWER OUTPUT 1
36 D- 2
17 D+ 3
- - 4
-5
23 RS232-TX AUX 6
6RS232-TX GPS 1PPS 7
18 AUX GROUND 8
- - 9
37-DSUB 9-DSUB
STRATUS ESG
AI RCRAFT POWER 1
AI RCRAFT POWER 2
AIRCRAFT GROUND 1
AIRCRAFT GROUND 2
28V LIGHTING BUS HI
14V LIGHTING BUS HI
EXTERNAL S TANDBY
EXTERNAL S UPPRESS IN
EXTERNAL S UPPRESS I/0
EXTERNALIDENT
EXTERNALSQUAT SWITCH
ALTITUDE A1
ALTITUDE A4
ALTITUDE B2
ALTITUDE C1
ALTITUDE C4
ALTITUDE D4
ALTITUDE A2
ALTITUDE B1
ALTITUDE B4
ALTITUDE C2
AUX +5V POWER
AUX +5V POWER
AUX +5V POWER
RS232-TX AUX
RS232-TX GPS 1PPS
AUX GROUND
ALTITUDE COMMON (GND)
P1002 – XPNDR A NTENNA
P1003 – GPS ANTENNA IN
P1004 – ADS-B AUX
2
21
1
20
15
33
7
14
32
25
26
9
10
11
12
13
27
28
29
30
31
19
36
17
23
6
18
37
11-33 VDC AIRCRAFT POWER
P1001
5A
TO LIGHT DIMMING BUS
PARALLEL ALTITUDE ENCODER
MUTUAL SUPPRESSION (ARINC 709)
DME
TRANSPONDER 2
RF
(BNC)XPNDR
ANTENNA
RF
(TNC)GPS ANTENNA
ALTITUDE COMMON (GND)
1
2
3
6
7
8
9-
DSUB
RF
(BNC)ADS-B AUX
IDENT INPUT
Optional
WoW
